Visonic ioXpander User manual

ioXpander-12x4 Module
Installation Guide
www.visonic.com
Page 1 of 11D-306783 ioXpander-12x4 Module
(Rev 2, 11/17)
English
1. Introduction
This installation guide provides the basic instructions for Visonic’s ioXpander-12x4 Module installation scenarios. A
new addition to the PowerMaster-33 E G2 control panel, the ioXpander-12x4 Module is a wired input/output expander
that communicates with the PowerMaster-33 E G2 through the ioXpander-8 module.
ioXpander-12x4 Module Features:
12 wired inputs that enable to connect to 12 H/W zones
4 relay outputs.
Siren output (SRN) and Strobe output (STR)
Front and back cover tamper switches for improved tamper protection
RS-485 bus to communicate with the panel
The ioXpander-12x4 Module is supported by the PowerMaster-33 E G2 only
1.1 Terminology:
Abbreviation
Definition
NO / NC
Normally Open / Normally Closed
EOL/DEOL
End of Line / Double EOL
HW-Zone
Hard wired zone
ioXpander-8
Expander and bus controller on the PowerMaster-33 E G2
PGM
Programmable Relay Output
PCB
Printed circuit board
2. General Guidelines
1. Keep away from all heat sources.
2. Do not expose to air drafts.
3. Do not install outdoors.
4. Avoid direct sunshine.
5. Keep wiring away from power cables.
6. Mount on solid stable surfaces.
IMPORTANT: The ioXpander-12x4 Module MUST BE POWERED
DOWN while wiring the I/Os and when connecting to the RS-485 bus.
This will prevent accidental damage to the device.

www.visonic.com
Page 2 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
3. Installing the ioXpander-12x4 Module
The ioXpander-12x4 Module enclosure provides tamper detection and accessible wiring cavities.
1. To open the front cover: remove screws on the
sides, place fingers in the opening grove of each
side and the push the cover upward.
3. Remove the securing screw and push the
tab to release the PCB with the interface.
2. Release the protective cover snap and remove
the cover.
4. Knockouts provide cable accessibility when
mounting on gang boxes or over hollow
panels. Use a cutter or screwdriver to open
knockouts. Insert screws through rear cover
into the wall or ceiling. Note: make sure the
trunking knockouts align with the holes.

www.visonic.com
Page 3 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
5. Mount to wall. To mount onto a wall, insert
screws through the corners holes of the base.
Note: drill mounting holes first. To thread wires
from the side, open the wire holes from any
direction (there is one on each side of the box),
and thread the wires through the holes. Wrap
any excess wire around the PCB.
7. Assemble the protective cover by placing it
over the interface and snapping it into place.
6. Snap the PCB back into place and make sure
the tamper cap is in place. Thread the cables
inside the box through the cable cavities and
connect as needed to the terminal blocks.
8. Place the top cover and secure it with
screws on both sides
.
Tamper Cap

www.visonic.com
Page 4 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
4. Configuration
The PowerMaster-33 E G2 can support up to 4 ioXpander-12x4 Modules for a total of 48 wired zones.
Every ioXpander-12x4 Module is connected and registered to the ioXpander-8 module using a RS-485 bus
(230000 bps).
The ioXpander-12x4 has two LEDs
Green
Power - Lights continuously when powered.
Red
When the ioXpander-12x4 is connected, registered, and communicating with the
PowerMaster-33 E G2 the red LED is off. Otherwise, it blinks every second.
4.1 Inputs:
Every HW-Zone that connects to a ioXpander-12x4 Module must be enrolled in the PowerMaster-33 E G2. Each
ioXpander-12x4 Module can connect up to 12 HW Zones. For more information refer to section 6: “Enrollment
Process.”
Configure each HW-zone wiring type setting: EOL/NO/NC based on the type of sensor wired to the zone input (see
below).
Note: Each HW-Zone reports 3 possible states: Normal, Alarm, or Tamper. Both Line Cut and Line Short are
reported as Tamper (see below). Regarding the wired zones, the control panel classifies the events according to the
resistance it measures as shown in the tables below.
NC–If the Wiring Type is End of Line
If Wiring Type is NC
If Wiring Type is NO
Condition
Zone Resistance
Tamper/Short Circuit
0 ÷ 1.76 kΩ
Normal
1.77 kΩ ÷ 2.64 kΩ
Tamper
2.65 kΩ ÷ 3.52 kΩ
Alarm
3.53 kΩ ÷ 5.26Ω
Tamper/Open Circuit
5.27 kΩ ÷ oc
When there is NO ALARM - the Panel
detects 2.2K ohm between Zx and
GND.
When there is ALARM - the Panel
detects 4.4K ohm between Zx and
GND.
When there is TAMPER or cut circuit
the Panel detects: ∞ ohm. When the
line is short circuited the panel detects
0 between Zx and GND.
Condition
Zone Resistance
Normal
0 –1.76 kΩ
Invalid Level
1.77 kΩ – 2.64 kΩ
Invalid Level
2.65 kΩ – 3.52 kΩ
Invalid Level
3.53 kΩ –5.26 kΩ
Alarm
5.27 kΩ – ∞
When there is NO ALARM - the
Panel detects 0 ohm (short
circuit) between Zx and GND.
When there is ALARM - the
Panel detects: ∞ ohm (cut circuit)
between Zx and GND.
When there is TAMPER - N/A
Zone Resistance
Condition
0 –1.76 kΩ
Alarm
1.77 kΩ – 2.64 kΩ
Invalid Level
2.65 kΩ – 3.52 kΩ
Invalid Level
3.53 kΩ – 5.26 kΩ
Invalid level
5.27 kΩ – ∞
Normal
When there is NO ALARM -
the Panel detects: ∞ ohm (cut
circuit) between Zx and GND.
When there is ALARM - the
Panel detects: 0 ohm (short
circuit) between Zx and GND.
When there is TAMPER - N/A
G
tamper switch orwithoutDetector
arming key (DEOL)
H
Detectors with tamper switch or
arming key’s tamper (DEOL)
J
Wired zones
K
GND

