Vitek VTC-TNT4FL-2 User manual

VITEK
VITEK
VTC-TNT4FL-2
Transcendent Series 4
MegaPixel Indoor/Outdoor IP
Fixed Turret Camera
FEATURES
• 1/2.7” 4.0 Megapixel CMOS Image Sensor
• Up to 30fps @ 4MP (2560 × 1440), 3MP (2304 × 1296), 1080P (1920 ×
1080), 720P (1280 × 720), D1, CIF, 480 × 240
• 2.8mm Fixed Iris Lens
• Matrix IR with up to 100’ IR Range
• Digital Wide Dynamic Range (D-WDR)
• True Mechanical Day/Night function by ICR
• XD-DNR (3D & 2D-DNR) Noise Reduction
• Built-in Mic*
• Region Intrusion Detection, Scene Change Detection, Line Crossing, Object
Removal, Video Blur Detection
• H.265, H.264 Compression
• MicroSD Card Slot for Local Recording (Up to 128GB)
• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps
• ONVIF Compliant
• IP67 Weather Resistance
• Optional Junction Boxes (VT-TJB08, VT-TJB01), Wall Mounts (VT-TWMT-3,
VT-TWMT-A1), Pendant Mounts (VT-TPDMT-A1 [reqs. VT-TJB08],
VT-TPDM-2 [reqs. VT-TJB01] Available
[for other mount options, see page 9]
• 12VDC & PoE (Power over Ethernet) Operation
• 2-Year Warranty
*Please research local, state and federal laws regarding the implementation of audio surveillance.
PLEASE NOTE:
Complete User Guide, Software, Tools, and Updates are
available online. Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
NDAA
COMPLIANT

2 3
Network Cable & Power Connections
First connect the Waterproof Cap to an Ethernet patch cable, then
connect the cameras ethernet adaptor. If not powering the camera
with PoE, also connect the power Cable to an approved 12VDC
power supply.
Overview
Components and Accessories
Camera
Quick Guide
Screws
Allen Key
Drill Template
Rubber Plug
Waterproof Cap
Ethernet connector
Mounting base
Micro SD card slot
Reset
1
6
2
7
3
5
4
Power connector
Microphone
Fixed screw
1
2
3
4
5
6
7
DC12V
Weather Resistant Security Cap

3
Weather Resistant Network Coupler
1. Loosen the nut from the Weather Resistant Network Coupler,
2. Run ethernet cable through coupler, then attach a RJ-45 connector.
3. Tighten the nut and coupler for a weather resistant seal.
Installation
Before beginning installation, make sure that the wall or ceiling is
strong enough to withstand 3 times the weight of the camera.
1. Attach the drill template to
the place where you want to
install the camera, then drill
3 screw holes and 1 cable
hole (if you want to route the
cables through the mounting
base) according to the drill
template
2. Route the cables and connect the power & video cables, using the
rubber plug to fill the gap of the mounting base, then secure the
mounting base to the ceiling or wall with screws (see fig. 2 on next
page).
∅
∅3.84”
∅.17”
1.92”
120° 120°
.96”
3.22”
4.25”
MicroSD Card Installation: Remove the bottom of the cover from the
camera, insert card and replace the cover (be sure it is even).
Cover Insert a micro SD card
Fixed Screw

4 5
Lock Screw
3. Loosen the lock screws,
then adjust the camera
to obtain the optimium
viewing angle. Confirm
the correct viewing
angle with a monitor.
Next, tighten the lock
screw to secure the
viewing angle adjust-
ments.
Fig. 2
Rubber Plug

5
LAN Configuration
The camera can be accessed on the local network either using the
IP-Tool or directly in a web browser.
Accessing the Camera Using the IP-Tool
1. Make sure the camera and PC are connected to the LAN.
2. Locate the IP-Tool installer at www.
vitekcctv.com/Downloads/Soft-
ware/Transcendent-IPTool_v2.0.2.zip
, then install on the PC. Open
the installed application.
3. Modify the IP address. The default IP address is 192.168.226.201.
Click the information of the camera listed in the above table to show
the network information on the right side. Modify the IP address and
gateway of the camera and make sure its network address is in the
same local network segment as the computer’s. Please modify the
IP address of your device according to the practical situation.
For example, the IP address of your computer
is 192.168.13.4. So the IP address of the
camera shall be changed to 192.168.13.X.
After modification, please input the password
of the administrator and click “Modify” button
to modify the setting.
** Default admin password: “123456".
MENU
IP Camera
Network Cable Network Cable
Switch
Router Computer

