Visionite VCV6-V8A0W User manual

Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE, REFER FOR SERVICE TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO WATER, OR WET LOCATIONS.
WARNING
!
!
INSTRUCTION MANUAL
1/3” COLOR VANDAL-PROOF DOME CAMERA
SPECIFICATIONS
Model name VCV6-V8A0W
Camera
Image Device 1/3 type Panasonic MOS
Scanning System Progressive Scan
Total Pixels 1304(H) x1074(V) : 1.40Mega pixel
Effective Pixels 1296(H) x 1032(V) : 1.34Mega pixel
Min. Illumination 0.1Lux@F2.0 , 30IRE
Lens DC auto iris with mechanical day & night filter
Electronic Shutter NTSC : 1/60~1/60,000sec, PAL : 1/50~1/60,000sec
Video Output CVBS (NTSC, PAL)
Resolution 850TVL
OSD
Language English, Chinese, Chinese(S), Japanese, Korean
LENS DC/ MANUAL
EXPOSURE BRIGHTNESS/ AGC/ SHUTTER/ SENS-UP(max. x32)
WHITE BALANCE AWB/ATW/ PUSH LOCK/ MANUAL
BACK LIGHT OFF/ BLC/ WDR
DNR OFF/ LOW/ MIDDLE/ HIGH
DAY&NIGHT AUTO/ COLOR/ B&W/ EXTERN/ CDS
IMAGE SHARPNESS/ COLOR LEVEL/ MIRROR/ FLIP/
LENS SHADING/ GAMMA/ D-ZOOM/ DEFOG/ D-WDR
SPECIAL COMM ADJUST/ PRIVACY/ HLC/
INTELLIGENT(MOTION/ ALARM/ QUICK ZOOM)
SYSTEM VIEW ANGLE/ CVBS/ LANGUAGE/ CAM TITLE
Others
Operating Temperature 14℉~122℉(-10℃~+50℃)
Storage Temperature -4℉~140℉(-20℃~+60℃)
Humidity Less than 80%
Power Consumption DC12V(±10%), Max.180mA

DIMENSIONS INSTALLATIONS
OSD key &
VIDEO OUTPUT
CASE BOTTOM
CAMERA
CAP PIPE
SCREW(3EA)
CASE TOP
SCREW (3EA)
DOME COVER
