Warnings
Your purchase of this pro uct attests to the importance you place upon
the quality an performance of the major appliances you use. With
minimal care, as outline in this gui e, this pro uct is esigne to
provi e you with years of epen able service. Please take the few
minutes necessary to learn the proper an efficient use an care of this
quality pro uct.
Some of the key features of this appliance inclu e:
• A broa range of baking an broiling mo es – up to 9 cooking
mo es in all - to make even your most challenging baking projects a
success.
• Split baking an broiling elements – which re uces preheating time
an provi es greater control an more even heating.
• A reversing fan which is 2 times larger than most on the market – this
allows you to cook foo s more thoroughly an evenly – even when
baking large quantities.
• Four convection mo es offering greater air circulation to shorten
cooking times an cook foo s more evenly.
• Dual broiling elements pro ucing intense ra iant heat for faster
broiling an a larger coverage area.
• Three broiling mo es inclu ing a new low-broil mo e for elicate
broiling an top-browning.
• A lighting system which provi es more light with less glare.
• A profile , hi en bake element for easier cleaning.
• Six a justable rack positions with the largest usable baking space
available in this class.
Your complete satisfaction is our ultimate goal. If you have any questions
or comments about this pro uct, please contact the ealer from whom
you purchase this pro uct – or contact our consumer support center at
1-888-845-4641.
We appreciate your choosing a Viking
Range, LLC pro uct an hope that you
will again select our pro ucts for your
other major appliance nee s. For more
information about the complete
selection of Viking pro ucts, contact
your ealer or go to vikingrange.com
Congratulations
WARNING
If the information in this manual is not followe exactly, a fire
or explosion may result causing property amage, personal
injury or eath.
WARNING
NEVER use this appliance as a space heater to heat or warm
the room. Doing so may result in carbon monoxi e poisoning
an overheating of the oven.
WARNING
Do not use commercial oven cleaners insi e the oven. Use of
these cleaners can pro uce hazar ous fumes or can amage
the porcelain finishes.
WARNING
NEVER cover any slots, holes or passages in the oven bottom
or cover an entire rack with materials such as aluminum foil.
Doing so blocks air flow through the oven an may cause
carbon monoxi e poisoning. Aluminum foil linings may also
trap heat, causing a fire hazar .
WARNING
To avoi sickness an foo waste when using automatic time
baking:
• Do not use foo s that will spoil while waiting for cooking to
start, such as ishes with milk or eggs, cream soups, custar s,
fish, pork, poultry, or foo s with stuffing.
• Any foo that has to wait for cooking to start shoul be very
col or frozen before it is place in the oven.
• Do not use foo s containing baking pow er or yeast when
automatic time baking. They will not rise properly.
• Do not allow foo to remain in the oven for more than two
hours after the en of the cooking cycle.
WARNING
To avoi sickness an foo waste, o not allow efroste foo
to remain in the oven for more than two hours.
32

5
Getting Starte
Important Safety Instructions ______________________ 5
Built-In Oven Features____________________________ 7
Pro uct Controls
Oven Control Panel ______________________________ 8
Setting the Clock ____________________________ 12
Oven Settings & Functions ________________________14
Clocks & Timers__________________________________19
Probe Function__________________________________ 25
Cooking Tips
Cooking with Your Oven _________________________ 26
Conventional/Convection Cooking________________ 27
Preheat________________________________________ 28
Conventional Baking Chart _______________________ 30
Convection Baking Chart _________________________ 31
Solving Baking Problems _________________________ 32
Roasting Instructions _____________________________ 33
Using Meat Probe _______________________________ 34
Conventional Roasting Chart _____________________ 35
Convection Roasting Chart _______________________ 36
Broiling Instructions _____________________________ 37
Broiling Chart ___________________________________ 39
Pro uct Care
Convection Dehy rate an Defrost ________________ 40
Cleaning an Maintenance _______________________ 41
Replacing Light _________________________________ 45
Trouble Shooting ________________________________ 46
Service Information ______________________________ 47
Warranty _______________________________________ 48
Rea before operating your oven.
• Use this appliance only for its inten e use as escribe in this
manual. Never use your appliance for warming or heating the room.
This is base on safety consi erations.
• Your unit shoul be installe by a qualifie technician. The appliance
must be installe an electrically groun e accor ing to local co es.
• Do not attempt to repair or replace any part of this appliance unless
specifically recommen e in this manual. All servicing shoul be
referre to a qualifie technician. Warranty service must be performe
by an authorize service agency.
• Chil ren shoul not be left alone in the kitchen while the oven is in
use. CAUTION: Do not store items of interest to chil ren over the
unit. Chil ren climbing to reach items coul be seriously injure .
• Do not hang on oor or allow chil ren to swing on oors.
•GREASE - Grease is flammable an shoul be han le carefully. Do
not use water on grease fires. Flaming grease can be extinguishe
with baking so a or, if available, multipurpose ry chemical or foam
type extinguisher. Let fat cool before attempting to han le it. Do not
allow grease to collect aroun the oven or in vents. Wipe up spillovers
imme iately.
• Loose-fitting or hanging garments shoul never be worn while using
the appliance. Do not rape towels or materials on oven oor
han les. These items coul ignite an cause burns.
• Use only ry pothol ers. Moist or amp pothol ers on hot surfaces
may result in burns from steam. Do not let pothol er touch hot
surface areas. Do not use a towel or other bulky cloth.
• Keep area clean an free from combustible materials, gasoline, an
other flammable liqui s. Never use your oven as a storage space.
Combustible items (paper, plastic, etc.) may ignite an metallic items
may become hot an cause burns.
•WWAARRNNIINNGG::French Door Mo els - DO NOT operate without control
knobs in proper place. With the knobs remove , the LED lights
surroun ing the knobs are visible an may cause permanent amage
to the eyes.
