VISTEON VNMC-1000 User manual

Preface
- 2 -
This user guide explains how to use the Car Infotainment System and
contains the information that a driver must know for safe driving.
Be sure to keep this user guide inside the car. Give it also to the other
driver when the car is delegated or rented.
:Danger:
It provides information that the users must keep to prevent from the
possibility of serious or fatal injury to themselves or others.
:Caution:
It provides information that the users must keep to prevent from the
possibility of vehicle or product damage.
:Recycling:
It provides information for environmental protection.
:Note:
It provides additional information.
2008 FMS Co., Ltd
All rights reserved. No part of this manual may be reproduced, copied,
transmitted, disseminated, transcribed, downloaded or stored in any storage
medium, in any form or for any purpose without the express prior written
consent of FMS. Furthermore, any unauthorized commercial distribution of
this manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. FMS
reserves the right to change the content herein without the obligation to notify
any person or organization of such changes.
is a registered trademark of FMS Co., Ltd. and may not be used in
any way without the express written consent of FMS. All other trademarks
used herein remain the exclusive property of their respective owners. Nothing
contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein.
Misuse of any trademarks or any other content in this manual is strictly
prohibited. FMS shall aggressively enforce its intellectual property rights to
the fullest extent of the law.

Preface
- 3 -
USA-Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used
in accordance with the instructions, it may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by tuning the equipment off and
on, the user is encouraged to try and correct the interference by one
or more of the following measures:
-Reorient or relocate the receiving antenna
-Increase the distance between the equipment and the receiver.
-Connect the equipment to outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Caution: Exposure to Radio Frequency Radiation.
To comply with FCC RF exposure compliance requirements, for
mobile configurations, a separation distance of at least 20 cm must be
maintained between the antenna of this device and all persons.
This device must not be co-located or operating in conjunction with
any other antenna or transmitter.
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of
Dolby Laboratories.
Note:
This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights. Use of
this copyright protection technology must be authorized by
Macrovision, and is intended for home and other limited viewing uses
only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.

Contents
- 4 -
1. Cautions.....................................................................................5
 Precautions........................................................................5
 Discs ..................................................................................5
 Safety Instructions .............................................................7
 Cautions before Use ..........................................................7
 Cautions while Using the Product......................................8
2. Product Features.......................................................................9
 Main Unit............................................................................9
 Remote Control................................................................10
3. Basic Operation.......................................................................12
 Initial Use and Power Supply...........................................12
 Volume Adjustment ..........................................................12
 Mute.................................................................................12
 Adjusting the Slope of LCD panel....................................13
 Inserting and Removing Disc/SD Memory Card..............13
 Using the Touch Screen...................................................14
 Replacing the Remote Control Batteries .........................14
4. Selecting Source.....................................................................15
 Selecting a source on the Main Menu .............................15
 Moving to the Main Menu ................................................15
5. Common GUI ...........................................................................16
6. Navigation................................................................................17
7. Radio ........................................................................................18
 Radio GUI ........................................................................18
 Inputting Radio Frequency...............................................18
8. Disc...........................................................................................19
 Disc GUI ..........................................................................19
 Inputting Title/Chapter/Track............................................20
 DVD/VCD Control ............................................................20
9. iPod™.......................................................................................21
 iPod Video GUI ................................................................21
 iPod Music GUI................................................................21
 iPod Menu & List..............................................................22
10. AV-IN.........................................................................................25
11. Sirius/XM (Optional)................................................................26
12. Phone.......................................................................................27
 Phone GUI.......................................................................27
 Phone Book.....................................................................28
13. Movie........................................................................................30
 Movie GUI .......................................................................30
 Movie Playlist Edit ...........................................................31
 Movie Playlist ..................................................................31
14. Music........................................................................................32
 Music GUI........................................................................32
 Music List ........................................................................33
15. Photo........................................................................................35
16. Rear View Camera...................................................................36
17. Phone Mute..............................................................................36
18. Setup........................................................................................37
 Display.............................................................................37
 Sound ..............................................................................40
 System ............................................................................43
 Version ............................................................................49
19. Appendix..................................................................................51
 Trouble Shooting ............................................................. 51
 Notices for Installation and Service .................................53
 Installation and Removal of the Main Unit.......................54
 Components and Accessories .........................................55
 System Connection ......................................................... 56
 Specifications ..................................................................57

