ViewSonic PJD5126 User manual

PJD5126/PJD6223/PJD6253/
PJD6553w
DLP Projector
User Guide
Model No. VS14295/VS14191/VS14193/VS14195
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://www.
viewsonic.com in English, or in specic languages using the Regional selection box in
the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente
las instrucciones en este manual”
Downloaded From projector-manual.com Viewsonic Manuals

i
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved by the
party responsible for compliance could void your authority to operate the equipment.
For Canada
• This Class B digital apparatus complies with Canadian ICES-003.
• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment including any spent or
discarded batteries or accumulators as unsorted municipal waste, but use the return and
collection systems available.
If the batteries, accumulators and button cells included with this equipment, display the
chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of
more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.
Downloaded From projector-manual.com Viewsonic Manuals

ii
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean with a soft, dry cloth.
7. Do not block any ventilation openings. Install the unit in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade and the third prong are provided
for your safety. If the provided plug does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs.
Convenience receptacles and the point where they exit from the unit. Be sure that the
power outlet is located near the unit so that it is easily accessible.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the unit. When a cart is used, use caution when
moving the cart/unit combination to avoid injury from tipping over.
13. Unplug this unit when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the unit
has been damaged in any way, such as: if the power-supply cord or plug is damaged,
if liquid is spilled onto or objects fall into the unit, if the unit is exposed to rain or
moisture, or if the unit does not operate normally or has been dropped.
Downloaded From projector-manual.com Viewsonic Manuals

iii
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/EC of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown below:
Substance Proposed Maximum
Concentration Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+)0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex of the RoHS Directives
as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not
specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic ceramic
parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up
to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.
Downloaded From projector-manual.com Viewsonic Manuals

iv
Copyright Information
Copyright© ViewSonic® Corporation, 2011. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are
trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this material, or
the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change
product specications without notice. Information in this document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes available,
please register your product on the Internet at: www.viewsonic.com. The ViewSonic® Wizard DVD-
ROM also provides an opportunity for you to print the registration form, which you may mail or fax to
ViewSonic.
For Your Records
Product Name:
Model Nu mber:
Document Number:
Serial Number:
Purchase Date:
PJD5126/PJD6223/PJD6253/PJD6553w
ViewSonic DLP Projector
VS14295/VS14191/VS14193/VS14195
PJD5126/PJD6223/PJD6253/PJD6553w_UG_ENG Rev. 1B 10-03-11
_______________________________________________________
_______________________________________________________
Product disposal at end of product life
The lamp in this product contains mercury which can be dangerous to you and the environment. Please
use care and dispose of in accordance with local, state or federal laws.
ViewSonic respects the environment and is committed to working and living green. Thank you for being
part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/kbase/article.php?id=639
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
Downloaded From projector-manual.com Viewsonic Manuals

1
Table of contents
Important safety
instructions .......................2
Introduction......................4
Projector features ................................. 4
Shipping contents................................. 5
Projector exterior view......................... 6
Controls and functions ......................... 7
Positioning your
projector..........................12
Choosing a location............................ 12
Projection dimensions........................ 13
Connection ......................16
Connecting a computer or monitor .... 17
Connecting Video source devices ...... 18
Operation ........................21
Starting up the projector..................... 21
Using the menus................................. 23
Utilizing the password function ......... 24
Switching input signal........................ 27
Adjusting the projected image ........... 28
Magnifying and searching for details. 30
Selecting the aspect ratio ................... 30
Optimizing the image......................... 32
Setting the presentation timer ............ 36
Hiding the image................................ 37
Locking control keys.......................... 37
Freezing the image ............................. 38
Operating in a high altitude
environment ....................................... 38
Creating your own startup screen....... 39
Controlling the projector through
a LAN environment ........................... 40
Using the projector in standby mode. 46
Shutting down the projector .............. 46
Menu operation.................................. 47
Maintenance ...................55
Care of the projector .......................... 55
Lamp information .............................. 56
Troubleshooting .............62
Specifications ..................63
Projector specifications...................... 63
Dimensions ........................................ 65
Ceiling mount installation ................. 65
Timing chart ...................................... 66
Copyright information...68
Appendix.........................69
IR control table .................................. 69
RJ45 response table ........................... 71
RS232 command table....................... 71
Downloaded From projector-manual.com Viewsonic Manuals

