VMM-T1 Shutter Driver Timer
14-0020
Version 2.00
2013
1.800.828.6972
*THIS IS A DISCONTINUED PRODUCT*

* THIS IS A DISCONTINUED PRODUCT*
For information regarding applicable intellectual property, please visit www.uniblitz.com/patents.
Information in this publication supersedes that in all previously published material. Due to our ongoing
development program, Vincent Associates reserves the right to discontinue or change specifications or
designs, at any time, without incurring any obligation.
Version 2.00
2013
Vincent Associates, a Division of VA, Inc., 803 Linden Ave., Rochester, NY 14625
Tel: [phone] Fax: [phone]
UNIBLITZ is a registered trademark of VA, Inc.
Printed in the U.S.A.

VMM-T1 User Manual 3
* THIS IS A DISCONTINUED PRODUCT*
Warranty
LIMITED PRODUCT WARRANTY: All Products manufactured by VINCENT ASSOCIATES®
(MANUFACTURER) are warranted to meet published specifications and to be free of defects in
materials and workmanship as defined in the specifications for 365 days - one year - (WARRANTY
PERIOD) from the date of original shipment of the product. DSS series shutters are additionally
warranted to achieve two million cycles within the WARRANTY PERIOD (as defined in the CYCLE
WARRANTY CRITERION). MANUFACTURER will, at its own option within the WARRANTY
PERIOD, repair or replace without charge any listed item discovered to be defective excepting
transportation charges. Burned out or otherwise damaged actuator coils are not covered under this
warranty. Any defective product returned to the MANUFACTURER must follow the RETURN
MATERIAL AUTHORIZATION PROCEDURE as defined below. This warranty does not extend to
cover damage resulting from alteration, misuse, negligence, abuse, normal wear and tear, or accident.
The MANUFACTURER will consider the return of unused equipment if returned within 30 days from
the original date of shipment, subject to a 20% restocking charge. This offer does not apply to used or
damaged equipment. This warranty extends only to the original purchase and is not available to any
third party, including any purchaser assemblies or other Products of which the goods may become
component equipment.
CYCLE WARRANTY CRITERION: One "cycle" is considered one open and one closure of the shutter.
DSS Shutter must be operated with the ED12DSS driver or equivalent H-Bridge type shutter driver
circuit at +10.7VDC across the actuator coil for the specified duration. DSS Shutter must be operated
within the defined environmental, electrical and mechanical specifications as listed on the device's data
sheet. After one year (WARRANTY PERIOD), the cycle warranty is null and void. If returned, the
device must be accompanied by a written statement indicating the approximate number of cycles
contained on the device, include all parameters to which the shutter was operated and follow the
RETURN MATERIAL AUTHORIZATION PROCEDURE as defined below.
RETURN MATERIAL AUTHORIZATION PROCEDURE: MANUFACTURER will only accept
returned Products from customers that have obtained an RMA (Return Material Authorization) number
from the MANUFACTURER. The customer must also include an itemized statement of defect(s). The
Product will then be evaluated per the MANUFACTURER'S standard repair guidelines. Any Product
which has been returned to the MANUFACTURER but which is found to meet the applicable
specifications and not defective in materials and workmanship shall be subject to the
MANUFACTURER's standard evaluation charge. The MANUFACTURER assumes no liability for
customer returned material.
LIMIT OF LIABILITY: The buyer's exclusive remedy and the limit of MANUFACTURER'S liability
for any loss whatsoever shall not exceed the purchase price paid by the buyer for the goods to which a
claim is made. MANUFACTURER does not give any implied warranties of merchantability, fitness for
a particular purpose, or of any other nature in connection with the sale of any Products.

