DK • EN • DE • FR • SE • Foam Cleaning MANUAL
Dosing
To have the best performance and dosing, it is necessary to:
• Have a water pressure of minimum 2 bar at the end of the water supply hose.
•Choose the right nozzle on the chemical inlet side:
See recommended concentration on the label/data sheet for the chemical. On most foam
cleaning chemicals, you can read the information on the right mixture proportion on the
packaging between chemicals and water. E.g. it can be 1 decilitre to 10 litres of water, which
can be explained as 1:100 or 1% concentration. By choosing and inserting the right nozzle,
the dosing can be adjusted to the recommendations on the chemical.
Replacement of Nozzles
By replacement it is recommended to screw the nozzles in/out using a pair of tongs or the like.
Maintenance
•The house coupling on the hose and foaming gun have to be greased regularly to maintain
the coupling ability on the equipment. The grease applied during mounting will be rinsed away
by the water flow and thus needs to be renewed.
•When the foam application is finalized, it is important to rinse the injector with clean water to
avoid blocking of the nozzle. Screw the injector of the container and let it suck clean water
through the suction hose to enable hose, filter and nozzle to be rinsed for chemicals.
Data
Min. Water pressure: 2 bar at the end of the dosed chemical outflow hose.
Max. Water pressure: 6 bar (9305x) or 12 bar (9301x).
Max. temp.: 40°C for 9305x og 60°C for 9301x.
Viscosity (ability to flow): Max. 50 mPas/cSt.
Injector: 93139 for 9305x or 93149 for 9301x.
Container: 1,4 L (9310x) or 2,5 L (9311x).
Combi gun: 93209 or 93219 (Ergo).
Spray Nozzles: Item no. 9350 or (9352, extra equipment).
Suction Hose: Item no. 93175.
Nozzle set: Item no. 9378.
The nozzle set contains the following:
Grey: 1:10 (10%) Black: 1:12 (8,3%) Beige: 1:14 (7,1%)
Red: 1:16 (6,3%) White: 1:18 (5,6%) Blue: 1:21 (4,8%)
Light Brown: 1:23 (4,4%) Green: 1:33 (3,0%) Orange: 1:40 (2,5%)
Brown: 1:45 (2,2%) Yellow: 1:57 (1,8%) Turquoise: 1:71 (1,4%)
Lilac: 1:100 (1,0%) Pink: 1:250 (0,4%) Transparent: Plug
Extra nozzle set can be ordered using item no. 9378.
