Dukane ImagePro 8888 User manual

8888
ImagePro 8888
Portable LCD Projector
e ImagePro 8888 is a light (5 lbs),
easy-to-install portable LCD projector
ideal for classroom or conference room.
8888 FEATURES
• 2200 Lumens Brightness
• XGA Resolution
• Lamp access on top
• High performance (5000 HR)
filter with easy side access
• Instant on ON and OFF
• New 3000/4000 hour lamp
• Built-in Anti-theft security
• Audio "passthrough" permits use
of sound system to play CDs on
the PC when projector is off
• Super reliable operation
NEW SIDE-LOADING FILTER PROVIDES
EASY FILTER MAINTENANCE
%DUCATION0RESENTATION)NSPIRATION
4(%!,,.%7
Toll-free: 888-245.1966•Web:www.dukane.com/av
Fax: 630-584-5156•E-mail:[email protected]
#11-00064-00

Specifications 8888
Image Element 0.63” polysilicon active-matrix TFT x3
Brightness 2200 ANSI lumens
(1800 lumens in Whisper Mode)
Resolution 1024 x 768 pixels (H X V), XGA
Contrast 500:1
Scanning Frequency fh 15 -106 kHz, fv 50-120 Hz
Lens Manual zoom 1.2X
Lens Throw Ratio 1.5 –1.8:1 throw distance to image width
Keystone Correction Digital, vertical +/-30 deg
Aspect Ratio 4:3, 16:9 selectable
Computer SVGA, VGA, XGA, SXGA, UXGA
Compatibility MAC13” and MAC16”
Video Compatibility NTSC, NTSC4.43, PAL, SECAM,
PAL-M, PAL-N, Component Video,
HDTV (1080i/p, 720p, 576i, 480i/p)
Image Control Freeze function, electronic
magnification and pan
Projection Modes Front/rear/ceiling
Color Reproduction 24 bit (16.7 million)
Lamp 200W UHP
Lamp Life 3000 hours (typical) 4000 hours (eco mode)
Audio Output 1 watt, speaker
Throw Distance 34” to 423”
Screen Size, diagonal 30” to 300”
Inputs, Video (1) Component, Share with RGB
(1) Composite video, RCA x 1
(1) S-Video, mini DIN 4-pin
Inputs, Computer (2) RGB, 15 pin D-sub
Inputs, Audio (2) Stereo mini jack
Outputs, Audio (1) Stereo mini jack, adjustable level
Outputs, Monitor (1) RGB, 15 pin D-sub
Control projector (1) 9pin D-sub, RS-232
Control mouse (1) USB, type B port
Security Kensington lock slot & Security Bar
Fan Level 35dB, ultra quiet; 29dB Whisper Mode
Closed Caption For NTSC only
Operating Temperature 41-95 deg F
Power AC 100-120V, AC 220-240V
50/60 Hz, 290 watt,
(0.5 W in the stand-by mode)
Size (WxHxD) 12” x 3.0” x 8.7”
Weight 5 lbs.
Shipping Weight 15 lbs.
Carton Size 15” x 8” x 19” (est.)
Accessories Included Remote control, batteries, power cord,
RGB cable, operation manual
Safety UL/C-UL, FCC Class B, CE, ROHS
Optional Accessories Lamp 456-8789
Ceiling Mount, Universal; PRG-UNV
Filter; UX36761
ImagePro 8888
Portable LCD projector
8888ProjectionTable
ThrowRatio(distancetowidth) 1.5 1.8
Connections
BackPanel
•XGA(1024x768)resolution
•2200ANSIlumensofbrightness
•Whiteboard&BlackboardModes
•Easymaintenanceinceilingmountwithlampaccessontop
and5000Hourfilterwithsideaccess
•Monitorloopthrough
•InstantOnandOff
•Built-InAnti-theftsecurity
•Audiopassthroughforsoundwhenprojectorisoff
•3000/4000hourlamplife
•Lockslot,securitybarandtransitiondetector
•FiveYearWarrantyandOneYearPeaceofMindService
ImageProisaregisteredtrademarkofDukaneCorporation
Image Size 4:3 Throw Distance
Diagonal Width Min. Max.
Inches Inches Feet Feet
30 24 2.8 3.4
60 48 5.8 7.0
80 64 7.8 9.3
100 80 9.8 11.7
120 96 11.7 14.1
150 120 14.7 17.6
200 160 19.5 23.5
300 240 29.3 35.3
Key features:
#10-00064-00
Five (5) year limited warranty to the original purchaser on parts and labor in North America,
lamp excluded (for other locations, local warranties apply) ImagePro is a registered trademark
of Dukane Corporation. Includes Dukane’s FREE 1 year Peace-of-Mind Loaner Program.
5YR
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, Illinois 60174
888-245.1966 toll-free
630-584-5156 fax
[email protected] e-mail
www.dukane.com/av
!
!
