Vivitek D77 Series User manual

D77 Series

—i—
Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without written consent of the author.
© Copyright 2018
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and
pending applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other
countries.
All other product names used in this manual are the properties of their respective owners and are
acknowledged.
Ver.：2

—ii—
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
General Safety Information
Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
Follow all warnings and cautions in this manual and on the unit case.
The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
Do not place the unit on an unstable surface, cart, or stand.
Avoid using the system near water, in direct sunlight, or near a heating device.
Do not place heavy objects such as books or bags on the unit.
Note:
RG1 IEC 62471-5:2015

—iii—
Projector Installation Notice
Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be
installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease
dramatically, and may lead to other unpredictable damages.
Allow at least 50 cm clearance around the exhaust vent.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.
Verify Installation Location
To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper
grounding and equalized ground potential for all of the equipment in the Projector System.
The power code provided with the Projector should be used. In case of any missing item, other
qualified 3-blade (with earthing lead) power cord can be used as substitution; however, do not use
2-blade power cord.
Verify if the voltage is stable, grounded properly and there is no electricity leakage.
Measure total power consumption which should not higher the safety capacity and avoid safety
issue and short circuit.
Turn on Altitude Mode when located in high altitude areas
The projector can only be installed upright or inverted.
When installation the bracket, make sure the weight limit is not exceed and firmly secured.
Avoid installing near air conditioner duct or subwoofer.
Avoid installing at high temperature, insufficient cooling and heavy dust locations.
Keep your product away from fluorescent lamps to avoid malfunction caused by IR interference.
The VGA IN connector should be connected to the VGA IN port. Note that it should be inserted
tightly, with the screws on both sides securely fastened to ensure proper connection of the signal
wire for achieving optimal display effect.
The AUDIO IN connector should be connected to the AUDIO IN port and CANNOT be connected
to AUDIO OUT or other ports like BNC, RCA; otherwise, it will lead to mute output and even
DAMAGE the port.
Install the projector above 200cm to avoid damage.
The power cord and signal cable should be connected before power on the projector. During the
projector starting and operating process, DO NOT insert or remove the signal cable or the power
cord to avoid damaging the projector.

—iv—
Cooling notes
Air outlet
Make sure the air outlet is 50cm clear of any obstruction to ensure proper cooling.
Air outlet location should not be in front of the lens of other projector to avoid causing illusions.
Keep the outlet at least 100cm away from the inlets of other projectors
The projector generates a massive amount of heat during use. The internal fan dissipates the heat
of the projector when shutting down, and such process may continue for a certain period. After the
project enters STANDBY MODE status, press the AC power button to turn off the projector and
remove the power cord. DO NOT remove the power cord during the shutdown process, as it may
cause damage to the projector. In the meantime, the delayed heat radiating will also affect the
service life of the projector. The shutdown process may vary depending on the model used.
Whatever the case may be, be sure to disconnect the power cord till after the projector enters the
STANDBY status.
Air inlet
Make sure there is no object blocking air input within 30 cm.
Keep the inlet away from other heat sources
Avoided heavy dust area

—v—
Power Safety
Only use the supplied power cord.
Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
Remove the batteries from the remote control when storing or not in use for a prolonged period.
Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 47
for clear and safe instructions for this procedure. Before replacing the lamp:
Unplug the power cord.
Allow the lamp to cool for about one hour.
Caution:
In rare cases the lamp bulb may burn out during normal operation and cause glass dust or shards
to be discharged outward from the rear exhaust vent.
Do not inhale or do not touch glass dust or shards. Doing so could result in injury.
Always keep your face away from the exhaust vent so that you do not suffer from the gas and
broken shards of the lamp.
Cleaning the Projector
Unplug the power cord before cleaning. See Cleaning the Projector on page 52.
Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the Regulatory Compliance section
on page 67.
Important Recycle Instructions:
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can
be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws.
For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp specific
disposal information check WWW.LAMPRECYCLE.ORG.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector. Wherever
possible, relevant information—such as an illustration and its description—has been kept on one page. This
printer-friendly format is both for your convenience and to help save paper, thereby protecting the
environment. It is suggested that you only print sections that are relevant to your needs.

