Pyle PYLE View Series PLTFT72 User manual

7.2 HEADREST LCD MONITOR
YOU'RE NOWREADY FOR
MORE FUN ON
THE ROAD THANEVER BEFOR
OWNER S MANUAL
7.2 TFTHEADREST LCDMONITOR
PLTFT72
WWW.PYLEAUDIO.COM

7.2 HEADRESTNTS LCDMONITOR
OSDADJUSTMENT
1. Press thePOWER ON/OFF buttonon the monitoror remote unitto turn onthe power.
a.Touch power switchon the monitorto select video/audioinputs.
b.Press powerswitch on themonitor 2 secondto turn off the monitor
2. Press MENUbutton on themonitor or remoteunit to activethe OSD functionshow on the
LCD screen andpress again toselect the adjustmentitem as below.
BRIGHTNESS
CONTRAST
COLOR
VOLUME
3. Press UP/DOWNbutton on themonitor or remoteunit to increaseor decrease thevalue of
the adjustment functionsfor optimum viewing.
REMOTE CONTROLUNIT
POWER on/off
FEATURESON SCREEN DISPLAY CONTROL
ON SCREEN DISPLAY CONTROL
WIDE SCREEN LCDPANEL
4. WIRE CONNECTION
Red wire: +ve
Black wire: -ve
Violet wire:none
YellowRCA Jack:Video1 In
YellowRCA Jack:Vudio2 In
Red RCAJack: AUDIO
5. ACCESSORIES
EXTENSION MINIDIN CABLE1PC
REMOTE CONTROLUNIT 1PC
VIDEO CABLE 1PC
HEADREST SHROUD
6.LCD MONITORREMOTE CONTROL
DISPLAY 7.2 WIDESCREEN LCD
BACK LIGHT BUILTIN CCFT
DOT FORMAT 960X234
VIDEO INPUT LEVEL COMPOSITE 1.0V P-P/75 OHMS
VIDEO INPUT SYSTEMS NTSC AUTO SWITCHING
POWER SOURCE DC 12V+/- 15%
POWER CONSUMPTION 700Ma (max) / 10w (max)
OPERATIONTEMPERATURE -20 Celcius to+ 75 Celcius
STORAGE TEMPERATURE -30 Celcius to+ 85 Celcius
DIMENSIONS 215 (W)x153 (H)x38 (D)mm
NET WEIGHT 0.8KGS
SPECIFICATIONS:
Power on /off
Color
Contrast
Volume
Brightness
Select
Mute
Video1/video2
OSD POWER MENU + EARPHONE JACK
