Viking VWH2410 User guide

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
All models include
• Heavy- uty construction
o Virtually seamless stainless steel
esign with no visible screws
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Recommen e for 24”W., 30”W. &
36”W. non-gri le/grill ranges,
rangetops, an cooktops
• 460 CFM interior-power ventilator
comes stan ar with pro uct
o Variable spee controls for custom
venting—separate on/off switch
allows you to leave ventilator at
favorite/most-use setting
• Two 50-watt halogen lights with
immer control
o Power switch an immer control
are separate, allowing you to leave
immer at favorite position
• Easy cleanup
o Design of low-profile filter system
means less interior hoo space to
be cleane
o Canopy interior is completely line
in stainless steel for increase
rigi ity, seamless appearance, an
easy cleaning
Pro essional 10”H. hoods include
• Commercial-type size, esign, an styling
• Allow replacement of most ol er
hoo s with minimal cabinet alteration
• Commercial-type baffle filter system
efficiently removes grease an heate
vapors from the air; especially
esigne for use with commercial-
type pro ucts
Designer 12”H. hoods include
• Professional-type size, esign, an
styling
• Delay function—can be set to shut off
from 10 – 30 minutes later (10 min.
increments)
• 12-hour timer built into controls
• Two ishwasher-safe stainless steel
mesh filters are easily remove for
quick cleaning (frame an mesh are
stainless steel)
Model numbers
PROFESSIONAL WALL HOODS, 10”H./21”D.
• VWH2410—24”W.
o Recommen e for use with 24”W.
non-gri le/grill ranges (for larger
equipment, use 18”H. hoo )
• VWH3010—30”W.
o Recommen e for use with 30”W.
ranges, 30”W. non-gri le/grill
rangetops, an 30”W. cooktops
• VWH3610—36”W.
o Recommen e for use with 36”W.
non-gri le/grill ranges, 36”W. non-
gri le/grill rangetops, an 36”W.
cooktops
DESIGNER CHIMNEY WALL HOODS,
12”H./24”D.
• DCH3042—30”W.
o Recommen e for use with 30”W.
ranges, 30”W. non-gri le/grill
rangetops, an 30”W. cooktops
• DCH3642—36”W.
o Recommen e for use with 36”W.
ranges, 36”W. non-gri le/grill
rangetops, an 36”W. cooktops
Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate
(CH), an Cobalt Blue (CB).
• Finish esignates front an si es.
• Accessory Rail Option—Front of hoo .
(Must be or ere factory installe )
o Stainless Steel/Chrome (CR)—
Stainless steel rail with chrome
supports/brackets an hooks
(inclu e ).
o Brass Trim Option (BR)—rail,
supports/brackets, an hooks
(inclu e ). Brass components have a
urable protective coating for
maintenance-free normal use.
supports/brackets an hooks
(inclu e ).
o Brass Trim Option (BR)—nameplate,
rail, supports/brackets, an hooks
(inclu e ). Brass components have a
urable protective coating for
maintenance-free normal use.
FINISH DETAILS DESIGNER MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Gol en Mist (GM),
Lemona e (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iri escent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
FINISH DETAILS FOR PROFESSIONAL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
• Finish esignates front an si es.
• Accessory Rail Option—Front of hoo .
(Must be or ere factory installe )
o Stainless Steel/Chrome (CR)—
Stainless steel rail with chrome
VWH Professio al
Wall Hood
DCH Desig er Chim ey
Wall Hood
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, followe by color co e (VWH2410SS). If or ering optional ecorative rail, specify co e at en
(VWH2410SSCR).

