OUTDOOR—REFRIGERATION
Portable (Freestanding)/Undercounter
24”W. Beverage Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 7 / 3 0 / 1 0
© 2 0 1 0 V R C — INFORMATION SUBJECT TO CHANGE
Both models include
• Available built-in or as portable model
• Spacious interior is capable of holding
up to 1/2 barrel—15.5 gal. (58.7 lit.)
• Includes easy-to-clean-and-use
stainless steel dispensing tower
• Tower tap handle is threaded so
custom handles can be installed
• VRBD portable model is easily moved
by four heavy-duty casters; two are
capable of being locked
• Packaged with unit – filled 5 lb. (2.3
kg) CO2 cylinder, keg coupler, air line
with clamps, and single-gauge
regulator
• Agency-certified for outdoor use
o Stainless steel exterior cabinet
surrounds unit and forms a water-
resistant seal
o Insulated electrical terminals, sealed
electrical contacts, and a water-
resistant thermostat provide optimal
performance in all weather elements
• Normal operating range is between
45 and 100 F (7.2 and 37.7 C)
• Factory-set for the ideal beverage
storage temperature – 38 F (3.3 C)
• Temperature-adjustable from
35 – 54 F (2 – 12 C)
VRBD1431T
24”W. Portab e Beverage
Dispenser
FINISH DETAILS FOR ALL MODELS
• Stainless Steel (SS)
VUBD1401T
24”W. Undercounter Beverage
Dispenser
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference (“R” for right or “L” for left)—(VRBD1431TRSS).

OUTDOOR—REFRIGERATION
Portable (Freestanding)/Undercounter
24”W. Beverage Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 7 / 3 0 / 1 0
© 2 0 1 0 V R C — INFORMATION SUBJECT TO CHANGE

Please see
Insta ation Notes &
Accessories
for important
information,
including lock and
cleaning supplies.
Dimensions & Speci ications
24-5/8”
(62.5cm)
22”
(55.9cm)
25-1/8”
(63.8cm)
24”
(61.0cm)
26-7/8”
(68.3cm)
41-25/32”
(106.2cm)
35-9/16”
(95.4cm)
VRBD1431T VUBD1401T
Overall width cabinet) 24” 61.0 cm) 23-7/8” 60.7 cm)
Across top lip 24-5/8” 62.5 cm) N/A
Overall height
From bottom of wheels to
Top of rail 41-25/32” 106.2 cm) N/A
Top of tower 53-11/16” 136.4 cm) N/A
Leveling legs fully extended N/A 34-3/4” 88.3 cm) max.
Overall depth from rear)
To front of handle 26-7/8” (68.3 cm)
With door fully open 47-1/4” (120.0 cm)
Approx. ship weight 177 lbs. 80.3 kg) 140 lbs. 63.5 kg)
VRBD1431T VUBD1401T
PRODUCT DIMENSIONS
VRBD1431T VUBD1401T
23-7/8”
(60.7cm)
22”
(55.9cm)
26-7/8”
(68.3cm)
24-3/8”
(61.9cm)
34”
(86.4cm)min.
to
34-3/4”
(88.3cm)max.
30-3/4”
(78.1cm)

24-3/8”
(61.9 cm)
90°
23-7/8”
(60.7 cm)
47-1/4”
(120.0 cm)
2-1/2”
(6.4 cm)
OUTDOOR—REFRIGERATION
Portable (Freestanding)/Undercounter
24”W. Beverage Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 7 / 3 0 / 1 0
© 2 0 1 0 V R C — INFORMATION SUBJECT TO CHANGE
Rear wall
Countertop Countertop
25”
(63.5 cm)
Standard
Depth
24”
(61.0 cm)
Standard
Cabinet
Depth
1-1/2”
3.8 cm)
1-11/32”
(3.4 cm)TYP 1-11/32”
(3.4 cm)TYP
12”
(30.5cm)
11”
(27.9 cm)
8”
(20.3cm)
5”
(12.7 cm)
1/2”
(1.3 cm)
4”
(10.2 cm)
1-1/2”
(3.8 cm)dia.
3/4”
(1.9 cm) dia.
Dimensions & Speci ications
DOOR SWING & CLEARANCE
Note: If removing the casters is necessary for installation, the unit should be raised off the ground using an
approved material (consult local building codes).

OUTDOOR—REFRIGERATION
Portable (Freestanding)/Undercounter
24”W. Beverage Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 7 / 3 0 / 1 0
© 2 0 1 0 V R C — INFORMATION SUBJECT TO CHANGE
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• 8’, 2-wire cord
with
grounded,
3-prong plug
attached to
product
• 115 VAC/60 Hz;
15-amp
dedicated circuit
• Max. amp
usage—3.3
PLUMBING
• Not applicable
Installation Requirements
24”
(61.0cm)
24”
(61.0 cm)*
24-3/4”
(62.9 cm)
35-9/16”
(90.3 cm)**
24”
(61.0cm)
24”
(61.0 cm)*
34-1/4”
(87.0 cm) min.
to
35”
(88.9 cm) max.
ACCESS REQUIREMENTS
VRBD1431T VUBD1401T
Cutout width lower) 24” (61.0 cm)*
Upper 24 3/4” 62.9 cm) N/A
Cutout height 35-9/16”(90.3 cm)** 34-1/4” 87.0 cm) min. to 35” 88.9 cm) max.
Cutout depth 24” (61.0 cm) min.
*24” (61.0 cm) width for cabinet only; if door is recessed between cabinets, cutout must be 24-1/4” (61.6 cm)
(for cabinet and door width clearance).
**35-9/16” (90.3 cm) is without casters mounted to unit; 39-3/4” (101.0 cm) is needed for height clearance with
casters.
VRBD1431T VUBD1401T
VRBD1431T
VUBD1401T

OUTDOOR—REFRIGERATION
Portable (Freestanding)/Undercounter
24”W. Beverage Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 7 / 3 0 / 1 0
© 2 0 1 0 V R C — INFORMATION SUBJECT TO CHANGE
Cleaning Kit
• For cleaning faucet and beverage lines
• Kit includes
o1 qt. (0.95 lit.) cleaning solution
o Tap/line cleaner
o Faucet wrench
o Faucet brush
Cleaning Solution Re ill
• Refills cleaning kit dispenser
• 4 oz. bottle
Faucet Lock
• Keyed entry
Compliance In ormation
WARRANTY SUMMARY*
• One-year full warranty—complete unit (w/in-home repairs)
• Five-year limited warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Ninety-day limited warranty—cosmetic parts such as glass, painted items, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
BDCK Beverage dispenser cleaning kit 1 (0.5)
Model Description Approx. ship wt. lbs. (kg)
BD4OZ Beverage dispenser cleaning solution .31 (0.1)
Model Description Approx. ship wt. lbs. (kg)
BDFLK Beverage dispenser faucet lock 0.5 (0.3)
