Viking Designer DFB450 User manual

Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
[phone]
For product information,
call 1 888 VIKING1 (845 4641)
or visit the Viking Web site at
vikingrange.com
F20622A EN (061110)
Professional & Designer Series
Dishwasher Door Panel
Viking Door Panel Installation

3
Door Panel Installation (Professional/Designer)
2
Installation
(Purchased Separately)
D
D
D
C
C
Plastic
Retainers
Dishwasher Door
Door Skin
D
1
step
CC
C
C
Dishwasher Door
Plastic
Retainers
Door Skin
2a
step
DD
D
D
D
Torx Driver
#8 1 3/4” long,
flat head,
Stainless Steel
Torx Screw
(4 supplied)
WARNING
The door skin must not obstruct the fan
exhaust vent.
Position door skin on front of dishwasher
door. Snap the plastic retainers on the door
skin into the holes (C) on dishwasher door.
While holding the door skin in position,
carefully open the dishwasher door Using
either the 4 flat head or 4 truss head screws
provided*, secure the door skin to the 4
holes (D) on the dishwasher door
2b
step
D
D
D
D
Carefully tighten all 4 screws and check to
ensure that the panel is square with the
dishwasher door Note: Verify the operation
of the door counterbalance springs after
installation of the door skin.
The unit comes with everything needed to make installing the door panel easy
What you will need:
OR
#8 1 3/4” long,
Stainless Steel
Truss Head Screw
(4 supplied)
*Note: Use the set of screws which matches
the screws already installed on the door
