1 Hardware Information
Security devices may be available in a portable, 1U, 2U, 4U, or 6U chassis. They are
applicable to various networking environments, including networks of governments,
enterprises, and carriers.
Hardware appearances and interface types and numbers may vary slightly with lots
and models.
The working/expansion ports of security devices can be a combination of four
electrical, eight electrical, four optical, eight optical, or two 10G ports or empty.
1.1 Hardware Appearance
This section describes the appearance of each hardware device in alphabetical order of device
name acronyms.
1.1.1 ADS
This section describes the front panels and rear panels of NSFOCUS Anti-DDoS System
(ADS).
1.1.1.1 ADS NX3-800E (1U)
Figure 1-1 and Figure 1-2 show the front panel and rear panel of ADS NX3-800E
respectively.

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
5
V1.0R01F00 (Restricted)
Front Panel
Figure 1-1 Front panel of ADS NX3-800E
①RST: reset LED
②STA: status LED
③PWR: power LED
④SYS: system LED
⑤RJ45 console port
⑥M: management port
⑦USB port
⑧Working ports: electrical
Rear Panel
Figure 1-2 Rear panel of ADS NX3-800E
①Ground connector
②Power switch
③Power connector
－
1.1.1.2 ADS NX3-HD1000 (1U)
Figure 1-3 and Figure 1-4 show the front panel and rear panel of ADS NX3-HD1000
respectively.

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
6
V1.0R01F00 (Restricted)
Front Panel
Figure 1-3 Front panel of ADS NX3-HD1000
①PWR: power LED
②SYS: system LED
③HDD: hard disk LED
④Bypass LED of working ports 5 and 6
⑤Bypass LED of working ports 3 and 4
⑥Bypass LED of working ports 1 and 2
⑦RJ45 console port
⑧USB port
⑨M: management port
⑩H: management port
⑪Working ports: electrical
⑫Working ports: optical
⑬Working/Expansion ports
－
Rear Panel
Figure 1-4 Rear panel of ADS NX3-HD1000
①Ground connector
②Heat dissipation holes
③Power switch
④Power connector
⑤Mute button: As the device supports two
power supplies, if only one power supply is
configured, a sound alert will be generated.
To clear the alert, press the mute button.
－

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
7
V1.0R01F00 (Restricted)
1.1.1.3 ADS NX3-HD2500/NX5-HD4500 (1U)
ADS NX3-HD2500 and NX5-HD4500 use the same hardware platform and have similar
appearances and hardware parameters. The following uses ADS NX3-HD2500 as an example
to show the appearance of the two models.
Figure 1-5 and Figure 1-6 show the front panel and rear panel of ADS NX3-HD2500
respectively.
Front Panel
Figure 1-5 Front panel of ADS NX3-HD2500
①PWR: power LED
②SYS: system LED
③STA: status LED
④RJ45 console port
⑤USB port
⑥M: management port
⑦Standby management port
⑧Working/Expansion ports
Rear Panel
Figure 1-6 Rear panel of ADS NX3-HD2500
①Ground connector
②Heat dissipation holes
③Power switch
④Power connectors

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
8
V1.0R01F00 (Restricted)
1.1.1.4 ADS NX3-2000E/NX5-4000E/6000E (2U)
ADS NX3-2000E, NX5-4000E, and ADS NX5-6000E use the same hardware platform, and
have similar appearances and hardware parameters. The following uses ADS NX5-4000E as
an example to show the appearance of these models.
Figure 1-7 and Figure 1-8 show the front panel and rear panel of ADS NX5-4000E
respectively.
Front Panel
Figure 1-7 Front panel of ADS NX5-4000E
①M: management port
②H1: management port
③RJ45 console port
④USB ports
⑤RST: reset LED
⑥PWR: power LED
⑦STA: status LED
⑧SYS: system LED
⑨Working ports: electrical
⑩Working ports: optical
Rear Panel
Figure 1-8 Rear panel of ADS NX5-4000E

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
9
V1.0R01F00 (Restricted)
①Ground connector
②Power switch
③Mute button: As the device supports two
power supplies, if only one power supply is
configured, a sound alert will be generated.
To clear the alert, press the mute button.
④Power connectors
1.1.1.5 ADS NX5-HD6500 (2U)
Figure 1-9 and Figure 1-10 show the front panel and rear panel of ADS NX5-HD6500
respectively.
Front Panel
Figure 1-9 Front panel of ADS NX5-HD6500
①PWR: power LED
②SYS: system LED
③STA: status LED
④RJ45 console port
⑤USB ports
⑥M: management port
⑦H1: management port
⑧Working/Expansion ports
⑨Monitor
⑩HDD caddy

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
10
V1.0R01F00 (Restricted)
Rear Panel
Figure 1-10 Rear panel of ADS NX5-HD6500
①Ground connector
②Heat dissipation holes
③Power switch
④Power supplies
⑤Mute button: As the device supports two
power supplies, if only one power supply is
configured, a sound alert will be generated.
To clear the alert, press the mute button.
－
1.1.1.6 ADS NX5-HD8500 (2U)
Figure 1-11 and Figure 1-12 show the front panel and rear panel of ADS NX5-8500
respectively.
Front Panel
Figure 1-11 Front panel of ADS NX5-8500
①PWR: power LED
②SYS: system LED
③STA: status LED
④RJ45 console port

