Viking Range VEDO5302T User manual

Professional Built-In Electric Touch Control
Single and Double Ovens
Use & Care
VESO5302T / VEDO5302T
CVESO5302T / CVEDO5302T

2
Congratulations
Your purchase of this product attests to the importance you place upon the quality and performance of the major appliances
you use. With minimal care, as outlined in this guide, this product is designed to provide you with years of dependable service.
Please take the few minutes necessary to learn the proper and efficient use and care of this quality product.
Some key features of this appliance include:
• 14 different cooking modes to make even your most challenging baking projects a success.
• Split baking and broiling elements, reducing your preheating time and heating your food more evenly.
• An extra-large reversing fan, allowing you to cook even large quantities of food more quickly and evenly.
• Four convection modes, offering greater air circulation to shorten cooking times and cook foods more evenly.
• Dual broiling elements, producing intense radiant heat for faster broiling and a larger coverage area.
• Three broiling modes, including a special low-broil mode for delicate broiling and top-browning.
• A profiled, hidden bake element for easier cleaning.
• Six adjustable rack positions with the largest usable baking space available in this class.
Your complete satisfaction is our ultimate goal. If you have any questions or comments about this product, please contact
our consumer support center at 1-888-(845-4641).
We appreciate your choosing a Viking Range, LLC product and hope that you will again select our products for your other
major appliance needs. For more information about the complete selection of products, contact your dealer or go to
vikingrange.com in the US or brigade.ca in Canada.
WARNING
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury
or death.
WARNING
NEVER use this appliance as a space heater to heat or warm
the room. Doing so may result in carbon monoxide poisoning
and overheating of the oven.
WARNING
Do not use commercial oven cleaners inside the oven. Use of
these cleaners can produce hazardous fumes or can damage
the porcelain finishes.
WARNING
NEVER cover any slots, holes or passages in the oven
bottom or cover an entire rack with materials such as
aluminum foil. Doing so blocks air flow through the oven
and may cause carbon monoxide poisoning. Aluminum foil
linings may also trap heat, causing a fire hazard.
WARNING
To avoid sickness and food waste when using automatic time
baking:
• Do not use foods that will spoil while waiting for cooking to
start, such as dishes with milk or eggs, cream soups,
custards, fish, pork, poultry, or foods with stuffing.
• Any food that has to wait for cooking to start should be very
cold or frozen before it is placed in the oven.
• Do not use foods containing baking powder or yeast when
automatic time baking. They will not rise properly.
• Do not allow food to remain in the oven for more than two
hours after the end of the cooking cycle.
WARNING
To avoid sickness and food waste, do not allow defrosted food
to remain in the oven for more than two hours.

3
Getting Started
Important Safety Instrutions ____________________________________________________________________________________________________ 4
Product Controls
Built-In Electric Oven Features __________________________________________________________________________________________________ 5
Oven Control Panel ________________________________________________________________________________________________________________6
Touch Pad Functions ______________________________________________________________________________________________________________ 7
Programming Modes
Clocks and Timers
S e t t i n g t h e C l o c k ________________________________________________________________________________________________________ 10
S e t t i n g t h e T i m e r ________________________________________________________________________________________________________ 10
C o o k T i m e a n d S t o p T i m e ____________________________________________________________________________________________________ 10
Oven Settings
B r i g h t n e s s ________________________________________________________________________________________________________________ 12
Degree Format (Fahrenheit or Celsius) ______________________________________________________________________________ 12
To n e s ______________________________________________________________________________________________________________________ 12
To n e Vo l u m e ______________________________________________________________________________________________________________ 13
T i m e o u t s __________________________________________________________________________________________________________________ 14
Clock Format (12-hour or 24-hour) __________________________________________________________________________________ 14
S a b b a t h M o d e __________________________________________________________________________________________________________ 15
Showroom Mode ____________________________________________________________________15
L o c k a n d U n l o c k ________________________________________________________________________________________________________ 15
Interior Oven Lights ____________________________________________________________________________________________________ 15
Recipe Function __________________________________________________________________________________________________________________ 16
Wa r m i n g M o d e s ________________________________________________________________________________________________________________ 17
B a k e M o d e s ______________________________________________________________________________________________________________________18
B r o i l M o d e s ______________________________________________________________________________________________________________________ 20
Roast Modes______________________________________________________________________________________________________________________ 21
M e a t P r o b e ______________________________________________________________________________________________________________________22
Cooking Tips
Rack Positions __________________________________________________________________________________23
Preheat _______________________________________________________________ _____ ____________ _____ _______ _ 23
P a n P l a c e m e n t T i p s __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ _ 24
B a k i n g T i p s _ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ _ 24
M u l t i p l e R a c k B a k i n g _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ 24
Conventional Baking Chart ___________________________________________________________ _____ _______ ____ 25
Convection Baking Chart ____________________________________________________________ _____ _______ _____ 26
S o l v i n g B a k i n g P r o b l e m s _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ _ 27
B r o i l i n g T i p s _ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ 28
B r o i l i n g C h a r t _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ 28
Roasting Tips ____________________________________________________________ _____ ____________ _____ ______ 29
Conventional Roasting Chart _________________________________________________________ _____ _______ ____ 29
Convection Roasting Chart _______________________________________________________ _____ _______ _____ ___ 30
Product Care
C l e a n i n g a n d M a i n t e n a n c e _ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ 31
Self-Clean Cycle _______________________________________________________________ _____ _______ _____ 32
R e p l a c i n g L i g h t __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ _ 33
Trouble Shooting _______________________________________________________________ _____ _______ _____ ____ 33
E r r o r H a n d l i n g _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ ___ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ 34
Service Information _______________________________________________________ _______ _____ _______ _____ ___ 34
Warranty __________________________________________________________________ _____ _______ _____ _________ 35
Table of Contents

