VisAccess AXS-100 User manual

AXS-100, AXS-100XT
Indoor Two-Door Proximity Access Control System Installation Guide
1. INTRODUCTION
The AXS-100/AXS-100XT is an electronic access control system
for controlling two doors.. Eight controllers can be networked
together to control a total of 16 doors. The controller relay
activates a lock or an electromagnetic strike (EMS), when a valid
proximity key card or tag is presented to the reader. For detailed
system description, refer to the AXS-100/AXS-100XT user’s
guide.
The use of a proximity (non-contact) key makes the installation of
the AXS-100/AXS-100XT system an attractive possibility in harsh
environments and in places with poor lighting conditions.
The proximity keys are totally sealed and wear resistant. The lock
reads the key ID, whenever the key is held close to the reader.
2. SPECIFICATIONS
AXS-100, AXS-100XT CONROLLER
Power Input: 14 - 16.5 VAC, 50VA
Max Current Consumption: 2.5A
Memory Capacity: 5,000 access card codes
Event Log: 1000 records per controller
Event Printout: RS-232 channel to printer or PC
System Programming: From controller #1. PC may be connected for
use as supplemental monitoring only.
Time Schedules: 64 separate schedules. Each key may be assigned
to 2 schedules.
Dry Contact Relay: Max 1A continuous
Doors Per Controller: Up to 2
Readers Per Controller: Up to 2 external + 1 internal (for programming)
Controllers Per Network: 8
Inputs (x 2 doors): Request-to-exit, door position, 2 programmable
inputs
Outputs: 2 lock relays, NO/NC dry contact, 30VDC 2A max
1 auxiliary relay, NO/NC dry contact, 30V DC 2A max
Output power for 2 locks: 10.3 - 12VDC, 400mA max
2 readers output: 70 mA max
Anti Passback (APB) Modes:
1. Local to each controller
2. Network APB
Indicators (LEDs): 5 (see figure 5)
Operating Temperatures: 0°C to 50°C (32°F to 122°F)
Dimensions (LxWxD): 315x262x74mm (12-3/8x10-5/16x10-15/16 in)
Weight: AXS-100: 3.8 kg (8.4 lb)
AXS-100XT: 3 kg (6.6 lb)
Color: White
Compliance with standards: Complies with Part 15 of the FCC
Rules and RSS-210 of Industry and Science Canada.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
READERS
Operating Temperatures: -20°C to 50°C (-4°F to 122°F)
Color: Dark brown
Minimum distance between readers: 60 cm (2 ft)
RDR-4 PROXIMITY READER
Weight: 121.5 g (4.3 oz)
Indicators: Tricolor LED (Green, Red, Amber)
Cable (to AXS-100/AXS-100XT control unit) maximum length:
22 AWG up to 60 m (200 ft)
18 AWG up to 100 m (320 ft)
Dimensions (LxWxD): 116 x 70 x 16.8 mm (4-1/2 x 2-3/4 x 5/8 in)
RDK-4 PROXIMITY READER WITH KEYPAD (optional, not evaluated by UL)
Weight: 170 g (6 oz)
Power input: 12-16V DC from the AXS-100 / AXS-100XT
Buttons: 12 (numeric keypad)
Dimensions (LxWxD): 122x82x31mm (4-13/16 x 3-1/2 x 1-1/4 in)
CARDS (*)
CRD-1SL ISO STANDARD SLOTTED AND NUMBERED
PROXIMITY CARD
Card ID: One of a trillion different combinations
Dimensions (LxWxD): 85x54x1mm (3 5/16 x 2 1/8 x 1/32 in)
Weight: 2.5 g (0.1 oz)
Color: White
CRD-25SL: Package of twenty-five CRD-1SL slotted proximity
cards with print
CRD-25: Package of twenty-five CRD-1 non-slotted proximity cards
(optional).
CRD-25S: Slotted proximity card
TAGS (*)
TAG-1: One proximity tag
* Both cards and tags contain 40-bit code and using
Manchester encoding
.
3. MOUNTING
3.1 Metal Box Mounting
The system must be installed indoors, within the protected
premise, in accordance with the National Electrical Code
(NFPA70) and the local authorities having jurisdiction.
For AXS-100XT use only the supplied plug-in transformer:
PRI 120V/60Hz @ 0.59A, SEC 16.5VAC / 50VA
BE116250CAA0040, Basler Electric, Class 2 NOT WET,
Do not connect (the transformer) to a power receptacle that is
controlled by a switch.
Use the box as a template
to mark on the mounting
surface, drill 4 holes on the
mounting surface and
fasten the box to the
mounting surface by using
4 screws.
Transformer (AXS-100 only).
In AXS-100XT there is no
transformer.