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
11
V1.0R01F00 (Restricted)
⑤USB ports
⑥IPMI port
⑦M: management port
⑧H1: management port
⑨Working/Expansion ports
⑩Empty slot (not for use)
⑪HDD caddy
－
Rear Panel
Figure 1-12 Rear panel of ADS NX5-8500
①Ground connector
②Heat dissipation holes
③Power switch
④Power connectors
1.1.1.7 ADS NX5-8000 (2U)
Figure 1-13 and Figure 1-14 show the front panel and rear panel of ADS NX5-8000
respectively.

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
12
V1.0R01F00 (Restricted)
Front Panel
Figure 1-13 Front panel of ADS NX5-8000
①Power switch
②RST: reset LED
③PWR: power LED
④STA: status LED
⑤SYS: system LED
⑥IPMI port
⑦M: management port
⑧H1: management port
⑨RJ45 console port
⑩USB port
⑪Working ports: optical
⑫Working ports: optical
⑬Working/Expansion ports
⑭Working/Expansion ports
Rear Panel
Figure 1-14 Rear panel of ADS NX5-8000
①Power connector
②Power supply
③Power switch 1
④Power switch 2
⑤Heat dissipation holes
⑥Ground connector

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
13
V1.0R01F00 (Restricted)
1.1.1.8 ADS NX5-HFA2000 (1U)
Figure 1-15 and Figure 1-16 show the front panel and rear panel of ADS NX5-HFA2000
respectively.
Front Panel
Figure 1-15 Front panel of ADS NX5-HFA2000
①PWR: power LED
②SYS: system LED
③STA: status LED
④Bypass LED of scanning ports
⑤Bypass LED of scanning ports
⑥Bypass LED of scanning ports
⑦RJ45 console port
⑧USB port
⑨M: management port
⑩Working ports: electrical
⑪Working ports: optical
⑫Working/Expansion ports
Rear Panel
Figure 1-16 Rear panel of ADS NX5-HFA2000
①Ground connector
②Heat dissipation holes
③Power switch
④Power connectors
1.1.1.9 ADS NX5-10000 (6U)
The front panel of ADS NX5-10000 supports three types of switch boards. The types and
numbers of ports that can be configured on these panels are different:

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
14
V1.0R01F00 (Restricted)
⚫HTCA-SFPP16TX4
Supports configuration of up to four 1000M electrical ports and 16 10G optical ports.
⚫HTCA-CXP2SFPP20
Supports configuration of up to two 100G optical ports and 20 10G optical ports.
⚫HTCA-QSFP28x6QSFP4SFPP16
Supports configuration of up to six 100G optical ports, four 40G optical ports, and 16
10G optical ports.
The following sections describe the front panel and rear panel of ADS NX5-10000 that
comes with each of these switch boards.
Front Panel with the HTCA-SFPP16TX4 Interface
Figure 1-17 shows the front panel of ADS NX5-10000 with the HTCA-SFPP16TX4 interface.
Figure 1-17 Front panel with the HTCA-SFPP16TX4 interface
①Working ports: electrical
②Working ports: 10G optical
③Working ports: 10G optical
④IPMI port
⑤RJ45 console port
⑥USB port
⑦PWR: power LED
⑧MGR: status LED
⑨STAT: status LED
⑩ACTN: IPMI status LED

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
15
V1.0R01F00 (Restricted)
Front Panel with the HTCA-CXP2SFPP20 Interface
Figure 1-18 shows the front panel of ADS NX5-10000 with the HTCA-CXP2SFPP20
interface.
Figure 1-18 Front panel with the HTCA-CXP2SFPP20 interface
①Working ports: 100G optical
②Working ports: 10G optical
③Working ports: 10G optical
④IPMI port
⑤RJ45 console port
⑥USB port
⑦PWR: power LED
⑧MGR: status LED
⑨STAT: status LED
⑩ACTN: IPMI status LED
Front Panel with the HTCA-QSFP28x6QSFP4SFPP16 Interface
Figure 1-19 shows the front panel of ADS NX5-10000 with the HTCA-
QSFP28x6QSFP4SFPP16 interface.

NSFOCUS Security Products Hardware Installation Guide
Copyright © NSFOCUS
16
V1.0R01F00 (Restricted)
Figure 1-19 Front panel with the HTCA-QSFP28x6QSFP4SFPP16 interface
①Working ports: 100G optical
②Working ports: 40G optical
③Working ports: 10G optical
④Working ports: 10G optical
⑤IPMI port
⑥RJ45 console port
⑦USB port
⑧PWR: power LED
⑨MGR: status LED
⑩STAT: status LED
⑪ACTN: IPMI status LED
－
Rear Panel
Figure 1-20 shows the rear panel of ADS NX5-10000.