6 7
4. Double-click the IP address and then the system will pop up the web
browser to connect IP-CAM . IE browser will download the Active X
control. After downloading, a login window will pop up as shown
below:
Input the user name and password to log in.
Default user name: admin / Default password: 123456.
Directly Access Through a Web Browser
The default network settings are as shown below:
IP address: 192.168.226.201 HTTP: 80
Subnet Mask: 255.255.255.0 Data Port: 9008
Gateway: 192.168.226.1
You may use the above default settings when you log in the camera for
the first time.
1. Manually set the IP address of the PC. The network segment should
be the same as the default settings of IP-CAM. Open the network
and share center. Click “Local Area Connection” to pop up the
following window.
Select “Properties” and then select Internet protocol according to the
actual situation (for example: IPV4). Next, click “Properties” button to
set the network of the PC.

7
2. Open the IE Browser and input the default address of IP-CAM and
confirm. The IE browser will download Active X control.
3. After downloading Active X control, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
WAN Configuration
Access the camera by the router or virtual server for example.
1. Make sure the camera is connected to the LAN; Then log into the
camera via LAN and go to System Congfig→Network Config→Port
menu to set up the port number.
2. Enter System Config→Network Config→IP Address menu to modify
the IP address.
4. Open the web browser and input its WAN IP and HTTP port to
access the IP-CAM.
3. Go to the router’s management interface through IE browser to
forward the IP address and port of IP-CAM in the “Virtual Server”.
5. For additional setup, features and functions, please scan the
QR code on the front page of this quick guide and download
the complete manual.

8 9
Image Sensor, Size
Resolution
Min. Illumination
Lens
Day / Night
IR LEDs / IR Distance
Video Compression
Main-Stream
Sub-Stream
Third Stream
Bit Rate
Bit Rate Type
Other Camera Features
Wide Dynamic Range (WDR)
Digital Noise Reduction (DNR)
Image Setting
Analytics
Smart Alarm
Region of Interest (ROI)
Network
Audio
Storage
Remote Viewing
Supported Browsers
Connection Protocol
Resistance
Power Input
Power Consumpt. (12VDC)
Power Consumpt. (PoE)
Working Environment
Weight, Dimensions: Dia × H
1/2.7” 4.0 Megapixel CMOS Image Sensor
4MP(2560 × 1440), 3MP(2304 × 1296), 1080P(1920 × 1080), 720P(1280 × 720), D1, CIF, 480 × 240
0.011 lux @F1.2, AGC ON; 0 lux with IR, 0.04 lux @ F2.2, AGC ON; 0 lux with IR
2.8mm Fixed Iris Lens
True Day/Night by ICR
1 Matrix / 100’
H.265 / H.264
60Hz: 4MP/3MP/1080P (1~30fps), 50Hz : 4MP/3MP/1080P (1~25fps)
60Hz : 720P(1~15fps)/D1 /CIF (1~30fps), 50Hz: 720P(1~12fps)/D1(1~25fps)/CIF (1~25fps)
60Hz : D1/CIF/480x240 (1~30fps), 50Hz: D1/CIF/480x240 (1~25fps)
64Kbps ~ 12Mbps
VBR / CBR
BLC, HLC, Defog
D-WDR (Digital Wide Dynamic Range)
XD-DNR (2D-DNR & 3D-DNR)
Saturation, Brightness, Chroma, Contrast, WDR, Noise reduction
Object Removal, Scene Change, Video Blur Detection, Intrusion and Line Crossing
Motion Alarm, SD Card Error, SD Card Full
Each ROI to be Configured Separately
RJ45
Built-in Mic*
MicroSD Card Slot (128GB)
CMS / Web Browser / Mobile (iOS/Android)
Microsoft Internet Explorer
ONVIF
IP67 Weather Rating
12VDC / PoE
150mA (LEDs Off) / 320mA (LEDs On)
< 5W
-22° ~140° / < 95% Humidity
16.58 oz. / 1.04 lbs. / 460g, 3.77” x 4.25” (95.7 × 108mm)
VTC-TNT4FL-2 Detailed Specifications
*Please research local, state and federal laws regarding the implementation of audio
surveillance.

