Vitek Alpha VTD-A2812/V User manual

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-A2812/V
Vandal Resistant High
Resolution WDR Varifocal
Dome Camera
• 620 TV Lines of Resolution
• Hercules DSP Engine
• 1/3” Sony SuperHAD II CCD
• 2.8~12mm Vari-Focal Auto-Iris Lens
• Advanced OSD Functions: WDR, 3D DNR,
DSS, DIS, Sens-up, Motion Detection, Privacy
• Semi Flush or Surface Mount
• IP68 Waterproof Rated
• Secondary Video Output (Cable Included)
• 3-Axis Mount for Optimum Viewing Angle
• Dual Voltage 12VDC/24VAC Operation
FEATURES
Internal Mechanism
Example of WDR
Conventional Camera
VTD-A2812/V
Privacy
3DNR
Day
Night
Hercules DSP
Engine
NTSC
PAL
Standards
Supports
600 TV Lines
OSD Menu
Motion Detection
Weatherproof
Original Measurements in mm
Actual night time image

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-VS48B2 1/4” 4mm-8mm Varifocal Color
Dome Camera w/420 TVL
BLACKYELLOWMAGENTACYAN
VTD-A2812/V
Vandal Resistant High
Resolution WDR Varifocal
Dome Camera
Detailed Specifications
Resolution
Sensor
Total Pixels
Effective Pixels
Scanning System
S/N (Y Signal)
Frequency
Video Output
Min. Illumination
White Balance
Standard Lens
Electronic Shutter Speed
WDR (Long and Short Exposure)
O.S.D.
Backlight Compensation
AGC (Auto Gain Control)
3DDNR (3D Digital Noise Reduction)
Day & Night
IP Rating
Privacy
Motion Detection
Image Conversion
DIS (Digital Image Stabilizer)
LSC (Lens Shading Compensation)
Digital Zoom
Sharpness
Operating Temperature/Humidity
Storage Temperature/Humidity
Power
Dimensions (Dia. X H)
620 TV Lines
1/3 Inch Sony SuperHAD II CCD
811(H) x 508(V) 410K pixels 795(H) X 595(V) 470K Pixels
768(H) x 494(V) 380K pixels 752(H) X 582(V) 440K Pixels
2:1 Interlace
More than 52 dB (AGC Off)
Horizontal: 15.734KHz / Vertical: 59.94Hz Horizontal: 15.625KHz / Vertical: 50.00Hz
CVBS: 1.0Vp-p / 75ohm
0.1 Lux at F1.2 (Color) / 0.0001Lux (Sense up x256)
ATW / AWC / PUSH / MANUAL Adjustable
2.8-12mm DC Auto Iris Lens
AUTO / MANUAL (1/60sec ~ 1/100,000sec)
ON, OFF Adjustable
Built-in
BLC (LOW, MIDDLE, HIGH, OFF Selectable) / HLM (Adjustable)
LOW, MIDDLE, HIGH, OFF Selectable
LOW, MIDDLE, HIGH, OFF
AUTO (Day <--> Night time Change), CDS, COLOR, B/W
IP68
OFF / ON (6 Zone)
OFF / ON (240 Zone)
FREEZE / V-FLIP / H-FLIP / ROTATE / NEGA: All ON/OFF Adjustable
ON / OFF
ON / OFF
ON (X1 ~ 10) / OFF
ADJUSTABLE
14’F ~ 122’F (-10’C ~ 50’C) / 30% ~ 80% RH
4’F ~ 140’F (-20’C ~ 60’C) / 20% ~ 90% RH
AC24V / DC12V DualPower
5.85” X 4.22” (148.48mm X 107.13mm)
NTSC PAL
Hercules DSP
Engine
OSD Menu
Privacy
3DNR
NTSC
PAL
Standards
Supports
Day
Night
Motion Detection
600 TV Lines
Weatherproof
