Viking Range VDB200 User manual

KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
All models include:
•Exclusive Multi-level power wash
oExclusive multi-level washing with
two stainless steel wash arms
oExclusive Block-proof Flexible-
Flui ™ coupling irect water fee
•Exclusive Five-Stage Filtration an
Waste Removal System
o Removable coarse strainer
oExclusive Triple-Clean™filtration
with self-cleaning jets
oExclusive ultra har foo waste
isposer/motor/pump
•Exclusive Sure-Temp™ Water Heating
o 1200 watt Hy roFlo™ water heater
o Operable with “col ” groun water
• Con ensate Quick Dry
• Quiet Clean™ Performance Package
o Separate motor/pump assemblies
for washing an raining
o Soun absorbing/heat retaining
insulation
• “Loa -As-You-Like” Stur i-Bilt™ Racks
o Accommo ates 13 international
place settings
o Fully usable nylon coate racks
o One-Piece silverware/cutlery basket
o Lower rack has 4 rows of 3 position
one-piece fol - own tines
o Upper rack has 1 one-piece cup shelf
•Exclusive Diamon -Brite™ stainless
steel tank an inner oor
• Cycles – Pots/Pans, Normal Wash,
Econo/China, Rinse/Hol
• Options – Hi Temp Wash, Delay Start
(up to 4 hours)
• Energy Star Qualifie
• CEE Tier I Super Efficient
Standard Features & Accessories
Model Options
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Finish etails for VDB mo el
• Stainless Steel (SS), Black (BK), White
(WH)
Finish etails for FDB mo el
• Han les not inclu e –opt for custom
han les or purchase a Viking
Professional or Designer han le kit
(see Installati n N tes & Access ries)
• Door panel not inclu e .*
• See Cust m Panels section for more
information an a itional
specifications.
VDB200
Pr fessi nal
Built-In Dishwasher
FDB200
Cust m Fr nt
Built-In Dishwasher
Finish etails for DDB mo el
• Stainless Steel (SS), Black (BK), White
(WH)
DDB200
Designer
Built-In Dishwasher
ORDERING INSTRUCTIONS
*Door panel not inclu e . Must or er either a Professional w/o louvers (PDDP24), Professional w/louvers (PDDPL24), or Designer (DDDP241)
oor panel if a custom panel will not be use . Specify color co e at en (PDDP24SS). If or ering optional brass accent, specify co e at
en (PDDP24SSBR). If or ering a custom mo el (to be fit with a custom panel or with a color panel), use no color or accent co e
(FDB200).

KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
23-7/8”
(60.6cm)
33-7/8”
(86.0cm)
min.
to
35”
(89.0cm)
max.
24”
(61.0cm)
All models
Overall width 23-7/8” (60.6 cm)
Overall height (from floor) 33-7/8” (86.0 cm) min. to 35” (89.0 cm) max.
Overall depth (from rear)
To edge of side (includes door panel) 24” (61.0 cm) includes door panel
With door open 49” (124.5 cm)
Dimensions & Specifications
PRODUCT DIMENSIONS
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VDB200
Pr fessi nal
Built-In Dishwasher
FDB200
Cust m Fr nt
Built-In Dishwasher
DDB200
Designer
Built-In Dishwasher
See Cust m Panels section for
more information an a itional
specifications.
PROFESSIONAL DESIGNER
✪
Please see
Installati n N tes &
Access ries
for important
information,
including door
panel and handle
kits.
23-7/8”
(60.6cm)
33-7/8”
(86.0cm)
min.
to
35”
(89.0cm)
max.
24”
(61.0cm)

KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
23-3/4”
(60.3 cm)
Cabinet flush
28-3/4”
(73.0 cm)
49”
(124.5 cm)
23-1/8”
(59.0 cm)
Panel flush
VDB200
Pr fessi nal
Built-In Dishwasher
FDB200
Cust m Fr nt
Built-In Dishwasher
DDB200
Designer
Built-In Dishwasher
Dimensions & Specifications
DOOR SWING
DESIGNER
See Cust m Panels section for
more information an a itional
specifications.
PROFESSIONAL
Note: If the dish asher is installed in a corner, there must be a minimum clearance of 2” (5.1 cm) from the side all so the door can
open.
23-3/4”
(60.3 cm)
Cabinet flush
28-3/4”
(73.0 cm)
49”
(124.5 cm)
23-1/8”
(59.0 cm)
Panel flush

A 2” cut-out is required
for water supply and
discharge lines.
24”
(61.0cm)
24”
(61.0cm)
34”min.
(86.4cm)
to
35”max.
(89.0cm)
KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
•120V/60 Hz
• Maximum amp
usage—15.0 amps
•Water-heating
element rating—
1,200 watts
PLUMBING
•120°F (49°C) hot
water recommen e ;
ishwasher will,
however, perform
properly with col
water*
• Inlet water pressure
operating range—
10 – 125 psi (0.69 –
8.62 bar)
• Five foot (1.5 m)
brai e stainless steel
water line with 3/8”
(0.95 cm)
compression fitting
supplie with
ishwasher
• Seven-foot (2.13 m)
1/2” (1.3 cm) ID
“crimp-proof”
flexible rain hose
with clamp attache
to ishwasher;
connections provi e
for 5/8” (1.5 cm), 3/4”
(1.9 cm), or 1” (2.5
cm) cut as require
• High loop of rain
hose require ; min.
height from floor—
20” (50.8 cm)
• Check local co es
for rain air gap
requirement
*Cycle times will be
exten e
Installation Requirements
ACCESS REQUIREMENTS
All models
Cutout width 24” (61.0 cm)
Cutout height 34” (86.4 cm) min. to 35” (89.0 cm) max.
Cutout depth 24” (61.0 cm)
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VDB200
Pr fessi nal
Built-In Dishwasher
FDB200
Cust m Fr nt
Built-In Dishwasher
DDB200
Designer
Built-In Dishwasher
See Cust m Panels section for
more information an a itional
specifications.

KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Door Panel Kits
• For use with FDB200 custom front ishwasher
• Kit inclu es one panel an installation har ware
•A BR to en of mo el number for optional brass accent (Professional only)
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PDDP24 SS Professional door panel – no louvers (Stainless Steel) 14 (6.3)
PDDP24 BK Professional door panel – no louvers (Black) 14 (6.3)
PDDP24 WH Professional door panel – no louvers (White) 14 (6.3)
PDDP24 MS Professional door panel – no louvers (Metallic Silver) 14 (6.3)
PDDP24 GG Professional door panel – no louvers (Graphite Gray) 14 (6.3)
PDDP24 SG Professional door panel – no louvers (Stone Gray) 14 (6.3)
PDDP24 TP Professional door panel – no louvers (Taupe) 14 (6.3)
PDDP24 BT Professional door panel – no louvers (Biscuit) 14 (6.3)
PDDP24 CW Professional door panel – no louvers (Cotton White) 14 (6.3)
PDDP24 OG Professional door panel – no louvers (Oyster Gray) 14 (6.3)
PDDP24 GM Professional door panel – no louvers (Golden Mist) 14 (6.3)
PDDP24 LE Professional door panel – no louvers (Lemonade) 14 (6.3)
PDDP24 SA Professional door panel – no louvers (Sage) 14 (6.3)
PDDP24 MJ Professional door panel – no louvers (Mint Julep) 14 (6.3)
PDDP24 SE Professional door panel – no louvers (Sea Glass) 14 (6.3)
PDDP24 IB Professional door panel – no louvers (Iridescent Blue) 14 (6.3)
PDDP24 VB Professional door panel – no louvers (Viking Blue) 14 (6.3)
PDDP24 PM Professional door panel – no louvers (Pumpkin) 14 (6.3)
PDDP24 RR Professional door panel – no louvers (Racing Red) 14 (6.3)
PDDP24 AR Professional door panel – no louvers (Apple Red) 14 (6.3)
PDDP24 BU Professional door panel – no louvers (Burgundy) 14 (6.3)
PDDP24 PL Professional door panel – no louvers (Plum) 14 (6.3)
PDDP24 CH Professional door panel – no louvers (Chocolate) 14 (6.3)
PDDP24 CB Professional door panel – no louvers (Cobalt Blue) 14 (6.3)
PDDPL24 SS Professional door panel – louvers (Stainless Steel) 14 (6.3)
lDDDP241 SS Designer door panel (Stainless Steel) 14 (6.3)
DDDP241 BK Designer door panel (Black) 14 (6.3)
DDDP241 WH Designer door panel (White) 14 (6.3)
DDDP241 MS Designer door panel (Metallic Silver) 14 (6.3)
DDDP241 GG Designer door panel (Graphite Gray) 14 (6.3)
DDDP241 SG Designer door panel (Stone Gray) 14 (6.3)
DDDP241 TP Designer door panel (Taupe) 14 (6.3)
DDDP241 BT Designer door panel (Biscuit) 14 (6.3)
DDDP241 CW Designer door panel (Cotton White) 14 (6.3)
DDDP241 OG Designer door panel (Oyster Gray) 14 (6.3)
DDDP241 GM Designer door panel (Golden Mist) 14 (6.3)
DDDP241 LE Designer door panel (Lemonade) 14 (6.3)
DDDP241 SA Designer door panel (Sage) 14 (6.3)
DDDP241 MJ Designer door panel (Mint Julep) 14 (6.3)
DDDP241 SE Designer door panel (Sea Glass) 14 (6.3)
DDDP241 IB Designer door panel (Iridescent Blue) 14 (6.3)
DDDP241 VB Designer door panel (Viking Blue) 14 (6.3)
DDDP241 PM Designer door panel (Pumpkin) 14 (6.3)
DDDP241 RR Designer door panel (Racing Red) 14 (6.3)
DDDP241 AR Designer door panel (Apple Red) 14 (6.3)
DDDP241 BU Designer door panel (Burgundy) 14 (6.3)
DDDP241 PL Designer door panel (Plum) 14 (6.3)
DDDP241 CH Designer door panel (Chocolate) 14 (6.3)
DDDP241 CB Designer door panel (Cobalt Blue) 14 (6.3)

Handle Kits
• For use on locally supplie full overlay panels
• Inclu es han le an installation har ware
•Allows ishwashers with full overlay panel to coor inate with other Professional an Designer pro ucts
Compliance Information
WARRANTY INFORMATION*
• Three-year full warranty—all components (Professional Series)
• Lifetime limite warranty—stainless steel tanks, inner oor liner
• Five-year limite warranty—electronic control, racks, motor/pump assemblies, an water istribution system
(Professional an Designer)
• Ninety- ay limite warranty—cosmetic parts (painte an ecorative items) (Professional an Designer)
*For complete warranty information info see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
KITCHEN CLEANUP
Built-In 24”W. Dishwasher 200
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 4 / 2 9 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PHK23 SS Professional handle (Stainless Steel) 5 (2.3)
DDHK23 SS Designer handle (Stainless Steel) 5 (2.3)