24”
(61.0 cm)
16”
(40.6 cm)
12”
(30.5cm)
2”
(5.1 cm)
12”
(30.5 cm)
A
2”
(5.1 cm)
21”
(53.3cm)
A
12”
(30.5cm)
10”
(25.4cm)
4”
(10.2cm)
3”
(7.6cm)
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
24”
(61.0 cm)
16”
(40.6 cm)
12”
(30.5cm)
18”
(45.7cm)
to
30”
(76.2cm)
12”
(30.5 cm)
A
2”
(5.1 cm)
✪
Please see
I stallatio Notes &
Accessories for
important information,
including conversion
kits, filters, duct
covers, backsplashes,
and warming shelf
panels.
21”
(53.3cm)
A
12”
(30.5cm)
10 ”
(25.4 cm)
12 ”
(30.5cm)
6”
(15.2 cm)
Dimensions & Speci ications
PRODUCT DIMENSIONS
VWH Professio al
Wall Hood
DCH Desig er Chim ey
Wall Hood
PROFESSIONAL DESIGNER
Model Hood Duct Cover Lights Filters Heat Approx.
Width (A) Height Width Depth Height Lamps Ship. wt.
VWH2410 23-7/8” (60.6 cm) 10” (25.4 cm) 23-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 48 lbs.
(60.6 cm) (21.7 kg)
VWH3010 29-7/8” (75.9 cm) 10” (25.4 cm) 29-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 56 lbs.
(75.9 cm) (25.2 kg)
VWH3610 35-7/8” (91.1 cm) 10” (25.4 cm) 35-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 60 lbs.
(91.1 cm) (27.0 kg)
DCH3042 29-7/8” (75.9 cm) 12” (30.5 cm) 16” (40.6 cm) 12” (30.5 cm) 18” (45.7 cm)— 22N/A 56 lbs.
30” (76.2 cm) (25.2 kg)
DCH3642 35-7/8” (91.1 cm) 12” (30.5 cm) 16” (40.6 cm) 12” (30.5 cm) 18” (45.7 cm)— 22N/A 60 lbs.
30” (76.2 cm) (27.0 kg)
PROFESSIONAL
W/RECIRCULATING KIT
DESIGNER
W/RECIRCULATING KIT

30”min.
(76.2cm)
to
33”max.
(83.8cm)
66”min.
(167.6cm)
to
69”max.
(175.3cm)
36”
(91.4 cm)
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
24”min.
(61.0cm)
to
27”max.*
(68.6cm)
60”min.
(152.4cm)
to
63”max.
(160.0cm)
36”
(91.4 cm)
Dimensions & Speci ications
CLEARANCE DIMENSIONS
PROFESSIONAL
DESIGNER
*Note: When in talling with a 24” high- helf, the
27” (68.6 cm) max. dimen ion mu t be u ed.

Proper i stallatio / ducti g is
extremely importa t to e sure
maximum performa ce. Use a qualified
a d trai ed i staller.
DUCTING
• 460 CFM interior (blower
inclu e )
• Check with a qualifie an
traine installer for local
co es an makeup air
requirements, if any.
• Max. uct run length—50’
(152.4 m)
o Duct run length is for
general reference only;
for longer uct runs,
increase uct size an
contact a qualifie an
traine installer.
o Straight runs an
gra ual turns are best; for
example, each 90° elbow
is equivalent to 5’ – 10’
(1.52 – 3.05 cm) of
straight run.
• 7” roun uct
o Never use flexible uct; it
creates back pressure/air
turbulence an greatly
re uces performance.
GAS
Not applicable
ELECTRICAL
• Har wire irect with two-wire
with groun
• 120 VAC/60 Hz
• Max. amp usage—5.6
PLUMBING
Not applicable
VWH Professio al
Wall Hood
DCH Desig er Chim ey
Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
UTILITY REQUIREMENTS
Installation Requirements
Model Interior Ventilator Kits Interior Duct Size Interior Max. Amps
VWH2410 460 CFM standard 7” (17.8 cm) 5.6
VWH3010 460 CFM standard 7” (17.8 cm) 5.6
VWH3610 460 CFM standard 7” (17.8 cm) 5.6
DCH3042 460 CFM standard 7” (17.8 cm) 5.6
DCH3642 460 CFM standard 7” (17.8 cm) 5.6
Note: All CFM are ba ed on te t with 0.1 tatic pre ure. Without applying tatic pre ure ( ome brand do not), CFM could be
greatly over tated.