• Use this appliance only for its intended use as described in this manual. Never use your appliance for warming or
heating the room. This is based on safety considerations.
• Your unit should be installed by a qualified technician. The appliance must be installed and electrically grounded
according to local codes.
• Do not attempt to repair or replace any part of this appliance unless specifically recommended in this manual. All
servicing should be referred to a qualified technician. Warranty service must be performed by an authorized
service agency.
• Children should not be left alone in the kitchen while the oven is in use. They should never be allowed to sit or
stand on any part of the appliance. CAUTION: Do not store items of interest to children over
the unit. Children climbing to reach items could be seriously injured. They should never be allowed to sit or stand
on any part of the appliance.
• GREASE - Grease is flammable and should be handled carefully. Do not use water on grease fires. Flaming
grease can be extinguished with baking soda or, if available, a multipurpose dry chemical or foam-type
extinguisher. Let fat cool before attempting to handle it. Do not allow grease to collect around the oven or in
vents. Wipe up spillovers immediately.
• Loose-fitting or hanging garments should never be worn while using the appliance. Do not drape towels or
materials on oven door handles. These items could ignite and cause burns.
• Use only dry potholders. Moist or damp potholders onhot surfaces may result in burns from steam. Do not let
potholder touch hot surface areas. Do not use a towel or other bulky cloth.
• Keep area clean and free from combustible materials, gasoline, and other flammable liquids. Never use your oven
as a storage space. Combustible items (paper, plastic, etc.) may ignite, and metallic items may become hot and
cause burns.
• Do not heat unopened food containers; build-up of pressure may cause the container to explode and result in
injury.
• Always position oven racks in desired location while oven is cool. If rack must be moved while oven is hot, do not
let potholder contact hot heating element in oven.
• Use care when opening oven door. Let hot air or steam escape before removing or replacing food. Hot air or
steam can cause burns to hands, face and/or eyes.
• Keep oven vents unobstructed. The oven vent is located at the front of the oven and vents into the room.
• Do not clean door gasket. It is essential for a good tight seal. Care should be taken not to rub, damage, or move
the gasket.
• No commercial oven cleaner or oven liner protective coating such as aluminum foil should be used in or around
any part of the oven. Improper oven liners may result in a risk of electric shock or fire. Keep oven free from grease
buildup.
• Before self-cleaning the oven, remove broiler pan, broiler grid, oven racks, and other utensils. Do not use your
oven to clean other parts. A fan noise should be heard during the cleaning cycle. If not, call service before self-
cleaning again.
• DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES OF OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of an oven become hot enough to cause burns. During and
after use, do not touch or let clothing or other flammable materials contact heating elements or interior surfaces
of oven until they have had sufficient time to cool. Other surfaces of the oven may become hot enough to cause
burns, such as the oven vent opening, the surface near the vent opening, and the oven door window.
Important Safety Instructions
4

Built-In Electric Oven Features
Professional Series Premiere double oven is shown above.
Broil Element
Interior
Oven Light
Oven Racks
(3/upper oven;
3/lower oven)
Bake Element
Lower Oven
Model/Serial
Number Plate
(under control
panel)
TruConvec™
Element
(behind baffle)
Interior Oven Light
Oven Function
and Temperature
Controls
Oven Control Panel
Electronic Key
Pad Entry
Meat Probe (available on Premiere models)
Plug
Cable Probe
Handles
Meat Probe Jack
5