www.visonic.com
Page 5 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
4.2 Outputs:
The PowerMaster-33 E G2 supports up to 16 outputs. The first 8 outputs are reserved for the ioXpander-8 Module.
The other 8 outputs (PGM9 –PGM16) can be distributed among the ioXpander-12x4 Module. The installer needs to
enroll each PGM output to the required output pin of the required ioXpander-12x4 Module. For more information
refer to section 6: “Enrollment Process.”
4.3 Siren and Strobe Outputs:
The ioXpander-12x4 Module has built-in Siren and Strobe outputs. There is NO NEED TO ENROLL these outputs.
The Siren and Strobe outputs automatically activate when their functions are enabled in the PowerMaster-33 E G2.
The installer can choose to leave these outputs unconnected.

www.visonic.com
Page 6 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
5. Connecting the ioXpander-12x4 Module
5.1 Wiring:
Power should be wired using < 22 AWG. Data should be wired using 26 AWG (Cat 5).
The wired detector should be installed at least 2 meters away from the control panel.
The Panel that connects to the ioXpander-12x4 Module should be wired as a bus configuration.
Use only a power supply that is safety approved for IEC/EN 60950-1 as a limited power source (LPS) with a
rated voltage of 12Vdc and rated current of __1__a max.
Both the CP and PS that are used for powering the ioXpander-12x4 Module must be EN 50131-6 certified.
The loads that can connect to the relay outputs must be limited to a maximum of 12 VDC, 8A or 24 VDC, 4A!
Example of ioXpander-12x4 Modules connected to external power supply with 12 hour backup battery.
5.2 Termination:
Each end of the RS-485 bus must be terminated with a 100 Ohm resistor.

www.visonic.com
Page 7 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
5.3 ioXpander-12x4 Module Circuit Board:

