Vitek VTC-BHOCRAZ User manual

VITEK VITEK
FEATURES:
• 1/2.9” Sony® CMOS
• 2.1 MegaPixel With full 1080p/720p HD-SDI Output (SMPTE 292M)
• Up to 30fps live view@ 1920x1080 (1080p)
• MegaPixel IR Corrected 3-9mm (VTC-BHOCRAZ39) / 9-22mm (VTC-
BHOCRAZ922) Varifocal Lens
• Mechanical IR Cut Filter (True Day/Night)
• 16:9 Video format
• On-board Intelligence (OBI Technology) delivers Auto-Focus-Zoom by
tracking motion, then optically zooming into that area of the frame
• Fully programmable advanced WDR
• 40 850nm IR LEDs with up to 150’ IR range
• Integrated Cooling Fan
• Advanced OSD Functions: Motion Activated Pointing Zoom, Defog, Dynamic
IR, BLC/HLC, Motion Deblur, Pixel Defect Compensation, Title Set, Mirror,
Flip
• 100% Pure Digital Transmission of video data
• Up to 700’ HD Transmission Range (Depending on cable characteristics and
integrity)
• Heavy Duty IP68 rated weather/vandal resistant
aluminum construction
• 12VDC / 24VAC Dual Voltage Operation
VTC-BHOCRAZ
2.1MP HD-SDI Vandal Resistant
AFZ/WDR IR Bullet Camera

2
Safety Precaution
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment . This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons .
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent electrical shock and/or fire hazard, use only specified power
source.
Main power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power interruptions, it is
recommended that the model be powered from an uninterruptible power supply
(UPS) or a battery.

3
Safety Precaution
NOTICE
The image used in this instruction manual are processed to help comprehension
and may differ from actual video of the camera.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair have to be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
The camera should never be operated beyond the technical specifications.
The camera should never be operated in water.
Avoid installing in areas where shock or vibration may occur.
Pay attention to safety when installing the connection cable and observe that the
cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
This can lead to damage to the camera and void the warranty.
Never open the device no user serviceable parts

4
Contents
Safety Precaution
Contents
Features
Dimensions
Part Names
Installation Instructions
Operating Instructions
Specifications
p. 02 - 03
p. 04
p. 05 - 06
p. 06
p. 07
p. 08
p. 09 - 11
p. 12 - 25
p. 26
Optional Dome Mounts
Package Includes
p. 29
Warranty

5
Key Features
Features
• Full HD, 2Mega Pixel HD-SDI CAMERA, 1920x1080(30p/25p)
• True WDR(Wide Dynamic Range)
• Improved Noise reduction with the enhanced 3D-NR
• VTC-BHOCRAZ39: f=3~9mm, F1.2~F2.1 Day&Night zoom lens
(Optical 3x Auto focus zoom / Digital 32x zoom)
• VTC-BHOCRAZ922: f=9~22mm, F1.6~F2.3 Day&Night zoom lens
(Optical 2.4x Auto focus zoom / Digital 32x zoom)
• Focusig Status Indicator on Screen
- ★(Blue) Focusing in process
-★(White) Focusing Completed
• Dual Filter Switching
• Pointing Zoom which enables the exible zooming at any area.
• Smart Motion Zoom in combining with Pointing Zoom.
• Selectable Scale down image to 720p mode
• Motion Detection, Privacy Mask, Defog, Sens-up(x32), BLC/HLC,
H/V/HV Flip, D-Zoom(1.1x~8x), LSC(Lens Shade Compensation),
Motion Deblur, Pixel Defect Compensation
• ID / TITLE / ZOOM RATIO DISPLAY
• Enhanced light Sensitivity by DSS technology
• Top performance at low light sensitivity (Sens-up On)
• OSD menu & Video sub-out for easy installation & maintenance.
• Circuit protection against faulty connection in power polarity
• Isolated power supply against ground loop problem
• Remote control via RS-485 (Pelco-D/P)
• Built-in 40 LEDs
• One-touch 3-Axis locking bracket, Easy installation Pad
• Built-in cooling Fan & Heating function
• IP68 protection