2
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.
Safety Instructions
1. Please read this manual before you operate your projector. Save it for future
reference.
2. Do not look straight at the projector lens during operation. The intense light beam
may damage your eyes.
3. Refer servicing to qualified service personnel.
4. Always open the lens shutter or remove the lens cap when the projector lamp is
on.
5. In some countries, the line voltage is NOT stable. This projector is designed to operate
safely within a mains voltage between 100 to 240 volts AC, but could fail if power
cuts or surges of ±10 volts occur. In areas where the mains voltage may fluctuate
or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector or uninterruptible power supply (UPS).
6. Do not block the projection lens with any objects when the projector is under
operation as this could cause the objects to become heated and deformed or even
cause a fire. To temporarily turn off the lamp, press BLANK on the projector or
remote control.
7. The lamp becomes extremely hot during operation. Allow the projector to cool for
approximately 45 minutes prior to removing the lamp assembly for replacement.
8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps
beyond the rated life could cause them to break on rare occasions.
9. Never replace the lamp assembly or any electronic components unless the projector is
unplugged.
10. Do not place this product on an unstable cart, stand, or table. The product may fall,
sustaining serious damage.
11. Do not attempt to disassemble this projector. There are dangerous high voltages inside
which may cause death if you should come into contact with live parts. The only user
serviceable part is the lamp which has its own removable cover.
Under no circumstances should you ever undo or remove any other covers. Refer
servicing only to suitably qualified professional service personnel.
12. Do not place this projector in any of the following environments.
- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls
and free flow of air around the projector.
- Locations where temperatures may become excessively high, such as the inside of a
car with all windows rolled up.
- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical
components, shortening the projector's life span and darkening the picture.
- Locations near fire alarms
- Locations with an ambient temperature above 40°C / 104°F
- Locations where the altitudes are higher than 3000 m (10000 feet).
Downloaded From projector-manual.com Viewsonic Manuals

3
13. Do not block the ventilation holes. If the ventilation holes are seriously obstructed,
overheating inside the projector may result in a fire.
- Do not place this projector on a blanket, bedding or any other soft surface.
- Do not cover this projector with a cloth or any other item.
- Do not place inflammables near the projector.
14. Always place the projector on a level, horizontal surface during operation.
- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of
more than 15 degrees front to back. Using the projector when it is not fully horizontal
may cause a malfunction of, or damage to, the lamp.
15. Do not stand the projector on end vertically. Doing so may cause the projector to fall
over, causing injury or resulting in damage to the projector.
16. Do not step on the projector or place any objects upon it. Besides probable physical
damage to the projector, doing so may result in accidents and possible injury.
17. Do not place liquids near or on the projector. Liquids spilled into the projector may
cause it to fail. If the projector does become wet, disconnect it from the power
supply's wall socket and call your local service center to have the projector serviced.
18. This product is capable of displaying inverted pictures for ceiling mount installation.
Use only qualified ceiling mount kit for mounting the projector and ensure it is
securely installed.
19. When the projector is under operation, you may sense some heated air and odor from
its ventilation grill. It is a normal phenomenon and not a product defect.
20. Do not use the Security bar for transporting or installation. It should be used with a
commercially available theft prevention cable.
Safety instructions for ceiling mounting of the
projector
We want you to have a pleasant experience using your projector, so we need to bring this
safety matter to your attention to prevent damage to person and property.
If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and that you ensure it is securely and safely
installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use of the
wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your projector.
We recommends that you also purchase a separate Kensington lock compatible security
cable and attach it securely to both the Kensington lock slot on the projector and the base of
the ceiling mount bracket. This will perform the secondary role of restraining the projector
should its attachment to the mounting bracket become loose.
Downloaded From projector-manual.com Viewsonic Manuals

