Viking Range 5 Series VGC User manual

F20813C EN (031515)
Viking Range, LLC
111 Front Street
Greenwood, Mississippi 38930 USA
[phone]
For product information
call 1-888-(845-4641)
or visit our webwite at
vikingrange.com in the US or
brigade.ca in Canada
Use & Care Manual
5 Series
Professional Built-In Electric Touch
Control Single and Double Ovens

3
Warnings
2
Congratulations
Your purchase of this product attests to the importance you
place upon the quality and performance of the major
appliances you use. With minimal care, as outlined in this
guide, this product is designed to provide you with years of
dependable service. Please take the few minutes necessary to
learn the proper and efficient use and care of this quality
product.
Some key features of this appliance include:
• 14 different cooking modes to make even your most
challenging baking projects a success.
• Split baking and broiling elements, reducing your
preheating time and heating your food more evenly.
• An extra-large reversing fan, allowing you to cook even
large quantities of food more quickly and evenly.
• Four convection modes, offering greater air circulation to
shorten cooking times and cook foods more evenly.
• Dual broiling elements, producing intense radiant heat for
faster broiling and a larger coverage area.
• Three broiling modes, including a special low-broil mode for
delicate broiling and top-browning.
• A profiled, hidden bake element for easier cleaning.
• Six adjustable rack positions with the largest usable baking
space available in this class.
Your complete satisfaction is our ultimate goal. If you have
any questions or comments about this product, please
contact the dealer from whom you purchased this product, or
contact our consumer support center at 1-888-(845-4641).
We appreciate your choosing Viking Range, LLC product
and hope that you will again select our products for your
other major appliance needs. For more information about
the complete selection of products, contact your dealer or
go to vikingrange.com in the US or brigade.ca in Canada
WARNING
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury
or death.
WARNING
NEVER use this appliance as a space heater to heat or warm
the room. Doing so may result in carbon monoxide poisoning
and overheating of the oven.
WARNING
Do not use commercial oven cleaners inside the oven. Use of
these cleaners can produce hazardous fumes or can damage
the porcelain finishes.
WARNING
NEVER cover any slots, holes or passages in the oven bottom
or cover an entire rack with materials such as aluminum foil.
Doing so blocks air flow through the oven and may cause
carbon monoxide poisoning. Aluminum foil linings may also
trap heat, causing a fire hazard.
WARNING
To avoid sickness and food waste when using automatic time
baking:
• Do not use foods that will spoil while waiting for cooking to
start, such as dishes with milk or eggs, cream soups, custards,
fish, pork, poultry, or foods with stuffing.
•Any food that has to wait for cooking to start should be very
cold or frozen before it is placed in the oven.
• Do not use foods containing baking powder or yeast when
automatic time baking. They will not rise properly.
•Do not allow food to remain in the oven for more than two
hours after the end of the cooking cycle.
WARNING
To avoid sickness and food waste, do not allow defrosted food
to remain in the oven for more than two hours.

4 5
Cooking Tips
R a c k P o s i t i o n s _ _ _____ ____ _____ ____ _____ _____ ____ ____ 39
Preheat ____________________________________________ 40
P a n P l a c e m e n t T i p s ___ _____ ____ _____ ____ _____ _____ __ 42
B a k i n g T i p s _ ____ _____ ____ _____ ____ _____ _____ ____ ___ 42
M u l t i p l e R a c k B a k i n g _ ____ _____ ____ _____ ____ _____ ___ 43
Conventional Baking Chart __________________________44
Convection Baking Chart ____________________________ 45
S o l v i n g B a k i n g P r o b l e m s _ ___ _____ ____ _____ ____ _____ _ 46
B r o i l i n g T i p s _ _ _____ _____ ____ _____ _____ ____ _____ ____ _ 47
B r o i l i n g C h a r t _ __ ____ _____ ____ _____ _____ ____ _____ ___ 48
Roasting Tips _______________________________________ 49
Conventional Roasting Chart ________________________ 50
Convection Roasting Chart __________________________ 51
Product Care
C l e a n i n g a n d M a i n t e n a n c e _ _____ ____ _____ _____ ____ __ 52
Self-Clean Cycle _______________________________ 54
R e p l a c i n g L i g h t _ __ _____ ____ _____ _____ ____ _____ ____ __ 56
Trouble Shooting ___________________________________ 57
E r r o r H a n d l i n g _ _____ ____ _____ ____ _____ _____ ____ _____ 57
Service Information _________________________________ 58
Warranty ___________________________________________ 59
Getting Started
Important Safety Instrutions ________________________ 6
Product Controls
O v e n C o n t r o l P a n e l _ _ ____ _____ _____ ____ _____ ____ ___ 8
Built-In Electric Oven Features ______________________ 10
Touch Pad Functions _______________________________11
Programming Modes
Clocks and Timers
S e t t i n g t h e C l o c k _ ____ _____ ____ _____ ____ _____ _ 16
S e t t i n g t h e T i m e r __ ____ _____ _____ ____ _____ ____ 17
C o o k T i m e a n d S t o p T i m e _ ___ _____ ____ _____ __ 18
Oven Settings
B r i g h t n e s s _ _ ____ _____ _____ ____ _____ ____ _____ __ 20
Degree Format (Fahrenheit or Celsius) _________20
To n e s _ _____ ____ _____ _____ ____ _____ _____ ____ __ 21
To n e V o l u m e __ _____ _____ ____ _____ ____ _____ ___ 23
T i m e o u t s _ ____ _____ ____ _____ ____ _____ _____ ___ 23
Clock Format (12-hour or 24-hour) _____________ 24
S a b b a t h M o d e ___ ____ _____ _____ ____ _____ _____ 25
Showroom Mode __________________________________25
L o c k a n d U n l o c k _ _ ____ _____ ____ _____ ____ _____ _ 26
Interior Oven Lights ___________________________ 26
Recipe Function ___________________________________ 27
Wa r m i n g M o d e s _ __ ____ _____ _____ ____ _____ _____ ___ 29
B a k e M o d e s __ _____ ____ _____ _____ ____ _____ ____ ____ 30
B r o i l M o d e s _ _________ ________ ________ ________ ____ 33
Roast Modes ______________________________________ 35
M e a t P r o b e _ _ _____ ____ _____ _____ ____ _____ _____ ____ 37
Table of Contents Table of Contents