Figure 1 - Mounting
Page 1 of 5
DE6280-9

3.2 Metal Box Door Lock Assembly
The door lock assembly of the system metal box is presented in
figure 2 (the lock and the brass nut are supplied in the system
accessories box).
Metal box door
Metal box
Align lock with the pre-
punched hole and
insert it into the hole.
Place the brass nut on the
lock, tighten by hand and
finally tighten with
spanner (7/8”). Verify that
you can lock the door (key
rotation of 90 degrees).
2
1
Figure 2 - Metal Cabinet Door Lock Assembly
3.3 Backup Battery Installation (Optional)
Locate the optional backup battery (12V, 7.0Ah, Lead-acid
battery) in the lower left side of the system enclosure (see fig. 3).
3.4 Tamper Switch Installation & Wiring
It is necessary to protect the controller against tampering. A UL
Listed Tamper switch must be installed (see fig. 4) and wired to
AUXIN1 and COM of lock #3 of each controller.
Backup
battery
(optional)
Fig. 3 - Backup Battery
Fig. 4 - Tamper Switch Installation
4. WIRING
1 2 3 4 5 .
6 7 8 9
13 12 11 10 9 8 7 6 5 4 3 2 1
25 24 23 22 21 20 19 18 17 16 15 14
EPROM
battery
-
+
holder
F
3
IN1
GND
IN2
Battery fuse 3.15A
Replace fuses (x2) with UL
Listed fuses.
WARNING: To reduce risk of
fire, replace only with the same
type and rate of fuse.
AC fuse 3.15A
PWR
GND
TX
RX
AC
AC
RTE
GND
DPOS
PWR
GND
NO
NC
COM
READER 2
RELAY 2
DOOR 2
Wire Jumper
(remove for dry contact)
READER 1
RELAY 1
DIP Switches
PWR
GND
TX
RX
BAT+
BAT-
RTE
GND
DPOS
PWR
GND
NO
NC
COM
12V, 7.0Ah
Lead-acid battery
(optional)
PWR
GND
N.O.
N.C.
COM
PWR
GND
N.O.
N.C.
COM
Lock connection configurations
Dry contact connection Internal 12V power supply
Normally open (EMS)
Common
Normally closed (maglock)
Twisted pair to A,B
of other AXS-100
Common gnd to
other AXS-100
must be connected!
Alarm relay
to Siren or
Bell
Door 1 Door 2
Symmetrical connectors
AXS-100, AXS-100XT Wiring Diagram
Prox. Reader
Red
Black
Green
White
RTE input
D.POS input
DB-9F
To computer
COM1 or COM2
DB-25M
To serial printer
F
2
DOOR 1
IN1
GND
IN2
NOTE:
Replace battery with PANASONIC.
Type: CR2032, 3V “COIN” battery.
Use of another battery may present
a risk of fire or explosion.
See user manuals for safety instructions.
NOTE:
All power outputs are power limited
except from the battery outputs.
NOTE:
For battery
replacement
see
installation
instructions.
Note:
Optional for future use
LD2 (red LED)
Power ON
LD3 (green LED)
ext. batt. charged
LD1 (green LED)
output relay
activated
LD4 (red LED) alarm
relay activated
LD5 (green
LED) output
relay activated
Plug-in transformer for AXS-100XT
only: PEI 120V/60Hz @ 0.59A,
SEC. 16.5VAC / 50VA.
BE116250CAA0040, Basler
Electric. Class 2 NOT WET,
UL Listed 49HO.
Figure 5 - Wiring
Page 2 of 5
DE6280-9

Each two-door controller connects to two proximity readers and two
electric locks. It can also be connected to two inputs per door:
•Request-to-Exit (RTE) button or PIR near the door in the
secure area will allow a person to open the door from within for
leaving.
•Door Position micro switch installed between the door and door
frame will provide the controller with door status indications.
A. Proximity Readers
Each reader is connected to the controller via a 4-wire cable. The
standard cable is color coded as follows:
•RED Power +
•BLACK Power –
•GREEN TX
•WHITE RX
Use an extension cable with the same colors to avoid connection
errors.
Note: Do not install the RDR-4 on a metal surface or a metal
door frame, since this decreases the read range significantly. If
you have to install the reader on a metal surface, use a spacer
so that the reader will be at least 1 cm (3/8 in.) away from the
metal. You may use RDR-BACK which is an optionally
available spacer made specifically for this purpose
Note: When installing more than one RDR-4, the distance
between them should be at least 60 cm (2 ft.), to ensure proper
operation.
B. Inputs
Both inputs (RTE and Door Position) can be connected to either
normally open or normally closed switches. The default is a
normally open RTE and normally closed Door Position (when
door is shut).