Oven Control Panel
Oven Function and
Temperature Controls
Each oven function has a separate setting. (See descriptions) The SET control up and down arrows can be used to set any temperature from 150°F (65.6°C) to 550°F (287.8°C).
Electronic Timing
Center
The Electronic Timing Center is used to program and control all timing functions. IMPORTANT–The time-of- day must be set before any other program can be used.
Electronic Keypad
Entry
The Electronic Keypad Entry is used to program and control all oven functions.
Oven Function Selector
Bake
Conventional, single-rack baking (breads, cakes, cookies, pastry, pies, entrees, vegetables)
Convection Bake
Multi-rack baking for heavier or frozen foods (e.g., frozen pies, pizzas, entrees, vegetables)
Defrost
Natural defrosting of food using fan without heat
Auto Roast*
Automatic searing of the outside of meats; simplifies roasting
Broil
Three conventional broil settings for cuts of flat pieces of meat or meat 1-2 inches thick
Convection Broil
Faster than regular broiling with less smoke generation for thicker meats
Dehydrate
Using the convection fan over a period of time, water is removed from food by evaporation
Meat Probe*
Automatically turns the oven off when the internal temperature of the meat being roasted is reached
TruConvecTM
Multi-rack baking for breads, cakes, cookies (up to 6 racks of cookies at once)
Convection Roast
Roasting whole turkeys, whole chickens, hams, etc. Self-Clean A self-cleaning cycle using high heat to burn off soils and deposits
Proof*
Creates an optimal environment for the rising of yeast in many kinds of dough
Recipes*
Accesses, programs, and saves cooking cycles from favorite recipes
Oven Light Controls
Controls the interior lights in the upper and lower ovens
Oven Lock
Childproofing feature preventing the controls from being activated when the oven is not in use
Settings
Accesses custom features such as display brightness, Sabbath/Showroom modes, and tones
Oven Selector
Controls
The Oven Selector Controls are used to turn the upper or lower oven on and off.
6

Temperature Control
Both ovens share the temperature control. To use this feature, select the upper or lower oven, and then set the desired
temperature. The controls can be set at any temperature from 150° F (65.6° C) to 550° F (287.8° C).
Electronic Keypad Entry
Both ovens share the electronic keypad entry. The alphanumeric keys can be used to program and control all oven
functions.
Oven Function Selector Control
Both ovens offer 14 separate cooking modes from which you can choose the
one that best meets your cooking needs.
Bake
When using this function, full-power heat is radiated from the bake element in
the bottom of the oven cavity, while supplemental heat is radiated from the broil
element. This function is recommended for single-rack baking. Use this setting
for baking, roasting, and casseroles.
Broil
This function is a dry-heat cooking method, using direct or radiant heat on three
different settings: low, medium and high. The distance between the foods and
the broil elements determines broiling speed. This function is recommended for
small, individualized cuts, such as steaks, chops and patties.
TruConvec™
With this function, only the rear element operates at full power. There is no
direct heat from the bottom or top elements, and the motorized fan in the rear
of the oven circulates for even heating. Use this setting for foods that require
gentle cooking, such as pastries, soufflés, yeast breads, quick breads, and
cakes. This setting produces breads, cookies, and other baked goods with an
even texture and golden crusts. No special bakeware is required. Use this
function for single-rack baking, multiple-rack baking, roasting, and preparation
of complete meals. This setting is also recommended when preparing large
quantities of baked goods at one time.
Convection Bake
With this function, the bottom element operates at full power, and the top broil
element operates at supplemental power. The motorized fan in the rear of the
oven circulates heated air, providing a more even heat distribution. This even
circulation of air equalizes the temperature throughout the oven cavity and
eliminates the hot and cold spots found in conventional ovens. A major benefit
of convection baking is the ability to prepare food in larger quantities using
multiple racks. When roasting using this setting, cool air is quickly replaced,
searing meats on the outside and retaining more juices and natural flavor on the
inside with less shrinkage. With this heating method, foods can be baked and
roasted at the same time with minimal taste transfer, even when different dishes
are involved, such as cakes, fish, or meat. The hot air system is especially
economical when thawing frozen food. Use this setting for baking and roasting.
Bake
Broil
Touch Pad Functions
7
TruConvecTM
convection bake

Touch Pad Functions
Convection Broil
Using this function, the top element operates at full power. This function is exactly the
same as regular broiling with the additional benefit of air circulation by the motorized
fan in the rear of the oven. Smoke is reduced since the airflow also reduces peak
temperatures on the food. Use this setting for broiling thick cuts of meat.
Convection Roast
With this function, the convection element runs in conjunction with the inner and
outer broil elements. The reversible convection fan runs at a higher speed in each
direction, allowing the moisture to be sealed inside large cuts of meat, such as
roasts. This saves time when compared with single fan convection roast modes. Use
this setting for whole turkeys, whole chickens, and roasts.
NOTE: Because this function uses a high-speed convection fan for optimum
cooking performance, some noise may be noticed from this high fan speed.
This is normal.
Defrost
With the temperature control off, a motorized fan in the rear of the oven circulates
air. This fan accelerates natural defrosting of the food without heat.
NOTE: To avoid sickness and food waste, do not allow defrosted food to remain in the oven for more than two hours.
Dehydrate
With this function, a motorized fan in the rear of the oven circulates warm air. Over a period of time, the water
is removed from the food by evaporation. Removal of water inhibits growth of microorganisms and retards the
activity of enzymes. It is important to remember that dehydration does not improve quality; only fresh, top-
quality foods should be dehydrated in your oven.
Self-Clean
The self-cleaning cycle is designed to eliminate the need for scrubbing and scouring food baked onto the oven
interior. During this cycle, the oven uses high temperatures to burn off soils and deposits. An integral smoke
eliminator reduces odors associated with the soil burn-off. A powder ash residue is left in the bottom of the
oven after completion of the self-clean cycle. When the oven has cooled, remove any ash from oven surfaces
with a damp sponge or cloth.
Auto Roast*
This function further simplifies roasting by automatically searing the outside of meats, raising the pre-set
temperature by 100° F for a short time to sear the outside of the meat. The temperature then returns to the
pre-set temperature in the standard convection roast mode.
Meat Probe*
The probe temperature function is used to automatically turn the oven off when the internal temperature of
meat being cooked is reached.
8
convection broil
convection roast

