ViM Teal User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Vim
Walker “Teal”
Model # 022011-297

Use only accessories as recommended by the supplier.
ALWAYS use the safety locks once the walker height is correctly adjusted.
Check that all safety locks are engaged before placing child in the walker.
This walker should not be used by a child who can walk unaided.
This walker should not be used by a child weighing less than 7kgs and 65cm in height.
A child should discontinue using this walker when weighing more than 11kgs and 80cm in height.The walker is not
suitable for babies under 6 months of age.
Electrical cords, heaters, replaces and other hot objects, or any other objects or substances that may be dangerous,
should be guarded or put out of reach of a child using the walker.
Promptly replace any broken parts.
The walker should not be used (whether indoors or outdoors) on surfaces that have any obstructions that could cause
the walker to tip over.
The walker should not be carried with a child in it.
Adjust the height of the walker so that both feet of a child in the walker should be able to touch the ground.
Care must be taken while folding and unfolding the walker to prevent ngers being caught.
Read all instructions before assembly and use of the walker. Keep
instructions for future use.
BEFORE ASSEMBLINGTHIS WALKER, READ AND UNDERSTANDTHE INSTRUCTIONS.
Never leave a child unattended.
Always keep child in view while in walker.
Only use on at surfaces free of objects that could cause the walker to tip over.
To avoid burns, keep the child away from hot liquids, ranges, radiators, space heaters and
replaces etc...
Do not use the walker if it is damaged or broken.
Do not use until baby can sit up by itself.
To avoid serious injury or death,block stairs/steps securely before using walker.
Clean (friction components) regularly to maintain stopping performance.
Remove packaging from walker vicinity after it’s assembly.
KEEP INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY PRECAUTIONS
WARNING
WARNING - STAIR HAZARD
AVOID SERIOUS INJURY OR DEATH:BLOCK STAIRS/STEPS SECURELY BEFORE USING WALKER.

Battery Safety Information
In exceptional circumstances, batteries leak uids that can cause a chemical burn injury or ruin your product.To avoid
leakage:
• DO NOT mix old and new batteries or batteries of different types: alkaline, standard (carbon zinc) or rechargeable
(nickle-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use.
• ALWAYS remove exhausted batteries from the product.
• Dispose of batteries safely.
• DO NOT dispose of this product in a re.The batteries inside may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same equivalent type,as recommended.
• DO NOT charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removable,rechargeable batteries are used,they are only to be charged under adult supervision.
SAFETY PRECAUTIONS
Keep medication,strings,elastics and small toys out of reach from any position of the walker.
ALWAYS attach the toys tightly to the walker according to the instructions.Check frequently.
This walker should be used only for short periods of time eg:20mins

Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Vim Walker
Congratulations on your purchase of the Vim Walker
“Teal”
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
There are no accessories recommended for use with this Childcare Walker.
Main frame
Toy tray
x 1
x 1
x 1
x 2
x 2
Seat pad
Rear wheel
Front castor
x 6Friction blocks

ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Front Castors...
1Flip the unit over to access the base.1a.
To assemble Rear Wheels...
To assemble Friction Blocks...
2
1
1
Push the castors into the position (the hole
closest to the edge of the front of the walker),
until it is fully locked as shown in the image
opposite.
Insert the Rear Wheels into the frame by
aligning the slot and pressing in until it is fully
locked as shown in the image opposite.
Insert the Friction Blocks around the base into
the corresponding mountings.
Push into place until fully locked as shown in
the image opposite.
2a.
1a.
1a.
1b.

ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Seat Pad...
2
1
3
4
5
Place the Seat Pad and the Seat Support with
the warning label facing the rear.
Push the plastic buckles through the openings
in the Main Frame provided.
Flip the unit over to access the Main Frame.
Lift main frame up to pull extension.
From the underside, pull the buckles down and turn
sideways to cover the opening.
On the front of the seat, push the 3 black tabs into
the frame holes and slide to lock.
Unit should now resemble the image opposite.
2a.
2b.
1a.
1b.
3a.
4a.
5a.

ASSEMBLY / OPERATING INSTRUCTIONS
2Position the rear side of the Toy Tray into the
Main Frame.
Push the front side of the ToyTray down to click
into position.
2a.
2b.
To adjust Unit Height...
1
2
To adjust the height of the unit,ip the unit over.
Grasp the base to prevent it from collapsing.
Twist red knob clockwise.
Push red knob in while sliding unit to desired
height.
Release red knob and it will automatically lock into
position.
1a.
1b.
1c.
1d.
2a.
To assemble Toy Tray...
1Turn ToyTray over and unscrew the battery cover.
Insert 2 x AA batteries (sold separately).
Replace battery cover by screwing back into place.
1a.
1b.
1c.

The walker is now ready for use.
ASSEMBLY / OPERATING INSTRUCTIONS
3There are 3 height positions for this walker and
one fold position.
3a.
To adjust Unit Height continued...

HOW TO CARE FOR YOUR CHILDCARE WALKER
Cleaning
Maintenance
This product has been designed and developed with safety,comfort
and functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
To ensure the long-lasting use of your walker, do not use abrasive
cleaners.Always store product in a clean dry place.
Seat Pad: Remove from frame. Fasten buckles on seat restraint and
seat pad. Hand wash with cold water. No bleach.
Toy and snack tray: Wipe clean with a damp cloth and mild soap.
Air dry. Do not immerse in water.
Frame: Wipe the metal frame with soft, clean cloth and mild soap.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required. To maintain the safety of
your walker, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the walker, please contact
our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
