Visionary INSURGENT VISH2 Series Instruction Manual

INSURGENTTM
LED HIGHBAY
OPERATING
INSTRUCTION
MANUAL
IP65 + IK10 IMPACT RATED LED HIGHBAY
150W Model V1.00
REV 0
VISH2-XXX-XXX-XXXX

Introduction
Thank you for choosing Visionary International as your lighting provider. This operating manual
provides information on how the product functions and how to safely operate and install the
product.
Installing the product (Existing installation)
Any electrical work must conform with the Electricity Act 1992 including section 79,
NZECP 50: 2004, Electricity Act 1992 Section 80 and NZECP 51: 2004.
1) Disable power to the circuit that you are working on. We highly recommend switching elec-
tricity off at the main switchboard of the premises for added safety.
2) (If applicable) Remove the previous tting from the ceiling being careful not to damage the
ceiling material. Ensure that there is no remaining driver/transformer connected to the specic
lighting mains cable.
Hook Mounted Installation
A) Apply the ring mount to the rear of the LED driver unit, ensuring the the spring is applied on
the screw part of the ring mount prior to connection. The spring helps to ensure that the ring
mount does not dislodge over time.
B)Tightly fasten the ring mount until very rm. We suggest using a large screw driver, applied
to the inside of the ring as a leverage tool to fasten at tightly as possible.
C) Connect the ring mount to the cable or d-Link and hang accordingly.
Bracket Mount Installation
A) Prepare the installation surface and ensure that it can support at least 10x the weight of the
LED highbay (7kg Max) = 70kg load requirement. Each Screw anchor should be capable of
holding at least 50kg of weight and at minimum of two anchor points should be used on the
bracket.
B) Using the bracket as a template, add screws to bracket using spacing as per the diagram
above.
3) Plug the 3-Pin NZ/AU plug into a surface or recessed mounted socket. Once securely plugged
in, re liven the circuit.

Usage areas
This product is suitable for use in commercial and industrial environments that are subject to
minor impacts and liquids. Insurgent is not suitable for use in high alkaline, high acidic or high
chemical usage areas of buildings. This product is not suitable for use in a parallel connection
with unsuppressed inductive loads or where there are known power quality issues. Doing so will
void the product warranty.
New Installations
The product must be installed by a fully licensed electrical contractor. Under New Zealand law,
a home owner or business that is not qualied to install electrical products cannot install Vision-
ary products that require new wiring. Visionary Technologies can assist you in nding a suitable
electrical contractor who is properly trained and experienced in installing Visionary products.
Contact us for more information.
DISCLAIMER
VISIONARY TECHNOLOGIES RESERVES THE RIGHT TO CHANGE PRODUCTS, INFOR-
MATION AND SPECIFICATIONS WITHOUT NOTICE. Products and specications discussed
herein are for reference purposes only. All information discussed herein may change without
notice and is provided on an “AS IS” basis, without warranties of any kind. This document and all
information discussed herein remain the sole and exclusive property of Visionary Technologies.
No license of any patent, copyright, mask work, trademark or any other intellectual property
right is granted by one party to the other party under this document, by implication, estoppels or
otherwise.Visionary products are not intended for use in life support, critical care, medical, safe-
ty equipment, or similar applications where product failure could result in loss of life or personal
or physical harm, or any military or defense application, or any governmental procurement to
which special terms or provisions may apply. For updates or additional information about Vision-
ary products, contact your nearest Visionary office.
Box Contents
1x Insurgent Highbay
1x 2M Cable with 3-Pin NZ/AU plug (Pre-Installed)
1x M10 Stainless Steel Ring Mount
1x (Extra Accessory) Bracket Mount

General Specications
Wattage 150W
Output 24,500lm
Efficacy
Lamp + Driver
Up to 165Lm/W
Delivered Lumens @150W, 5000K, 70CRI
Optic Options 600, 900, 1200
IP Rating IP65
IK Rating IK10
Warranty 5 - Years
Parts & Labour NA
CCT Options 5000K
3000K & 4000K Option (Lead Time Applies)
Mount Options Ring Mount
U-Bracket (Option)
Lighting Engine >50,000hr L70 TM-21
Driver Class I
Connections 2M Cable with 3-Pin NZ/AU Plug
Accessories U-Bracket Option
Colour/s Black / Aluminium
SDCM 5-Step | <5-SDCM
Input Connection NZ/AU Plug
IP68 3-Pole Gasket
Material Aluminum + Polycarbonate