Touch Pad Functions
Proof*
This function uses a low temperature to create an optimal environment for the yeast to rise in many types of
dough.
Recipes*
This setting accesses, programs, and saves cooking cycles from favorite recipes.
Interior Oven Light Controls
The upper and lower ovens have interior oven lights controlled by the right touch pad. Push the light button
to turn the interior oven lights on and off.
Oven Lock
This child protection function prevents the oven controls from being activated when the oven is not in use.
Settings
Use this function to access, program, and customize special features of your oven. Special features include
tones, timeouts, display brightness, and the Sabbath mode.
*Note: The AUTO-ROAST, PROOF, RECIPE and PROBE functions are included on the Premiere models.
9
Clocks and Timers
Electronic Timing Center
The Electronic Timing Center is used to program and control all timing functions on
your Viking appliance. It has four display and programming modes that are activated by
the four push buttons. Both the Timer and the Cook Time/Stop Time Modes can be
used to time cooking periods. These features can even be used at the same time when
both ovens are in use. For example, you can time-bake a casserole in the upper oven
using the Cook Time/Stop Time Mode, while broiling in the lower oven using the Timer.
One oven can also be cleaned while timing foods in the other oven using the timer.
Timer Alarm
• At the end of a program, the alarm will consist of three beeps, followed by two beeps every 10 seconds until the “CLEAR” button
is pressed.
• Whenever a valid function key is pressed or when a control function starts automatically, one beep will sound.
• When an invalid function key is pressed, two beeps will sound.

Setting the Clock
The time-of-day must be set before any other program can be used. When your oven is first connected to the power in
your home, the timer display will show 12:00.
To Program the Time-Of-Day:
1. Press either the “UPPER OVEN” or “LOWER OVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash.
The word “CLOCK” will be lit on the display.
3. Type in the correct time on the electronic number keypad.
4. Press the “CLOCK SET” button again. The clock is now set.
Alternate Method:
1. Press either the “UPPER OVEN” or “LOWER OVEN” button.
2. Press the “CLOCK SET” button. The clock will begin to flash. The word “CLOCK” will be lit on the display.
3. Use the up and down arrows to change the current time.
4. Press the “SET” button on the temperature control or the “CLOCK SET” button on the electronic timing center. The
clock is now set.
Note: The time-of-day cannot be changed while there is a Bake Hours or Start Time cycle programmed into the
timer.
Setting the Timer
The timer is designed for accurate timing and is ideal for baking delicate items such as biscuits, cookies, and popovers,
and for precise broiling. The timer can be used for timing up to 12 hours. When setting the timer, the time displayed will
decrease in 1 minute increments. When the timer counts down to 1 minute, the timer alarm will give one short beep and
the display will change to seconds. When the timer reaches 0:00, the alarm will give one long beep.
To Set the Timer:
1. Press the “TIMER” button. The timer will display “0:00” and the word “TIMER.”
2. Type in the desired duration time on the electronic number keypad.
3. The timer will start automatically. (To cancel the entry, press the “CLEAR” button on the left side of the control panel
before the count down begins and the time is still flashing.)
4.The timer is now set.
Alternate Method:
1. Press the “TIMER” button. The timer will display “0:00” and the word “TIMER” will be lit on the display.
2. Use the up and down arrows to set the timer.
3. Press “SET” or “TIMER” to program the timer. (To cancel the entry, press the “CLEAR” button on the left side of the
control panel.)
4. The timer is now set.
Press and Release Press and Hold
LTime increases by
one minute
Time increases by
10 minutes
MTime decreases by
one minute
Time decreases by
10 minutes
Clocks and Timers
10
Press and Release Press and Hold
LTime increases by
one minute
Time increases by
10 minutes
MTime decreases by
one minute
Time decreases by
10 minutes

