VITEK
VT-IPSD102H
Dual Streaming IP Server
with H.264 Compression
• High quality of compression algorithm (H.264/MJPEG)
• H.264 + H.264 / H.264 + MJPEG Dual Streaming
• Encoder/Decoder selectable
• Full-duplex audio/video transmission
• 30fps/25fps @ full D1 resolution
• 1:N Multi-casting and relayed data transmission
• Protocols : TCP/IP, Multicast, HTTP, SMTP, SNMP, FTP, DHCP, DNS, Dynamic DNS,
RTP, RTSP
• Real time monitoring/recording/playback through CMS viewer S/W and Internet
Explorer
• Dynamic IP support with Dynamic DNS
• Power over Ethernet(PoE) support
• Data storage against network failure or event (USB2.0)
• Watchdog for system recovery
• Support for PTZ and Controller
• Motion detection

VT-IPSD102H Manual
-1-
Safety Precaution
Make sure to turn off the power before installing the VT-IPSD102H.
Do not install under direct sunlight or in dusty areas.
Make sure to use the product within the temperature and humidity that is specified.
Do not operate the product in the presence of vibrations or strong magnetic fields.
Do not put electrically conducting materials in the ventilation hole.
Do not open the top cover of the product. It may cause a failure or electric shock on the
components.
To prevent from overheating, make sure to keep the distance at least 10cm from the ventilation
hole.
Check for proper voltage before connecting the power.

VT-IPSD102H Manual
-2-
Table of Content
Table of Content......................................................................................................................................2
1. Introduction .........................................................................................................................................4
1. About User Manual ......................................................................................................................4
2. Feature.........................................................................................................................................4
3. Product and Accessories .............................................................................................................6
4. Part Names and Description........................................................................................................7
5. System Modes and Connections.................................................................................................9
2. Installation.........................................................................................................................................12
1. Connecting Video.......................................................................................................................12
2. Connecting Audio.......................................................................................................................12
3. Connecting Serial Ports.............................................................................................................12
4. Connecting Sensor and Alarm...................................................................................................12
5. Connecting Power......................................................................................................................12
6. Checking Operating...................................................................................................................13
3. System Operation .............................................................................................................................14
1. LED Display...............................................................................................................................14
2. Remote Video Monitoring ..........................................................................................................15
3. Initialization of IPAddress..........................................................................................................16
4. Remote Configuration.......................................................................................................................17
1. Remote Configuration................................................................................................................17
2. Encoder Configuration...............................................................................................................17
2.1 System Configuration .......................................................................................................18
2.2 Video Configuration..........................................................................................................20
2.3 Audio Configuration ..........................................................................................................24
2.4 Network Configuration......................................................................................................25
2.5 Serial Port Configuration ..................................................................................................28
2.6 Event Configuration..........................................................................................................30
2.7 Preset Configuration.........................................................................................................33
2.8 User Configuration............................................................................................................34
3. Decoder System ........................................................................................................................36
3.1 Video Configuration..........................................................................................................36
3.2 Network Configuration......................................................................................................37
3.3 Event Configuration..........................................................................................................39
5. ENVI Visual Management Software (VMS) ......................................................................................41
1. ENVI Visual Management Software ..........................................................................................41
2. Server Registration and Removal..............................................................................................41
3. Server Connection Management...............................................................................................43

VT-IPSD102H Manual
-3-
4. Server Status Monitoring ...........................................................................................................44
5. Network and System Diagnostics..............................................................................................45
6. F/W Upgrade..............................................................................................................................48
7. Remove Configuration and Video Monitoring............................................................................49
6. Trouble Shooting...............................................................................................................................49
Appendix A: Sensor and Alarm Port......................................................................................................50
1. Sensor Port................................................................................................................................50
2. Alarm Port ..................................................................................................................................50
Appendix B: Serial Port..................................................................................................................51
1. RS-232 Port ...............................................................................................................................51
2. RS-422/485 Port........................................................................................................................51