www.visonic.com
Page 8 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
6. Enrollment Process
Refer to the KP-250 PG2 Installer Guide and follow the procedure under Programming.
A general description of the procedure is as follows:
Note: Steps 1-5 describe the enrollment of the ioXpander-12x4 Module device.
6.1 Step 1
On the KP-250 keypad enter the Installer menu, select “02: Zone/Devices.”
6.2 Step 2
Select “ADD NEW DEVICE.”
6.3 Step 3
6.3.1 Enroll the ioXpander-12x4 using one of the following options:
Connect the ioXpander-12x4 Module to the ioXpander-8 module.
Power on the ioXpander-12x4 Module.
Remove the ioXpander-12x4 Module front cover to release a tamper switch then replace the cover to reset the
tampers.
6.3.2 Wait until the red LED stops blinking (up to 10 seconds) and only the green LED is on. The following is
displayed:
“DEVICE ENROLLED” “E0x:Expander IOV” “ID NO. 441-xxxx” (“441” are always the first 3 digits for any
ioXpander-12x4 Module)
6.4 Step 4 –Pre-enroll process (optional to Step 3)
Enter the device ID, “441-xxxx”as it appears on the ioXpander-12x4 Module's back casing and press <OK>. The
following is displayed:
"ID ACCEPTED" "E0x:Expander IOV" "ID NO. 441-xxxx"
After connecting the ioXpander-12x4 Module to the PowerMaster-33 E G2 and exiting the Installer Mode, the
ioXpander-12x4 Module enrolls into the system.
6.5 Step 5 (optional: to change a specific ioXpander-12x4 Module’s ID)
Select the desired ioXpander-12x4 Module number: E01...E04 and press <OK>.
Note: The ioXpander-12x4 Module has no Location or Device Settings that need programming.
Note: Only after the ioXpander-12x4 Module is enrolled can its Inputs (Step 6) and Outputs (Step 7) be enrolled.
6.6 Step 6 - Pre-enroll an HW-Zone to a ioXpander-12x4 Module's Input
To define a HW-Zone onto a ioXpander-12x4 Module:
6.6.1 On the Keypad, select the “ADD NEW DEVICE” menu.
6.6.2 Enter the following 7 digits code: "052-0xyy". The following is displayed:
"ID ACCEPTED" "Zxx:Wired Sensor" "ID NO. 052-0xyy"
052
HW-Zone on a ioXpander-12x4 Module
0x
The requested ioXpander-12x4 Module's number (01…04)
yy
The requested ioXpander-12x4 Module's Input number (01…12)
The installer may change the pre-programmed HW-Zone number (only) at this point using Next/Back buttons and
then pressing OK.
The Input “yy”of ioXpander-12x4 Module number 0x is now associated to HW-Zone Zxx.

www.visonic.com
Page 9 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
6.6.3
Configure the HW-Zone settings (Location, Zone Type, SET CHIME, DEV SETTINGS: WIRING TYPE) like every
other HW-Zone (for more information consult the KP-250 PG2 Installer Guide).
6.7 Step 7 - Pre-enroll PGM Output to a ioXpander-12x4 Module's Output
To define a PGM Output onto a ioXpander-12x4 Module:
6.7.1 Select “ADD NEW DEVICE.”
6.7.2 Enter the following 7 digits code: "072-0x0y". The following is displayed:
"ID ACCEPTED" "Pxx:PGM on HwExp" "ID NO. 072-0x0y”
072
PGM Output on a ioXpander-12x4 Module
0x
The requested ioXpander-12x4 Module's number (01…04)
0y
The requested ioXpander-12x4 Module's Output number (01…04)
Note: Pxx may be P09-P16 (PGM9-PGM16). PGM1-PGM8 are reserved for the ioXpander-8 module.
The installer may change the pre-programmed PGM Output number (only) at this point using Next/Back buttons and
then pressing OK.
Output “0y”of ioXpander-12x4 Module number “0x”is now associated (attached) to PGM Output Pxx.
Note: The PGM Output has no Device Settings that need programming.
The Installer may configure the PGM Outputs in the Menu: "05:OUTPUTS" "PGM OUTPUTS" "PGM on
HwExpndrs" "E0x:Expander IOV" "Pxx:PGM PIN #0y", (for more information consult the KP-250 PG2 Installer
Guide).
6.8 Cautions-
If an enrolled ioXpander-12x4 Module does NOT communicate with the PowerMaster-33 E G2 (whether it is
powered OFF, not connected, or for any other reason), the following is displayed on the KP-250 screen:
"Expander IOV E0x MISSING", it must be deleted at once by the Installer.
Every ioXpander-12x4 Module connected to the PowerMaster-33 E G2 must be enrolled.
Whenever deleting a ioXpander-12x4 Module, all its defined HW Zones and PGM Outputs are also deleted.
Step 1
Step 2
Step 3
Step 4 -5
(optional)
Step 6 - 7
Enter the Installer
menu and select
“02: Zone/Devices”
Select “ADD NEW
DEVICE”
Enroll the device or Enter the
device ID
Pre-enroll the
device
Configure the
ioXpander-12x4
Module
Outputs and
Inputs
“02: Zone/Devices” ADD NEW DEVICES ENROLL NOW ENTR ID:XXX-XXXX OUTPUTS Connect to ioXpander-8 INPUT
ZONES Or
Power On
OrRelease and Reset Tamper