6
This camera realizes the natural and crisp image as you see the scene in front
of you by adopting Auto Focus Full HD(1920x1080p) camera module.
Features
General Description
Package Includes
VTC-BHOCRAZ Camera General Operation
Instructions
Complete Installation and
Operation Instructions on CD
• With ICR mechanism
- Enhances its sensitivity about 10x at night time
- Can accept infrared light
• 24VAC/12VDC dual power
- Offers the exibility of installation
- Ensures the reliability
Mounting Template
Torque Wrench:
3mm (1pc)
Video Sub-out
Cable (1pc)
Assembly Screw:
4 x 14mm (4pcs)
Mounting Screw:
4 x 30mm (4pcs)
Plastic Anchor:
6 x 30mm (4pcs)
Easy
Bracket

7
(unit: inches)
Dimensions
3.15
3.31
3.53
4.35
3.39
10.11
3.94 4.37

8
Part Names
CAUTION
Torque
wrench
Lock/Unlock
Screw
• Adjustment of viewing angle
with one-touch 3-Axis bracket
• Extreme care should be taken NOT to scratch the
window in front of lens while installing or adjusting
the camera.
• Care should be taken the cable is NOT damaged,
kinked or exposed in a hazardous area.
• Do not expose the camera lens directly to a strong
light source such as the sun or a spot light.
DUAL WINDOW
SUNSHIELD BOLT
SUNSHIELD
FRONT CASE
OSD Setup
CONTROL COVER
BRACKET
REAR CASE
POWER AND VIDEO CABLE

9
Installation Instructions
1. Locate the mounting template at the installation position and drill the ceiling
or wall if needed. (*The easy bracket can not be installed on the ceiling)
2. Place the easy bracket on pre-drilled position and attach using mounting
screws(4x30mm). Skip this step when an easy bracket is not installed.
3. Route the power cable to the connecting place.
Hook up the camera bracket with the easy bracket as illustrated below.
4. Attach the camera bracket using the assembly screws (4x14mm).
5. Set the camera’s viewing angle.
6. Attach the sunshield to the camera unit and tighten the sunshield-bolt.
Mounting Screw
: 4x30mm
Plastic Anchor
: 6x30mm
1
2
Torque Wrench
REAR VIEW
3
Cable exit
4
Assembly Screw
: 4x14mm

10
Limit of pan & tilt
Installation Instructions
90¡ 90¡
80¡
90¡
–90¡
• Unlock the screw on the camera bracket using the torque wrench supplied
• Set the camera’s viewing angle then lock the screw on the bracket.
1) Pan limit:
Pan is limited to +/- 90°.
2) Tilt limit:
Tilt is limited to 0°(2°) min ~ 90° max.
for wall(ceiling) installation respectively
with reference to the wall(ceiling) when
the inclination of camera module is 0°,
that is, the image is aligned horizontally.
3) Inclination limit
(Horizontal image alignment):
Inclination limited to +/-90° max.

11
Power Supply Connections
• Make sure the power is removed before installation.
• Camera can work with either 24VAC or 12VDC, dual voltage power.
• Primary and secondary grounds are completely isolated to avoid the possible
ground-loop problems
In case that HD-SDI Inputs are not supported by Monitor, please use HD-SDI
Converter to connect HD-SDI cable with Monitor
Please check Specification of Monitor before installation.
Installation Instructions
VIDEO (BNC)
AC24V/GND (Black wire)
AC24V/DC12V (Red wire)
RTX- (Gray wire)
RTX+ (White wire)

12
Operating Instructions
Cover Open
Video Sub-out
Connector
OSD Control
Joy Stick
SUB-OUT
Setup menu can be accessed and controlled by OSD control joy stick on the
side of camera unit.
Five commands are available with the joy stick.
The design of OSD could be different according to the Model.
Description of the joystick operation
Description of the ZOOM&FOCUS adjustment
Using OSD controller
4) denotes long press down for about 2 seconds