4
Introduction
Projector features
The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.
The projector offers the following features.
• Dynamic PC and Dynamic Movie function adjusting the power consumption of the
lamp according to the brightness of the image being projected
• Smart Eco function decreasing the power consumption of the lamp by up to 70% when
no input signal can be detected for a set period of time.
• Presentation timer for better control of time during presentations
• Support 3D DLP Link
• Color management allowing color adjustments to your liking
• Less than 1W power consumption when power saving mode is turned on
• Screen Color correction allowing projection on surfaces of several predefined colors
• Quick auto search speeding up the signal detecting process
• Up to 10 sets of picture modes providing multiple choices for different projection
purposes
• One-key auto-adjustment to display the best picture quality
• Digital keystone correction to correct distorted images
• Adjustable color balance control for data/video display
• High brightness projection lamp
• Ability to display 1.07 billion colors
• Multi-language On-Screen Display (OSD) menus
• Switchable normal and economic modes to reduce the power consumption
• Component HDTV compatibility (YPbPr)
• The apparent brightness of the projected image will vary depending on the ambient
lighting conditions, selected input signal contrast/brightness settings, and is directly
proportional to projection distance.
• The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.
Downloaded From projector-manual.com Viewsonic Manuals

5
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those
illustrated.
Optional accessories
1. Replacement lamp
2. Soft carry case
3. VGA-Component adapter
Projector Power Cord VGA Cable
Multi-language user manual
DVD Quick Start Guide Remote Control & Batteries
PJD5126/PJD6223 PJD6253/PJD6553w
Downloaded From projector-manual.com Viewsonic Manuals

6
Projector exterior view
1. External control panel
(See "Projector" on page 7 for
details.)
2. Lamp cover
3. Vent (heated air exhaust)
4. Quick-release button
5. Lens cover
6. Focus and Zoom ring
7. Front IR remote sensor
8. Projection lens
9. Type B USB port
10. RJ45 LAN input port
11. RS-232 control port
12. HDMI port
13. RGB signal output socket
14. RGB (PC)/Component video
(YPbPr/YCbCr) signal input
socket-1/2
15. S-Video input socket
16. Video input socket
17. Audio signal input socket
Audio signal output socket
18. Kensington anti-theft lock slot
19. AC power cord inlet
20. Rear adjuster foot
21. Quick-release foot
22. Security bar
Connects a commercially available
theft prevention cable.
Warning
• THIS APPARATUS MUST BE EARTHED.
• When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring,
or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should
occur during operation of the unit, operate the disconnect device to switch the power supply
off, or disconnect the power plug.
Front/upper side
1
2
3
4
5
6
7
8
PJD6223/PJD6253/
PJD6553w
18
21
20
PJD5126
TYPE B
USB COMPUTER IN 2
RS-232
MONITOR OUT COMPUTER IN 1
S-Viseo Video Audio in
Audio
out
910 12 13 15 16 17 11 14
915 16 17 11
1413
19
22
Rear/lower side
Downloaded From projector-manual.com Viewsonic Manuals

7
Controls and functions
Projector
1. Focus ring
Adjusts the focus of the projected image.
2. Zoom ring
Adjusts the size of the image.
3. Keystone/Arrow keys ( / Up, /
Down)
Manually corrects distorted images
resulting from an angled projection.
4. Left/Blank
Hides the screen picture.
5. POWER indicator light
Lights up or flashes when the projector is
under operation.
POWER
Toggles the projector between standby
mode and on.
6. SOURCE
Displays the source selection bar.
7. Top IR remote sensor
Not available for the PJD5126.
8. MENU/EXIT
Turns on the On-Screen Display (OSD)
menu. Goes back to previous OSD menu,
exits and saves menu settings.
9. Right/
Activates panel key lock.
When the On-Screen Display (OSD)
menu is activated, the #3, #4, and #9 keys
are used as directional arrows to select the
desired menu items and to make
adjustments.
10. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
11. AUTO
Automatically determines the best picture
timings for the displayed image.
12. TEMPerature indicator light
Lights up red if the projector's
temperature becomes too high.
13. MODE/ENTER
Selects an available picture setup mode.
Enacts the selected On-Screen Display
(OSD) menu item.
ZOOM
TEMP LMMP
MODE
ENTER AUTO
SOURCE
MENU
EXIT
1
2
3
4
5
6
3
8
9
10
12
13
11
7
I
I
Downloaded From projector-manual.com Viewsonic Manuals

