Vision Audio Visual TECHCONNECT TC3 HDMITP2 User manual

1
TC3_HDMITP2_manual_en
TECHCONNECT TC3 HDMITP2
OWNERS MANUAL
www.visionaudiovisual.com/techconnect/tc3_hdmitp2

2
TC3_HDMITP2_manual_en
DECLARATION OF CONFORMITY
Where applicable Vision products are certified and comply with all known local regulations to a
„CB Certification‟ standard. Vision commits to ensure all products are fully compliant with all
applicable certification standards for sale in the EU and other participating countries.
The product described in this owner manual is in compliance with RoHS (EU directive
2002/95/EC), and WEEE (EU directive 2002/96/EC) standards. This product should be returned
to the place of purchase at the end of its useful life for recycling.
WARNINGS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product‟s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
All products are designed and imported into the EU by „Vision‟ who is wholly owned by „Azlan
Logistics Ltd.‟, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park,
Clifton Moor, York, YO30 4GH. WEEE Registration: GD0046SY
DECLARATION OF ORIGIN
All Vision products are made in the People‟s Republic of China (PRC).

3
TC3_HDMITP2_manual_en
PLACE OF INSTALLATION
Avoid installing this product under the following conditions:
• Moist or humid places
• Places exposed to direct sunlight or close to heating equipment
• Extremely cold locations
• Places subject to excessive vibration or dust
• Poorly ventilated places
Do not expose this product to dripping or splashing. DO NOT PLACE OBJECTS FILLED WITH
LIQUIDS ON OR NEAR THIS PRODUCT!
WARNING SIGNS
If you detect an abnormal smell or smoke, turn this product off immediately and unplug the
power cord. Contact your reseller or Vision.
PACKAGING
Save all packing material. It is essential for shipping in the event the unit ever needs repair.
NOTE: If original packaging is not used to return the unit to the service centre, damage in
transit will not be covered by warranty.

4
TC3_HDMITP2_manual_en
FRONT AND REAR PANELS
Transmitter –clips into Techconnect faceplate
Receiver –positioned at display device
HDMI Output (via RJ45)
HDMI Input
5V 2A DC
Power Input
HDMI Output
(directly into display device)
5V 0.8A DC Power Input
Via Micro USB
Backup; not usually required.
HDMI Input (via RJ45)
EQ Button
EDID Reset
Button
Link LED
Shows that Tx is
connected to Rx

5
TC3_HDMITP2_manual_en
AUTO EQ
This product does not compress, so if image is poor or there is no image press LENGTH button
on receiver. Press button repeatedly until image is clear.
1. PRESS ONCE OR TWICE –the device will automatically select the best gain level
2. PRESS MORE THAN TWICE –the device will switch into manual selection mode. There are
10 steps. When you reach the 10th step it will switch back to auto mode.
If the display is a TV disable any “auto image” functions. They can make the image look
unclear.
CONNECTION
POWER
Power is passed from Tx to Rx. If cable is very long or poor quality it may be necessary to apply
power at receiver as well. It requires 0.8A minimum so any mobile phone charger –normally 2A
- can be used.
LINK
If LINK light is flashing or not on there is no connection between Tx and Rx. Try another CAT6
cable.
EDID (EXTENDED DISPLAY IDENTIFICATION DATA)
This enables source device to „ask‟ display device what resolution it is, and output that
resolution.
On connection an EDID conversation takes place automatically. If display is changed it may be
necessary to request the new display details. The RESET button is for this purpose.