13
Operating Instructions
MAIN DEFAULT DESCRIPTION
ZOOM/FOCUS Sets FOCUS MODE, D-ZOOM, LENS REFRESH and LENS INIT
-
EXPOSURE
Sets EXPOSURE MODE, BRIGHTNESS, SENS-UP, AGC and
MOTION DEBLUR.
-
SCENE
ENHANCE
NORMAL
.
Press ☟’
Lens Initializing is strongly recommended at the first stage of setup menu control.
ZOOM/FOCUS > LENS INIT > Press the joystick ☟’straight down for about
2 seconds.
MENU V3.12
1. ZOOM/FOCUS
2. EXPOSURE
3. SCENE ENHANCE
4. 3D-NR
5. DAY/NIGHT
6. PICT ADJUST
7. SPECIAL
8. SYSTEM
9. EXIT
NORMAL
MID
EXT
SAVE&EXIT
OSD menu Start up
Direct Control menu
(OSD menu SET key) down to access the setup menu mode.
SCENE ENHANCE provides several ways to enhance the video
in various environments with the settings in NORMAL, WDR,
D-WDR, BLC and HLC.
NORMAL Optimized for normal indoor and outdoor in good
lighting condition.
WDR Improves the visibility for bright areas and dark
areas by double capture of image with LONG and SHORT
exposures. With WDR ON, the frame rate becomes half by the double
capture. WDR level can be selected from LOW, MID and HIGH.
Care should be taken to select this mode because video may lose
its quality in some environments by over compensation.
CVBS video signal: Connecting 2nd video to CVBS port disables
WDR function temporarily. It should be considered when installer
adjusts the video with installation monitor via CVBS video signal.
D-WDR Improves the visibility by compensating the video gain for
the dark area. Noise can increase in the dark area accordingly.
※

14
Operating Instructions
Sets WHITE BAL, SHARPNESS, COLOR GAIN, GAMMA
PICT ADJUST
Sets MIRROR/FLIP,PRIVACY, MOTION, PIXEL DEFECT, TITLE SET,
DISPLAY, DEFOG, POINTING ZOOM
SPECIAL
Sets TV SYSTEM, RESOLUTION, COMM.SETUP, LANGUAGE and
FACTORY DEFAULT
SYSTEM
SAVE & EXIT — Exits the menu after saving the parameters.
EXIT — Exits the menu without saving the menu.
EXIT
.
DAY/NIGHT
.
.
EXT
for
IR LED
AUTO
for
No IR
LED
SCENE
ENHANCE
NORMAL
3D-NRM ID
.
BLC — Improves the visibility of dark objects caused by bright back
light. Outside area of BLC window can over saturate.
BLC has a target window for compensation and its size and position
can be set by H-POS, V-POS, H-SIZE and V-SIZE.
HLC — Cuts out the highlight area with a black mask and excludes it
from compensation. Lower HLC LEVEL the more sensitive it is to
bright light.
3D-NR is a very sophisticated and powerful time-based noise
reduction technology by monitoring the noise for several video
frames and defining and eliminating them consecutively at low light.
Higher setting reduces more noise but results in losing the sharp-
ness and tail effects or motion blur may occur.
Sets DAY / NIGHT to EXT, AUTO, COLOR or B/W.
SMART IR can be set to reduce saturation by strong IR
illumination at night in any menu of EXT, AUTO and B/W(NIGHT)
Setting SMART IR in any menu is identically applied to other menu.
Zero(0) turns off SMART IR and High setting decreases saturation
but the corners will become darker accordingly.
IR LED Control(AUTO/OFF) is available with IR LED model only.
If IR LED is set to OFF, IR LED will be turned OFF but DAY or
NIGHT
is still determined by the built-in light photo sensor.
EXT — DAY or NIGHT is determined by the built-in light photo
sensor.
Camera with IR LED must be set to EXT.
AUTO — Used when DAY or NIGHT is determined by light level
through
the lens and DAY from/to NIGHT is switched automatically by the
scene brightness.
D<-->N THRESHOLD, D<->N DELY and SMART IR can be set in
the menu. When EXPOSURE>AGC is less than 12, DAY/NIGHT
AUTO is disabled and forcibly switches to ___(DAY) to avoid
malfunction. EXT, B/W(NIGHT) and COLOR(DAY) is independent
on AGC level. When EXTERNAL IR LED is used with NON IR LED
model, please set to IR LED MODE ON.
B/W(NIGHT) — Forcibly removes IR cut filter and switches to B/W
regardless of light level.
COLOR(DAY) — Forcibly DAY/NIGHT is disabled and outputs color
video.