Cautions
- 5 -
1. Cautions
Precautions
WARNING:
TO PREVENT FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol warns the user of uninsulated voltage within
the unit that can cause dangerous electric shocks.
This symbol alerts the user that there are important
operating and maintenance instructions in the literature
accompanying this unit.
CAUTION:
THIS DVD VIDEO RECORDER IS A CLASS 1 LASER PRODUCT.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN
COVERS AND DO NOT REPAIR THE PLAYER YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
Discs
• Playable Discs
Type of
Media Mark (Logo) Recorded Signals
DVD-Video
Digital Video
(MPEG2)
DVD-RW
DVD-R
Digital Video
Divx
Digital Audio
MP3/WMA/OGG
DVD+RW
DVD+R
Digital Video
Divx
Digital Audio
MP3/WMA/OGG
Audio CD Digital Audio
CD-RW
CD-R
Divx
Digital Audio
MP3/WMA/OGG
VCD
Digital Video
is a trademark of DVD Format/Logo Licensing Corporation.
• Unplayable Discs
- DVD-RAM, DVD-audio, CD-i, photo CD, super audio CD, DVD with
region codes other than 1 or ALL, DTS-CD, DVD-ROM for personal
computers, CD-ROM for personal computers
- Any other discs without compatibility indications

Cautions
- 6 -
• DVD Area Code
DVD Video System assigns the area code to DVD Video Players and DVD
Discs, according to the areas where they are sold. For example, DVD Video
Players that are sold in U.S.A. can only play discs with the correct number
(‘1’ and ‘ALL’ or any combination of numbers including ‘1’) The DVD
region number is indicated on the disc as shown below.
Please, refer to the provided manual in the DVD Title which you purchased
for the detailed information of area codes per country.
• Handling Discs
Do not use discs with rough edges. Using such discs could cause the product
to malfunction or be damaged.
Do not attach labels to the disc surface or mark it with a pencil or a pen.
Doing so could cause the product to malfunction or be damaged.
Do not use discs if they have scotch tape or other adhesive materials or traces
of such material on them. Using such discs could cause the product to
malfunction or be damaged.
Do not use discs that are badly scratched, deformed or cracked. Using such
discs could cause the product to malfunction or be damaged.
Do not use commercially available CD protectors or disc stabilizers. Doing so
could cause the product to malfunction or be damaged.
Do not touch the disc surface when inserting or removing the disc.
• Cleaning Discs
Use a soft cloth to wipe the disc from the center out towards the
circumference.
Do not use any cleaner, static-proof spray or thinner on the disc. The discs
can be damaged.
• Keeping Discs
Do not keep discs in places where it is too hot or too cold. Doing so could
deform them. Using deformed discs could cause the product to malfunction or
be damaged.
Do not keep discs in places exposed to direct sunlight or close to heaters.
Doing so could deform the discs. Using deformed discs could cause the
product to malfunction or be damaged.
Do not keep discs in places that are too dusty or too humid. Using discs
stored in such places could cause the product to malfunction or be damaged.
• Color Monitor System
DVD player can only play discs of NTSC or PAL, not play discs of SECAM.