6 7
Getting Started
Getting Started
• Do not heat unopened food containers; build-up of pressure
may cause the container to explode and result in injury.
• Always position oven racks in desired location while oven is
cool. If rack must be moved while oven is hot, do not let
potholder contact hot heating element in oven.
• Use care when opening oven door. Let hot air or steam
escape before removing or replacing food. Hot air or steam
can cause burns to hands, face and/or eyes.
• Keep oven vents unobstructed. The oven vent is located at
the front of the oven and vents into the room.
• Do not clean door gasket. It is essential for a good tight
seal. Care should be taken not to rub, damage, or move
the gasket.
• No commercial oven cleaner or oven liner protective
coating such as aluminum foil should be used in or around
any part of the oven. Improper oven liners may result in a
risk of electric shock or fire. Keep oven free from grease
buildup.
• Before self-cleaning the oven, remove broiler pan, broiler
grid, oven racks, and other utensils. Do not use your oven
to clean other parts. A fan noise should be heard during
the cleaning cycle. If not, call service before self-cleaning
again.
•DO NOT TOUCH HEATING ELEMENTS OR INTERIOR
SURFACES OF OVEN. Heating elements may be hot even
though they are dark in color. Interior surfaces of an oven
become hot enough to cause burns. During and after use,
do not touch or let clothing or other flammable materials
contact heating elements or interior surfaces of oven until
they have had sufficient time to cool. Other surfaces of the
oven may become hot enough to cause burns, such as the
oven vent opening, the surface near the vent opening, and
the oven door window.
• Use this appliance only for its intended use as described in
this manual. Never use your appliance for warming or
heating the room. This is based on safety considerations.
• Your unit should be installed by a qualified technician. The
appliance must be installed and electrically grounded
according to local codes.
• Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this manual.
All servicing should be referred to a qualified technician.
Warranty service must be performed by an authorized
service agency.
• Children should not be left alone in the kitchen while the
oven is in use. They should never be allowed to sit or stand
on any part of the appliance.
CAUTION: Do not store items of interest to children over
the unit. Children climbing to reach items could be seriously
injured. They should never be allowed to sit or stand on any
part of the appliance.
• GREASE - Grease is flammable and should be handled
carefully. Do not use water on grease fires. Flaming grease
can be extinguished with baking soda or, if available, a
multipurpose dry chemical or foam-type extinguisher. Let fat
cool before attempting to handle it. Do not allow grease to
collect around the oven or in vents. Wipe up spillovers
immediately.
• Loose-fitting or hanging garments should never be worn
while using the appliance. Do not drape towels or materials
on oven door handles. These items could ignite and cause
burns.
• Use only dry potholders. Moist or damp potholders on
hot surfaces may result in burns from steam. Do not let
potholder touch hot surface areas. Do not use a towel or
other bulky cloth.
• Keep area clean and free from combustible materials,
gasoline, and other flammable liquids. Never use your oven
as a storage space. Combustible items (paper, plastic, etc.)
may ignite, and metallic items may become hot and cause
burns.
Important Safety Instructions Important Safety Instructions

98
Oven Control Panel
Product Controls
Product Controls
*Note: Professional Series Premiere model control panel and features are shown.
Oven Function and
Temperature Controls
Each oven function has a separate setting.
(See descriptions)
The SET control up and down arrows can be
used to set any temperature from
150°F (65.6°C) to 550°F (287.8°C).
Electronic Timing Center
The Electronic Timing Center is
used to program and control all
timing functions.
IMPORTANT–The time-of-day
must be set before any other
program can be used.
Electronic Keypad
Entry
The Electronic Keypad
Entry is used to program
and control all oven
functions.
Bake
Conventional, single-rack baking
(breads, cakes, cookies, pastry, pies,
entrees, vegetables)
Convection Bake
Multi-rack baking for heavier or frozen
foods (e.g., frozen pies, pizzas, entrees,
vegetables)
Defrost
Natural defrosting of food using fan
without heat
Auto Roast*
Automatic searing of the outside of
meats; simplifies roasting
TruConvecTM
Multi-rack baking for breads, cakes,
cookies (up to 6 racks of cookies at once)
Convection Roast
Roasting whole turkeys, whole chickens,
hams, etc.
Self-Clean
A self-cleaning cycle using high heat to
burn off soils and deposits
Proof*
Creates an optimal environment for the
rising of yeast in many kinds of dough
Recipes*
Accesses, programs, and saves cooking
cycles from favorite recipes
Oven Light Controls
Controls the interior lights in the upper
and lower ovens
Oven Lock
Childproofing feature preventing the
controls from being activated when the
oven is not in use
Settings
Accesses custom features such as display
brightness, Sabbath/Showroom modes,
and tones
Broil
Three conventional broil settings for cuts of
flat pieces of meat or meat 1-2 inches thick
Convection Broil
Faster than regular broiling with less smoke
generation for thicker meats
Dehydrate
Using the convection fan over a
period of time, water is removed
from food by evaporation
Meat Probe*
Automatically turns the oven off when the
internal temperature of the meat being
roasted is reached
Oven Selector Options
Oven Selector
Controls
The Oven Selector Controls
are used to turn the upper or
lower oven on and off.
Oven Control Panel