6
TC3_HDMITP2_manual_en
SPECIFICATIONS
TRANSMITTER DIMENSIONS: 76 x 21 x 50 mm / 2.9" x 0.8" x 2.0" (length x width x height)
RECEIVER DIMENSIONS: 71 x 26 x 16 mm / 2.8" x 1.0" x 0.6" (length x width x height)
PACKAGED DIMENSIONS: 150 x 117 x 77 mm / 5.9" x 4.6" x 3.0"
PRODUCT WEIGHT: 25 g / 0.06 lb per set
PACKAGED WEIGHT: 0.27 kg / 0.6 lb per set
RECOMMENDED MAXIMUM CABLE LENGTH:
CAT5e: 1280 x 1024: 50m / 1600 x 1200: 40m / 1920 x 1080: 30m
CAT6/7: 1280 x 1024: 60m / 1600 x 1200: 55m / 1920 x 1080 (@ 60Hz): 50m
CONSTRUCTION MATERIAL: Plastic
COLOUR: White
TECHNICAL DETAILS
Video Amplifier Bandwidth: 6.75Gbps (2.25Gbps/TDMS Channel)
Input Video Signal: 0.5-1.5 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
Maximum Video Format Supported: 1920×1080 / 1080P
Output Video: HDMI 1.3, 3D @ 60Hz
Operating Temperature Range: -15 to +70°C
Operating Humidity Range: 5 to 90 % RH (no condensation)
Maximum operation current: 500mA
POWER SUPPLY: 100-240v 50/60Hz AC 5 volt / 2 amp
Transformer integrated into plug. Includes interchangeable plugs: UK/EU/US/AU. DC tail length:
1.8 m / 5.9 ft. Transformer dimensions: 66 x 43 x 32mm / 2.6" x 1.7" x 1.3"
ACCESSORIES INCLUDED:
-
WARRANTY: Lifetime return-to-base
2 years onsite (UK only)
COMPLIANCES: RoHS, WEEE, CE/ EMC, and FCC compliant.
ORDER PART CODE: TC3 HDMITP2 [SAP:4274132]
SPARE POWER SUPPLY UNIT (PSU):
TC2 P5V2A [SAP:2940996]

7
TC3_HDMITP2_manual_en
LIFETIME RETURN-TO-BASE WARRANTY
This product comes with a lifetime return to base warranty. If you have a problem you are
required to provide a DETAILED DESCRIPTION of the fault.
Some Vision products are very technical and require troubleshooting all elements of the
installation as it may not be the Vision product at fault. Because of this the manufacturer may
refuse to replace the item if an adequate description is not provided.
This warranty applies only to the original purchaser and is not transferable.
This warranty protects you against the following:
oFailure of any components, including the power supply.
oDamage when the product is first removed from its packaging if reported within
24 hours of purchase.
If the product is DOA (dead on arrival), you have 21 days from purchase date to notify the
national distributor via your AV reseller.
The original purchaser is responsible for shipment of the product to the Vision‟s appointed
service centre.
The liability of Vision is limited to the cost of replacement of the faulty unit under warranty
except for death or injury (EU85/374/EEC).
If the product is end of line (EOL) the Vision will provide a credit instead of replacement.
This warranty does not protect this product against faults caused by abuse, misuse,
incorrect installation, unstable or faulty power input, or modification.
Vision aims to send a replacement item within 5 working days however this may not always be
possible, in which case it will be sent as soon as practicably possible. UK End users and resellers
can request support at http://www.visionaudiovisual.com/support
2-YEAR ONSITE WARRANTY (UK ONLY)
The manufacturer provides an onsite warranty for the first two years taken from date of sale.
This service can be requested at the url above and is provided at the manufacturer‟s discretion.
This service is only provided for products which are difficult for an end user to get at
and replace.
The manufacturer will not provide the onsite service if
oThe reseller or end user has been abusive
oThe user has is taking unfair advantage of this service
The manufacturer will pre-qualify the visit to ensure the fault relates to the Vision
product.
The engineer visits are timed to ensure you are onsite and the room is accessible. A revisit
WILL NOT be provided if access to the room is not provided at the arranged time. Engineers will
wait 15 minutes only.

8
TC3_HDMITP2_manual_en
LEGAL DISCLAIMER: Because we are committed to improving our products, the details above
may change without prior warning. This User Manual is published without warranty and any
improvements or changes to the User Manual necessitated by typographical errors, inaccuracies
of current information, or improvements to programs and/or equipment, may be made at any
time and without notice. Such changes will be incorporated into new editions of the User
Manual.