Cautions
- 7 -
Safety Instructions
• Do not use when the product contains a defect or malfunction.
Do not operate the product while it is in abnormal conditions. When any
foreign material is inserted or a smoke or strange smell is continuously
detected, stop using the product and contact with a purchase site or customer
support center. It may cause an accident, fire, or electric shock.
•This product uses 12V DC vehicle power supply.
This product operates on 12V vehicle power supply. Be sure to use the cable
enclosed with the product. Or it may cause a product failure or serious
malfunction of the vehicle.
•Be cautioned not to damage any vehicle parts during installation.
Be careful not to damage any vehicle parts (electric devices, wiring, pipes,
screws, etc.) while installing the product. When the product is abnormally
installed, it may cause an abnormal control of vehicle, fire, electric shock, or
traffic accident by damage of vehicle parts.
•Never arbitrarily disassemble or modify the product.
Do not arbitrarily disassemble or modify the product. It may cause a fire,
electric shock, or product damage. If a product failure was caused by a user’s
fault, the user cannot get after-sales services.
•Set the volume at an adequate level while using the product.
When the product is used in a large volume, a traffic accident may happen
because the driver cannot hear sound from outside. Adjust the volume level
of the product for right use.
•Use genuine parts only.
Use genuine parts only. Or it may cause product damage, misinstallation, or
malfunction. In this case, the user assumes all responsibility for errors. When
any parts are lost or damaged, contact with a purchase site or customer
support center.
•Preserve the product from humidity or by direct contact with liquid,
and do not block the ventilation hole.
When any humidity or liquid substance is inserted inside the product, it may
cause a product failure or fire. Do not block the ventilation hole. If it is
blocked, a product failure or fire may happen due to accumulated heat.
•Do not cut or modify the provided cable.
Do not cut or modify the provided cable. The power cord has its own fuse for
preventing overcurrent. If the user uses the cord without the fuse, the
protection circuit does not work and it may cause a product failure or fire.
•Never manipulate or watch the product while driving.
Do not manipulate or watch the product while driving. It may cause a traffic
accident by careless driving. Be sure to park or stop the car in a safe area to
manipulate or watch the product.
Cautions before Use
• Install the product correctly for use.
Before using the product, correctly install the product after reading the system
connection section in this user guide.
•Use the product after starting the engine.
When the user uses the product for a long time while not starting the engine,
the battery may be discharged.
•Configure all settings for use before driving.
If the driver manipulates or changes the settings while driving, driving can be
interrupted. When the user especially uses the navigation function, start
driving after finishing the configuration for path setting, search, and the like.
If any configuration change is needed while driving, park the car in a safe
place, change to the desired settings, and drive the car again.
•Use the exclusive navigation GPS antenna.
For the navigation GPS antenna to be connected to the product, use the
exclusive antenna only. Place the navigation antenna over 30cm away from
the body.
When the antenna is installed outside the car, its cable may be damaged,
disconnected, or stolen.

Cautions
- 8 -
Cautions while Using the Product
•The operation temperature range of the product is -10 to 60℃.
Use the product only when the ambient temperate is within -10 to 60℃. If the
user uses the product out of the temperature range, it may cause a product
failure. Because of the nature of LCD panel, the screen may be darker when it
is initially operated in a very low temperature. After several minutes, the
brightness of the screen returns to normal.
Do not operate the product after turning on the heater when the temperature
in the car is very low. It may cause a product malfunction or damage due to a
frozen disk or optical lens surface.
•Be cautioned when using the LCD panel.
Be careful not to manually pull the LCD panel or not to place a cigarette light
on it. Do not apply an impact to the LCD panel. It may cause damage to the
panel.
When any foreign material is caught between the LCD panel and its body
while adjusting the slope of the panel, product damage may happen.
Do not forcibly press the case around the touch panel. It may cause a product
malfunction or damage.
•Observe actual traffic laws and regulations.
While the navigation is running, the driver can encounter the guided
information is different from actual traffic situation due to change of traffic
regulations. Be sure to follow actual traffic regulations. The service provider
assumes no responsibility for damage caused by not observing actual traffic
regulations. Drive carefully all the time.

