UNITE SERIES MODULAR LIGHT BAR
INSTALLATION
INSTRUCTIONS
VISIONXLIGHTING.COM

2VISIONXLIGHTING.COM
INSTALLATION INSTRUCTIONS
NOTES:
• Depending on length, your Unite Modular Light Bar Kit will include a
di󰀨erent amount of pieces labeled with “Qty: *”.
1
Qty: *
Unite
Module
LIGHT
INCLUDED WITH UNITE MODULE
PREPARATION
1. We recommend completely reading instructions before installing.
2. Consult your state regulatory agency regarding the use of LED lighting.
3. The placement of LED lighting should not restrict airow to the radiator,
block head lamps, turn signals, or parking lights.
4. Ensure you are using proper gauge wire and connectors when wiring
without Vision X Wiring Harness.
2
Qty: *
“H” Power
Bridge
POWER
3Module
Hardware
HARDWARE
WARNING: Bolts, Nuts, and Washers are Stainless Steel.
DO NOT USE pneumatic or electric tools to tighten and loosen.
The hardware will permanently seize together.
Qty: *

3
LIGHTING EVOLVED
UNITE MODULAR BAR
10
Qty: 2
Washers
HARDWARE
1
Qty: 1
Quick
Connect Rail
LIGHT RAIL
5
Qty: 1
Pigtail
WIRING
INCLUDED WITH UNITE QUICK CONNECT RAIL
9
Qty: 2
Nylock Nut
HARDWARE
12
Qty: 1
2.5mm Allen
Key
TOOL
11
Qty: 1
5mm Allen
Key
TOOL
2
Qty: 2
Wing Mounts
MOUNTING
3
Qty: 1
Power
Plug/Cap
POWER
7
Qty: 4
Wing Mount
Bolts
HARDWARE
8
Qty: 2
Mounting
Bolts
HARDWARE
6
Qty: 2
Set
Screws
HARDWARE
4
Qty: 1
Deutsch Power
Connector
POWER

4VISIONXLIGHTING.COM
INSTALLATION INSTRUCTIONS
UNITE MODULE ASSEMBLY INSTRUCTIONS
1. Included with each module is a set of allen head bolts and locking
T-Nuts. Insert the two allen head bolts from the back and loosely thread
on the locking T-Nuts with the rounded end facing towards the module.
Leave about a 2-3 threads gap. (Figure 1.)
2. With all the modules prepped, decide which module will be on the left
end (passenger side) of the bar. For this module, you will need to install
the power end plug/cap. To install, press the plug/cap rmly into the
module and secure using one of the set screws and the 2.5mm Allen
Key. (Figure 2.)
3. Next, insert the “H” Power Bridge into the right side of the rst module.
The Bridge is not polarity specic, so there is no wrong way to insert it.
(Figure 3.)
FIG. 1
FIG. 3
FIG. 2

5
LIGHTING EVOLVED
UNITE MODULAR BAR
4. Prep the Quick Connect Rail by installing the left (passenger side) wing
mount using 2 wing mount bolts and a 13mm socket wrench. (Figure 4.)
5. Slide the rst module onto the quick connect rail by aligning the T-Nuts
on the back of the module. NOTE: If you nd it di󰀩cult to slide on, try
loosening the T-Nuts a couple more threads. (Figure 5.)
6. With the rst module on, continue to slide on the following modules
making sure to add the “H” Power Bridge to each module before sliding it
on. (Figure 6.) NOTE: Firmly press each module into the next to ensure
the “H” Power Bridge is making solid contact.
7. For the last module, you will need to install the Deutsch Power Connector
on the right side of the module before sliding it onto the mounting rail. To
install, rmly push the connector into the module and secure using one of
the set screws and the 2.5mm Allen Key. (Figure 7.)
FIG. 4
FIG. 6
FIG. 5
FIG. 7

6VISIONXLIGHTING.COM
INSTALLATION INSTRUCTIONS
8. Slide on the last module with Deutsch Power Connector attached.
(Figure 8.)
9. Install the wing mount using 2 Wing Mount Bolts and a 13mm socket
wrench. (Figure 9.)
6. Adjust all the modules so that they are centered on the bar. Once
centered, secure all the modules to the rail by tightening the bolts on the
back of each module using the 5mm Allen Key. (Figure 10.)
FIG. 8
FIG. 10
FIG. 9