10
Built-In Electric Oven Features
11
Touch Pad Functions
Temperature Control
Both ovens share the temperature control. To use this feature, select the
upper or lower oven, and then set the desired temperature. The controls
can be set at any temperature from 150° F (65.6° C) to 550° F (287.8° C).
Electronic Keypad Entry
Both ovens share the electronic keypad entry. The alphanumeric keys can
be used to program and control all oven functions.
Oven Function Selector Control
Both ovens offer 14 separate cooking modes from which you can choose
the one that best meets your cooking needs.
Bake
When using this function, full-
power heat is radiated from
the bake element in the
bottom of the oven cavity,
while supplemental heat is
radiated from the broil
element. This function is
recommended for single-rack
baking. Use this setting for
baking, roasting, and
casseroles.
Broil
This function is a dry-heat
cooking method, using direct
or radiant heat on three
different settings: low,
medium and high. The
distance between the foods
and the broil elements
determines broiling speed.
This function is recommended
for small, individualized cuts,
such as steaks, chops and
patties.
Bake
Product Controls
Product Controls
Professional Series Premiere double oven is shown above.
Broil Element
Interior
Oven Light
Oven Racks
(3/upper oven;
3/lower oven)
Bake Element
Lower Oven
Model/Serial
Number Plate
(under control
panel)
TruConvec™
Element
(behind baffle)
Interior Oven Light
Oven Function
and Temperature
Controls
Broil
Oven Control Panel
Electronic Key
Pad Entry
Meat Probe (available on Premiere models)
Plug
Cable Probe
Handles
Meat Probe Jack

12
TruConvec™
With this function, only the rear
element operates at full power.
There is no direct heat from the
bottom or top elements, and
the motorized fan in the rear of
the oven circulates for even
heating. Use this setting for
foods that require gentle
cooking, such as pastries,
soufflés, yeast breads, quick
breads, and cakes. This setting
produces breads, cookies, and
other baked goods with an
even texture and golden crusts. No special bakeware is required. Use this
function for single-rack baking, multiple-rack baking, roasting, and preparation
of complete meals. This setting is also recommended when preparing large
quantities of baked goods at one time.
Convection Bake
With this function, the bottom
element operates at full power,
and the top broil element
operates at supplemental
power. The motorized fan in the
rear of the oven circulates
heated air, providing a more
even heat distribution. This
even circulation of air equalizes
the temperature throughout
the oven cavity and eliminates
the hot and cold spots found in
conventional ovens. A major benefit of convection baking is the ability to
prepare food in larger quantities using multiple racks. When roasting using this
setting, cool air is quickly replaced, searing meats on the outside and retaining
more juices and natural flavor on the inside with less shrinkage. With this
heating method, foods can be baked and roasted at the same time with
minimal taste transfer, even when different dishes are involved, such as cakes,
fish, or meat. The hot air system is especially economical when thawing frozen
food. Use this setting for baking and roasting.
13
Touch Pad Functions Touch Pad Functions
Convection Broil
Using this function, the top
element operates at full
power. This function is exactly
the same as regular broiling
with the additional benefit of
air circulation by the
motorized fan in the rear of
the oven. Smoke is reduced
since the airflow also reduces
peak temperatures on the
food. Use this setting for
broiling thick cuts of meat.
Convection Roast
With this function, the
convection element runs in
conjunction with the inner
and outer broil elements.
The reversible convection
fan runs at a higher speed
in each direction, allowing
the moisture to be sealed
inside large cuts of meat,
such as roasts. This saves
time when compared with
single fan convection roast
modes. Use this setting for
whole turkeys, whole
chickens, and roasts.
NOTE: Because this function uses a high-speed convection fan for
optimum cooking performance, some noise may be noticed from this
high fan speed. This is normal.
Defrost
With the temperature control off, a motorized fan in the
rear of the oven circulates air. This fan accelerates natural
defrosting of the food without heat.
NOTE: To avoid sickness and food waste, do not allow
defrosted food to remain in the oven for more than
two hours.
TruConvecTM
convection bake
Product Controls
Product Controls
convection broil
convection roast

1514
Touch Pad Functions Touch Pad Functions
Proof*
This function uses a low temperature to create an optimal
environment for the yeast to rise in many types of dough.
Recipes*
This setting accesses, programs, and saves
cooking cycles from favorite recipes.
Interior Oven Light Controls
The upper and lower ovens have interior oven lights
controlled by the right touch pad. Push the light button to
turn the interior oven lights on and off.
Oven Lock
This child protection function prevents the oven controls
from being activated when the oven is not in use.
Settings
Use this function to access, program, and customize special
features of your oven. Special features include tones,
timeouts, display brightness, and the Sabbath mode.
*Note: The AUTO-ROAST, PROOF, RECIPE and PROBE functions are
included on the Premiere models.
Dehydrate
With this function, a motorized fan in the rear of the oven
circulates warm air. Over a period of time, the water is
removed from the food by evaporation. Removal of water
inhibits growth of microorganisms and retards the activity
of enzymes. It is important to remember that dehydration
does not improve quality; only fresh, top-quality foods
should be dehydrated in your oven.
Self-Clean
The self-cleaning cycle is designed to eliminate the need
for scrubbing and scouring food baked onto the oven
interior. During this cycle, the oven uses high temperatures
to burn off soils and deposits. An integral smoke eliminator
reduces odors associated with the soil burn-off. A powder
ash residue is left in the bottom of the oven after
completion of the self-clean cycle. When the oven has
cooled, remove any ash from oven surfaces with a damp
sponge or cloth.
Auto Roast*
This function further simplifies roasting by automatically
searing the outside of meats, raising the pre-set
temperature by 100° F for a short time to sear the outside
of the meat. The temperature then returns to the pre-set
temperature in the standard convection roast mode.
Meat Probe*
The probe temperature function is used to automatically
turn the oven off when the internal temperature of meat
being cooked is reached.
Product Controls
Product Controls

