Vivitek DH758USTIR series User instructions

Setting Up DT01v2 with D-point software
1.Download the correct D-point driver from Vivitek.eu
http://www.vivitek.eu/products/education-projectors/
These models use the following D-point version
D755WTI (not compatible with laser module)
- D-point software version 1.1.1.3 for Windows
- D-point software version 1.1.1.4 for Mac
D755WTIR
- D-point software version 2. 2.3.1.8 for Windows
- D-point software version 2. 2.3.0.7 for Mac
D758USTIR
- D-point software version 2. 2.3.1.8 for Windows
- D-point software version 2. 2.3.0.7 for Mac
Please note that these models are not compatible with
D-point software and need the Novo-pointer software
D756USTi
D759USTi
Follow these steps when installing the software.
Install the D-point software and follow the steps.

2. Connect projector to PC
Connect the Mini USB cable to the projector and your
computer.
Make sure that you have installed the D-point software
before you plug in the USB cable.
When you connect the USB for the first time Windows will
install the driver.
Please wait until windows is finished, after installation is
completed you will get an notification that the projector is
connected.

3. Open the D-point software and select the correct
settings
Select pen mode and click configuration.
(Pen mode is used for calibration even if you want to use
Finger mode)
Select all the correct settings and press next

4. Calibration
After Auto calibration is done press the Finish button.
With the interactive Pen you can check if the interactivity works.

5. Connect the USB cable of the laser module.
Use the D-point alignment view to adjust the laser module.
More details about alignment view can be read from the
user manual.
User manual can be found on the green CD or
downloaded from www.vivitek.eu

6. Change the settings in D-point software from Pen
mode to Finger mode.
The setup is now complete.
If the Finger mode is not accurate then go back to step 3
and select Manual calibration.

Driver not installed message.
When you receive the message Driver not installed
it usually means something went wrong during installation.
In this case you need to uninstall the D-point software.
In Windows that can be done in the control panel
(Control Panel\Programs\Programs and Features.)
You also must delete the folder called D-point from your
C: drive.
You can usually find this folder on
C:\Program Files\Vivitek\D-Point 2
From our web site you can download the latest D-point version.
http://www.vivitek.eu/products/education-projectors/
Make sure that you have installed the D-point software before
you plug in the USB cable.