7
LIGHTING EVOLVED
UNITE MODULAR BAR
UNITE MODULE MULTI-CIRCUIT INSTRUCTIONS
THIS FEATURE IS ONLY AVAILABLE WITH THE PURCHASE OF
ADDITIONAL UNITE POWER ACCESSORIES.
• To utilize the Multi-Circuit power accessories, add the Deutsch Power
Connectors and Power Plugs/Caps to the specic sections of the Unite
Bar you choose using the provided set screws and 2.5mm Allen Key.
NOTE: As shown in the example below, the red “|” indicates where the
“H” Power Bridges are not used.
• EXAMPLE: The Deutsch Power Connectors Labeled “1” would be wired
together utilizing a dual harness to a switch so that both ends of the
Unite Bar would be turned On/O󰀨 simultaneously.
The Deutsch Power Connectors Labeled “2” would be wired with a
separate switch so that it may be power independently from the outer
section of the bar.
1 2 1

8VISIONXLIGHTING.COM
INSTALLATION INSTRUCTIONS
MOUNTING INSTALLATION INSTRUCTIONS
1. Determine where the light/lights will be placed.
2. Place mounting bracket with light to desired location. Using a marker or
pick tool, mark the center point of the bolt hole on the mounting surface.
3. Set the light aside. Drill out a large enough hole to t the mounting bolts.
4. Using a 13mm socket wrench, secure the light to the mounting surface
with the provided Mounting Bolts followed by a Washer and Nylock Nut.
WIRING INSTALLATION INSTRUCTIONS
1. Find a suitable place to mount Relay Part (R1) leaving enough room
for Power & Ground wires Part (W1 & W2) to reach the battery & the
Deutsch connector Part (C1) to reach the Light. Mount Relay.
2. Run Power wire (W1) & Ground wire (W2) to the battery. Connect the
Power wire (W1) to the Positive (+) battery terminal and connect the
Ground wire (W2) to the Negative (-) battery terminal.
3. Run the Deutsch connector wire (C1) to the light and plug in.
4. Disconnect the Switch Part (S1) at the white Plug Part (P1) and run the
wire through the vehicles re wall to desired mounting location inside the
Cab [using a factory rubber or plastic grommet is suggested].
5. Drill the hole to the required size for the Switch (S1) and mount to
desired position.
6. Reconnect the Switch (S1) to the Harness.
7. Test Light.
MULTI-CIRCUIT WIRING NOTES:
• For Multi-Circuit Wiring, you would follow the same steps as above, but
utilize multiple harnesses depending on the amount of circuits used.

9
LIGHTING EVOLVED
UNITE MODULAR BAR
(R1)
(S1)
(P1)
(W1)
(W2)
*To Light
(C1)
SINGLE CIRCUIT WIRING DIAGRAM:
FOR USE WITH VISION X WIRING HARNESS
(+)
(-)
COMPONENTS KEY
• Part (R1): Relay
• Part (W1): Power Wire for Relay Coil
a. 9-32V DC Positive (+) Input Wire
• Part (W2): Ground Wire for Relay Coil
a. 9-32V DC Negative (-) Input Wire
• Parts (C1): Deutsch Connector for Light
a. Attached to 9-32V DC Positive (+) Power Wires
• Part (S1): Switch
• Part (P1): Switch Plug

10 VISIONXLIGHTING.COM
INSTALLATION INSTRUCTIONS
UNITE LIGHT ANGLE ADJUSTMENT INSTRUCTIONS
1. To adjust the beam angle, loosen the 4 Wing Mount Bolts on the sides of
the light bar using a 13mm socket wrench. (Figure 11.)
2. Adjust the light bar to desired angle and re-tighten the 4 Wing Mount
Bolts.
FIG. 11
MAINTENANCE
All Vision X models have been designed for maintenance free use. In the
case that an LED lamp or other part replacement is needed, please contact
your authorized service center.

11
LIGHTING EVOLVED
UNITE MODULAR BAR

VISIONXLIGHTING.COM | [email protected]
LEARN MORE | CONTACT US
