Vimco LUTRON SVQ-4GD-OCIT User manual

E n g l i s h
D e s c r i p t i o n
The SVQ-4GD-OCIT Hand-held Remote
Control provides control of Sivoia®or Sivoia
QEDTM window shades.The user can
individually select up to four groups of shades
by pressing a window group button (1-4). Each
group of shades can be controlled individually
or all groups (1-4) can be selected for control of
all groups simu l t a n e o u s l y.Each window group
(1-4) can consist of one or more shades. For
Sivoia QED Electronic Drive Units (EDUs),
please refer to the Sivoia QED Wiring and
Programming Guide or the Sivoia QED
Technical Reference Guide for the setup
procedure. For Sivoia Electronic Drive Units
(EDUs), please refer to the Sivoia Electronic
Drive Unit installation instructions or the Sivoia
Technical Reference Guide for the setup
procedure.
O p e r a t i o n
Point the Infrared Hand-held Remote Control at the
Sivoia or Sivoia QED IR receiver.
A. Select the window group(s). Press the
appropriate window group button, 1, 2, 3, 4 or All
(default is All window groups).
B. Select the shade(s). Press the appropriate shade
button, Front, Rear or Both (default is Both
shades).
C. Operate the shade(s). Select the desired function
by pressing the appropriate button, Open, Close,
Raise or Lower.
The Infrared Hand-held Remote Control is
safe for use around baths and spas.
DO NOT SUBMERGE IN WATER.
B a t t e r y Replacement
The SVQ-4GD-OCIT Infrared Hand-held
Remote Control uses 3 AAA batteries which
are pre-installed (see diagram). For best results
use Energizer® brand alkaline batteries. Do
not use NiCad batteries.
To replace batteries:
1. Remove the battery cover.
2. Replace with 3 size AAA alkaline
batteries as shown.
3. Replace the battery cover.
Press here to
Raise selected
shade(s).
Press here to
Lower selected
shade(s).
Press here to
select both Front
and Rear shades.
Press here to
select shade(s)
in all window
groups.
Install 3 AAA
Alkaline batteries
with terminals as
shown.
Press on arrow, slide and lift
off battery cover.
Press here to
Open selected
shade(s) to
upper limit.
Press here
to Close
selected
shade(s) to
lower limit.
Press here to
select Front or
Rear shade.
Press to select
shade(s) in
window group
1, 2, 3 or 4.
Operating Instructions
Please Leave for Occupant
S V Q - 4 G D - O C I T
Infrared Hand-held
Remote Control
N o t e : Pressing any button while the
shade is moving will stop the shade.
C
B
A
LUTRON
WINDOW
SHADE
OPEN
CLOSE
1 2 ALL
Both
1
3 4

V I M C O
11520 Sun Shade Lane
Ashland, VA 23005
Made and printed in the U. S. A . 10/04 P/N 040-209 Rev. B
Tr o u b l e s h o o t i n g
Electronic Drive Unit (EDU) power is OFF.
Dead, low, or no batteries in the Infrared
Hand-held Remote Control.
Infrared Hand-held Remote Control is
too far away from the IR receiver.
Batteries inserted incorrectly.
Infrared Hand-held
Remote Control has no
effect on the Electronic
Drive Unit (EDU).
Restore power.
Install new batteries.
Try moving closer to the
shade(s) you wish to
control.
If an IR receiver is
installed on the Electronic
Drive Unit (EDU), verify
that it is properly installed
and the IR receiver is not
obstructed (e.g. by
curtains, fascia, drapes).
Install batteries per
diagram on the first page.
C a u s e sP r o b l e m R e m e d i e s
Limited Wa r r a n t y
Lutron Shading Solutions byVIMCO offers an 8-year limited
warranty for our shading systems.Please contact customer
service or visit our website for a complete warranty statement.
Lutron Shading Solutions byVIMCO reserves the right to make
improvements or changes to these products without prior
notice.Although every attempt is made to ensure that this
information is accurate and up to date, please check with
Lutron Shading Solutions byVIMCO to confirm product
availability, the latest specifications, and suitability for your
application.
These products may be covered under one or more of the
following U.S. patents: 5 , 4 6 7 , 2 6 6 ; 5 , 6 7 1 , 3 8 7 ; 5 , 8 4 8 , 6 3 4 ;
6 , 1 0 0 , 6 5 9 ; DES 317,593; DES 344,068; DES 370,663; D E S
3 7 8 , 8 1 4 ; DES 387,736; DES 391,924; DES 396,448; D E S
4 3 7 , 5 8 5 ; and corresponding foreign patents.US and foreign
patents pending.
Lutron, the Sunburst logo, and Sivoia are registered
trademarks, and Sivoia QED and “Lutron controls your light”
are trademarks of Lutron Electronics Co., Inc.
Technical A s s i s t a n c e
Lutron Shading Solutions byVIMCO
11520 Sun Shade Lane
Ashland, Virginia 23005
www.lutron.com
24/7 service and support:
call: 1-800-446-1503
fax: [phone]
email: shadinginf[email protected]
©2004 LUTRON Electronics Co., Inc.
