Installation Instructions & User’s Manual
CG2 LED MINI CANNON KIT

VISION X
About The CG2 LED Mini Cannon Kit:
FEATURES
1. Lightweight hybrid housing.
2. 7W High Output Cree LEDs.
3. Integrated electronic thermal management (ETM).
CG2 MINI CANNON KIT SERIES SPECIFICATIONS
1. Warranty : Extended
2. Amp Draw : 3.5A @ 12V DC
3. Input Voltage : 9-32V DC
4. Beam Patterns : 10°, Snap-On Filters Available
5. LED Lifespan : 50,000 Hours
PREPARATION
1. We recommend completely reading instructions before
installing.
2. Consult your local state regulatory agency regarding the
use of LED lighting.
3. The placement of LED lighting should not restrict airow to
the radiator, or block head lamps, turn signals, or parking
lights.
MAINTENANCE
1. All Vision X models have been designed for
maintenance free use. In the case an LED lamp or other
part replacement is needed please contact your authorized
service center.

3.7” CG2 LED MINI CANNON
WARNINGS
As with many other high-tech products, this VISION X LED
requires a bit of attention before you can use it. Please read
the accompanying information carefully rst.
1. Don’t stare directly into the light or shine directly into the
eyes of another person as this may cause temporary loss
of vision.
2. Never disassemble the products, as all parts must be
factory serviced to insure proper operation.
3. Don’t interchange the parts inside this light with other
products.
4. The LED light is to be mounted on the vehicle only in a
vertical, bottom mounting, or in a suspended position.
5. After turning on the light, the body might be hot enough
to warrant a burn risk. Be careful when you touch the
body after turning on the light for a long period of time.
6. Use the supplied wire harness for electrical installation.
7. The LED light must not adversely a󰀨ect the performance
of low beam, high beam, engine cooling or the driver’s
view.
123
4
Qty: 2 Qty: 1
Qty: 2
CG2 Mini
Cannon
Two Light
Harness
Hex Head Bolt
[M8]
Allen Key
[5mm]
LIGHT WIRING
PART (A1)
Qty: 2
PART (B1)
5
Qty: 2
Washer
[M8]
PART (W1)
6
Qty: 2
Nylock Nut
[M8]
PART (N1)

VISION X
WIRING INSTALLATION INSTRUCTION
1. Find a suitable place to mount Relays Part (R1 & R2)
leaving enough room for Power & Ground wires Part
(W1,W2,W3,W4) to reach the battery & the Deutsch
connectors Part (C1 & C2) to reach the lights. Mount
Relays.
2. Run Power wires (W1, W3) & Ground wires (W2 , W4)
to the battery. Connect the Power wires (W1 , W3) to the
Positive (+) battery terminal and connect the Ground wire
(W2 , W4) to the Negative (-) Battery Terminal.
3. Run the Deutsch Connector wiring, (C1 & C2) to each light
and plug in. It doesn’t matter which Deutsch Connector
plugs into which light.
4. Disconnect the Switch Part (S1) at the white Plug Part (P1)
and run the wire through the vehicles re wall to desired
mounting location inside the Cab, [using a factory rubber
or plastic grommet is suggested].
5. Drill the hole to the required size for the Switch (S1) and
mount to desired position.
6. Reconnect the Switch (S1) to the Harness.
7. Test Light.
MANUFACTURER RECOMMENDATION
For those unfamiliar with electrical wiring on vehicles, Vision X
recommends that all LED Lighting products are professionally
installed.
DIMMING FUNCTION
Your light is capable of dimming through the Prime Drive wire
on the light’s plug. To achieve this requires our authorized
accessories, the XIL-PDIMMER, or XIL-PDIMMERBUTTON.
Do Not connect the Prime Drive wire without authorized
accessories as this will damage the electronics.

3.7” CG2 LED MINI CANNON
(R1)
(S1) (W3)
(W1)
(W2)
*To Light *To Light
(C2)(C1)
(R2)
(P1) (W4)
WIRING DIAGRAM:
(-)
(-)
(+)
(+)
TIP: For complete application guide see website
COMPONENTS KEY
Part (R1 & R2) Relay
Part (W1 & W3) Power Wire for Relay Coil
a. 9-32V DC Positive (+) Input Wire
Part (W2 & W4) Ground Wire for Relay Coil
a. 9-32V DC Negative (-) Input Wire
Part (C1 & C2) Deutsch Connectors for Lights
a. Attached to 9-32V DC Positive (+) Power Wires
Part (S1) Switch
Part (P1) Switch Plug
DIMMER WIRE:
Do Not connect
without authorized
accessories.

VISION X
ADDITIONAL INFORMATION
If needed, additional information and related products, as well
as a digital copy of these instructions, can be located online at
www.visionxusa.com
WARNING: Bolts, Nuts, and Washers are Stainless Steel.
DO NOT USE Pneumatic or Electric Tools to Tighten and
Loosen. The Hardware Will Permanently Lock Together.
LIGHT ANGLE ADJUSTMENT
1. Use the 5mm Allen Key Part (A1) to loosen the Allen Head
Bolts Part (B2) on each light.
2. Adjust the light until you have your desired angle.
3. Tighten the Allen Head Bolts to hold the desired position.
MOUNTING INSTALLATION INSTRUCTION
1. Determine where the light/lights will be placed.
2. Place mounting bracket with light to desired location. Using
a marker or pick tool, mark the center point of the bolt hole
on the mounting surface.
3. Set the light aside. Drill out a large enough hole to t the
[M8] bolt Part (B1).
4. Remove the mounting bracket from the lights by
unscrewing the (2) 5mm Allen Head Bolt Part (B2).
5. Line up the mounting bracket with the hole you just drilled,
slide the [M8] Bolt (B1) through both.
6. On the other side of mounting surface slide the [M8]
Washer Part (W1) and [M8] Nylock Nut Part (N1) onto the
[M8] Bolt (B1). Tighten Nut & Bolt to desired tightness.
7. Reassemble the light back on the mounting bracket by
reapplying the 5mm Allen Head Bolts (B2). Tighten to
desired tightness.

3.7” CG2 LED MINI CANNON
(B2)
(Mounting Bracket)
ADJUSTMENT KEY
Part (B2) 5mm Locking Bolt
TIP: For complete application guide see website
MOUNTING KEY
Part (B1) Bolt [M8]
(Mounting Bracket)
Part (W1) Washer
Part (N1) Nut [M8]
(B1)
(W1)
(N1)
(Mounting Bracket)