Product Features
- 9 -
2. Product Features
Main Unit
Wide TFT LCD Touch Screen①
- It outputs video signals on the touch screen.
- You can manipulate menus by touching each icon.
[Mute] Button②
- It mutes the sound or cancels the Mute function.
[Volume] Button③
- It increases or decreases the volume level.
[④] Button
- It repeats the recent navigation audio signals.
- When pressed for over one second, it returns to the navigation source.
[⑤] Button
- (Ignition key is in ACC or ON and power is Off) The power is turned on.
- It sequentially switches between running sources.
- When pressed for over one second, the power is turned off.
[⑥] Button
- It goes to the main menu for you to select a source.
- When pressed for over one second, it goes to Setup.
[Tilt] Button⑦
- By pressing it shortly, the slope of LCD panel changes by one level.
- While pressing it, the slope of LCD panel continuously changes.
- By adjusting the slope, you can insert or remove the SD card that contains
the navigation map program, video files, MP3 files, and picture files.
[⑧] Button
- In order to insert, exchange, or remove a disc, it automatically adjusts the
slope of LCD panel.
- When a disc is inserted, it automatically extracts the disc.
ⓐRemote Control Receiver
- It receives signals from the remote control.
:Note: Use of remote control
When you have any devices with remote controls other than of this product,
the use of remote control may cause malfunction of other devices.
Reset Holeⓑ
- When this product malfunctions, you can reset the system by poking a pin
(e.g. clip) through this hole.

Product Features
- 10 -
Remote Control
[PWR/SRC]①
- It functions the same as the Body [ ] button.
②[BAND] Button
• Radio
- It switches the frequency band (AM →FM1 →FM2→AM).
- When pressed for over one second, it switches the radio source (AM-FM →
HD →AM-FM).
③Numeric Button
• Radio
- Select any of frequencies (1–6) stored in Preset.
- When pressed for over one second, the current frequency is stored in the
corresponding preset (1–6).
- Enter the frequency in the frequency input panel.
• Disc: Enter values for Title, Chapter, and Track in the corresponding panel.
• Movie/Music/Photo: Select a file in the playback list panel.
• Phone: Enter the phone number.
[SETUP]④Button
- It returns to the main menu.
- When pressed for over one second, it goes to Setup.
[DIRECT]⑤Button
• Radio: Opens or closes the frequency input panel.
• Disc: Opens or closes the Title/Chapter/Track input panel.
• Movie/Music/Photo: Opens or closes the playback list panel.
[VOLUME]⑥Button
- It increases or decreases the volume level.
[▲/▼//]⑦◀▶Button
• Navigation: Moves the map up/down/left/right.
• Radio
- / :◀▶ Repeats scanning (8 seconds) of receivable frequencies forward or
backward. When pressed again, the function ends.
- ▼: Removes the frequency entered in the frequency input panel.
• Disc: Moves the cursor on the DVD/VCD control.
• iPod: / :◀▶ Performs the Rewind/Fast Forward function.
[ENT]⑧Button
• Radio: Select a frequency that has been entered in the frequency input panel.
• Disc
- Select values for Title, Chapter, and Track entered in the corresponding
panel.
- Select the item where the cursor is located in the DVD/VCD control.
• iPod: Stops the Rewind/Fast Forward function.

Product Features
- 11 -
• Phone: When a phone call is issued or received for the entered phone
number, it answers.
• Movie/Music/Photo: Selects or unselects a playback file in the playback list
editing area.
[RETURN]⑨Button
• Radio: Closes the frequency input panel.
• Disc: Closes the Title/Chapter/Track input panel.
[MUTE]⑩Button
- Performs or cancel the Mute function.
[PLAY/PAUSE]⑪Button
• Disc/iPod/Phone/Movie/Music: Plays back a file or pauses it.
• Photo: Starts or stops a slideshow.
:Note: Manipulation of MP3 player on the Bluetooth mobile phone
This function works only when your mobile phone supports the Bluetooth
stereo headset and has the MP3 player function.
[STOP]⑫Button
• Disc/iPod/Phone/Movie/Music/Photo: Stops the playback.
[SEEK]⑬Button:
• Radio: Used to select a previous or next receivable frequency.
• Disc: Used to select a previous or next chapter/track.
• iPod/ Phone/Movie/Music/Photo: Used to select a previous or next file.
:Note: Multi Zone Rear Source
When Multi Zone Rear Source is active, the remote control can control the
rear source only. In this case, the current source (front source) can be
controlled by using the icon.

