vissari VISPP900S User manual

VISSARI ONBOARD PRODUCT
& INSTALLATION USER GUIDE
MODEL
VISPP900S
www.vissari.co.nz

VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S
03 Welcome
04 Safety
05 Pre-Installation
06 Installation
08 Operation
09 Cleaning
10 Condensation
11 Warranty
CONTENTS
02 VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S

WELCOME
Thank you for purchasing a Vissari Rangehood.
Please read through this guide before installation and use.
Please retain your proof of purchase to aid in any warranty claim.
03

VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S
SAFETY
04
There shall be adequate ventilation in the room when the rangehood is in operation.
Do not flambé under the rangehood. This will damage the rangehood and it will not be
covered by warranty.
Do not ignite burners that give off intense, uncontrolled flames beneath the rangehood.
Make sure that no flames emerge from the sides of pans.
The rangehood ducting system must not be discharged into a flue that is used for any other
duct and or extract system.
Prior to cleaning or any maintenance, disconnect the rangehood from the power supply.
Do not use the rangehood without the filters installed.
Keep the filters clean, clean frequently.
Turn the rangehood fan on 5-10 minutes before starting to cook.
Turn the rangehood fan off 10-15 minutes after you finish cooking.
Range hoods and other cooking fume extractors may adversely affect the safe operation of
appliances burning gas or other fuels (including those in other rooms) due to back flow of
combustion gases. These gases can potentially result in carbon monoxide poisoning. After
installation of a range hood or other cooking fume extractor, the operation of flued gas
appliances should be tested by a competent person to ensure that back flow of combustion
gases does not occur.

05
PRE-INSTALLATION
Please check your Vissari rangehood for any damages prior to installation, do not install any
damaged rangehood
Please contact Vissari Rangehoods in the event of a damaged rangehood at installation time.
Vissari rangehoods must be installed to the specifications below, we recommend using
Vissari ducting and ducting components.
Vissari is not responsible for any substandard installation that is carried out differently to the
installation guidelines below.
Please contact Vissari for a list of recommended trained installers.
Please read the entire set of instructions before installing or using this appliance.
Heavy lifting – Please take care when lifting and installing the Rangehood to prevent any
personal injury.
Suitable solid in wall fixings will be required to install this rangehood, the rangehood must
not be installed directly to gib board, there must be solid timber fixing behind the gib board at
the installation screw fixing points.
Always switch the power off prior to installation.
All electrical work must be carried out in accordance with local building codes and regulations.
A power outlet can either be on the wall, behind the chimney or in the ceiling. The socket
must be accessible, or have an accessible isolating switch, to enable the end user to isolate
the rangehood from the power for the purpose of internal cleaning or maintenance.
If the supply cord of the rangehood is damaged, it must only be replaced by Vissari, its
service agent or similarly qualified person.
Ducting accessories are not supplied. All ducting must comply with local requirements and
building codes.
All ducting roof penetrations must be carried out in accordance with local building codes
and regulations.
Exhaust air must not be discharged into an existing flue or any combined flue that is used for
exhausting fumes from gas appliances or bathrooms.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible
for their safety.
Remove all packaging, including protective wrappings, before use.

VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S
Required equipment for installation
We recommend Vissari rangehoods are installed by a recommended installation tradesperson.
Variety of Battery Drill Tools
Variety of Hand Tools
Variety of Drill Bits and Hole Saws
Ladders / Drop Sheets
Installation
Do not install this appliance if you find it damaged.
If this Vissari rangehood is installed damaged, Vissari will not be responsible for any costs
associated with the repair, replacement, removal or re installation of the Vissari rangehood.
Vissari recommends the rangehood be installed by a qualified rangehood installer.
Do not modify the rangehood in any way, Modification of any kind will void the warranty.
Ensure the rangehood is installed in accordance with all local council laws and regulations.
Recommended & Optimum Installation height is 750mm from benchtop to underside of
the rangehood.
Minimum Installation height above an electric hob is 650mm and a gas hob is 750mm.
Unwrap the rangehood and inspect for damage, plug in, and test the power and operation
while planning the installation.
Mark the centre line of the hob below on to the pre-installed overhead cabinet above,
then mark out the cut-out dimensions to the cabinet under panel.
Cut out the under panel to size with a jigsaw.
Screw and fix the rangehoods main body into the overhead cabinet.
Cut (depending on the model) a 160mm or 210mm hole for the ducting in the top of the
overhead cabinet and the ceiling.
Draw the ducting down from ceiling and connect to the rangehood outlet with tape and cable ties.
Plug in the rangehood and test.
Clean and commission rangehood.
06
INSTALLATION

Ducting
Vissari onboard rangehoods must be installed with high quality 150mm semi rigid
ducting to achieve optimum extraction and performance noise levels.
This requires a 160mm round hole cut in the ceiling or wall.
Do not reduce ducting size.
Avoid sharp bends in the ducting route.
A short direct ducting route is optimum, avoid long ducting routes with many bends.
Avoid using flexible ducting.
Flexible ducting should only be installed as a last option, if installed ensure that it is a
short direct route to the termination point and extended tort, so no slack duct occurs.
All ducting materials and fittings are available from Vissari.
07
860mm
293mm
260mm
824mm
125mm
305mm
Total height
430mm

VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S
08
OPERATION
Turn the rangehood fan on 5-10 minutes before starting to cook.
Turn the rangehood fan off 10-15 minutes after you finish cooking.
Replacing the Light Bulb
Control Panel
DANGER
Always switch off and disconnect power before replacing the light.
Failure to do so may cause serious injury. Please be aware that the light
bulb will retain heat for a short period of time after being switched off.
Step 3
Insert a new bulb by lining up
the pins of the light bulb with the
larger holes inside the light holder.
Once the pins are in place, turn
clockwise to secure the light bulb.
Step 2
Gently turn light bulb anti-
clockwise, pull the light
bulb down and remove it
from the light holder.
Step 1
Remove the filters
from the rangehood.
Press + to switch on the fan. The timer will only operate when the fan is switched on.
Press – to decrease the fan speed
Press + to increase the fan speed
To switch on or off the lights
Up to 15 minutes timer setting and fully adjustable. When you press the timer
button the digital display will change to “00” timer mode. You can adjust your
timer mode (up to 15 minutes) by pressing “–” or “+”

CLEANING
Interior
Clean the interior of the rangehood with neutral detergent and a damp cloth.
Exterior
We recommend using spray on ‘Steel Kleen’ applied to a soft cloth and then gently
applied to the rangehood body and flue covers.
Filters
Filter should be cleaned every 3-6 weeks or after approximately every 40 hours of use.
Clogged and dirty filters will restrict airflow and lower your rangehoods performance.
Hand Washing
Use detergent and hot soapy water, rinse after soaking with hot water.
Dishwasher
Wash separately, the colour of the mesh filters can change after several washes, this is
normal and is not a necessary indication for new replacement filters.
09

VISSARI ONBOARD PRODUCT & INSTALLATION USER GUIDE
MODEL VISPP900S
CONDENSATION
An induction cooktop is designed to provide rapid heating, improved thermal efficiency and
greater heat consistency. For some customers with an induction cooktop, condensation can
form on their rangehood filters while using their cooktop.
The induction cooktops heat source is contained in the conductive base of the pot.
When compared with a gas, electric or wok burner, the heat is not isolated or contained
to one area and therefore gradually rises on all sides of the pot or fry pan. This
combination allows the rangehood filters to warm up slowly and eliminate the formation
of condensation. For induction cooktops, the immediate and contained heat source
can produce vapours rapidly. This prevents the filters from gradually warming up and
increases the chance of condensation forming.
Some variables that can contribute to condensation forming on rangehoods & filters
above induction cooktops are:
Location in New Zealand and variable daily temperatures
The position of your home, relative to morning and afternoon sun
The quality of cookware being used
The height of the installed rangehood
Rapid heating
Filter type and size
Condensation avoidance tips:
Turn on the rangehood 10 mins before starting to cook and turn off the rangehood
10-15mins after finishing cooking.
Do not cook at high/full power straight away, start on low or medium heat so the
rangehood can warm up slightly.
Keep the filters clean and grease free.
There must be a constant flow of air into the cooking area to avoid the creation of a
depression which can affect the rate of extraction.
Optimum rangehood installation height is 750mm above the cooking surface area.
Neither the rangehood nor the induction cooktop are faulty. That in some circumstances,
the combination of the rangehood, the induction cooktop and the many variables within
your home, can lead to condensation forming on your rangehood filters. With a gas or a
standard electric cooktop, you should not have or at least have very minimal condensation.
10

WARRANTY
Vissari Rangehoods Onboard Series Warranty
This Warranty is provided by Rangehood Solutions Ltd – Distributor for Vissari Rangehoods.
This warranty covers the following Vissari Onboard Series Rangehoods used and installed in
domestic and household applications.
Vissari Onboard Series – VISC600 Vissari Onboard Series – VISC900
Vissari Onboard Series – VISBC600 Vissari Onboard Series – VISBC900
Vissari Onboard Series – VISBCS900 Vissari Onboard Series – VISPP600S
Vissari Onboard Series – VISPP600D Vissari Onboard Series – VISPP750D
Vissari Onboard Series – VISPP900S
Vissari Onboard Series rangehoods are covered with a 5-year warranty from the original date
of purchase, this is applicable for only the original purchaser.
This warranty applies in New Zealand only.
The customer must produce the original invoice to make any warranty claim.
Warranty Exclusions
The warranty does not apply where, in Vissari Rangehoods opinion:
The product has been repaired or serviced by an unauthorised appliance service agent.
The Rangehood and was not installed in accordance with our instructions.
The Rangehood/Product was not cared for in accordance with our instructions.
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage.
LED Light replacements are not covered.
Service agents call out costs, if the rangehood is found to be in normal working order.
The customer must provide the original invoice as proof of the original purchase date.
Costs incurred on installation or removal of a product, or any reinstallation or any associated
costs are not covered by this warranty.
The repairs relate to the replacement of consumable parts such as fuses in plugs.
Damage of defects have not been reported within 48 hours of delivery, otherwise no claim
will be recognised.
The breakdown occurs after the expiry of the warranty period.
How to make a claim
You may make a claim under this warranty by emailing us at: [email protected]
Please email a copy of your original invoice as proof of purchase.
11

SHOWROOMS
Auckland – East Tamaki
Bay Of Plenty – Mount Maunganui
Waikato – Te Rapa
P0800 RANGEHOODS / [e-mail] / www.vissari.co.nz