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
Recirculating Hood Conversion Kits
• Stainless Steel (SS)
• Eliminates ucting
•Kit inclu es
o Two charcoal filters
o Installation har ware
o Top vent/grille
•Professional—4”H. x 12”D.
•Designer—2”H. x 12”D.
Charcoal Filters
• For use with VRK & DRK conversion kits
• Recommen e replacement every 6 – 12 months
Duct Covers
• Specify finish co e following accessory mo el number (for example, DCW24-SS)
o Professional mo els
•For VWH hoo s
•12”D.
•Exten s height of hoo by 12”—conceals uct
•Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate (CH), an Cobalt Blue (CB).
o Designer mo els
•For DCH hoo s
•For 8’ – 9’ ceilings
•Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate (CH), an Cobalt Blue (CB).
•Not nee e if using a DCCE1610
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
VRK24 Profess onal 24”W. convers on k t 10 (4.5)
VRK30 Profess onal 30”W. convers on k t 13 (5.9)
VRK36 Profess onal 36”W. convers on k t 16 (7.3)
DRK30 Des gner 30”W. convers on k t 15.4 (7)
DRK36 Des gner 36”W. convers on k t 15.4 (7)
Model Description Approx. ship wt. lbs. (kg)
CFV11 Profess onal hood f lter for 24”W. 1 (0.5)
CFV13 Profess onal hood f lter for 30”W. & 36”W. 2 (0.9)
CF-D12 Des gner hood f lter for 30”W. 2 (0.9)
CF-D14 Des gner hood f lter for 36”W. 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
DCW24 Profess onal 24”W. duct cover 9 (4.0)
DCW30 Profess onal 30”W. duct cover 10 (4.5)
DCW36 Profess onal 36”W. duct cover 11 (5.0)
DCC16 Des gner adjustable duct cover – for DCH 30” & 36” models 20 (9.0)

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
Duct Cover Extension
• For DCH hoo s
• 16”W. x 12”D. x 28 – 40”H.
•Exten s height of hoo by up to 12” (for 10’ ceilings)
• Replaces a justable uct cover supplie stan ar with hoo
• Specify finish co e following accessory mo el number (for example, DCCE1610-SS)
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR),
Burgun y (BU), Plum (PL), Chocolate (CH), an Cobalt Blue (CB).
Backsplashes
• Stainless Steel (SS)
• 30”H.
• For both VWH & DCH hoo s
• Backsplashes protect the wall space below hoo
• Create a continuous finish between cooking surface an hoo
• Low maintenance, easy to clean
• Hemme e ges with screw holes
• Kit inclu es backsplash an fastening screws
Warming Shel Panels
• Stainless Steel (SS)
• 12”D. X 12”H.
• For both VWH & DCH hoo s
• Shelf panels hol cookware an con iments
• Kit inclu es shelf (or shelves) an fastening screws
• Fol up/ own, heavy- uty warming shelves (non-removable), factory installe on stainless steel backsplash
• 5-7/8”W. X 10-1/8”D.
Compliance In ormation
WARRANTY SUMMARY*
• Three-year full warranty—complete pro uct (Professional an Designer)
• Five-year limite warranty—all ventilator motors (Professional an Designer)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items (Professional an Designer)
* For complete warranty see U e & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
DCCE1610 Des gner duct cover extens on 7 (15.4)
Model Description Approx. ship wt. lbs. (kg)
BKS24 24”W. backsplash 5 (2.3)
BKS30 30”W. backsplash 7 (3.2)
BKS36 36”W. backsplash 9 (4.1)
Model Description Approx. ship wt. lbs. (kg)
WGP24 24”W. warm ng shelf panel (one shelf) 6 (2.7)
WGP30 30”W. warm ng shelf panel (one shelf) 9 (4.1)
WGP36 36”W. warm ng shelf panel (two shelves) 12 (5.4)