Basic Operation
- 12 -
3. Basic Operation
Initial Use and Power Supply
The power of this product is set to Off by default. Accordingly when you use
this product for the first time after installation, move the ignition key location
to ACC or ON and press the [ ] button on the remote control to supply
power to the product. When the power is supplied, the LCD panel is moved
inside and returns to the original position.
:Caution: Battery Discharge
Use this product while the car engine is started. If you use this for a long time
while the engine is not started, the battery may be exhausted. Then you
cannot start the car engine.
When the ignition key is turned to LOCK or extracted, the current source and
settings are automatically saved and the power is turned off. When the
ignition key is turned to ACC or ON, the power is automatically turned on
and the saved settings are returned.
When the [ ] button is pressed for over one second, the power is turned
off. In this case, turn the ignition key to ACC or ON and press the [ ]
button to supply power.
:Note: Automatic Start
When you press the [ ] button for over one second to turn off the power,
the power of the product is not automatically turned on when starting the
engine.
In order to automatically turn on the product, do not press the [ ] button
but stop the engine by using the ignition key.
:Note: Disk Resume Play
If you turned off the power with a disc inserted, when you play back the disc
after turning on the power, it is played back from the location where you
previously listened.
:Note: Illumination at Night Driving
When you turn on headlights at night driving, the lamp for the product is
turned on even though you turn off the power of the product.
Volume Adjustment
When you press the [Volume] button or Volume (+)/(-) icons on the LCD
screen, the volume level increases or decreases.
:Danger: Volume for Safe Driving
Set to the adequate volume level in which you can hear the sound from
outside.
:Danger: Max. Volume Setting
If the power is turned off while the volume is higher than Max. Volume set
in Setup > Sound > Speaker Control, when you turn on the power again,
the volume is adjusted to Max. Volume.
Mute
When you press the [Mute] button or the Mute icon on the LCD screen, the
Mute function is activated and the shape of icon is changed. When you press
the icon again, the function is deactivated.
:Note: No Sound
When the video of the product is normal but no sound is heard, check
whether the Mute function is active.

Basic Operation
- 13 -
Adjusting the Slope of LCD panel
By pressing the [Tilt] button shortly, you can change the slope of LCD panel
level by level.
When you press the [Tilt] button continuously, the slope of LCD panel
changes continuously.
:Note: Auto Close
•You can set this in Setup > System > ETC (see page **).
•ON: When the engine is stopped, the LCD panel is automatically closed.
When the engine is started, the slope of LCD panel is automatically
adjusted to the finally saved angle.
Angle adjustment during use Power OFF by ignition key Power ON by ignition key
• OFF: Even if the engine is stopped or started, the LCD panel is not
automatically closed and sustains the current angle.
Angle adjustment during use Power OFF by ignition key Power ON by ignition key
:Caution: LCD Panel TILT Mechanism
Do not forcibly move the LCD panel or press it
hard. It may cause a product damage or
malfunction.
Inserting and Removing Disc/SD Memory Card
When you press the [ ] button, the LCD panel moves downward to expose
the slot for disc insertion on the rear. Push a disc in arrow direction to insert it.
When a disc is inserted in the slot, push the [ ] button. The LCD panel
moves downward and extracts the disc. After removing it, press the [ ]
button again to move the LCD panel to the previous angle.
:Note: Disc Ejection and LCD Panel Angle
If the current angle of the LCD panel is lower than the moving angle of the
[ ] button, when you press the [ ] button, the LCD panel does not
move but (if a disc is inserted) just extracts the disc. When you
insert/remove/replace a disc and press the [ ] button again, the LCD panel
does not move. In this case, adjust the angle by using the [Tilt] button.
By using the [Tilt] button, you can move the LCD panel downward and
extract or insert an SD memory card for the slot on the rear panel.

