Vision 2GIG-Z-BRG1-433 User manual

Federal Communications Commission Statement
This equipment has been followed to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try and
correct the interferene by one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undersired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every wireless lighting module is free from physical defects in
material and workmanship under normal use for one year from the date of purchase. If the
product proves defective during this one-year warranty period, Vision will replace it free of
charge. Vision does not issue any refunds. This warranty is extended to the original end
user purchase only and is not transferable. This warranty does not apply to : (1) damage
to units caused by accident, dropping or abuse in handling, or any negligent use; (2) units
which have been subject to unauthorized repair, taken apart, or otherwise modified; (3)
units not used in accordance with instruction; (4) damages exceeding the cost of the
product; (5) transit damage, initial installation costs, removal cost, or reinstallation cost.
For information on addional devices, plesae visit us at www.visionsecurity.com.tw
-3-
Operation Manual
2GIG-Z-BRG1-433
Z-Wave Bridge – 433MHz
2GIG-Z-BRG1-
433
V0
1011218

Introduction
Thanks for choosing the Vision’s CT Clamp Bridge of the home automation device. This
module is a Z-Wave
TM
enabled device (interoperable, two-way RF mesh networking
technology) and is fully compatible with any Z-Wave
TM
enabled network. Every main
powered Z-Wave
TM
enabled device acts as a signal repeater and multiple devices result in
more possible transmission routes which helps eliminate “RF dead-sport”.
Z-Wave
TM
enabled devices displaying the Z-Wave
TM
logo can also be used with it
regardless of the manufacturer, and ours can also be used in other manufacturer’s
Z-Wave
TM
enabled networks. This module will receive the most update energy usage
from CT Clamp, and send to the controller by its signal. This module will also send
dimmer signal to the appliance that attached to this module by receiving Z-Wave
TM
signal
from controller or manually switch. With special design, this module won’t interfere the
other power outlet when plug into the AC outlet. This module also acts as repeater
(supporting FLiRS).
Product Description and Specification
* For indoor use *
Specification:
Package Content:
Protocol: Z-Wave
TM
(ZM3102N)
Frequency Range:
908.42MHz (2GIG-Z-BRG1-433)
Operating Range: Up to 100 feet line of sight
Operating Temp.: -15 °C ~ 60 °C (5 °F ~140 °F )
Operating Voltage: 120V~, 15A, 60Hz
For 2GIG-Z-BRG1-433 only
Max. Load: 300W for Resistive Load
-1-
1pc 2GIG-Z-BRG1-433
(CT Clamp Bridge)
1pc User Manual
Z-Wave
™
™™
™ Command Class:
COMMAND_CLASS_SWITCH_MULTILEVEL
(Mapping COMMAND_CLASS_BASIC)
COMMAND_CLASS_SWITCH_ALL
COMMAND_CLASS_METER_V2
COMMAND_CLASS_PROTECTION
COMMAND_CLASS_VERSION
COMMAND_CLASS_MANUFACTURER_SPECIFIC
Operation
If you are installing the entire Z-Wave
TM
system for the first time, please refer to the
installation guide of Z-Wave
TM
Interface Controller before installing 2GIG-Z-BRG1-433.
1. Learning CT Clamp: Press program button before power on and green LED will flash
3 times, release the button till the green LED stay on. Switch on the CT Clamp. LED
shall go off after learning.
2. For “Inclusion” in (adding to) a network: Put the Z-Wave
TM
Interface Controller into
“inclusion” mode, and following its instruction to add the 2GIG-Z-BRG1-433 into your
controller. To get in the “Inclusion” mode, the distance between 2GIG-Z-BRG1-433
and controller is suggested to be in one meter. User can press program switch
once to be included.
For “Exclusion” from (removing from) a network: Set up the Z-Wave
TM
Interface
Controller into “exclusion” mode, and following its instruction to delete the
2GIG-Z-BRG1-433 from your controller. Press program button to be excluded.
3. 2GIG-Z-BRG1-433 will store the latest energy usage (W & kWh) from CT Clamp,
and send to controller if the controller is asking for information.
4. Manually turn the connected lighting On/Off by your controller or pressing the
program button. This is toggle switch. If the light is Off, pressing the button turns
the light On and vice versa. User can also adjust the brightness level of the
connected lighting by your controller or pressing and holding the program button.
Release the button when the desired level is attained. This is toggle function. The
lighting will dim until the minimum level is attained or the button is released. The
next time the button is pressed and held, the level will increase until the maximum
level is attained or the button is released.
5. Protection Function: User can use the Protection command class to disable the
Program Switch.
(1) Protection State=0x00 (Unprotected, Program Switch acts as normal);
(2) Protection State=0x01 (Protection by sequence, user can manual turn the
appliance on/off by press Program Switch 3 times, instead of 1 time);
(3) Protection State=0x02 (No operation possible, temporarily turn the Program
Switch function off).
-2-

Industry Canada Notice
Operation is subject to the following two conditions: (1) this device may
not cause interference and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.