15
Operating Instructions
ZOOM / FOCUS
FOCUS MODE
D-ZOOM
LENS REFRESH
LENS INIT.
RETURN
ZOOM PUSH
OFF
OFF
ON
RET
1. ZOOM/FOCUS
: ZOOM PUSH, AUTO and MANUAL modes are available for focusing.
1-1. FOCUS MODE (default: ZOOM PUSH)
: D-ZOOM(Digital zoom) is available up to 32x. D-ZOOM starts working when
the optical zoom reaches its maximum tele-position. Zoom ratio is displayed
on the right bottom corner of the monitor if SPECIAL>DISPLAY>ZOOM RATIO
is set to ON.
1-2. D-ZOOM (default: OFF)
Initialization automatically. Every initialization occurs when the time reaches
the scheduled time after setup or power up. When LENS REFRESH initiates
LENS Initialization, a notification LENS INITIALIZING appears on the top
left corner on the monitor.
1-3. LENS REFRESH (default: OFF)
: Lens initialization is necessary during the installation or the regular operation
to align the position data with the mechanical positions whose lens elements
example,during the transportation.
LENS INIT starts the lens initialization when pressing the joystick lever straight
down for about 2 sec.
and saves them for the references.
Lens initialization is automatically executed at power up.
1-4. LENS INIT (default: ON ☟’)
LENS REFRESH can be set to 1~10 days and performs a scheduled LENS
may move and deviate from its calibrated position by shock or vibration, for
LENS INIT checks the positions for zoom and focus at both end positions

16
Operating Instructions
EXPOSURE
MODE
BRIGHTNESS
SENS-UP
AGC
MOTION DEBLUR
RETURN
AUTO
OFF
ON
RET
2. EXPOSURE
2-1. MODE (default: AUTO)
: Adjusts the brightness of video(0~20).
2-2. BRIGHTNESS (default: 10)
CAUTION
|:::::::|::::::| 10
|:::::::|::::::| 12
• It is necessary to execute LENS INIT in cases below;
1) At the final step of installation.
2) When out of focus due to shock or vibration.
: Can set EXPOSURE MODE to AUTO, IRIS Priority, SHUT. Priority, MANUAL
and Flickerless. SHUT. Priority, MANUAL and Flickerless modes disable
SENS-UP and MOTION BLUR functions.
• AUTO: Optimizes the video level by controlling the iris and the shutter speed
automatically.
• IRIS Priority: Select to x IRIS in a certain apperture and the video level is
controlled by an automatic shutter control. Lower IRIS LEVEL will close more
iris and increase the field of depth in the daytime but significantly decrease
the low light performance. Too much low IRIS LEVEL will result in foggy
video by diffusion from the lens iris.
• SHUT. Priority: Select to x SHUTTER speed at a certain speed and the video
level is controlled by an automatic iris control.
This mode is useful when color rolling occurs under the uorescent lighting .
It is not recommended for outdoor or daytime.
• MANUAL: Iris and Shutter can be set to xed.
• Flickerless : Reduces the icker in video when US(60Hz)/EU(50Hz) mode is
used in 50Hz/60Hz uorescent lighting respectively.

17
Operating Instructions
.
.
2-3. SENS-UP (default: OFF)
2-4. AGC (default: 12)
2-5. MOTION DEBLUR (default: ON)
: ATW, ATWext, ONE PUSH and MANUAL are available for the white balance
modes.
3-1. WHITE BAL (default: ATW)
WHITE
SHARPNESS
COLOR GAIN
GAMMA
RETURN
ATW
0.5
RET
3. PICT ADJUST
|:::::::|::::::| 10
|:::::::|::::::| 10
: A brighter video can be obtained by increasing the exposure time at night
with SENS-UP. SENS-UP is the maximum integrations of frame by DSS (Digital
Slow Shutter) in low light.
• AUTO: SENS-UP is enabled or disabled automatically by the scene brightness.
Higher SENS-UP can get brighter video but the slower frame rates will cause motion
blur and more white pixels. If set to AUTO, maximum integration limit for SENS-UP
can be set to x2, x4, X8, x16, X32 in SENS-UP menu.
• OFF: Disables SENS-UP.
: AGC amplifies the video gain for brighter video but will cause noise and white pixel
accordingly.
AGC level less than 10 disables AUTO in DAY/NIGHT.
: ON enables MOTION DEBLUR to reduce the motion blur in certain indoor
environments. Noise or color rolling can increase.