17
16
Clocks and Timers
Electronic
Timing Center
The Electronic Timing
Center is used to
program and control
all timing functions on
your Viking appliance.
It has four display and programming modes that are activated by
the four push buttons. Both the Timer and the Cook Time/Stop
Time Modes can be used to time cooking periods. These
features can even be used at the same time when both ovens are
in use. For example, you can time-bake a casserole in the upper
oven using the Cook Time/Stop Time Mode, while broiling in the
lower oven using the Timer. One oven can also be cleaned while
timing foods in the other oven using the timer.
Timer Alarm
• At the end of a program, the alarm will consist of three beeps,
followed by two beeps every 10 seconds until the “CLEAR”
button is pressed.
• Whenever a valid function key is pressed or when a control
function starts automatically, one beep will sound.
• When an invalid function key is pressed, two beeps will sound.
Setting the Clock
The time-of-day must be set before any other program can be
used. When your oven is first connected to the power in your
home, the timer display will show 12:00.
To Program the Time-Of-Day:
1. Press either the “UPPER OVEN” or “LOWER OVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash.
The word “CLOCK” will be lit on the display.
3. Type in the correct time on the electronic number keypad.
4. Press the “CLOCK SET” button again. The clock is now set.
Alternate Method:
1. Press either the “UPPER OVEN” or “LOWER OVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash.
The word “CLOCK” will be lit on the display.
3. Use the up and down arrows to change the current time.
4. Press the “SET” button on the temperature control or the
“CLOCK SET” button on the electronic timing center. The
clock is now set.
Note: The time-of-day cannot be changed while there is a
Bake Hours or Start Time cycle programmed into the timer.
Setting the Timer
The timer is designed for accurate timing and is ideal for baking
delicate items such as biscuits, cookies, and popovers, and for
precise broiling. The timer can be used for timing up to 12 hours.
When setting the timer, the time displayed will decrease in 1
minute increments. When the timer counts down to 1 minute, the
timer alarm will give one short beep and the display will change
to seconds. When the timer reaches 0:00, the alarm will give one
long beep.
To Set the Timer:
1. Press the “TIMER” button. The timer will display “0:00” and
the word “TIMER.”
2. Type in the desired duration time on the electronic number
keypad.
3. The timer will start automatically. (To cancel the entry, press the
“CLEAR” button on the left side of the control panel before
the count down begins and the time is still flashing.)
4.The timer is now set.
Alternate Method:
1. Press the “TIMER” button. The timer will display “0:00” and
the word “TIMER” will be lit on the display.
Press and Release Press and Hold
LTime increases by
one minute
Time increases by
10 minutes
MTime decreases by
one minute
Time decreases by
10 minutes
Clocks and Timers
Programming Modes
Programming Modes

19
18
Clocks and Timers
2. Use the up and down arrows to set the timer.
3. Press “SET” or “TIMER” to program the timer. (To cancel the
entry, press the “CLEAR” button on the left side of the control
panel.)
4. The timer is now set.
Cook Time and Stop Time
With the Viking oven, you can choose what times you need to
start and stop cooking your food. The Cook Time and Stop Time
functions allow you to program your preferences.
Here’s how it works:
It is 2:00 PM and you would like to have your dinner ready at 6:00
PM. By programming your oven with a two-hour cook time and a
6:00 PM stop time, your oven will delay cooking until 3:50 PM. At
3:50, the oven will begin preheating. At 4:00 PM, the oven will
begin its two-hour cook time.
Cook Time and Stop Time Facts:
Both ovens can be set individually for Cook Time and Stop Time
functions.
To Set Cook Time:
1. Select UPPER OVEN or LOWER OVEN.
2. Select an oven function and temperature before setting Cook
Time and Stop Time functions.
3. Press “COOK TIME” and the display will flash “0:00” and
“COOK TIME” will be lit below.
4. Use numeric keyboard to enter the amount of time needed for
cooking.
5. After the time is entered, the display will show “COOK TIME”
under the timer field. (To cancel the entry, press the “CLEAR”
button on the left side of the control panel.)
6. Press “SET” or “ENTER” if the cook time is correct. Cook time
is set.
NOTE: To cancel cook time during its cycle, press “COOK TIME”
and then press the “CLEAR” button on the left side of the oven
control. Cooking will continue if the oven is on.
To Set Stop Time:
1. Set Cook Time, following the steps provided in the previous
section.
2. Press “STOP TIME” and “STOP TIME” will be lit on the display.
3. Use numeric keyboard to enter the time you want to stop for
cooking.
4. After the time is entered, the display will flash the time. (To
cancel stop time, press the “CLEAR” button on the left side of
the control panel.)
5. Press “SET” or “STOP TIME” if the stop time is correct. Stop
time is set and will begin when the oven is preheated.
NOTE: Display will show Cook Time and Stop Time. If you
have entered a time incorrectly, you will hear a long beep
and the display will not change.
NOTE: To cancel stop time during its cycle, press “STOP TIME”
and then press the “CLEAR” button on the left side of the oven
control. Cooking will continue if the oven is on.
When Stop Time has been reached:
1. Your oven will sound three beeps, and “HOLD” will appear on
the display.
• The oven will stay at 150º F in hold mode for two hours.
• After two hours, the oven will sound four long beeps and
shut off.
2. Press “OFF” to turn off the oven manually.
Clocks and Timers
Press and Release Press and Hold
LTime increases by
one minute
Time increases by
10 minutes
MTime decreases by
one minute
Time decreases by
10 minutes
Programming Modes
Programming Modes