11
Cook Time and Stop Time
With this oven, you can choose what times you need to start and stop cooking your food. The Cook Time and Stop Time functions
allow you to program your preferences.
Here’s how it works:
It is 2:00 PM and you would like to have your dinner ready at 6:00 PM. By programming your oven with a two-hour cook time and a
6:00 PM stop time, your oven will delay cooking until 3:50 PM. At 3:50, the oven will begin preheating. At 4:00 PM, the oven will
begin its two-hour cook time.
Cook Time and Stop Time Facts:
Both ovens can be set individually for Cook Time and Stop Time functions.
To Set Cook Time:
1. Select UPPER OVEN or LOWER OVEN.
2. Select an oven function and temperature before setting Cook
Time and Stop Time functions.
3. Press “COOK TIME” and the display will flash “0:00” and “COOK TIME” will be lit below.
4. Use numeric keyboard to enter the amount of time needed for cooking.
5. After the time is entered, the display will show “COOK TIME” under the timer field. (To cancel the entry, press the “CLEAR”
button on the left side of the control panel.)
6. Press “SET” or “ENTER” if the cook time is correct. Cook time is set.
NOTE: To cancel cook time during its cycle, press “COOK TIME” and then press the “CLEAR” button on the left side of the oven
control. Cooking will continue if the oven is on.
To Set Stop Time:
1. Set Cook Time, following the steps provided in the previous section.
2. Press “STOP TIME” and “STOP TIME” will be lit on the display.
3. Use numeric keyboard to enter the time you want to stop for cooking.
4. After the time is entered, the display will flash the time. (To cancel stop time, press the “CLEAR” button on the left side of the
control panel.)
5. Press “SET” or “STOP TIME” if the stop time is correct. Stop time is set and will begin when the oven is preheated.
NOTE: Display will show Cook Time and Stop Time. If you have entered a time incorrectly, you will hear a long beep and
the display will not change.
NOTE: To cancel stop time during its cycle, press “STOP TIME” and then press the “CLEAR” button on the left side of the oven
control. Cooking will continue if the oven is on.
When Stop Time has been reached:
1. Your oven will sound three beeps, and “HOLD” will appear on the display.
• The oven will stay at 150º F in hold mode for two hours.
• After two hours, the oven will sound four long beeps and shut off.
2. Press “OFF” to turn off the oven manually.
Clocks and Timers

These functions allow you to customize controls to suit your specific tastes.
Brightness
This mode offers users the ability to decrease or increase the intensity of the brightness of the electronic display panel.
Users may choose between four levels of brightness: 25%, 50%, 75%, and 100%.
To customize brightness level:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “BRIGHTNESS: 100%” appears in the display. (The % shown is the current
brightness level.)
3. Press “ENTER” to change brightness level. Current value will flash.
4. Move up and down arrows to select desired brightness level.
5. Press “ENTER” to confirm brightness level.
6. To exit the Settings menu, press “SETTINGS.”
Degree Format
The oven has been preset to the Fahrenheit temperature scale. With this feature, users can switch to the Celsius
temperature scale.
To change degree format to Celsius:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “DEGREES: FAHRENHEIT” appears in the display.
3. Press “ENTER” to change degree format. Current value will flash.
4. Use arrow keys to select “CELSIUS.”
5. Press “ENTER” again to set degree format.
6. To exit the Settings menu, press “SETTINGS.”
Tones
This function allows you to define the duration of tones and the number of tones for different events. Your oven is
programmed with different audible tones as demonstrated by the following chart:
To change the frequency and/or duration of any of the tone signals:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press the up or down arrows until “TONES…” appears in the display.
3. Press “ENTER,” and “RESTORE FACTORY DEFAULTS: NO” appears on the display.
4. Scroll up or down using the arrow keys to find the Tone you would like to change and press “ENTER.” Display will flash
and appear as follows:
5. Press “ENTER,” and the “1 x 1 SEC” value will flash.
6. Using the numeric keyboard, enter the number and the duration of tones desired. The number of tones can be a
value from 0 to 9. The duration of tones is measured in tenths of a second. You can enter a number from 0.0 to 9.0.
7. Press “ENTER” when finished. The tone is customized to your preference. At this point the oven plays the new tone. If
you do not like it, return to Step 10 to adjust the tone.
8. To exit the Settings menu, press “SETTINGS.”
Oven Settings
12
“Short Key Entry: 5 sec”
Timeout
Name Duration of
Timeout

Tone Volume
To change the TONE volume setting,
1. Press "SETTINGS." Settings menu will appear on display.
2. Press the up or down arrows until "TONES ..." appears on the display.
3. Press "ENTER," and "RESTORE FACTORY DEFAULTS: NO" appears on the display.
4. Press the down arrow until "VOLUME: HIGH" appears on the display.
5. Press "ENTER" to change volume level. The current value will flash.
6. Use up and down arrows to select the desired volume level. Setting options are “HIGH”, “LOW” and “OFF.”
7. Press "ENTER" to confirm volume level setting.
8. To exit the Settings menu, press "SETTINGS.”
Oven Settings
Description of
Tone Used in… Number of Tones
Duration
(measured
in seconds)
1 Minute Left Min/Sec or Cook Timer 1 1
Autostart Cooking mode or timer starts without
pressing Set or Enter 20.1
End of Hold Cook Time/Stop Time 4 1
Timer Expired Min/Sec or Cook Timer 3 1
Failure RTD error/Latch error 5 1
Invalid Entry Error in programming 30.1
Periodic Reminder After cooking mode finishes or during
programming to prompt action by user 10.1
Key Press Information Entry 10.1
Invalid Key Information Entry 30.1
Repeat Key Information Entry 0 0
Oven Light Off Turning light off 20.1
Oven Light On Turning light on 10.1
Panel is Locked Information Entry 30.1
Setpoint Reached Cooking Modes 1 1
Meat Probe Roasting Modes 3 1
Meat Probe within
10 degrees Roasting Modes 2 1
Searing Time
Reached Roasting Modes 3 1
Start Time Reached Various Cooking Modes 1 1
Panel is Unlocked Information Entry 20.1
13