VT-IPSD102H Manual
-4-
1. Introduction
1. About User Manual
This user manual provides information on operating and managing the optimal video surveillance
system, VT-IPSD102H. The manual includes instructions for installation, operation and configuration
of VT-IPSD102H as well as how to troubleshoot.
2. Feature
VT-IPSD102H is a video and audio surveillance transmission system based on IP network through
LAN, ADSL/VDSL, and Wireless LAN. The VT-IPSD102H series operates as one of two modes:
Encoder or Decoder. The Encoder system compresses and transmits video data. Decoder receives
and decompresses the video data.
Video
-High-quality compression algorithm, H.264 & MJPEG support
-Compression in various resolution: CIF, Half-D1 and D1
-Wide range of video transmission rate: 32kbps ~ 8Mbps
-Various transmission mode: CBR and VBR
-Motion Detection
Audio
-Multi-transmission mode: Uni-direction (Encoder -> Decoder, Decoder -> Encoder), Bi-
direction
Network
-Fixed IP & Dynamic IP (DHCP) support
-1:1, 1:N support
-Multicasting
-Automatic transmit rate control according to network condition
Serial Data
-Two serial ports
-Various PTZ camera protocol
-Data pass-through mode: Serial data communication between Encoder –Decoder
Sensor and Alarm
-Support direct connections of external sensor and alarm devices.
-Event Alarm

VT-IPSD102H Manual
-5-
USB
-Connection to internal or external USB storage for remote access
User Interface
-System status display utilizing OSD (On Screen Display)
-Diagnose and upgrade through dedicated program called ENVI VMS
-System configuration using Internet Explorer
High Reliability
-Reliable embedded system
-System recovery utilizing dual watch-dog functions

VT-IPSD102H Manual
-6-
3. Product and Accessories
VT-IPSD102H Quick Manual
Power adaptor and cable User Manual & S/W CD
Screws Brackets
<Picture 1> Product and Accessories

VT-IPSD102H Manual
-7-
4. Part Names and Description
Front View
Parts
Function
LEDs
Display power On/Off condition, Link, Status and Data
Audio In, Out
Audio Input and Output
USB
USB port for any USB device
LAN(Ethernet)
100/10-base-T Ethernet interface
Reset button
Initialization of network setting






VT-IPSD102H Manual
-8-
Rear View
Terminal
Function
POWER IN
DC 12V power input
SENSOR
Sensor input
ALARM
Relay output
RS-422/485
(COM2)
Serial port 2 (COM2) for PTZ control and etc. Support RS-422 and
RS-485 protocol
RS-232 (Com1)
Serial Port 1 (COM1) for PTZ control and etc. Support RS-232
protocol
VIDEO OUT
Video output
VIDEO IN
Video input








VT-IPSD102H Manual
-9-
5. System Modes and Connections
The VT-IPSD102H system operates in one of two modes: Encoder or Decoder. The VT-IPSD102H
system can be connected in either a ‘1-to-1’fashion, where one encoder is connected to one decoder,
or a ‘1-to-many’fashion, where one encoder is connected to many decoders.
The following chart shows possible combinations of video, audio and serial data transmission.
System Mode
Video
Audio
Serial Data
Encoder
Transmit
Transmission/Receive
Transmit/Receive
Decoder
Receive
Transmission /Receive
Transmit/Receive
Therefore, the system modes are defined by the video communication and all system modes are
capable of bi-directional transmission of audio or serial data.
Topology
Generally, the encoder and the decoder are connected in a 1-to-1 mode. To support specific situations,
1-to-many connection is also supported.
1:1 Connection (Unidirection)
The most commonly used configuration is the 1 to 1 connection. An encoder is installed at a site
where video images can be transmitted and a decoder is installed at a center location to receive and
view the video images on analog monitor.Audio and serial data are transferred in either direction.
Encoder
Decoder
Site
Remote Center