2120
Programming Modes
Programming Modes
These functions allow you to customize controls to suit your
specific tastes.
Brightness
This mode offers users the ability to decrease or increase the
intensity of the brightness of the electronic display panel. Users
may choose between four levels of brightness: 25%, 50%, 75%,
and 100%.
To customize brightness level:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “BRIGHTNESS: 100%”
appears in the display. (The % shown is the current
brightness level.)
3. Press “ENTER” to change brightness level. Current value
will flash.
4. Move up and down arrows to select desired brightness
level.
5. Press “ENTER” to confirm brightness level.
6. To exit the Settings menu, press “SETTINGS.”
Degree Format
The oven has been preset to the Fahrenheit temperature scale.
With this feature, users can switch to the Celsius temperature
scale.
To change degree format to Celsius:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “DEGREES:
FAHRENHEIT” appears in the display.
3. Press “ENTER” to change degree format. Current value
will flash.
4. Use arrow keys to select “CELSIUS.”
5. Press “ENTER” again to set degree format.
6. To exit the Settings menu, press “SETTINGS.”
Oven Settings
Tones
This function allows you to define the duration of tones and the
number of tones for different events. Your oven is programmed
with different audible tones as demonstrated by the following
chart:
Oven Settings
Description
of Tone Used in… Number of Tones
Duration
(measured
in seconds)
1 Minute Left Min/Sec or Cook
Timer 1 1
Autostart
Cooking mode or
timer starts without
pressing Set or
Enter
20.1
End of Hold Cook Time/Stop
Time 4 1
Timer Expired Min/Sec or Cook
Timer 3 1
Failure RTD error/Latch
error 5 1
Invalid Entry Error in
programming 30.1
Periodic
Reminder
After cooking mode
finishes or during
programming to
prompt action by
user
10.1
Key Press Information Entry 10.1
Invalid Key Information Entry 30.1
Repeat Key Information Entry 0 0
Oven Light
Off Turning light off 20.1
Oven Light
On Turning light on 10.1

23
22
Programming Modes
Programming Modes
Oven Settings Oven Settings
To change the frequency and/or duration of any of the above tone
signals:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “TONES…” appears in the
display.
3. Press “ENTER,” and “RESTORE FACTORY DEFAULTS: NO”
appears on the display.
4. Scroll up or down using the arrow keys to find the Tone you
would like to change and press “ENTER.” Display will flash
and appear as follows:
5. Press “ENTER,” and the “1 x 1 SEC” value will flash.
6. Using the numeric keyboard, enter the number and the
duration of tones desired. The number of tones can be a
value from 0 to 9. The duration of tones is measured in tenths
of a second. You can enter a number from 0.0 to 9.0.
7. Press “ENTER” when finished. The tone is customized to your
preference. At this point the oven plays the new tone. If you
do not like it, return to Step 10 to adjust the tone.
8. To exit the Settings menu, press “SETTINGS.”
Tone Volume
To change the TONE volume setting,
1. Press "SETTINGS." Settings menu will appear on display.
2. Press the up or down arrows until "TONES ..." appears on
the display.
3. Press "ENTER," and "RESTORE FACTORY DEFAULTS:
NO" appears on the display.
4. Press the down arrow until "VOLUME: HIGH" appears on
the display.
5. Press "ENTER" to change volume level. The current value
will flash.
6. Use up and down arrows to select the desired volume
level. Setting options are “HIGH”, “LOW” and “OFF.”
7. Press "ENTER" to confirm volume level setting.
8. To exit the Settings menu, press "SETTINGS.”
Timeouts
Your oven is programmed with 4 preset timeouts that allow the
user varying amounts of time to key in entries to the oven control
display. The amount of time allowed the user to respond to a
programming prompt is called a timeout. If the user fails to make
an entry during the timeout period, the oven will default to its
previous mode.
If you find that the amount of time allowed for programming does
not meet your needs, you can redefine the limits of any of the
four timeouts. The chart below defines the 4 timeouts, their
duration, and when they’re used:
Description
of Timeout Used in…
Duration
of
Timeout
1Short Entry
Cycle setpoint, meat probe
setpoint, and setting the
minute/second timer
5 seconds
2Medium Entry
Entering cook/stop times,
setting time, selecting
functions and settings
10 seconds
3Long Entry Selecting, editing, and
entering Recipes 30 seconds
4Lock Key
Hold Time Locking the Oven 3 seconds
Description
of Tone Used in… Number of Tones
Duration
(measured
in seconds)
Panel is
Locked Information Entry 30.1
Setpoint
Reached Cooking Modes 1 1
Meat Probe Roasting Modes 3 1
Meat Probe
within 10
degrees
Roasting Modes 2 1
Searing Time
Reached Roasting Modes 3 1
Start Time
Reached
Various Cooking
Modes 1 1
Panel is
Unlocked Information Entry 20.1
“Short Key Entry: 5 sec”
Timeout
Name Duration of
Timeout

25
Programming Modes
Sabbath Mode
This mode offers users belonging to religions with “no work”
restrictions to program their ovens to comply with the Sabbath
requirement. When the oven door is opened in Sabbath mode,
the oven light stays off while the convection fan and heating
elements remain on.
To program the Sabbath mode:
1. Press “SETTINGS”. Settings menu will appear in display.
2. Press up or down arrows until “SABBATH: NO” appears
in the display.
3. Press “ENTER,” and “NO” will flash on display.
4. Use arrow keys to choose “YES” or “NO.”
5. Press “ENTER” again to accept Sabbath mode.
6. To exit the Settings menu, press “SETTINGS.”
Showroom Mode
This mode allows the oven to be hooked up to a 120 volt
electrical supply for display or showroom mode purposes. In this
mode, the electronic display/controls and oven lights will function
but the heating elements and convection fan will NOT function.
To program the Showroom mode:
1. Press “SETTINGS”. Settings menu will appear in display.
2Use the down arrow to scroll to “TIMEOUTS”.
3. At “TIMEOUTS” mode, hold the down arrow for 5 seconds.
4. Use the down arrow to scroll to “SHOWROOM”.
5. Push “SET” button.
6. Use the up arrow to toggle between “YES” and “NO”.
7. Select “YES” and push “SET” button.
8.To exit the “SETTINGS” menu, press “SETTINGS”.
Oven Settings
24
Programming Modes
To change the duration of a Timeout:
1. Press “SETTINGS”. Settings menu will appear in display.
2. Press the up or down arrows until “TIMEOUTS…” appears
in the display.
3. Press “ENTER” and “RESTORE FACTORY DEFAULTS”:
NO” will appear on the display.
4. Scroll up or down using the arrow keys to find the timeout
you would like to change and press “ENTER.” Display will
flash and appear as follows:
5. Using the numeric keyboard, enter the number of seconds
desired.
6. Press “ENTER” when finished. Timeout is customized to
your preference.
7. To exit the Settings menu, press “SETTINGS.”
Clock Format
This feature allows users to choose a 12-hour or 24-hour
format for the clock display.
To program the clock format:
1. Press “SETTINGS.” Settings menu will appear in
display.
2. Press up and down arrows until “12 or 24 HOURS: 12”
appears in the display.
3. Press “ENTER” and the current setting will flash in the
display.
4. Use arrow keys to choose “12” or “24.”
5. Press “ENTER” again to accept desired clock format.
6. To exit the Settings menu, press “SETTINGS.”
5. Push “SET” button.
6. Use the up arrow to toggle between “YES” and “NO”.
7. Select “YES” and push “SET” button.
8.To exit the “SETTINGS” menu, press “SETTINGS”.
Oven Settings
“1 Minute Left: 1 X 1 sec”
Tone Name Number of
Tones
Duration of Tones
(in seconds)