Oven Settings
Timeouts
Your oven is programmed with 4 preset timeouts that allow the user varying amounts of time to key in entries to the oven
control display. The amount of time allowed the user to respond to a programming prompt is called a timeout. If the user
fails to make an entry during the timeout period, the oven will default to its previous mode.
If you find that the amount of time allowed for programming does not meet your needs, you can redefine the limits of any
of the four timeouts. The chart below defines the 4 timeouts, their duration, and when they’re used:
Description
of Timeout Used in…
Duration
of
Timeout
1Short Entry
Cycle setpoint, meat probe
setpoint, and setting the
minute/second timer
5 seconds
2Medium Entry
Entering cook/stop times,
setting time, selecting
functions and settings
10 seconds
3Long Entry Selecting, editing, and
entering Recipes 30 seconds
4Lock Key
Hold Time Locking the Oven 3 seconds
14
To change the duration of a Timeout:
1. Press “SETTINGS”. Settings menu will appear in display.
2. Press the up or down arrows until “TIMEOUTS…” appears in the display.
3. Press “ENTER” and “RESTORE FACTORY DEFAULTS”: NO” will appear on the display.
4. Scroll up or down using the arrow keys to find the timeout you would like to change and press “ENTER.”
Display will flash and appear as follows:
5. Using the numeric keyboard, enter the number of seconds desired.
6. Press “ENTER” when finished. Timeout is customized to your preference.
7. To exit the Settings menu, press “SETTINGS.”
Clock Format
This feature allows users to choose a 12-hour or 24-hour format for the clock display.
To program the clock format:
1. Press “SETTINGS.” Settings menu will appear in display.
2. Press up and down arrows until “12 or 24 HOURS: 12” appears in the display.
3. Press “ENTER” and the current setting will flash in the display.
4. Use arrow keys to choose “12” or “24.”
5. Press “ENTER” again to accept desired clock format.
6. To exit the Settings menu, press “SETTINGS.”
7. Push “SET” button.
8. Use the up arrow to toggle between “YES” and “NO”.
9. Select “YES” and push “SET” button.
10.To exit the “SETTINGS” menu, press “SETTINGS”.
“1 Minute Left: 1 X 1 sec”
Tone Name Number of
Tones
Duration of Tones
(in seconds)

Oven Settings
15
Sabbath Mode
This mode offers users belonging to religions with “no work” restrictions to program their ovens to comply with the Sabbath
requirement. When the oven door is opened in Sabbath mode, the oven light stays off while the convection fan and heating
elements remain on.
To program the Sabbath mode:
1. Press “SETTINGS”. Settings menu will appear in display.
2. Press up or down arrows until “SABBATH: NO” appears in the display.
3. Press “ENTER,” and “NO” will flash on display.
4. Use arrow keys to choose “YES” or “NO.”
5. Press “ENTER” again to accept Sabbath mode.
6. To exit the Settings menu, press “SETTINGS.”
Showroom Mode
This mode allows the oven to be hooked up to a 120 volt electrical supply for display or showroom mode purposes. In this
mode, the electronic display/controls and oven lights will function but the heating elements and convection fan will NOT
function.
To program the Showroom mode:
1. Press “SETTINGS”. Settings menu will appear in display.
2Use the down arrow to scroll to “TIMEOUTS”.
3. At “TIMEOUTS” mode, hold the down arrow for 5 seconds.
4. Use the down arrow to scroll to “SHOWROOM”.
5. Push “SET” button.
6. Use the up arrow to toggle between “YES” and “NO”.
7. Select “YES” and push “SET” button.
8.To exit the “SETTINGS” menu, press “SETTINGS”.
Lock and Unlock
This feature prevents the control pads from being activated while the ovens are not being used.
To lock the ovens:
1. Press on the right side of your oven control panel. Display shows “HOLD FOR LOCK.”
2. When locked, three short beeps will sound and the display will show “PANEL IS LOCKED.”
3. To unlock a double oven, press and hold “UPPER OVEN” or “LOWER OVEN” for 3 seconds. When unlocked, two short
beeps will sound and the display will show “PANEL IS UNLOCKED.”
4. To unlock a single oven, press and hold the and simultaneously press and hold the “OVEN ON” button
for 3 seconds. When unlocked, two short beeps will sound and the display will show “PANEL IS UNLOCKED”.
Interior Oven Lights (Two Pads)
Each oven has an interior light that can be turned off and on using the designated buttons on the oven control panel.
Press or to turn on the light in the upper or lower oven. (You will hear a beep to signal that the light is on.)
Press or again to turn off the light in the upper or lower oven. (You will hear two beeps to signal that the light is off.)