VT-IPSD102H Manual
-10-
1:N Connection (Unidirection)
In this configuration, a site can be monitored from many remote center locations. Although up to 64
decoders can be connected to on encoder, in the real network environment, network bandwidth can
limit the maximum connections.
Functionally, the VMS (Video Management System) software can replace the decoder.
Multicast Mode
In 1:N Connection, the network that supports multicasting, a large number of decoders, can receive
video efficiently from an encoder transmitting a single streaming of video and audio.
Relaying
In this arrangement, video and audio can be retransmitted from one center to another center. The
arrangement is useful when the network bandwidth to the site is limited while there is more than one
center wanting to monitor the site.
Encoder
Decoder
Site
Center 1
Decoder
Center 2
Encoder
Decoder
Decoder
Decoder
Remote Center
Site

VT-IPSD102H Manual
-11-
VMS (Video Management System)
VMS SW is a Windows based remote monitoring program to access multiple encoders for real-time
monitoring or control of the encoders and connected cameras. Please refer to VMS User Manual for
more information on VMS.
Encoder
Decoder
Site
Remote Center
Encoder
VMS
VMS
Site
Remote Center

VT-IPSD102H Manual
-12-
2. Installation
1. Connecting Video
Encoder System
-Connect the camera video output line to the encoder VT-IPSD102H video input port.
Decoder System
-Connect the monitor video input line to the decoder VT-IPSD102H video output port.
2. Connecting Audio
Audio is bi-directional in any configuration regardless of the system mode. If necessary, it can be
configured to be in transmit-only, receive -only or bi-directional mode.
-Connect audio input and output ports to audio devices accordingly.
-Audio signal is in line level, therefore, microphone or speaker with amplification function should
be used.
3. Connecting Serial Ports
For camera control, the PTZ controller (keyboard) and receiver can be connected to serial ports. Two
corresponding serial ports in encoder and decoder which are connected in 1-to-1 fashion works in
pass-through mode. This means that commands at a local system’s COM1 port will be transparently
passed to the remote system’s COM1 port. Also, a command at a local system COM2 port will pass to
the remote system’s COM2 port.
4. Connecting Sensor and Alarm
Connect sensor and alarm devices to corresponding terminals.
5. Connecting Power
After confirming the power source, connect power adaptor and connect the 12VDC connector to the
system.

VT-IPSD102H Manual
-13-
6. Checking Operating
Once the power is supplied to the camera, it will start booting. The system will boot up to an operating
mode after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the
system is ready.
Software provided on the disc called ENVI VMS allows you to check the IP address and other network
details of the camera.
Encoder LED Display
The above LED status display shows that neither camera or decoder are connected. Once the
encoder is connected to a decoder, the color of link LED will light in green and the LED will blink as
video or audio transmissions occur.
Decoder LED Display
The above LED status display shows that the encoder has started without connecting to an encoder.
Once an encoder is connected, the color of link LED will be changed to green and the LED will blink
as video or audio data transmissions occur.
PWR
STATUS
LINK
Red
Green
Blinking
DATA
OFF
PWR
STATUS
LINK
DATA
OFF
Red
Green
Blinking
OFF
Red
Blinking

VT-IPSD102H Manual
-14-
3. System Operation
1. LED Display
Description of LEDs
System status can be monitored with LEDs.
LED
State
Description
PWR
Off
No power
Red
Power on
STATUS
Green blinking
Normally operating
Red
System failure: Needs diagnostics
Constant change of colors
between Red and Green
NTSC/PAL setting does not match with input
video signal
Red Blinking
Failed to obtain IP address in DHCP mode
Constant change of colors
between Green blinking 2
times and Red blinking
once
Failed to register on DDNS server
Green blinking, Red blinks
once every 5 seconds
Video loss in Encoder system
Orange blinking
Improper resolution setting in duplex mode
LINK
Off
No connection to remote system
Green
Connected to a remote system
Red blinking
Decoder only: trying to connect to an Encoder
Orange
Illegal connection (unsupported combination of
system modes)
DATA
Green
Data transmission in progress
Red
Data loss
Off
No data transmission