8
Remote control
To use the remote mouse control
keys (Page Up, Page Down, , and
), see "Using the remote mouse
control" on page 10 for details.
1. POWER
Toggles the projector between standby
mode and on.
2. Source selection keys (VGA 1/VGA
2/Video)
Selects an input source for display.
Video/
Selects Video, S-Video or HDMI
source for display.
Performs the same function as the
right mouse button when the mouse
mode is activated.
3. Source
Displays the source selection bar.
4. Keystone keys ( / )
Manually corrects distorted images
resulting from an angled projection.
5. ///
Selects the desired menu items and
makes adjustments.
6. Enter/
Enacts the selected On-Screen Display
(OSD) menu item.
Performs the same function as the left
mouse button when the mouse mode is
activated.
7. My Button
Allows user to define a short cut key
on the remote control, and the function
item is selected in OSD menu.
8. Menu
Turns on the On-Screen Display
(OSD) menu.
9. Mouse
Switches between the normal and
mouse modes.
Page Up, Page Down, , : active
after pressing Mouse. An icon appears
on the screen to indicate the activation
of the mouse mode.
1
2
3
5
8
9
4
18
19
14
20
21
22
23
24
6
10
12
16
13
17
11
15
7
4
1
2
3
5
8
9
4
25
19
14
20
21
22
23
24
6
10
16
11
17
18
15
7
4
12
PJD5126/PJD6223 PJD6253/PJD6553w
I
I
Downloaded From projector-manual.com Viewsonic Manuals

9
Remote control code
The projector can be assigned to two different remote control codes, A or B. When several
adjacent projectors are in operation at the same time, switching the remote control codes
can prevent interference from other remote controls. Set the remote control code for the
projector first before changing that for the remote control.
To switch the code for the projector, select Aor Bin the SYSTEM SETUP: Advanced >
Remote Control Code menu.
To switch the code for the remote control, press PgUp and PgDn buttons on the remote
control together for 5 seconds or more. The initial code is set to A.
If different codes are set on the projector and remote control, there will be no response from
the remote control. When that happens, switch the code for the remote control again.
10. Lock
Activates panel key lock.
11. Aspect
Selects the display aspect ratio.
12. Magnify
Displays the zoom bar that magnifies or
reduces the projected picture size.
13. Info
Displays the INFORMATION menu.
14. Freeze
Freezes the projected image.
15. Pattern
Displays embedded test pattern.
16. Blank
Hides the screen picture.
17. Smart Eco
Decreases the power consumption of the
lamp by up to 70%.
It takes the projector several minutes
after it is turned on or resumed to
initiate the function.
18. Auto Sync
Automatically determines the best picture
timings for the displayed image.
19. Exit
Goes back to previous OSD menu, exits
and saves menu settings.
20. PgUp (Page Up)/PgDn (Page Down)
Operates your display software program
(on a connected PC) which responds to
page up/down commands (like Microsoft
PowerPoint) when the mouse mode is
activated.
21. Volume keys (+, -)
Magnifies or reduces the volume level.
22.
Toggles the projector audio between on
and off.
23. Color Mode
Selects an available picture setup mode.
24. Timer
Displays the presentation timer settings
menu.
25. Laser
Emits visible laser pointer light for
presentation purposes.
Operating the Laser pointer
The Laser Pointer is a presentation aid for
professionals. It emits red colored light when
you press it and the indicator lights up red.
The laser beam is visible. It is necessary to
press and hold LASER for continuous output.
The laser pointer is not a toy. Parents should be
mindful of the dangers of laser energy and keep
this remote control out of the reach of children.
Do not look into the laser light window
or shine the laser light beam on
yourself or others. See the warning
messages on the back of the remote
control prior to using it.
Downloaded From projector-manual.com Viewsonic Manuals

