Vivitek D-635MX User manual

D-635MX
User Manual
China Projectors Group Room 207, 2/F., Block B, Seaview Estate, Watson Road, North Point, Hong Kong.
Telephone: [phone] Fax: [phone] E-mail: [email protected] Website: http://www.chinaprojectors.com
Multi-Media DLP projector

Copyright
This publication, including all photographs, illustrations and software, is protected under international copy-
right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be
reproduced without written consent of the author.
© Copyright September, 2004
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no repre-
sentations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.
Trademark Recognition
All product names used in this manual are the properties of their respective owners and are acknowledged.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
— ii —
Important Safety Information
Congratulations on purchasing the DLP projector!
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years safe use of the projector. Keep
this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following boxes are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause per-
sonal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
Main Features
• Lightweight unit, easy to pack away and transport
• Compatible with all major video standards including NTSC, PAL, and SECAM
• A high brightness rating allows for presentations in daylight or in lit rooms
• Supports resolutions up to XGA at 16.7 million colors to deliver crisp, clear images
• Flexible setup allows for front rear and ceiling projection
• Line-of-vision projections remain square, with advanced keystone correction for angled
projections
• Input source automatically detected

P
P
Pr
r
re
e
ef
f
fa
a
ac
c
ce
e
e
–iii –
Remote Control
The remote control has a laser for pointing out items on a screen.
DANGER: Do not point the laser in the eyes. Doing so can damage the eyes permanently.
General Safety Information
 Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
 Follow all warnings and cautions in this manual and on the unit case.
 The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
 Do not place the unit on an unstable surface, cart, or stand.
 Avoid using the system near water, in direct sunlight, or near a heating device.
 Do not place heavy objects such as books or bags on the unit.
Power Safety
 Only use the supplied power cord.
 Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
 Remove the batteries from the remote control when storing or not in use for a prolonged period.
Replacing the Lamp
 Replacing the lamp can be hazardous if done incorrectly. Refer to “Replacing the Projection Lamp”
on page 26 for clear and safe instructions for this procedure.
 Unplug the power cord.
 Allow the lamp sufficient time to cool.
Cleaning the Projector
 Unplug the power cord before cleaning. Refer to “Cleaning the Projector” on page 28.
 Allow the lamp sufficient time to cool.
Regulatory Warnings
 Before installing and using the projector, read the regulatory notices in the “Regulatory Compli-
ance” section on page 39.
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector. Wher-
ever possible, relevant information—such as an illustration and its description—has been kept on one
page. This printer-friendly format is both for your convenience and to help save paper and thereby protect
the environment. It is suggested that you only print sections that are relevant to your needs.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
— iv —
Table of contents
GETTING STARTED...............................................................................................................................................................1
PACKING CHECKLIST................................................................................................................................................................1
VIEWS OF PROJECTOR PARTS...................................................................................................................................................2
Front-left view .....................................................................................................................................................................2
Top view—OSD buttons and LEDs.....................................................................................................................................3
Rear view—connectors........................................................................................................................................................5
Bottom view .........................................................................................................................................................................7
REMOTE CONTROL PARTS........................................................................................................................................................8
REMOTE CONTROL OPERATING RANGE...................................................................................................................................9
PROJECTOR AND REMOTE CONTROL BUTTONS .................................................................................................................... 10
SETUP AND OPERATION.................................................................................................................................................. 11
INSERTING THE REMOTE CONTROL BATTERIES.................................................................................................................... 11
CONNECTING INPUT DEVICES ............................................................................................................................................... 12
STARTING AND SHUTTING DOWN THE PROJECTOR ............................................................................................................... 13
ADJUSTING THE PROJECTOR LEVEL...................................................................................................................................... 14
ADJUST THE ZOOM, FOCUS AND KEYSTONE......................................................................................................................... 15
ADJUSTING THE VOLUME...................................................................................................................................................... 16
ON-SCREEN DISPLAY MENU SETTINGS..................................................................................................................... 17
ON-SCREEN DISPLAY MENU CONTROLS .............................................................................................................................. 17
Navigating the OSD.......................................................................................................................................................... 17
Setting the OSD Language............................................................................................................................................... 18
Main Menu........................................................................................................................................................................ 19
Setup Menu ....................................................................................................................................................................... 21
Config Menu ..................................................................................................................................................................... 22
Utility Menu...................................................................................................................................................................... 23
Language Menu................................................................................................................................................................ 24
Status Menu ...................................................................................................................................................................... 25
MAINTENANCE AND SECURITY.................................................................................................................................... 26
REPLACING THE PROJECTION LAMP...................................................................................................................................... 26
Resetting the Lamp ........................................................................................................................................................... 27
CLEANING THE PROJECTOR................................................................................................................................................... 28
Cleaning the Lens............................................................................................................................................................. 28
Cleaning the Case............................................................................................................................................................. 29
USING THE KENSINGTON LOCK............................................................................................................................................. 29
TROUBLESHOOTING......................................................................................................................................................... 30
COMMON PROBLEMS AND SOLUTIONS .................................................................................................................................. 30
TIPS FOR TROUBLESHOOTING ............................................................................................................................................... 30
LED ERROR MESSAGES........................................................................................................................................................ 31
IMAGE PROBLEMS ................................................................................................................................................................. 31
LAMP PROBLEMS................................................................................................................................................................... 32
REMOTE CONTROL PROBLEMS.............................................................................................................................................. 32
AUDIO PROBLEMS ................................................................................................................................................................. 32
HAVING THE PROJECTOR SERVICED ..................................................................................................................................... 33
SPECIFICATIONS................................................................................................................................................................ 34
SPECIFICATIONS .................................................................................................................................................................... 34
Input/output connectors.................................................................................................................................................... 35
PROJECTION DISTANCE VERSUS PROJECTION SIZE............................................................................................................... 36
TIMING MODE TABLE............................................................................................................................................................ 37
DIMENSIONS .......................................................................................................................................................................... 38
REGULATORY COMPLIANCE ........................................................................................................................................ 39
FCC WARNING...................................................................................................................................................................... 39
CANADA ................................................................................................................................................................................ 39
SAFETY CERTIFICATIONS ...................................................................................................................................................... 39
EN 55022 WARNING............................................................................................................................................................. 39

GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
DLP PROJECTOR WITH LENS CAP REMOTE CONTROL
(WITH TWO AAA BATTERIES)
250V POWER CABLE USB CABLE S-VIDEO CABLE C
OMPUTER CABLE (DVI-
DB15)
CD-ROM (THIS USER’S MANUAL) MULTI-LANGUAGE QUICK START GUIDE CARRYING CASE
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work.
Caution:
1. Avoid using the projector in dusty environments.
2. Leave the power cable plugged in (for 5-10 minutes) until the projector returns to room temperature before
placing the projector inside the soft case. Placing the projector into the case soon after switching off the power
could cause the projector to break down. Be sure to attach the lens cap and place the projector into the soft
case with the lens facing upward.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 2 –
Views of Projector Parts
Front-left view
123
4
5
6
7
8
ITEM LABEL DESCRIPTION SEE PAGE:
1. Zoom Enlarges the projected image 15
2. See OSD buttons and LEDs below 3
3. Projection lamp cover Remove when changing lamp 26
4. IR receiver Receiver for IR signal from remote control 9
5. Lens/focus Remove cover, turn the lens to focus 15
6. Height adjuster Adjusters drop down when adjuster button is
pushed
7. Height adjuster button Push to release height adjuster
14
8. Speaker Built-in mono speaker
Important:
Grill openings on the projector allow for good air circulation, which keeps the projector lamp cool.
Do not obstruct any of the grill openings.

G
G
Ge
e
et
t
tt
t
ti
i
in
n
ng
g
g
S
S
St
t
ta
a
ar
r
rt
t
te
e
ed
d
d—
—
—V
V
Vi
i
ie
e
ew
w
ws
s
s
o
o
of
f
f
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r
P
P
Pa
a
ar
r
rt
t
ts
s
s
–3 –
Top view—OSD buttons and LEDs
VOL -
KEYSTONE
MENU
POWERREADY
SOURCE
POWER
AUTO
VOL +
12 3 4
5
7
6
8
9
1011
ITEM LABEL DESCRIPTION SEE PAGE:
1. Volume/
left cursor Decreases volume Navigates and changes settings in the OSD
2. Keystone/
Up cursor Corrects image-trapezoid (narrower top) effect Navigates and changes settings in the OSD
16
Orange Lamp ready—you can safely turn on or off the projector
3. Ready (LED)
Flashing Lamp not ready—do not press the power button
4. Power Turns the projector on or off (main power switch must
be turned on first, see item 8 on page 5) 13
Green Unit is powered on and working correctly
Off Unit is powered off
5. Power (LED)
Flashing Operational error code
(refer to “LED Error Messages” on page 31)
6. Source Detects the input device 13
7. Volume/
right cursor Increases volume Navigates and changes settings in the OSD 17

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 4 –
ITEM LABEL DESCRIPTION SEE PAGE:
8. Auto Optimizes image size, position, and resolution
9. Menu Opens/exits the On-Screen Display (OSD)
10. Enter Changes settings in the OSD
11. Keystone/
Down cursor Corrects image-trapezoid (narrower bottom) effect Navigates and changes settings in the OSD