Recipe Function (Premiere Model Only)
Entering Recipe Name
This function programs and saves up to 100 cooking cycles from favorite recipes. Recipe
names are entered on the numeric keypad on the right side of the keyboard. When a key
with several letters is pressed for the first time, the first letter is entered. If the same key
is pressed a second time, the second letter is entered, and so on. For example, if the key
“2 ABC” is pressed once, the letter ‘A’ is entered. If the key is pressed 2 times, the letter
‘B’ is entered. If the key is pressed 3 times, the letter ‘C’ is entered. If the key is pressed
4 times, the digit ‘2’ is entered. Then lower case ‘a’, then ‘b’, then ‘c’, then ‘A’ again, and
so on.
If nothing is pressed within 2 seconds, the cursor moves to the next position. To return to the previous position use the right
“CLEAR” key. Pressing the ‘1’ key will also move the cursor to the next position as well as entering a space.
When subsequent characters are entered, the case and type of the character matches the previous character. For example, if
the previous character is a digit, then pressing the “2 ABC” key once would result in the digit ‘2’. If the previous character is a
lower case letter, then pressing the “2 ABC” key once would result in the letter ‘a’.
“Amy’s Oatmeal Cookies”
Entering a new recipe
1. Hit “RECIPES” twice.
2. “NAME” should be flashing.
3. Enter a recipe name using numeric keypad.
4. Hit a Bake function key.
5. Use arrow or numeric keypad to set the temperature.
6. If needed, hit “COOK TIME” key to enter cook time.
7. Hit “SET” or “ENTER” to save the recipe.
Editing a recipe
1. In the recipe list mode, hit “RECIPES.”
2. Recipe name should be flashing.
3. Use the following instructions to make changes:
• To change recipe name, use numeric keypad.
• To change cycle, press a Cycle key.
• To change temperature, press an arrow key.
• To change cook time, press the “COOK TIME” key.
4. Hit “SET” or “ENTER” to save the recipe.
Using a recipe
1. To use a programmed recipe, scroll through the list and press “ENTER” or “SET” to select and start the program.
Deleting a recipe
1. In the recipe list mode, hit “RECIPES.”
2. Recipe name should be flashing.
3. Use right “CLEAR” key to erase the name.
4. Hit “SET” or “ENTER.”
16

Warming Modes
Dehydrate
This oven is designed not only to cook, but also to dehydrate fruits and vegetables. Here are some tips for using your oven’s
dehydrate feature:
1. Prepare the food as recommended.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Arrange the food on drying racks (not included with the oven, but available from specialty cooking dealers).
4. Select “DEHYDRATE” from the oven function control panel.
5. Press “SET” or “ENTER.” Dehydrate mode will begin immediately.
Defrost
This oven can defrost frozen food. To use the defrost function, take the following steps:
1. Place the frozen food on a baking sheet.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Select “DEFROST” from the oven function control panel.
4. Press “SET” or “ENTER” to begin defrosting. The defrost mode will begin and the defrost temperature will be displayed.
Proof
This function uses a low temperature between 90º and 110º F to create an optimal environment for the yeast to rise in many types
of dough. To use the proof function, take the following steps:
1. Place the dough on a baking sheet.
2. Choose and press “UPPER OVEN” or “LOWER OVEN.”
3. Select “PROOF” from the oven function control panel.
4. Press “SET” or “ENTER” to begin proofing.
Oven Off
The oven will continue operating until you press the “OFF” button for the oven you are using. For example, if you are cooking in the
“UPPER OVEN,” press the “OFF” button nearest this button on the control panel.
Bake
This function is recommended for single-rack baking. Use this setting for baking, roasting, and casseroles. To bake, follow these
steps:
1. Arrange the oven racks in the desired positions before heating the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “BAKE.” Temperature display flashes a preset temperature of 350º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.” The oven will begin Bake Preheat immediately.
OR
b. Change the temperature by typing the desired temperature
on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will begin Bake Preheat immediately.
WARNING
To avoid sickness and food waste, do not allow defrosted food
to remain in the oven for more than two hours.
17

Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)
During Bake Preheat
The display will alternate between showing the set baking temperature and the actual preheat temperature every 5
seconds. When the set baking temperature is reached, one long beep will sound and the display will show “BAKE.” Open
oven door and put food in oven.
To change set temperature during preheat stage:
Convection Bake
This function is recommended for multi-rack baking. Foods can be baked and roasted at the same time with minimal taste
transfer, even when different dishes are involved, such as cakes, fish, or meat. To use convection bake, take the following
steps:
1. Arrange the oven racks in the desired positions before heating the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “CONV. BAKE.” Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.” The oven will begin Conv. Bake Preheat immediately.
OR
b. Change the temperature by typing the desired temperature on the numeric keypad or using the up and down arrow
keys. Press “SET” or “ENTER” when finished. The oven will begin Conv. Bake Preheat immediately.
During Convection Bake Preheat
The display will alternate between showing the set baking temperature and the actual preheat temperature every 5
seconds. When the set baking temperature is reached, one long beep will sound and the display will show “CONV.
BAKE.” Open oven door and put food in oven.
To change set temperature during preheat stage:
Bake Modes
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)
18