10
Using the remote mouse control
The capability of operating your computer with the remote control gives you more
flexibility when delivering presentations.
1. Connect the projector to your PC or notebook with a USB cable prior to using the
remote control in place of your computer’s mouse. See "Connecting a computer" on
page 17 for details.
2. Set the input signal to D-Sub / Comp. 1, D-Sub / Comp. 2 or HDMI.
3. Press Mouse on the remote control to switch from the normal mode to the mouse
mode. An icon appears on the screen to indicate the activation of the mouse mode.
4. Perform the desired mouse controls on your remote control.
• To move the cursor on the screen, press / / / .
• To left-click, press .
• To right-click, press .
• To operate your display software program (on a connected PC) which responds to
page up/down commands (like Microsoft PowerPoint), press PgUp/PgDn.
• To return to the normal mode, press Mouse again or other keys except for the
mouse related multi-function keys.
Remote control effective range
Infra-Red (IR) remote control sensors are located on the front and the top of the projector.
The remote control must be held at an angle within 30 degrees perpendicular to the
projector's IR remote control sensors to function correctly. The distance between the remote
control and the sensors should not exceed 8 meters (~ 26 feet).
Make sure that there are no obstacles between the remote control and the IR sensors on the
projector that might obstruct the infra-red beam.
• Operating the projector from the
front
Approx.15°
Approx.+15°
• Operating the projector from the
top
Downloaded From projector-manual.com Viewsonic Manuals

11
Replacing the remote control batteries
1. To open the battery cover, turn the remote control over to view its back, push on the
finger grip on the cover and slide it in the direction of the arrow as illustrated. The
cover will slide off.
2. Remove any existing batteries (if necessary) and install two AAA batteries observing
the battery polarities as indicated in the base of the battery compartment. Positive (+)
goes to positive and negative (-) goes to negative.
3. Refit the cover by aligning it with the base and sliding it back down into position.
Stop when it clicks into place.
• Avoid leaving the remote control and batteries in an excessive heat or humid environment
like the kitchen, bathroom, sauna, sunroom or in a closed car.
• Replace only with the same or equivalent type recommended by the battery manufacturer.
• Dispose of the used batteries according to the manufacturer's instructions and local
environment regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are dead or if you will not be using the remote control for an extended
period of time, remove the batteries to avoid damage to the remote control from possible
battery leakage.
Downloaded From projector-manual.com Viewsonic Manuals

12
Positioning your projector
Choosing a location
Your room layout or personal preference will dictate which installation location you select.
Take into consideration the size and position of your screen, the location of a suitable power
outlet, as well as the location and distance between the projector and the rest of your
equipment.
Your projector is designed to be installed in one of four possible installation locations:
1. Front Table
Select this location with the projector placed near
the floor in front of the screen. This is the most
common way to position the projector for quick
setup and portability.
2. Front Ceiling
Select this location with the projector suspended
upside-down from the ceiling in front of the
screen.
Purchase the projector ceiling mount kit from your
dealer to mount your projector on the ceiling.
Set Front Ceiling in the SYSTEM SETUP:
Basic > Projector Position menu after you turn
the projector on.
3. Rear Ceiling
Select this location with the projector suspended
upside-down from the ceiling behind the screen.
Note that a special rear projection screen and the
projector ceiling mounting kit are required for this
installation location.
Set Rear Ceiling in the SYSTEM SETUP: Basic
> Projector Position menu after you turn the
projector on.
4. Rear Table
Select this location with the projector placed near
the floor behind the screen.
Note that a special rear projection screen is
required.
Set Rear Table in the SYSTEM SETUP: Basic >
Projector Position menu after you turn the
projector on.
Downloaded From projector-manual.com Viewsonic Manuals