Basic Operation
- 14 -
Using the Touch Screen
This product uses the touch screen LCD display. You can perform functions
by using their respective icons on the screen.
When video sources such as DVD, VCD, iPod VIDEO, AV-IN, Movie, Photo,
and Rear View CAM are played, the icon disappears in three seconds.
When the icon does not appear, touch the LCD screen to display the icon.
Be sure not to manipulate the touch screen while driving.
Replacing the Remote Control Batteries
①Push the battery cover of the remote control in arrow direction to open it.
②Install two AAA (AM4 1.5V) batteries with correct polarity as shown in
the remote control.
③Close the cover.
:Danger: Handling Remote Control Batteries
• If you do not use batteries properly, they may explode.
• Do not disassemble or apply heat to the batteries.
• Do not place the batteries near any heat source.
• After removing the batteries, do not throw them to men or animals.
:Recycling: Handling Remote Control Batteries
• If you do not use the batteries any more, scrap them properly.
• If the batteries are left for a long time, it may cause harms to children or
animals, or cause environmental pollutions. Scrap in a designated place
after keeping them.
:Note: Handling Remote Control Batteries
• When you replace batteries, replace two batteries by new ones at the same
time.
• To keep them for a long time, separate batteries from the remote control.

Selecting Source on
- 15 -
4. Selecting Source
Selecting a source on the Main Menu
• Click any source icon on the main menu to run it.
• When you press the [ ] button on the body or [PWR/SRC] button on the
remote control, the next source is selected.
• The sources that cannot be run with the currently running source are
deactivated. In order to run a deactivated source, stop the running source
first and run the desired source.
• The currently running source appears on the bar at the bottom. But the rear
view camera source does not appear.
:Note: Rear Source
• A rear source can be selected in Setup > Display > Zone > Multi Zone
(see page **).
• When the phone rings, Phone automatically runs (see page **).
• When you back your car, Rear View Camera automatically runs (see page
**).
Moving to the Main Menu
• When you press the [ ] button on the body or the [SETUP] button
on the remote control while a source is running, the main menu appears.
• When you click the menu icon on the upper left corner, the main menu
appears while the current source is running.
• When you click the X icon on the upper right corner, the current source
stops running and the main menu appears.
• When video sources such as DVD, VCD, iPod VIDEO, AV-IN, Movie,
Photo, and Rear View CAM are played, the icon disappears in three
seconds.
• When the icon does not appear, touch the LCD screen to display the icon.
.

Common GUI
- 16 -
5. Common GUI
①Changes to the main menu while the current source is running.
②Changes to the main menu after stopping the current source running.
③Performs or stops the Mute function. The shape of icon changes according
to the Mute function’s activation.
④Increases or decreases the volume level.
⑤Displays the currently running sources. Depending on the source, some
sources cannot run at the same time.
Multi Zone Rear Source⑥appears in Setup > Display > Zone. When Single
Zone is selected, it does not appear (see page **).
ⓐDisplays the current output source.
ⓑIndicates that the product is connected to a Bluetooth mobile phone (see
page **).
ⓒIndicates that a disc (DVD/CD/VCD/MP3CD) is inserted.
ⓓDisplays the current time.

Navigation
- 17 -
6. Navigation
Insert the SD memory card that contains the Navigation map program into the
NAVI slot and refer to the user guide for the Navigation map program that is
separately provided.
:Note: Moving to the Main Menu while Navigation is Running
The icon does not appear while the Navigation is running or outputting. Press
the [ ] button on the body or the [SETUP] button on the remote
control to move to the main menu.