2726
Oven Settings Recipe Function (Premiere Model Only)
Lock and Unlock
This feature prevents the control pads from being activated while
the ovens are not being used.
To lock the ovens:
1. Press on the right side of your oven control
panel. Display shows “HOLD FOR LOCK.”
2. When locked, three short beeps will sound and the display
will show “PANEL IS LOCKED.”
3. To unlock a double oven, press and hold “UPPER OVEN” or
“LOWER OVEN” for 3 seconds. When unlocked, two short
beeps will sound and the display will show “PANEL IS
UNLOCKED.”
4. To unlock a single oven, press and hold the
and simultaneously press and hold the “OVEN ON” button
for 3 seconds. When unlocked, two short beeps will sound
and the display will show “PANEL IS UNLOCKED”.
Interior Oven Lights (Two Pads)
Each oven has an interior light that can be turned off and on
using the designated buttons on the oven control panel.
Press or to turn on the light in the upper or lower
oven. (You will hear a beep to signal that the light is on.)
Press or again to turn off the light in the upper or
lower oven. (You will hear two beeps to signal that the light is off.)
Entering Recipe Name
This function programs and
saves up to 100 cooking
cycles from favorite recipes.
Recipe names are entered on
the numeric keypad on the
right side of the keyboard.
When a key with several letters is pressed for the first time, the
first letter is entered. If the same key is pressed a second time,
the second letter is entered, and so on. For example, if the key
“2 ABC” is pressed once, the letter ‘A’ is entered. If the key is
pressed 2 times, the letter ‘B’ is entered. If the key is pressed 3
times, the letter ‘C’ is entered. If the key is pressed 4 times, the
digit ‘2’ is entered. Then lower case ‘a’, then ‘b’, then ‘c’, then
‘A’ again, and so on.
If nothing is pressed within 2 seconds, the cursor moves to the
next position. To return to the previous position use the right
“CLEAR” key. Pressing the ‘1’ key will also move the cursor to
the next position as well as entering a space.
When subsequent characters are entered, the case and type of
the character matches the previous character. For example, if
the previous character is a digit, then pressing the “2 ABC” key
once would result in the digit ‘2’. If the previous character is a
lower case letter, then pressing the “2 ABC” key once would
result in the letter ‘a’.
“Amy’s Oatmeal Cookies”
Programming Modes
Programming Modes

29
Warming Modes
Dehydrate
This oven is designed not only to cook, but also to dehydrate
fruits and vegetables. Here are some tips for using your Viking
oven’s dehydrate feature:
1. Prepare the food as recommended.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Arrange the food on drying racks (not included with the oven,
but available from specialty cooking dealers).
4. Select “DEHYDRATE” from the oven function control panel.
5. Press “SET” or “ENTER.” Dehydrate mode will begin
immediately.
Defrost
This oven can defrost frozen food. To use the defrost function,
take the following steps:
1. Place the frozen food on a baking sheet.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Select “DEFROST” from the oven function control panel.
4. Press “SET” or “ENTER” to begin defrosting. The defrost
mode will begin and the defrost temperature will be displayed.
Proof
This function uses a low temperature between 90º and 110º F to
create an optimal environment for the yeast to rise in many types
of dough. To use the proof function, take the following steps:
1. Place the dough on a baking sheet.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Select “PROOF” from the oven function control panel.
4. Press “SET” or “ENTER” to begin proofing.
Oven Off
The oven will continue operating until you press the “OFF”
button for the oven you are using. For example, if you are
cooking in the “UPPER OVEN,” press the “OFF” button nearest
this button on the control panel.
28
Recipe Function (Premiere Model Only)
Entering a new recipe
1. Hit “RECIPES” twice.
2. “NAME” should be flashing.
3. Enter a recipe name using numeric keypad.
4. Hit a Bake function key.
5. Use arrow or numeric keypad to set the temperature.
6. If needed, hit “COOK TIME” key to enter cook time.
7. Hit “SET” or “ENTER” to save the recipe.
Editing a recipe
1. In the recipe list mode, hit “RECIPES.”
2. Recipe name should be flashing.
3. Use the following instructions to make changes:
• To change recipe name, use numeric keypad.
• To change cycle, press a Cycle key.
• To change temperature, press an arrow key.
• To change cook time, press the “COOK TIME” key.
4. Hit “SET” or “ENTER” to save the recipe.
Using a recipe
1. To use a programmed recipe, scroll through the list and press
“ENTER” or “SET” to select and start the program.
Deleting a recipe
1. In the recipe list mode, hit “RECIPES.”
2. Recipe name should be flashing.
3. Use right “CLEAR” key to erase the name.
4. Hit “SET” or “ENTER.”
WARNING
To avoid sickness and food waste, do not allow defrosted food
to remain in the oven for more than two hours.
Programming Modes
Programming Modes