13
Projection dimensions
Refer to "Dimensions" on page 65 for the center of lens dimensions of this projector before
calculating the appropriate position.
The "screen" mentioned below refers to the projection screen usually consisting of a surface
and a support structure
PJD5126/PJD6223/PJD6253
PJD5126/PJD6223
(a) Screen
Size
[inch (m)]
4:3 image on a 4:3 Screen 16:9 image on a 4:3 Screen
(b) Projection
distance [m (inch)]
(c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection distance
[m (inch)]
(c) Image
height
[cm (inch)
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
40 (1.0) 1.5 (60) 1.7 (66) 61 (24) 3 (1.2) 1.5 (60) 1.7 (66) 46 (18) 10.7 (4.2)
50 (1.3) 1.9 (75) 2.1 (82) 76 (30) 4 (1.5) 1.9 (75) 2.1 (82) 57 (23) 13.3 (5.3)
60 (1.5) 2.3 (90) 2.5 (99) 91 (36) 5 (1.8) 2.3 (90) 2.5 (99) 69 (27) 16.0 (6.3)
70 (1.8) 2.7 (105) 2.9 (115) 107 (42) 5 (2.1) 2.7 (105) 2.9 (115) 80 (32) 18.7 (7.4)
80 (2.0) 3.0 (120) 3.4 (132) 122 (48) 6 (2.4) 3.0 (120) 3.4 (132) 91 (36) 21.3 (8.4)
90 (2.3) 3.4 (135) 3.8 (148) 137 (54) 7 (2.7) 3.4 (135) 3.8 (148) 103 (41) 24.0 (9.5)
100 (2.5) 3.8 (150) 4.2 (165) 152 (60) 8 (3.0) 3.8 (150) 4.2 (165) 114 (45) 26.7 (10.5)
120 (3.0) 4.6 (180) 5.0 (198) 183 (72) 9 (3.6) 4.6 (180) 5.0 (198) 137 (54) 32.0 (12.6)
150 (3.8) 5.7 (225) 6.3 (247) 229 (90) 11 (4.5) 5.7 (225) 6.3 (247) 171 (68) 40.0 (15.8)
200 (5.1) 7.6 (300) 8.4 (330) 305 (120) 15 (6.0) 7.6 (300) 8.4 (330) 229 (90) 53.3 (21.0)
250 (6.4) 9.51 (375) 10.5 (412) 381 (150) 19 (7.5) 9.51 (375) 10.5 (412) 286 (113) 66.7 (26.3)
300 (7.6) 11.4 (450) 12.6 (495) 457 (180) 23 (9.0) 11.4 (450) 12.6 (495) 343 (135) 80.0 (31.5)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(d)
(b)
(e)
(f)
(c)
(a)
(d)
(c)
(b)
(e)
(f)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 4:3 image on a 4:3 screen
• 16:9 image on a 4:3 screen
Downloaded From projector-manual.com Viewsonic Manuals