9
OPTIONAL MOUNTS FOR
VTC-TNT4FL-2
VT-TWMT3
Optional Wall
Mount
VT-TJB01
Optional
Junction Box
VT-TJB08
Optional
Junction Box
VT-TPDMT-A1
Transcendent
Universal 10”
Pendant Mount.
Reqs. VT-TJB08
VT-TWMT-A1
Transcendent
Wall Mount. Reqs.
VT-TJB08
VT-TPLMT
Transcendent
Universal Pole
Mount - Ivory,
reqs. VT-TJB08
VT-TCNMT
Transcendent
Universal Corner
Mount - Ivory,
reqs. VT-TJB08
8.46”
6.43”
8.46”
8.47”
5.10”
6.10”
2.93”
1.46”
6.28”
2.50”
1.46”
5.83”
VT-TPDM-2
Transcendent
Universal 10”
Pendant Mount.
Reqs. VT-TJB01

10 11
RELATED PRODUCTS FOR
TRANSCENDENT IP CAMERAS
VT-TNR1626PL
VT-TNR414PL
VT-TNR818PL
NEW Vitek Transcendent
LITE Version 4, 8, and 16 Ch.
6 MegaPixel Real Time PoE
Network Video Recorders!
VT-TNR414PL, VT-TNR818PL,
VT-TNR1626PL
• Stand-alone Real-time IP Network Video Recorders w/ 1080P Hi Res Display
• Network Input: 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
• 6MP @20fps (NTSC/PAL), 5MP or lower @30fps/25fps (NTSC/PAL)
• Plug and Play & Auto Configuration for Leading ONVIF Compliant IP Camera Models
• H.265+ / H.265S / H.265 / H.264 Video Compression
• Video Content Analysis: Object Removal, Region Intrusion, Tripwire, Exception
• License Plate Recognition
• SATA2.0: Up to 20TB (Model Dependant)
• All Model Video Output
• LAN + USB2.0
• HDMI & VGA Video Output

11
Also Consider Vitek Wireless Access Points to
Reduce Costly Cable Installation!
VT-WAP1150 and VT-WAP2150 High Speed 5.8GHz DIP
AP / CPE Wireless Bridge w/ 8MB Storage, 64MB RAM,
150MBps transmission, and Point-to-Multi-Point (P2MP)
Topology
With high speed transmission of 150Mbps and a wireless range
of 3000ft. (VT-WAP1150) and 1.25 miles (VT-WAP2150) these
products eliminate the need for expensive and troublesome long-
distance cables in areas where CCTV monitoring and rigorous
surveillance take place. These small, lightweight and durable units are
easy to install and easy to use with an innovative and straitghtforward
10-button plug-and-play dip switch that facilitates the creation of a
robust wireless network without a computer. Set-up can be simply
configured for point-to-point or point-to-multipoint topology depending
on the application, with up to 128 IP group configurations!
VT-WAP1150 VT-WAP2150

28492 CONSTELLATION ROAD VALENCIA, CA 91355
WWW.VITEKCCTV.COM
Version 1.0
Nov. 2020
LIMITED PRODUCT WARRANTY
This VITEK product carries a two (2) year limited warranty. VITEK
warrants to the purchaser that products manufactured by VITEK are free
of any rightful claim of infringement or the like, and when used in the
manner intended, will be free of defects in materials and workmanship for
a period of two (2) years, or as otherwise stated above, from the date of
purchase by the end user. This warranty is nontransferable and extends
only to the original buyer or end user customer of a VITEK Authorized
Reseller.
The product must have been used only for its intended purpose, and
not been subjected to damage by misuse, willful or accidental damage,
caused by excessive voltage or lightning.
The product must not have been tampered with in any way or the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
VITEK makes no warranty or guarantee whatsoever with respect to
products sold or purchased through unauthorized sales channels.
Warranty support is available only if product is purchased through a
VITEK Authorized Reseller.