18
Operating Instructions
¥ OFF : Normal display without mirroring or flipping
¥ Hor.: Video is reversed left and right
¥Ver. : Video is reversed upside down
¥ HV :Video is reversed left and right and upside down
When the video is reversed by Ver. or HV, then the joystick directions are
reversed accordingly.
: Reverses the video left and right and/or up and down by MIRROR/FLIP.
4-1. MIRROR/FLIP (default: OFF)
¥ ZONE NUMBER : Set a number to select a privacy zone from 1~10.
¥ ZONE DISP: ON enables to display relevant privacy zone
¥ H-POS, V-POS, H-SIZE and V-SIZE : Adjust the size and position of zone.
¥ COLOR : Select the color used for masking the zone form eight colors.
¥TRANSPARENCY : Defines the transparency for the mask zone.
4-2. PRIVACY
SPECIAL
MIRROR/FLIP
PRIVACY
MOTION
PIXEL DEFECT
TITLE SET
DISPLAY
DEFOG
POINTING ZOOM
RETURN
OFF
OFF
OFF
OFF
RET
4. SPECIAL
: Adjusts the sharpness of video.
3-2. SHARPNESS (default: 10)
: Adjusts the color level of video.
3-3. COLOR GAIN (default: 10)
: Adjusts the gamma of video.
3-4. GAMMA (default: 0.5)
This feature is very useful when a camera is installed upside down.
: 10 Privacy zones which can be enabled individually by ZONE DISP are
available to mask the video

19
Operating Instructions
4-3. MOTION (default: OFF)
.
4-4. PIXEL DEFECT (default: OFF)
4-5. TITLE SET
¥ Set the direction of video by MIRROR/FLIP before SMART MOTION ZOOM
setting. Otherwise ZOOM TARGET could be different from your intention.
CAUTION
: MOTION can detect the changes in the motion window and displays the
results
in blocks and/or a text message.
• SENSITIVITY : Adjusts the detection sensitivity for motion.
Higher value increases the sensitivity to detect small motion easier. Too low
of sensitivity will cause erratic detection.
• H-POS,V-POS, H-SIZE and V-SIZE -
Adjust the size and position of the detection window.
• BLOCK DISP : ON enables to display the blocks for the detected area.
• MOTION OSD : ON enables to display a text message, MOVING !!!,
• SMART MOTION ZOOM : ON enables to Automatic Zoom IN/OUT when
motion is detected and also enables MOTION OSD to ON.
Area to be zoomed in by SMART MOTION ZOOM can be set at SPECIAL>
MOTION> SMART MOTION ZOOM>ZOOM TARGET. Adjusting
◀
,
▶
(Joy-
stick) for ZOOM TARGET varies the viewing angle to be zoomed when
motion occurs. Set the video left and right and/or up and down by MIRROR/
FLIP.
SMART MOTION ZOOM does not work in low light condition and BW
• STAY ZOOMING : Sets the duration time for zooming by Motion.
: Detects and compensates the white pixels which become defective.
Once CALIBRATE is selected, the pixel calibration is initiated with lens
closed and can not be canceled.
• THRESHOLD : Denes the level of detection and low value defective pixels.
Be sure to set the value so that the pixels are uniformly blinking over the en-
tire screen. Too low of value will get bad results because too many pixels are
detected as bad pixels and the maximum number of pixels for compensation
will be filled by the upper area.
• EXECUTE ’: Long pressing will execute the pixel calibration for the detect-
ed pixels. Menu will exit automatically after compensation.
※
☟’

20
Operating Instructions
choose a character and ☟’selects it. The selected characters are added and
displayed on the top left Corner and the cursor moves right automatically for
next input.
.
¥ ZOOM RATIO : ON enables to display the zoom ratio on the bottom right
corner. OZx.x appears during the optical zoom and DZx.x will display by
multiplying the optical zoom ratio and the actual digital zoom ratio.
¥ FOCUS INDICATE : * mark on the bottom right corner indicates the focusing
status in blue during focusing and white after finishing.
4-6. DISPLAY
4-7. DEFOG (default: OFF)
ON enables to set off-centered location to be the center of zoom H-POINTER,
V-POINTER- Able to set the location of zoom center D-Zoom is available to
~ 32x.
4-8. POINTING ZOOM
¥ Set the direction of video by MIRROR/FLIP before POINTING ZOOM setting.
Otherwise location of zoom center could be different from your intention.
CAUTION
Detail Function Description
: Enables or disables the OSD display.
• ID : ON enables camera ID display dened by SYSTEM>COMM.
SETUP>CAM ID.
• TITLE : ON enables camera ID display set by SPECIAL>TITLE SET
• AUTO : Enhance foggy video automatically according to status of scene.
• MANUAL : Sets to enhance foggy video manually regardless of status of scene.
• LEVEL : LOW, MID, HIGH
Video quality can be less in normal environments.
SMART MOTION ZOOM enlarges the area dened by a yellow window
to a full size image when motion is detected in the black window.
SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO
and moved by H-POINTER and V-POINTER.