VMM-T1 User Manual 4
* THIS IS A DISCONTINUED PRODUCT*
TABLE OF CONTENTS
WARRANTY ..................................................................................................................... 3
GENERAL SAFETY SUMMARY .................................................................................. 5
Injury Precautions ..................................................................................................... 5
Product Damage Precautions.................................................................................... 5
Safety Terms and Symbols ........................................................................................ 7
PREFACE .......................................................................................................................... 8
GETTING STARTED ...................................................................................................... 9
Features....................................................................................................................... 9
Introduction .............................................................................................................. 10
Start Up ..................................................................................................................... 10
Line Fuse Replacement............................................................................................ 11
Voltage Change ........................................................................................................ 12
Shutter Fuse Replacement....................................................................................... 12
Initial Operation and Testing.................................................................................. 13
OPERATOR CONTROLS............................................................................................. 15
VMM-T1 Front Panel Operator Controls ............................................................. 15
VMM-T1 Rear Panel Operator Controls .............................................................. 19
OPERATING BASICS ................................................................................................... 23
Function Switches .................................................................................................... 23
Gate Input ................................................................................................................. 23
RS-232C Operation.................................................................................................. 25
RS-232C Test Program............................................................................................ 27
Shutter Frequency of Operation............................................................................. 30
Trigger Cautions and Trouble Shooting Tips ....................................................... 30
Pulse Voltage Graphs............................................................................................... 31
Dimensions ................................................................................................................ 32
Maintenance ............................................................................................................. 32
General Care............................................................................................................. 33
Inspection and Cleaning .......................................................................................... 33
Inspection –Exterior ........................................................................................33
Cleaning Procedure –Exterior ......................................................................... 33
Inspection –Interior ......................................................................................... 33
Cleaning Procedure –Interior .......................................................................... 33
SPECIFICATIONS ......................................................................................................... 34
System Characteristics............................................................................................. 34
External Input Characteristics ...............................................................................35
External Output Characteristics ............................................................................ 37
General Characteristics ........................................................................................... 37
INDEX .............................................................................................................................. 41

VMM-T1 User Manual 5
* THIS IS A DISCONTINUED PRODUCT*
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to this product or any
products connected to it. To avoid potential hazards, use the product only as specified.
Only qualified personnel should perform service procedures.
Injury Precautions
Use proper Power Cord –To avoid fire hazard and risk of personal injury use only the power
cord supplied with this product.
Avoid Electric Overload –To avoid electrical shock or fire hazard do not apply a voltage to a
terminal that is outside the range specified for that terminal.
Avoid Electric Shock –To avoid injury or loss of life, do not connect or disconnect line cord
while it is connected to the line voltage.
Ground the Product –This product is grounded through the grounding conductor of the power
cord. To avoid electrical shock, the grounding connector must be connected to earth ground.
Before making connections to the input or output terminals of the product, ensure that the
product is properly grounded. DO NOT DEFEAT THE GROUND CONNECTION ON THE
SUPPLIED LINE CORD.
Access to On/Off Switch –Due to the location of the unit’s On/Off switch on the rear panel, do
not position the unit such that the On/Off switch is difficult to access and operate while installed
and in use.
Do Not Operate Without Covers –To avoid electric shock or fire hazard, do not operate this
product with case or panels removed.
Use Proper Fuse –To avoid fire hazard, use only the fuse type and rating specified for this
product.
Do Not operate in Wet/Damp Conditions –To avoid electric shock, do not operate this product
in wet or damp conditions.
Do Not Operate in an Explosive Atmosphere –To avoid injury or fire hazard, do not operate
this product in an explosive atmosphere.
Product Damage Precautions
Use Proper Power Source –Do not operate this product from a power source that applies more
than the voltage specified.

VMM-T1 User Manual 6
Provide Proper Ventilation –To prevent product overheating, provide proper ventilation.
Do Not Operate with Suspected Failures –If you suspect there is damage to this product, have
it inspected by qualified service personnel.

VMM-T1 User Manual 7
* THIS IS A DISCONTINUED PRODUCT*
Safety Terms and Symbols
These terms appear in this manual
CAUTION
Warning statements identify conditions or practices that
could result in injury or loss of life.
Caution statements identify conditions or practices that
could result in damage to this product or other property.
WARNING

VMM-T1 User Manual 8
* THIS IS A DISCONTINUED PRODUCT*
Preface
This Manual provides information for the VMM-T1 Shutter Driver/Timer. The manual contains the
following chapters:
Getting Started contains a brief product description, information needed to power on the driver
and a brief procedure to verify that it functions.
Operator Controls provide an outline of the panel control functions and locations at the front and
rear panels. This also includes the location and function of the input/output signals.
Operating Basics gives further details to the operational features of the controllers.
Specifications are described for all input/output levels as well as timing accuracy of the VMM-
T1 Shutter Driver/Timer including other pertinent details and information required for the RS-
232 interface.
Index contains a full index.
What follows is the complete operator’s manual for the UNIBLITZVMM-T1 Shutter
Driver/Timer.Please read this manual completely before operating your unit. Due to the
construction of this unit, we recommend that the unit be returned to the manufacturer for
repair, no user-serviceable parts inside.