VT-IPSD102H Manual
-15-
2. Remote Video Monitoring
There are two ways to view the remote video when the connections are completed between a site and
center system. In order for a proper operation, an IP address must be set accordingly.
Video Monitoring with Decoder System
Once the encoder IP address is set in the remote IP address section of the decoder, the decoder
system will connect to the encoder system and start receiving the video images. Normally, a monitor
connected to the decoder will display video images.
Video Monitoring using Internet Explorer
If the VT-IPSD102H’s IP address is entered in Internet Explorer, the system will ask for confirmation to
install Active-X control. Once authorized, Internet Explorer will start to display video images from the
encoder as shown below.
Video Selection
If Primary is selected, Max. 720 x 480 (NTSC) or 704 x 756 (PAL) via H.264 compression
algorithm video can be displayed. And once activated Dual Video compression and Secondary
may be selected, H.264 or MJPEG compression algorithm video can be displayed in this case.
.
Screen Size:
Adjustable Screen Size
Digital Zoom:
Max 5x Digital Zoom is available.
http://192.168.10.100

VT-IPSD102H Manual
-16-
Focus Near, Focus Far, Auto Focus
Adjust the focus
Sensor Input
When the sensor on the VT-IPSD102H is connected and working, the light turns red.
Alarm Output
Alarm Output button can trigger an event directly from the Live View page.
Snapshot
Snapshot button saves a snapshot of the video image currently on display. Captured picture
can be stored as BMP or a JPEG file.
Talk
Transfer audio to audio device connected to the VT-IPSD102H.
3. Initialization of IP Address
If a system IP address is lost, the system can be reset to a known IP address using the reset button in
the back side of the system:
While system is in operation, press the reset button for 5+ seconds.
The system will reboot automatically
Once the system has been rebooted, the IP address will be set to the following.
-IP mode: Fixed IP
-IP address: 192.168.10.100
-Subnet mask: 255.255.255.0
-Gateway : 192.168.10.1
-Base port : 2222
-Http port : 80

VT-IPSD102H Manual
-17-
4. Remote Configuration
1. Remote Configuration
The server can be configured using a web browser. Type the IP address of VT-IPSD102H in the
address input area of Internet Explorer, then a live viewing screen will be displayed. Press Setup
button located in the upper right area of the monitoring screen, then the server setup page will be
displayed.
The remote configuration window may be slightly different depending on the system modes (Encoder,
Decoder). The general explanation of the configuration in this manual is based on Encoder system
and differences according to the modes will be clarified when needed.
The configurations are grouped into 8 categories: System, Video, Audio, Network, Serial, Event,
Preset and User. No configuration changes are applied until Apply is pressed. Leaving the page
without pressing Apply will discard any changes.
2. Encoder Configuration
While most configuration items are common for Encoder, Decoder and Duplex mode, there are items
that are relevant to specific system mode. All the configuration items for Encoder mode were
explained first. Then, items specific only to Decoder and Duplex modes are described respectively.
Sections for Decoder and Duplex will not include items common for all modes.
Enter IP Address
Press Setup button

VT-IPSD102H Manual
-18-
2.1 System Configuration
System Mode
System mode: Select Encoder, Decoder
System ID
System ID: Alphanumeric System ID to be transferred to remote software
Language
Language to be used for web-based configuration
Firmware version
Current firmware version

VT-IPSD102H Manual
-19-
Board ID
Network board ID of VT-IPSD102H recognized by system
Start Time
Latest system boot date and time
Current Time
Current date & time: Enter a new date and time and press Set Current Time button to
update date & time.
Time Zone
Time zone: Select time zone of where the system is installed. Depending on the time zone,
Daylight Saving Time will work automatically.
Automatically synchronize with NTP server
Synchronize system time with an NTP server using NTP (network time protocol). Name of the
NTP server should be registered on NTP server Name.
Reboot Server
Pressing Reboot Server button will cause the system to reboot. Do not press the Reboot
button unless the server needs a reboot.
Factory Reset
Set all settings to the factory default values. System log and user registrations are also
cleared.