G
G
Ge
e
et
t
tt
t
ti
i
in
n
ng
g
g
S
S
St
t
ta
a
ar
r
rt
t
te
e
ed
d
d—
—
—V
V
Vi
i
ie
e
ew
w
ws
s
s
o
o
of
f
f
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r
P
P
Pa
a
ar
r
rt
t
ts
s
s
–5 –
Rear view—connectors
12
3456
78
9
1011121314
15
16
17
18
ITEM LABEL DESCRIPTION SEE PAGE:
1. DVI-I Connect the DVI cable (supplied) from a computer
2. RGB IN Connect a VGA cable (not supplied) from a computer
3. RGB OUT Connect to a monitor
4. RS-232 Installation control and firmware upgrades
5. USB Connect the USB cable (supplied) from a computer
6. Audio-in Connect the audio cable (supplied) from the input device
7. Power connector Connect the supplied power cord
8. Main power Turns the main power on or off
13
9. IR receiver Receiver for IR signal from remote control 9
10. Audio-out Audio loop-thru
11. Audio-in-R Connect an RCA audio cable (not supplied) from the input
device right channel
12. Audio-in-L Connect an RCA audio cable (not supplied) from the input
device left channel
13. Video Connect a composite video cable (not supplied)from a
video device
14. S-video Connect the supplied S-video cable from a video device
13

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 6 –
ITEM LABEL DESCRIPTION SEE PAGE:
15. Kensington Lock Secure to permanent object with a Kensington Lock system 29
16. Pr/Cr
17. Pb/Cb
18. Y
Component
video in Connect a component video enabled device 13
Note:
If your video equipment has both S-video and RCA jacks (composite video) connect to the S-video
connector.
S-video provides a better quality signal.

G
G
Ge
e
et
t
tt
t
ti
i
in
n
ng
g
g
S
S
St
t
ta
a
ar
r
rt
t
te
e
ed
d
d—
—
—V
V
Vi
i
ie
e
ew
w
ws
s
s
o
o
of
f
f
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r
P
P
Pa
a
ar
r
rt
t
ts
s
s
–7 –
Bottom view
2 3 3 3112
ITEM LABEL DESCRIPTION SEE PAGE:
1. Height adjuster buttons Push to release height adjusters
2. Height adjusters Adjusters drop down when adjuster buttons
are pushed
14
3. Ceiling support holes Contact your dealer for information on mounting the projector on a
ceiling.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 8 –
Remote Control Parts
Blank
Blank
Powe r
Menu
Keystone
Auto
Enter
Source
Volume Mute
Freeze
12
14
15
16
22
21
20
19
18
17
3
4
5
6
7
8
9
10
11
12
13
12
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo-
rescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path be-
tween remote and projector is obstructed, you can bounce the remote signal off certain reflective
surfaces such as projector screens.

G
G
Ge
e
et
t
tt
t
ti
i
in
n
ng
g
g
S
S
St
t
ta
a
ar
r
rt
t
te
e
ed
d
d—
—
—V
V
Vi
i
ie
e
ew
w
ws
s
s
o
o
of
f
f
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r
P
P
Pa
a
ar
r
rt
t
ts
s
s
–9 –
ITEM LABEL DESCRIPTION SEE PAGE:
1. Laser Use as on-screen pointer. DO NOT POINT IN EYES.
2. IR transmitter Transmits signals to projector 9
3. Status LED Lights when the remote control is used
4. Auto Optimizes image size, position, and resolution
5. Blank Makes the screen blank 22
6. Enter Changes settings in the OSD
7. Up cursor
8. Right cursor Navigates and changes settings in the OSD 17
9. Cursor pad Moves the on-screen cursor when connected to a PC
10. Keystone top
11. Keystone bottom Corrects image-trapezoid (narrower top/bottom) effect 15
12. Mute Mutes the built-in speaker
13. Right mouse Functions as right mouse button when connected to a PC
14. Left mouse Functions as left mouse button when connected to a PC
15. Volume down
16. Volume up
Adjusts volume 16
17. Down cursor
18. Left cursor
Navigates and changes settings in the OSD
19. Menu Opens the On-Screen Display (OSD)
17
20. Freeze Freeze/unfreezes the on-screen picture
21. Source Detects the input device
22. Power Turns the projector on or off 13
Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote functions within a radius of about (7) meters (23 feet) and 30 de-
grees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 10 –
Projector and Remote Control Buttons
The projector can be operated using the remote control or the buttons on the top of the projector. All
operations can be carried out with the remote control; however the buttons on the projector are lim-
ited in use. The following illustration shows the corresponding buttons on the remote control and on
the projector.
Blank
Blank
Power
Menu
Keystone
Auto
Enter
Source
Volume Mute
Freeze
12
7
8
13
12
11
10
9
1
2
3
4
5
6
VOL -
KEYSTONE
MENU
POWERREADY
SOURCE
POWER
AUTO
VOL +
7/10 3/5 13
4/8
12
1
11
26/9
Some buttons on the projector have two functions. For example, item 7/10 on the projector functions
both as the volume down button and as the left cursor key in OSD menus.