VMM-T1 User Manual 9
* THIS IS A DISCONTINUED PRODUCT*
Getting Started
Features
The VMM-T1 Shutter Driver/Timer replaces the T132 controller. The VMM-T1 contains nearly all
of the features of the T132 plus some new features which enhance the unit’s capability in even more
demanding applications.
These new features include:
An addressable RS-232 input. Eight units can be daisy-chained together via the RS-232 input
connector (DB-9 female) and the user can select an address for each unit at the rear panel
through the use of the ADDRESS switch.
Switching capability on all BNC input jacks to provide either an active-high or active-low logic
trigger level.
An Auxiliary (AUX) output that is the DELAY timer output, on a three-pin terminal located on
the rear panel. This terminal also includes pins for +5VDC and Ground.
A GATE INPUT which allows the user to select a single or multiple trigger signals from a
stream of trigger signals.
An EXPOSURE PRESET (EXP PRESET) control which combines the functions of the
NORM/CONT switch of the previous Model T132 and an exposure counter. The user can pre-
select a number of exposures per trigger signal from 1 to 99. By selecting the EXP PRESET to
00 the unit will re-trigger continuously.
A user-configurable AC input module. This AC input module includes the AC power cord input
receptacle, power switch, dual 3AG, 0.5A time-lag (slo-blo) line fuses (For 115 VAC
operation), line voltage change-over fuse block, and line filter. Dual 3AG, 0.25A time-lag (slo-
blo) line fuses for 230 VAC operation are supplied.

VMM-T1 User Manual 10
* THIS IS A DISCONTINUED PRODUCT*
Introduction
The UNIBLITZ VMM-T1 is capable of controlling all shutter types in the UNIBLITZ product line. The
VMM-T1 incorporates two precise timers to control shutter exposure and delay intervals. Each timer
has a range from 0.1msec to 9999 seconds. Four-digit pushwheel switches provide exceptional
resolution for use in a multitude of shutter applications, ranging from holography to microscopy. The
VMM-T1 incorporates a state of the art shutter driver and relies on the user’s input signal to determine
exposure and frequency.
Another feature of the VMM-T1 is the PRE or POST exposure delay. The PRE/POST toggle switch
allows the user to actuate the shutter immediately upon receipt of a trigger signal or delay the
EXPOSURE for a predetermined period. The period of the DELAY interval is determined from the
front panel DELAY TIME SELECT. The DELAY signal is provided to the AUX output terminal
located at the rear panel. In addition to the PRE/POST DELAY, the VMM-T1 can re-trigger itself
continuously to provide low level chopper control. By selecting the EXP PRESET pushwheel switch to
“00”, the DELAY interval control acts as the recycle interval to determine the exposure frequency. The
unit will run continuously until reset. By selecting any value between 01 and 99 the shutter will trigger
for the number of exposures selected.
The VMM-T1 contains an addressable RS-232C input. By using the Model 910RSDC daisy-chain
cable, multiple controllers can be connected and controlled. Eight separate addresses are available
which allows up to eight units to be individually controlled by a single computer serial port.
The patented driver design of the VMM-T1 allows the controller to operate all shutter types in the
UNIBLITZ product line.
A Model 710C, 7-pin female to 7-pin male (3 meter length), shutter interconnect cable is also included
with each unit.
Start Up
After unpacking the unit, inspect for any obvious defects and that all manufacturer supplied materials
are present.
If a problem is found or a part (or parts) is missing, please contact Vincent Associates immediately for
problem resolution. Do not attempt to connect the unit if defects or damage are noted until Vincent
Associates has been contacted and the problem resolved.
After the initial inspection the unit is ready to use. To properly install and power on the VMM-T1,
please follow the procedure below.
1. Check for proper electrical connections. Please note the label covering the AC input module. It
is there as a reminder to re-configure the AC input module if the unit requires operation at
230VAC. The VMM-T1 is shipped with the proper fuses for 115 VAC operation installed (two
3AG, 0.5A time-lag (slo-blo)). See “Voltage Change” instructions elsewhere in this manual.
CAUTION
This label must be removed prior to inserting the power cord into the
AC input receptacle regardless of which AC voltage level is used.
Caution statements identify conditions or practices that could result in
damage to this product or other property.