14
PJD6253
(a) Screen
Size
[inch (m)]
4:3 image on a 4:3 Screen 16:9 image on a 4:3 Screen
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection distance
[m (inch)] (c) Image
height
[cm (inch)
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
40 (1.0) 1.2 (48) 1.6 (63) 61 (24) 5 (1.8) 1.2 (48) 1.6 (63) 46 (18) 12.2 (4.8)
50 (1.3) 1.5 (61) 2.0 (79) 76 (30) 6 (2.3) 1.5 (61) 2.0 (79) 57 (23) 15.2 (6.0)
60 (1.5) 1.8 (73) 2.4 (94) 91 (36) 7 (2.7) 1.8 (73) 2.4 (94) 69 (27) 18.3 (7.2)
70 (1.8) 2.2 (85) 2.8 (110) 107 (42) 8 (3.2) 2.2 (85) 2.8 (110) 80 (32) 21.3 (8.4)
80 (2.0) 2.5 (97) 3.2 (126) 122 (48) 9 (3.6) 2.5 (97) 3.2 (126) 91 (36) 24.4 (9.6)
90 (2.3) 2.8 (109) 3.6 (142) 137 (54) 10 (4.1) 2.8 (109) 3.6 (142) 103 (41) 27.4 (10.8)
100 (2.5) 3.1 (121) 4.0 (157) 152 (60) 11 (4.5) 3.1 (121) 4.0 (157) 114 (45) 30.5 (12.0)
120 (3.0) 3.7 (145) 4.8 (189) 183 (72) 14 (5.4) 3.7 (145) 4.8 (189) 137 (54) 36.6 (14.4)
150 (3.8) 4.6 (182) 6.0 (236) 229 (90) 17 (6.8) 4.6 (182) 6.0 (236) 171 (68) 45.7 (18.0)
200 (5.1) 6.2 (242) 8.0 (315) 305 (120) 23 (9.0) 6.2 (242) 8.0 (315) 229 (90) 61.0 (24.0)
250 (6.4) 7.7 (303) 10.0 (394) 381 (150) 29 (11.3) 7.7 (303) 10.0 (394) 286 (113) 76.2 (30.0)
300 (7.6) 9.2 (363) 12.0 (472) 457 (180) 34 (13.5) 9.2 (363) 12.0 (472) 343 (135) 91.4 (36.0)
Downloaded From projector-manual.com Viewsonic Manuals

15
PJD6553w
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should physically
test the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.
(a) Screen
Size
[inch (m)]
16:10 image on a 16:10 Screen 16:10 image on a 4:3 Screen
(b) Projection distance
[m (inch)]
(c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection distance
[m (inch)]
(c) Image
height
[cm (inch)
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
30 (0.8) 0.78 (31) 1.02 (40) 40 (16) 1 (0.4) 0.74 (36) 0.96 (38) 38 (15) 3.8 (1.5)
40 (1.0) 1.05 (41) 1.36 (54) 54 (21) 1 (0.5) 0.99 (48) 1.28 (50) 51 (20) 5.1 (2.0)
50 (1.3) 1.31 (51) 1.70 (67) 67 (26) 2 (0.7) 1.23 (61) 1.60 (63) 64 (25) 6.4 (2.5)
60 (1.5) 1.57 (62) 2.04 (80) 81 (32) 2 (0.8) 1.48 (73) 1.92 (76) 76 (30) 7.6 (3.0)
70 (1.8) 1.83 (72) 2.38 (94) 94 (37) 2 (0.9) 1.73 (85) 2.24 (88) 89 (35) 8.9 (3.5)
80 (2.0) 2.09 (82) 2.72 (107) 108 (42) 3 (1.1) 1.97 (97) 2.57 (101) 102 (40) 10.2 (4.5)
90 (2.3) 2.35 (93) 3.06 (120) 121 (48) 3 (1.2) 2.22 (109) 2.89 (114) 114 (45) 11.4 (4.5)
100 (2.5) 2.61 (103) 3.40 (134) 135 (53) 3 (1.3) 2.47 (121) 3.21 (126) 127 (50) 12.7 (5.0)
120 (3.0) 3.14 (124) 4.08 (161) 162 (64) 4 (1.6) 2.96 (145) 3.85 (151) 152 (60) 15.2 (6.0)
150 (3.8) 3.92 (154) 5.10 (201) 202 (79) 5 (2.0) 3.70 (182) 4.81 (189) 191 (75) 19.1 (7.5)
200 (5.1) 5.23 (206) 6.80 (268) 269 (106) 7 (2.6) 4.93 (242) 6.41 (252) 254 (100) 25.4 (10.0)
250 (6.4) 6.54 (257) 8.50 (335) 337 (132) 8 (3.3) 6.17 (303) 8.02 (316) 318 (125) 31.8 (12.5)
300 (7.6) 7.84 (309) 10.20 (401) 404 (159) 10 (4.0) 7.40 (363) 9.62 (379) 381 (150) 38.1 (15.0)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 16:10 image on a 16:10 screen
• 16:10 image on a 4:3 screen
(a)
(d)
(c)
(b)
(e)
(f)