3130
Programming Modes
Programming Modes
Convection Bake
This function is recommended for multi-rack baking. Foods can be
baked and roasted at the same time with minimal taste transfer,
even when different dishes are involved, such as cakes, fish, or
meat. To use convection bake, take the following steps:
1. Arrange the oven racks in the desired positions before heating
the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “CONV. BAKE.”
Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.”
The oven will begin Conv. Bake Preheat immediately.
OR
b. Change the temperature by typing the desired temperature
on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will
begin Conv. Bake Preheat immediately.
During Convection Bake Preheat
The display will alternate between showing the set baking
temperature and the actual preheat temperature every 5 seconds.
When the set baking temperature is reached, one long beep will
sound and the display will show “CONV. BAKE.” Open oven
door and put food in oven.
To change set temperature during preheat stage:
Bake Modes
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)
Bake
This function is recommended for single-rack baking. Use this
setting for baking, roasting, and casseroles. To bake, follow these
steps:
1. Arrange the oven racks in the desired positions before heating
the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “BAKE.” Temperature
display flashes a preset temperature of 350º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.”
The oven will begin Bake Preheat immediately.
OR
b. Change the temperature by typing the desired temperature
on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will
begin Bake Preheat immediately.
During Bake Preheat
The display will alternate between showing the set baking
temperature and the actual preheat temperature every 5 seconds.
When the set baking temperature is reached, one long beep will
sound and the display will show “BAKE.” Open oven door and
put food in oven.
To change set temperature during preheat stage:
Bake Modes
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)

3332
Programming Modes
Programming Modes
Conventional broiling is most successful for cuts of meat one to
two inches thick, and is also suitable for flat pieces of meat.
High Broil
With this setting, heat radiates at full power from both broil
elements, located in the top of the oven cavity. The distance
between the foods and the broil elements determines broiling
speed. For fast broiling, place food as close as two inches from
the broil element. Fast broiling is best for meats where "rare to
medium" doneness is desired. Use this setting for broiling small
and average cuts of meat.
Medium Broil
With this setting, inner and outer broil elements pulse on and off
to produce less heat for slow broiling. For slow broiling, allow
about four inches between the top surface of your food and the
broil element. Slow broiling is best for chicken and ham. Use this
setting for broiling small and average cuts of meat.
Low Broil
This mode uses only a fraction of the oven’s available power to
the inner broil element to produce delicate top-browning in only
three to four minutes on items such as meringue.
To Use Broil:
1. Arrange the oven rack in the desired position before
turning the broiler on.
2. Place the food in the center of the cold broiler pan and grid
supplied with your oven, and then place the broiler pan in the
oven.
3. Select “UPPER OVEN” or “LOWER OVEN.”
4. Set the Oven Function Selector to “BROIL.” Display will show
“BROIL HIGH” and “ON” will flash. Medium and low displays
will show “CONV BROIL M” and “CONV BROIL L.”
5. Choose power level for BROIL:
a. For “HIGH BROIL,” press “SET.”
b. For “MEDIUM BROIL,” press down arrow key once. Display
will change to MED, then press “SET.”
c. For “LOW BROIL,” press down arrow key twice. Display will
change to LO, then press “SET.”
6. Close the door to the oven. With closed-door broiling, the broil
element might cycle on and off if an extended broiling time is
required. A built-in smoke "eliminator" in the top of the oven
will help reduce smoke and odors.
7. When cooking is complete, press the “OFF” button for the
selected oven.
TruConvec™
This function is ideal for foods that require gentle cooking, single-
rack baking, multiple-rack baking, roasting, and preparation of
complete meals. This setting is also recommended when
preparing large quantities of baked goods at one time. To use
TruConvec™, take the following steps:
1. Arrange the oven racks in the desired positions before heating
the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “TRUCONVEC.”
Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.”
The oven will begin TruConvec™ Preheat immediately.
OR
b. Change the temperature by typing the desired temperature
on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will
begin TruConvec™ Preheat immediately.
During TruConvec™ Preheat
The display will alternate between showing the set baking
temperature and the actual preheat temperature every 5 seconds.
When the set baking temperature is reached, one long beep will
sound and the display will show “TRUCONVEC.” Open oven
door and put food in oven.
To change set temperature during preheat stage:
Bake Modes
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)
Broil Modes

35
34
Programming Modes
Programming Modes
Convection Roast
Use this function when roasting tender cuts of meat or poultry of
any size. To use Convection Roast, follow these steps:
1. Arrange the oven racks in the desired positions before heating
the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “CONV. ROAST.”
Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.”
The oven will begin Convection Roast Preheat immediately.
OR
b. Change the temperature by typing the desired temperature
on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will
begin Convection Roast Preheat immediately.
During Convection Roast Preheat
The display will alternate between showing the set temperature
and the actual preheat temperature every 5 seconds. When the
set temperature is reached, one long beep will sound and the
display will show “CONV. ROAST.” Open oven door and put
food in oven.
To change set temperature during preheat stage:
Roast Modes
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)
Convection Broil
Convection broiling has the advantage of broiling food slightly
more quickly than conventional. Convection broiling of meats also
produces better results, especially for thick cuts. This is because
meat sears on the outside and retains more juices and natural
flavor inside with less shrinkage.
To Use Convection Broil:
1. Arrange the oven rack in the desired position before turning
the broiler on.
2. Place the food in the center of the cold broiler pan and grid
supplied with your oven, and then place the broiler pan in the
oven.
3. Select “UPPER OVEN” or “LOWER OVEN.”
4. Set the Oven Function Selector to “CONV. BROIL.” Display will
show “CONV BROIL H” and “ON” will flash. Medium and low
displays will show “CONV BROIL M” and “CONV BROIL L.”
5. Choose power level for CONVECTION BROIL:
a. For “HIGH CONVECTION BROIL,” press “SET.”
b. For “MEDIUM CONVECTION BROIL,” press down arrow
key once. Display will change to MED, then press “SET.”
c. For “LOW CONVECTION BROIL,” press down arrow key
twice.
d. Display will change to LO, then press “SET.”
6. Close the door to the oven. With closed-door broiling, the broil
element might cycle on and off if an extended broiling time is
required. A built-in smoke "eliminator" in the top of the oven
will help reduce smoke and odors.
7. When cooking is complete, press the “OFF” button for the
selected oven.
Oven Off
The oven will continue operating until you press the “OFF”
button for the oven you are using. For example, if you are
cooking in the “UPPER OVEN,” press the “OFF” button
nearest this button on the control panel.
Broil Modes (cont.)