Radio
- 18 -
7. Radio
Radio GUI
①Saves quality frequencies to maximum 6 presets after scanning the
bandwidth for the selected radio band. When pressed again, it ends.
②Selects the previous/next frequency.
③Repeats scanning (for 7 seconds) receivable frequencies forward or
backward. When pressed again, it ends.
④Sequentially selects radio sources such as AM-FM, and HD.
⑤Sequentially selects frequency bands for AM-FM sources such as AM,
FM1, and FM2.
⑥Displays the preset number for the current frequency. Additionally it
sequentially selects the stored frequencies.
⑦Opens the frequency input panel.
⑧Displays the preset frequencies that have been set automatically or
manually. You can directly select the desired frequency. The selected
frequency is distinguished with blue background. When pressed for over
one second, the current frequency is stored in the corresponding preset.
ⓐDisplays the currently listening PS (program service code), Stereo or not,
frequency, band, RT (radio text), and the like.
:Note: Radio Source Deactivation/Activation
When a disc, iPod or AV-IN, SAT radio , movie, or music source is running,
the radio source is deactivated. To activate the radio source, quit the running
disc, iPod or AV-IN, SAT radio, movie, or music source.
Inputting Radio Frequency
①Enter the frequency to listen to.
②Changes to the main display and sets the input frequency.
③Deletes the input frequency.
④Cancels inputting the frequency and closes the frequency input panel.
ⓐDisplays the input frequency.

Disc
- 19 -
8. Disc
Disc GUI
▪DVD
①Plays a disc or pauses it.
②Pauses the disc playback and displays the message, “Press Play Key To
Continue.” When pressed again, it ends.
③In case of DVD, it plays back the previous/next chapter. In case of CD,
VCD, or MP3CD, it plays back the previous/next track.
④Selects Random or Repeat for the playback mode. If not selected, it
repeatedly plays back all chapters or tracks in a disc.
:Note: Exceptional Cases for Disc Playback
• DVD: Does not support the random playback mode.
• MP3CD: Repeatedly plays back all tracks in the folder (not in the disc).
⑤Displays the playback information. When pressed, it opens the
corresponding input panel. It does not support the playback period.
- In case of DVD, it displays the title, chapter, and played time.
- In case of CD/VCD, it displays the track and played time.
- In case of MP3CD, it displays the track and folder name.
⑥Changes to the DVD/VCD control. If the disc is CD/MP3CD, this is not
supported.
⑦Displays the current playback position. You can change it by clicking the
desired position on the bar or dragging the arrow.
ⓐDisplays the played time and the running time.
:Note: Disc Source Deactivation/Activation
When a radio, iPod or AV-IN, SAT radio, movie, or music source is running,
the disc source is deactivated. To activate the disc source, quit the running
radio, iPod or AV-IN, SAT radio, movie, or music source.
▪MP3CD
①Displays the list of MP3 files and playable files in the folder. When
pressed, it is played back.
②Changes to the track input panel.
③Displays the current folder. When pressed, it opens or closes the folder
playback list panel.
④Moves to the previous/next page.
ⓐDisplays the current page and total page number.

Disc
- 20 -
Inputting Title/Chapter/Track
The following figure displays the chapter input panel that has been open by
clicking the chapter icon.
①Enter the chapter number to play back.
②Changes to the main display and starts playing the input chapter.
③Deletes the input chapter number.
C④ancels inputting the chapter and closes the chapter input panel.
ⓐDisplays the current chapter and total chapter number.
ⓑDisplays the input chapter number.
:Note: Title/Chapter/Track Input Panel
According to the icon pressed just before the input panel appears, the title
input panel, chapter input panel, or track input panel is open.
• In case of DVD, you can input or set the title number and chapter number.
• In case of CD/VCD/MP3CD, you can input or set the track number.
DVD/VCD Control
①Moves the cursor on the root/title menu or selects the item where the
cursor is located.
②Moves to the DVD root menu.
When pressed for over one second, it moves to the DVD title menu.
③Used to change the output of audio while playing DVD.
But the DVD must support this function.
④Used to change the angle while playing DVD.
But the DVD must support this function.
⑤Used to change the subtitle (caption) while playing DVD.
But the DVD must support this function.
:Note: Root/Title Menu
The Root/Title menu differs depending on the DVD product and its version.
You can select the desired item using (▲)/(▼)/( )/( )◀▶and ( ) icons
and confirm or change it.
:Note: VCD Control Screen
In VCD control, only the ①icon is displayed and supported.