C. Locks
The system can operate both electromagnetic strikes - EMS
(normally open) and electromagnetic locks - EML (normally
closed). Each connector block has a COMMON as well as N.O.
and N.C. connectors.
If the controller is configured for one door, connect it to the
EMS/EML, at the left side of the controller.
All types of connections are detailed in the next drawing.
NC
COM
PWR
NO
GND
Power+
Jumper
NC
COM
PWR
NO
GND
Jumper
NC
COM
PWR
NO
GND
------
------
NC
COM
PWR
NO
GND
------
------
12VDC
Normally Open
12VDC
Normally Closed
Non-12VDC or
high current
devices - Dry
contact N.O.
Non-12VDC or
high current
devices - Dry
contact N.C.
Power-----
Power+-----
Power+-----
Power-----
The lock sections include also 12V power connectors. These
connectors provide power to the lock with a current limit of 400mA
for each lock. The controller supplies power from a backup battery if
available when the AC power is down. Electromagnetic locks which
constantly draw a large current, should use the dry contact ONLY
without connecting the internal power supply. The same holds true
for any other device, which does NOT operate at 12VDC.
If you notice problems with a controller operating an EMS that
uses an internal power supply, connect the diode supplied
between + and – of the EMS output (see Panel Wiring Diagram).
D. Controller Network
Up to eight system controllers can be connected together in a
network. The controller provides two 3-connector blocks for daisy
chaining controllers in a bus configuration.
The controllers’ addresses need not be in the physical order
of connection.
Connect system units with a single twisted pair cable.
Connect terminal A to A and B to B, GND to GND, this way up to
eight controllers.
E. RS-232 Channel
The RS-232 channel is used for connecting the AXS-100 / AXS-
100XT to either a computer or a serial printer.
The RXD and TXD notation refers to the PC’s RXD and TXD
The use of PC and printer were not evaluated by UL. The PC can
be used as supplemental monitoring and/or for programming and
downloading only.
F. Power Connection
Connect the AC power cable to the power connector on the top
right side of the board.
G. Backup Battery Connection
Connect backup battery to black and red wires on the left side.
5. SPECIAL INSTALLER FUNCTIONS
The AXS-100 / AXS-100XT system has a few special functions,
which should not be accessible to the regular user. These
functions allow the installer to initialize the system to a known
state before starting to set up user data. The functions are:
•Reset passwords
•Clear key database
•Load setup defaults
•Setting address & operation mode
5.1 Reset Passwords
If password #1 is not known, it is impossible to change some
system parameters. The following steps reset the passwords:
When the idle screen is displayed, repeatedly press the arrow up
(↑) key until a long beep is heard. As a result, Password #1 has
been reset to “2975”. Password #2 is cleared.
5.2 Clear Keys Database
It is recommended to clear the key database before starting to
program user keys for the first time.
This operation should be performed from controller #1.
F
ollow these steps to clear the keys database:
•Enter password #1 and log in into the system.
•In EDIT KEYS menu select DELETE KEY screen.
•Enter 9999 as the key number and press Enter.
•The controller will prompt you with a “Y/N”. Press “1” followed
by another Enter to confirm.
•The keys database will be erased. The operation will be
logged and printed as “DB ERASED”.
5.3 Setup Defaults
To return the system to its default setup, perform the actions that
are shown in figure 6 (text in rectangles represents displayed text).
(16 times)
Enter ENTER PASSWORD
XXXX Enter SETUP EDIT KEYS
Enter DATE TYPE
DATE/TIME
EDIT REGISTER
LOCAL SETUP
Enter APB RESET HOUR
99:00
SETUP FLAGS 1
- - - - - - 7 8
Enter PC PASSWORD
65535
LOAD SETUP
DEFAULTS (Y/N)N
Enter (long beep is heard
to indicate success)
LOAD SETUP
DEFAULTS (Y/N)Y
1
Figure 6 - Returning to Setup Defaults
Page 3 of 5
DE6280-8

5.4 Setting Address & Operation Mode
Setting the controller address and operation mode, in AXS-100 /
AXS-100XT version 2.06 and above, is performed by using the
controller keypad (not by using DIP switches) - see figure 7.
Enter controller No. (e.g. 1)
ENTER PASSWORD
XXXX
The display will be:
SETUP
EDIT KEYS
CONTROLLER
1
Enter EnterEnter
Enter
Select operation mode (e.g. 7)
MODE
7
Note: Mode list is attached
to the AXS-100 door.