3736
Programming Modes
Programming Modes
The meat probe takes the guesswork out
of roasting by cooking foods to the ideal
internal temperature. . Your Viking oven’s
built-in probe will help you prepare meats
exactly as you want them.
Meat Probe Use and Care
• Use of probes other than the one
provided with your oven
may result in damage to the probe.
• Use the handles of the probe and plug when inserting and
removing them from the meat and outlet.
• To avoid damaging your probe, never use tongs to pull on the
cable when removing.
• To avoid breaking the probe, make sure food is completely
defrosted before inserting.
• To prevent possible burns, do not unplug the probe from the
outlet until the oven has cooled.
• Never leave the probe inside the oven during a self-cleaning
cycle.
• Never store the probe inside the oven.
To Insert the Meat Probe:
After preparing the meat and placing it on the broiler pan, follow
these steps for proper probe placement:
1. Lay the probe on the outside of the meat along the top or
side and use your finger to mark where the edge of the meat
meets the probe. The point where they meet should rest in
the center of the thickest, meatiest part of the roast.
2. Insert the probe completely into the meat. It should not touch
the bone, fat, or gristle.
• For roasts with no bone, insert the probe into the meatiest
part of the roast.
• For bone-in ham or lamb, insert the probe into the center
of the lowest large muscle or joint.
• With a whole turkey, insert the probe into the meatiest part
of the inner thigh from below and parallel to the leg.
Plug
Cable Probe
Handles
Auto Roast
Use this function to simplify roasting by automatically searing the
outside of roasts. To use Auto Roast:
1. Arrange the oven racks in the desired positions before heating
the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “AUTO ROAST.”
Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature, press “SET” or
“ENTER.” The oven will begin TruConvec™ Preheat
immediately.
OR
b. Change the temperature by typing the desired
temperature on the numeric keypad or using the up
and down arrow keys. Press “SET” or “ENTER” when
finished. The oven will begin TruConvec™ Preheat
immediately.
During Auto Roast Preheat
The display will alternate between showing the set roasting
temperature and the actual preheat temperature every 5 seconds.
When Set Auto Roast Temperature Is Reached
One long beep will sound and the display will show “SEARING.”
The oven will remain at searing temperature (set temperature plus
100º F) for 30 minutes. If set, the Cook Time timer will begin.
To Turn Off Oven:
Press the “OFF” button on the control panel display for the oven
you are using. One beep will sound and the oven will turn off.
Roast Modes Meat Probe (Available on Premiere Models)

3938
Cooking Tips
Position 6
Position 5
Position 4
Position 3
Position 2
Position 1
To Set the Meat Probe Function:
• A cooking mode must be selected before setting meat probe.
• Bake, Convection Bake, Convection Roast, TruConvec™, and
Convection Broil are the cooking modes that can be used with
the meat probe function.
• Set the internal temperature about 10° F lower than the
actual desired internal temperature. The meat will continue to
cook when removed from the oven and will reach desired
internal temperature while “standing.”
1. Insert probe into the meat and slide into oven after the oven
has reached the set preheat temperature. Double oven
models have a meat probe in the upper oven only.
2. Plug the probe into the outlet located on the left interior wall of
the oven and close the oven door.
3. Press the “MEAT PROBE” button on the control panel. The
display will show “SET PROBE” and flashing preset
temperature.
4. The preset temperature of 160º F or a stored temperature will
be displayed on the electronic timing center. If you desire this
temperature, the probe mode will begin after 10 seconds.
5. To set another temperature, use the keypad to enter the
desired temperature and press “SET” or “ENTER.”
• The temperature must be within the range of 120º to 190º F.
• Display alternates between cook mode and probe
temperature.
• Probe temperature displays LO until 100º F is reached, then
displays actual temperature.
6. When the probe is within 10º F of setpoint, two long beeps will
sound. When the setpoint is reached, three long beeps will
sound and the oven will turn off. The display will alternate
between cook mode and “DONE.” One short beep will sound
every minute until the probe function is closed.
7. Press any key to close the probe function.
Meat Probe (Available on Premiere Models)
Cooking Tips
Programming Modes
Rack Positions
Each oven is equipped with tilt-proof racks and at least one
TruGlide rack. (See chart below for number of TruGlide racks
found in each oven.) With the TruGlide rack, the bottom section
remains in the oven and the top section smoothly glides outward
when pulled. This reduces the chances of spills and makes
removing heavy items from the oven much easier. Below is a list
of how many TruGlide racks are found in each oven. Please note
that the TruGlide rack can be used in any of the six rack positions.
•Select Single and Double Ovens – One TruGlide rack (upper
oven only in double ovens)
•Premiere Single Ovens – Two TruGlide racks
•Premiere Double Ovens – Three TruGlide racks (two in upper
oven and one in lower oven)
All ovens have six rack positions. Position 6 is the farthest from the
oven bottom. Position 1 is the closest to the oven bottom. The
racks can be easily removed and arranged at various levels. For
best results with conventional baking, do not use more than one
rack at a time. It is also recommended, when using two racks, to
bake with the racks in positions 2 and 4 or positions 3 and 5.
1. Arrange the oven racks in the desired positions BEFORE
heating the oven. If cooking on two racks at the same time,
use rack positions 2 and 4 or positions 3 and 5.
2. Turn the Oven Function selector to desired function. Cooking
starts immediately and stops when the Oven Function selector
is turned to OFF.
3. Set the Temperature Control to the desired temperature.
4. Place food in the oven after the Oven indicator light goes out.