www.visonic.com
Page 10 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
7. Product Specifications
Electrical
Power Requirements
12VDC (Normal), 10.8VDC (Min.), 15VDC (Max)
Output Power
12VDC, 500mA (Max)
Circuit Board
Device Interfaces
1 - four position terminal block RS-485 data bus & power; 11 - three-position removable terminal blocks; 1 two
position output terminal block; 4 - Relay Outputs/LEDs; 1 - Power LED; 1 - Status LED
Outputs
4 Relays NO/NC contact; 1 Siren output (sink), 1 Strobe output (sink)
Input
12 Inputs
Buzzer
Beeps intermittently (in a sequence of 1 second ON, 1 second OFF) when the Installer is locating the ioXpander-
12x4 Module (in the "Find Me" Menu).
LED Status Indicators
Green: Power LED - Lights continuously when powered
Red: When the ioXpander-12x4 Module is connected, registered, and communicating with the ioXpander-8 the
red LED is off. Otherwise, it blinks every second.
Tamper Protection
Open Double Tamper front and rear, if either breaks alarm will activate.
Power Relays
SRU-S-112L (TV-5); 12 VDC, 8A or 24 VDC, 4A
RS-485 Bus
Data Rate
230Kbit/sec
Bus Backbone
26AWG (Cat 5)
DC
< 22 AWG
Bus Length
500M/1640Ft: Max.
Termination
100 Ohm Termination: The RS-485 Bus needs to be terminated at both ends with a 100 Ohm resistor
Operating
Environment
Temp: -10°C to 70°C (14°F to 159°F) Humidity: 20% to 80%, non-condensing
Physical
Weight
670 grams (23.57 ounces)
Construction
ABS plastic
Dimensions (H x W x
D)
230 x 199 x 47mm (90.625 x 7.83 x 1.84 inches)
Regulatory
EN 50131-3 Grade 2, Class II
Warranty
1-year limited warranty
Product offerings and specifications are subject to change without notice.
Important Shipment Information: The ioXpander-12x4 Module PGM Terminal Blocks are labeled in two different ways. There is no difference in
their functionality. The only difference is how the PGM’s PCBs are labeled.
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from which you orignially purchased it.
If you are discarding this product and not returning it for repair then you must ensure that it is returned as identified by your supplier.
This product is not to be thrown away with everyday waste - Directive 2002/96/EC Waste Electrical and Electronic Equipment.

www.visonic.com
Page 11 of 11
D-306783 ioXpander-12x4 Module (Rev 2, 11/17)
8. Compliance with Standards & Warranty
This device complies with EN 50131-3 Grade 2, Class II
Visonic Limited (the “Manufacturer") warrants this product only (the
"Product") to the original purchaser only (the “Purchaser”) against defective
workmanship and materials under normal use of the Product for a period of
twelve (12) months from the date of shipment by the Manufacturer.
This Warranty is absolutely conditional upon the Product having been
properly installed, maintained and operated under conditions of normal use
in accordance with the Manufacturers recommended installation and
operation instructions. Products which have become defective for any other
reason, according to the Manufacturers discretion, such as improper
installation, failure to follow recommended installation and operational
instructions, neglect, willful damage, misuse or vandalism, accidental
damage, alteration or tampering, or repair by anyone other than the
manufacturer, are not covered by this Warranty.
There is absolutely no warranty on software, and all software products are
sold as a user license under the terms of the software license agreement
included with such Product."
The Manufacturer does not represent that this Product may not be
compromised and/or circumvented or that the Product will prevent any death
and/or personal injury and/or damage to property resulting from burglary,
robbery, fire or otherwise, or that the Product will in all cases provide
adequate warning or protection. The Product, properly installed and
maintained, only reduces the risk of such events without warning and it is not
a guarantee or insurance that such events will not occur.
Conditions to Void Warranty
: This warranty applies only to defects in parts and workmanship relating to
normal use of the Products. It does not cover:
damage incurred in shipping or handling;
damage caused by disaster such as fire, flood, wind, earthquake or
lightning;
damage due to causes beyond the control of the Seller such as excessive
voltage, mechanical shock or water damage;
damage caused by unauthorized attachment, alterations, modifications or
foreign objects being used with or in conjunction with the Products;
damage caused by peripherals (unless such peripherals were supplied by
the Seller;
defects caused by failure to provide a suitable installation environment for
the products;
damage caused by use of the Products for purposes other than those for
which they were designed;
damage from improper maintenance;
damage arising out of any other abuse, mishandling or improper
application of the Products.