Enter Enter Esc Esc
4 times
EDIT REGISTERS
LOCAL SETUP
Figure 7 - Controller Address and Operation Mode Setting
6. MAINTENANCE
6.1 Replacement Parts List
1. Lithium battery 3V, cat. No. 0-9913-0.
2. CRD-1, cat. No. 0-9923-2, or 0-9923-8.
3. Proximity reader RDR-4, cat. No. 3-6304-0
6.2 Periodic Check
Once a month, the system must be checked by presenting a
tag/card to the reader and verifying that the proper door is opened.
6.3 Lithium Battery Handling/Disposal
Caution: Battery may explode if mistreated, do not recharge,
disassemble or dispose in fire.
Replace battery with PANASONIC Coin battery type CR2032, 3V
only. Use of another battery may present a risk of fire or explosion.
Dispose any used Lithium battery only in an approved disposal
container.
This device complies with the essential requirements and provisions of Directive 1999/5/EC of the European Parliament and of the Council of 9
March 1999 on radio and telecommunications terminal equipment.
WARNING! Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
W
ARRANTY
Visonic Technologies Ltd. and/or its subsidiaries and its affiliates ("the Manufacturer")
warrants its products hereinafter referred to as "the Product" or "Products" to be in
conformance with its own plans and specifications and to be free of defects in materials
and workmanship under normal use and service for a period of twelve months from the
date of shipment by the Manufacturer. The Manufacturer's obligations shall be limited
within the warranty period, at its option, to repair or replace the product or any part
thereof. The Manufacturer shall not be responsible for dismantling and/or reinstallation
charges. To exercise the warranty the product must be returned to the Manufacturer
freight prepaid and insured.
This warranty does not apply in the following cases: improper installation, misuse,
failure to follow installation and operating instructions, alteration, abuse, accident or
tampering, and repair by anyone other than the Manufacturer.
This warranty is exclusive and expressly in lieu of all other warranties, obligations or
liabilities, whether written, oral, express or implied, including any warranty of
merchantability or fitness for a particular purpose, or otherwise. In no case shall the
Manufacturer be liable to anyone for any consequential or incidental damages for breach
of this warranty or any other warranties whatsoever, as aforesaid.
This warranty shall not be modified, varied or extended, and the Manufacturer does not
authorize any person to act on its behalf in the modification, variation or extension of this
warranty. This warranty shall apply to the Product only. All products, accessories or
attachments of others used in conjunction with the Product, including batteries, shall be
covered solely by their own warranty, if any. The Manufacturer shall not be liable for any
damage or loss whatsoever, whether directly, indirectly, incidentally, consequentially or
otherwise, caused by the malfunction of the Product due to products, accessories, or
attachments of others, including batteries, used in conjunction with the Products.
The Manufacturer does not represent that its Product may not be compromised and/or
circumvented, or that the Product will prevent any death, personal and/or bodily injury
and/or damage to property resulting from burglary, robbery, fire or otherwise, or that the
Product will in all cases provide adequate warning or protection. User understands that a
properly installed and maintained alarm may only reduce the risk of events such as
burglary, robbery, and fire without warning, but it is not insurance or a guarantee that
such will not occur or that there will be no death, personal damage and/or damage to
property as a result.
The Manufacturer shall have no liability for any death, personal and/or bodily injury
and/or damage to property or other loss whether direct, indirect, incidental,
consequential or otherwise, based on a claim that the Product failed to function.
However, if the Manufacturer is held liable, whether directly or indirectly, for any loss or
damage arising under this limited warranty or otherwise, regardless of cause or origin, the
Manufacturer's maximum liability shall not in any case exceed the purchase price of the
Product, which shall be fixed as liquidated damages and not as a penalty, and shall be
the complete and exclusive remedy against the Manufacturer.
Warning: The user should follow the installation and operation instructions and among
other things test the Product and the whole system at least once a week. For various
reasons, including, but not limited to, changes in environmental conditions, electric or
electronic disruptions and tampering, the Product may not perform as expected. The user
is advised to take all necessary precautions for his /her safety and the protection of
his/her property.
6/91
VT World Headquarters * Tel Aviv, Israel * Tel: + 972 3 768-1400 * [email protected]
VT Americas * Bloomfield, CT (USA) * Tel: [phone] * [email protected]
VT United Kingdom * Beckenham Kent BR3 90BF, U.K. * Tel: + 44-870-730-0840 * vtuk_support@ visonictech.com
Visonic GmbH * D-40215 Düsseldorf, Germany * Tel: + 49-0-211-600-696-0 * support@ visonictech.de
Additional information may be found at: www.visonictech.com
Page 4 of 5
DE6280-9 Oct. 09
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from which you orignially purchased it.
If you are discarding this product and not returning it for repair then you must ensure that it is returned as identified by your
supplier. This product is not to be thrown away with everyday waste.
Directive 2002/96/EC Waste Electrical and Electronic Equipment.

DE6280 5