TruConvec™
This function is ideal for foods that require gentle cooking, single-rack baking, multiple-rack baking, roasting, and preparation of
complete meals. This setting is also recommended when preparing large quantities of baked goods at one time. To use
TruConvec™, take the following steps:
1. Arrange the oven racks in the desired positions before heating the oven.
2. Select “UPPER OVEN” or “LOWER OVEN.”
3. Set the Oven Function Selector to “TRUCONVEC.” Temperature display flashes a preset temperature of 325º F.
4. Set the temperature using one of the following two methods:
a. Confirm preset temperature and press “SET” or “ENTER.” The oven will begin TruConvec™ Preheat immediately.
OR
b. Change the temperature by typing the desired temperature on the numeric keypad or using the up and down arrow keys.
Press “SET” or “ENTER” when finished. The oven will begin TruConvec™ Preheat immediately.
During TruConvec™ Preheat
The display will alternate between showing the set baking temperature and the actual preheat temperature every 5 seconds. When
the set baking temperature is reached, one long beep will sound and the display will show “TRUCONVEC.” Open oven door and
put food in oven.
To change set temperature during preheat stage:
Bake Modes
19
Press and Release
LTemperature increases by 5º F (or 2º C)
MTemperature decreases by 5º F (or 2º C)

Conventional broiling is most successful for cuts of meat one to two inches thick, and is also suitable for flat pieces of meat.
High Broil
With this setting, heat radiates at full power from both broil elements, located in the top of the oven cavity. The distance between
the foods and the broil elements determines broiling speed. For fast broiling, place food as close as two inches from the broil
element. Fast broiling is best for meats where "rare to medium" doneness is desired. Use this setting for broiling small and average
cuts of meat.
Medium Broil
With this setting, inner and outer broil elements pulse on and off to produce less heat for slow broiling. For slow broiling, allow
about four inches between the top surface of your food and the broil element. Slow broiling is best for chicken and ham. Use this
setting for broiling small and average cuts of meat.
Low Broil
This mode uses only a fraction of the oven’s available power to the inner broil element to produce delicate top-browning in only
three to four minutes on items such as meringue.
To Use Broil:
1. Arrange the oven rack in the desired position before turning the broiler on.
2. Place the food in the center of the cold broiler pan and grid supplied with your oven, and then place the broiler pan in the
oven.
3. Select “UPPER OVEN” or “LOWER OVEN.”
4. Set the Oven Function Selector to “BROIL.” Display will show “BROIL HIGH” and “ON” will flash. Medium and low displays
will show “CONV BROIL M” and “CONV BROIL L.”
5. Choose power level for BROIL:
a. For “HIGH BROIL,” press “SET.”
b. For “MEDIUM BROIL,” press down arrow key once. Display will change to MED, then press “SET.”
c. For “LOW BROIL,” press down arrow key twice. Display will change to LO, then press “SET.”
6. Close the door to the oven. With closed-door broiling, the broil element might cycle on and off if an extended broiling time is
required. A built-in smoke "eliminator" in the top of the oven will help reduce smoke and odors.
7. When cooking is complete, press the “OFF” button for the selected oven.
Convection Broil
Convection broiling has the advantage of broiling food slightly more quickly than conventional. Convection broiling of meats also
produces better results, especially for thick cuts. This is because meat sears on the outside and retains more juices and natural flavor
inside with less shrinkage.
To Use Convection Broil:
1. Arrange the oven rack in the desired position before turning the broiler on.
2. Place the food in the center of the cold broiler pan and grid supplied with your oven, and then place the broiler pan in the
oven.
3. Select “UPPER OVEN” or “LOWER OVEN.”
4. Set the Oven Function Selector to “CONV. BROIL.” Display will show “CONV BROIL H” and “ON” will flash. Medium and low
displays will show “CONV BROIL M” and “CONV BROIL L.”
5. Choose power level for CONVECTION BROIL:
a. For “HIGH CONVECTION BROIL,” press “SET.”
b. For “MEDIUM CONVECTION BROIL,” press down arrow key once. Display will change to MED, then press “SET.”
c. For “LOW CONVECTION BROIL,” press down arrow key twice.
d. Display will change to LO, then press “SET.”
6. Close the door to the oven. With closed-door broiling, the broil element might cycle on and off if an extended broiling time is
required. A built-in smoke "eliminator" in the top of the oven will help reduce smoke and odors.
7. When cooking is complete, press the “OFF” button for the selected oven.
Oven Off
The oven will continue operating until you press the “OFF” button for the oven you are using. For example, if you are cooking in the
“UPPER OVEN,” press the “OFF” button nearest this button on the control panel.
Broil Modes
20
