VT-IPS402H Dual Streaming IP Server
with H.264 Compression
• H.264 + H.264 / H.264 + MJPEG Dual Streaming
• 4CH Video Encoding
• Full-duplex audio/video transmission
• 30fps/25fps @ full D1 resolution
• Protocols : TCP/IP, Multicast, HTTP, SMTP, SNMP, FTP, DHCP, DNS, Dynamic DNS , RTP, RTSP
• 1:N Multi-casting and relayed data transmission
• Real time monitoring/recording/playback through CMS viewer S/W and Internet Explorer
• Dynamic IP support with Dynamic DNS
• Power over Ethernet(PoE) support
• Data storage against network failure or event (USB2.0)
• Watchdog for system recovery
• Support for PTZ and Controller
• Motion detection
FEATURES

blackyellowmagentacyan
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VT-IPS402H Dual Streaming IP Server
with H.264 Compression
System Mode
Network Interface
Network Protocol
Standards
Data Rate
Resolution
Max Frame Rate
Frame Rate Range
Input
Motion Detection
Standards
Sample Rate
Data Rate
Input
Output
Port1
Port2
Data Rate
Sensor Input
Alarm Output
Beep
Reset Button
System Status
Recording/Backup
CMS/Web Viewer
Dimension
Weight
Power Source
Power Consumption
Operating Temp.
Detailed Specifications
Encoder
Ethernet 10/100Base-T (RJ-45)
TCP/IP, UDP, Multicast, DHCP, SMTP, HTTP, SNMP, RTP, RTSP
Main Stream: H.264
Secondary Stream: H.264, MJPEG
32Kbps ~ 2Mbps
NTSC : 720x480, 720x240, 352x480, 352x240
PAL : 720x576, 720x288, 352x576, 352x288
NTSC : Max 30fps / PAL : Max 25fps
NTSC : 0.2 ~ 30fps / PAL : 0.2 ~ 25fps
4 x Composite (1 Vpp 75 Ohm, BNC)
Sensitivity Adjustment
G.711
8KHz
64Kbps
1 x Line-In (Mini-stereo, Single Mono)
1 x Line-Out (Mini-stereo, Single Mono)
1 x RS-232 (Terminal Block)
1 x RS-422/485 (Terminal Block)
2,400bps ~ 115,200bps
4 x NO Contact (Terminal Block)
4 x NO Contact (Terminal Block)
1 x Buzzer 88dB Min
1 x Factory Reset Button
LED
1 x USB 2.0 Port
Live Monitoring, Recording, Search & Playback, Backup
134(W) X 125(D) X 35(H)mm
486g
DC 12V/0.5A, PoE(Power over Ethernet): 802.3af
Max 6W
-10°C ~ 50°C / 14°F ~ 122°F