SETUP AND OPERATION
Inserting the Remote Control Batteries
1.
Remove the battery compartment cover
by sliding the cover in the direction of
the arrow.
2.
Insert the supplied batteries taking note
of the polarity (+/-) as shown here.
3.
Replace the cover.
Caution:
1. Only use AAA alkaline batteries.
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 12 –
Connecting Input Devices
A PC or notebook computer as well as video devices can be connected to the projector at the same time.
Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras.
Check the user manual of the connecting device to confirm it has the appropriate output connector.
DVI-I IN
YCOMPONENT VIDEO IN
P/C
BS P/C RR
RGB IN
S-VIDEO IN VIDEO IN L-AUDION IN -R AUDIO OUT
RGB OUT RS-232C USB AUDIO-IN
BC
ADE F
G
H
J
KI
ITEM LABEL DESCRIPTION
A
DVI-I Connect the supplied DVI cable from a computer.
B
RGB in Connect a VGA cable (not supplied) from a computer.
C
RGB out Connect a VGA cable (not supplied) to a monitor.
D
RS-232 Reserved for installation control and firmware upgrades.
E
USB Connect the supplied USB cable from a computer.
F
Audio-in Connect an audio cable (not supplied) from the computer’s audio-out connector.
G
Audio-out Audio loop-thru
H
L-Audio in-R Connect the audio cable (not supplied) from an audio input device.
I
Video Connect a composite video cable (not supplied) from a video device.
S-video Connect the supplied S-video cable from a video device.
Component
video in Connect a component video cable (not supplied) from a video device.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.

S
S
Se
e
et
t
tu
u
up
p
p
a
a
an
n
nd
d
d
O
O
Op
p
pe
e
er
r
ra
a
at
t
ti
i
io
o
on
n
n
–13 –
Starting and Shutting down the Projector
1.
Connect the power cord to the projec-
tor. Connect the other end to a wall
outlet. (A)
Turn on the power switch. (B)
The Power LED and Lamp-ready LED
turn on.
2.
Remove the lens cover.
3.
Turn on the connected devices.
ON OFF
4.
Ensure the Lamp-ready LED is on a
steady (not flashing) orange and then
press the Power button to turn on the
projector.
The projector splash screen displays
and connected devices are detected.
If the connected device is a PC, press
the appropriate Fn hot keys on the
computer keyboard to switch the dis-
play output to the projector. (Check the
PC user manual to determine the ap-
propriate Fn hot keys to change display
output.)
5.
If more than one input device is con-
nected, press the Source button
repeatedly to switch among devices.
6.
To turn off the projector, press the
Power button. The projector prepares
for shutdown and a “Wait a moment
please…” message appears.
7.
When the “Power Off?/Press Power
again” message appears, press the
Power button. The projector turns off.
Attention : Power off the projector normally and unplug the power cord before moving the projector

D
D
DL
L
LP
P
P
P
P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r
M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
– 14 –
Adjusting the Projector Level
Take note of the following when setting up the projector:
• The projector table or stand should be level and sturdy.
• Position the projector so that it is perpendicular to the screen.
• Be sure cables are not in the way or can cause the projector to be knocked over.
1. To raise the level of the projector, lift the projector [A] and press the height-adjuster
buttons [B].
The height-adjusters drop down [C].
2. To lower the level of the projector, press the height-adjuster buttons and push down
on the top of the projector.

S
S
Se
e
et
t
tu
u
up
p
p
a
a
an
n
nd
d
d
O
O
Op
p
pe
e
er
r
ra
a
at
t
ti
i
io
o
on
n
n
–15 –
Adjust the Zoom, Focus and Keystone
1.
Use the Image-zoom con-
trol (on the projector only)
to resize the projected im-
age and screen size
A
.
2.
Use the Image-focus con-
trol (on the projector only)
to sharpen the projected
B
3.
Use the Keystone buttons
(on the projector or the
remote control) to correct
image-trapezoid (wider
top or bottom) effect.
The keystone control ap-
pears on the display.