Items Not Covered by Warranty:
In addition to the items which void the Warranty, the following items shall not
be covered by Warranty: (i) freight cost to the repair centre; (ii) customs fees,
taxes, or VAT that may be due; (iii) Products which are not identified with the
Seller's product label and lot number or serial number; (iv) Products
disassembled or repaired in such a manner as to adversely affect
performance or prevent adequate inspection or testing to verify any warranty
claim. Access cards or tags returned for replacement under warranty will be
credited or replaced at the Seller's option.
THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, OBLIGATIONS OR LIABILITIES, WHETHER WRITTEN, ORAL,
EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, OR OTHERWISE. IN NO CASE SHALL
THE MANUFACTURER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS WARRANTY OR ANY OTHER
WARRANTIES WHATSOEVER, AS AFORESAID.
THE MANUFACTURER SHALL IN NO EVENT BE LIABLE FOR ANY SPECIAL,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES OR FOR
LOSS, DAMAGE, OR EXPENSE, INCLUDING LOSS OF USE, PROFITS, REVENUE,
OR GOODWILL, DIRECTLY OR INDIRECTLY ARISING FROM PURCHASER’S USE
OR INABILITY TO USE THE PRODUCT, OR FOR LOSS OR DESTRUCTION OF
OTHER PROPERTY OR FROM ANY OTHER CAUSE, EVEN IF MANUFACTURER HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
THE MANUFACTURER SHALL HAVE NO LIABILITY FOR ANY DEATH, PERSONAL
AND/OR BODILY INJURY AND/OR DAMAGE TO PROPERTY OR OTHER LOSS
WHETHER DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE,
BASED ON A CLAIM THAT THE PRODUCT FAILED TO FUNCTION. HOWEVER, IF
THE MANUFACTURER IS HELD LIABLE, WHETHER DIRECTLY OR INDIRECTLY,
FOR ANY LOSS OR DAMAGE ARISING UNDER THIS LIMITED WARRANTY, THE
MANUFACTURER'S MAXIMUM LIABILITY (IF ANY) SHALL NOT IN ANY CASE
EXCEED THE PURCHASE PRICE OF THE PRODUCT INVOLVED, WHICH SHALL BE
FIXED AS LIQUIDATED DAMAGES AND NOT AS A PENALTY, AND SHALL BE THE
COMPLETE AND EXCLUSIVE REMEDY AGAINST THE MANUFACTURER.
When accepting the delivery of the Product, the Purchaser agrees to the said
conditions of sale and warranty and he recognizes having been informed of.
Some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages, so these limitations may not apply under certain
circumstances.
The Manufacturer shall be under no liability whatsoever arising out of the
corruption and/or malfunctioning of any telecommunication or electronic
equipment or any programs.
The Manufacturers obligations under this Warranty are limited solely to repair
and/or replace at the Manufacturer’s discretion any Product or part thereof
that may prove defective. Any repair and/or replacement shall not extend the
original Warranty period. The Manufacturer shall not be responsible for
dismantling and/or reinstallation costs. To exercise this Warranty the Product
must be returned to the Manufacturer freight pre-paid and insured. All freight
and insurance costs are the responsibility of the Purchaser and are not
included in this Warranty.
For sales in Israel only:
The Purchaser shall comply with the provisions of the Israeli Consumer
Protection Law –1981("Consumer Protection Law") related regulations,
including the Israeli Consumer Protection Regulations (Warranty Sticker),
5772-2012) ("Regulations"), including, without limitation (i) providing its
customers with at least the minimum warranty required by the Consumer
Protection Law, and (ii) ensuring that a warranty certificate and a warranty
sticker (as defined in the Regulations) ("Warranty Sticker") shall be attached
to any sold Products and the date of the sale of the Product to the consumer
or the end-user shall be added in a readable manner on the Warranty Sticker.
In no event shall the Purchser’s compliance with the Consumer Protection
Law and Regulations expand any of the Manufacturer's warranty obligations
under this warranty, and the Purchaser shall be responsible for any warranty
that it provides with respect to the Products which exceeds or is different from
this warranty.
This warranty shall not be modified, varied or extended, and the
Manufacturer does not authorize any person to act on its behalf in the
modification, variation or extension of this warranty. This warranty shall apply
to the Product only. All products, accessories or attachments of others used
in conjunction with the Product, including batteries, shall be covered solely
by their own warranty, if any. The Manufacturer shall not be liable for any
damage or loss whatsoever, whether directly, indirectly, incidentally,
consequentially or otherwise, caused by the malfunction of the Product due
to products, accessories, or attachments of others, including batteries, used
in conjunction with the Products. This Warranty is exclusive to the original
Purchaser and is not assignable.
This Warranty is in addition to and does not affect your legal rights. Any
provision in this warranty which is contrary to the Law in the state or country
were the Product is supplied shall not apply.
Governing Law:
This disclaimer of warranties and limited warranty are governed by the
domestic laws of Israel.
Warning
The user must follow the Manufacturer’s installation and operational
instructions including testing the Product and its whole system at least once
a week and to take all necessary precautions for his/her safety and the
protection of his/her property.
* In case of a conflict, contradiction or interpretation between the English
version of the warranty and other versions, the English version shall
prevail.