—vi—
Table of Contents
GETTING STARTED..............................................................................................................................................1
Packing Checklist................................................................................................................................................1
Views of Projector Parts......................................................................................................................................2
Front-right View...............................................................................................................................................2
Limited lens shift..............................................................................................................................................3
Top view—On-screen Display (OSD) buttons and LEDs................................................................................4
Rear view.........................................................................................................................................................5
Bottom view.....................................................................................................................................................7
Remote Control Parts..........................................................................................................................................8
Remote Control Operating Range ....................................................................................................................10
Projector and Remote Control Buttons.............................................................................................................10
SETUP AND OPERATION...................................................................................................................................11
Inserting the Remote Control Batteries.............................................................................................................11
Starting and Shutting down the Projector.........................................................................................................12
Setting an Access Password (Security Lock)...................................................................................................13
Adjusting the Projector Level............................................................................................................................15
Adjusting the Focus and Keystone ...................................................................................................................16
Adjusting the Volume........................................................................................................................................16
ON-SCREEN DISPLAY (OSD) MENU SETTINGS..............................................................................................17
OSD Menu Controls..........................................................................................................................................17
Navigating the OSD.......................................................................................................................................17
Setting the OSD Language...............................................................................................................................18
OSD Menu Overview ........................................................................................................................................19
Image Menu......................................................................................................................................................22
Computer Menu.............................................................................................................................................23
Advanced Feature.........................................................................................................................................24
White Balance ...............................................................................................................................................25
Color Manager...............................................................................................................................................26
Settings 1 Menu................................................................................................................................................27
Audio..............................................................................................................................................................28
Advanced 1 Feature......................................................................................................................................29
Advanced 2 Feature......................................................................................................................................31
Settings 2 Menu................................................................................................................................................32
Status.............................................................................................................................................................33
Advanced 1 Feature......................................................................................................................................34
Advanced 2 Feature......................................................................................................................................45
MAINTENANCE AND SECURITY.......................................................................................................................47
Replacing the Projection Lamp.........................................................................................................................47
Resetting the Lamp .......................................................................................................................................49
Cleaning the filter (filter: optional parts)............................................................................................................50
Replacing the Filter...........................................................................................................................................51
Cleaning the Projector.......................................................................................................................................52
Cleaning the Projector Mirror: .......................................................................................................................52
Cleaning the Case.........................................................................................................................................53
Using the Physical Lock....................................................................................................................................54
Using the Kensington Security Slot...............................................................................................................54
Using the Security Bar...................................................................................................................................54
TROUBLESHOOTING.........................................................................................................................................55
Common problems and solutions .....................................................................................................................55
Tips for Troubleshooting...................................................................................................................................55
LED Error Messages.........................................................................................................................................56
Image Problems................................................................................................................................................56
Lamp Problems.................................................................................................................................................57
Remote Control Problems.................................................................................................................................57
Audio Problems.................................................................................................................................................57

—vii—
Having the Projector Serviced ..........................................................................................................................58
HDMI Q & A ......................................................................................................................................................59
SPECIFICATIONS................................................................................................................................................60
Specifications....................................................................................................................................................60
Projection Distance vs. Projection Size ............................................................................................................62
Projection Distance and Size Table ..............................................................................................................62
Timing Mode Table ...........................................................................................................................................63
Projector Dimensions (DW771USTi/DH773USTi)............................................................................................65
Projector Dimensions (DW770UST/DH772UST)..............................................................................................66
REGULATORY COMPLIANCE ...........................................................................................................................67
FCC Warning ....................................................................................................................................................67
Canada..............................................................................................................................................................67
Safety Certifications..........................................................................................................................................67
APPENDIX I .........................................................................................................................................................68
FOR DW770UST / DW771USTi.......................................................................................................................68
RS-232C Protocol.............................................................................................................................................68
FOR DH772UST / DH773USTi.........................................................................................................................73
Communication parameter setup......................................................................................................................73

—1—
GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
INTERACTIVE PROJECTOR (DW771USTI/DH773USTI)
DLP PROJECTOR (DW770UST/DH772UST)
REMOTE CONTROL
(W ITH T WO AAA B ATTERIES )
POWER CORD
VGACABLE
QUICK START CARD
WARRANTY CARD
THE FOLLOWING ITEMS ONLY FOR DW771USTI/DH773USTI
USB CABLE
(A-TAPE TO MINI)
PENS BOX
(WITH FOUR AAA BATTERIES
&FOUR TIPS)
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not
work. It is recommend that you keep the original packing material should you ever need to return the
equipment for warranty service.
Caution:
Avoid using the projector in dusty environments.

—2—
Views of Projector Parts
Front-right View
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Lamp cover
Removes cover to replace lamp module
2.
IR receiver
Receives IR signal from remote control
3.
Lens
Projection Lens
4.
Focus ring
Focuses the projected image
5.
Manual Lens shift
For Image vertical shift adjustment
6.
Function keys
See Top view—On-screen Display (OSD)
buttons and LEDs.
4
7.
Interactive Camera
Interactive function use
Note: Only available in DW771USTi/DH773USTi
8.
Aspheric mirror
Reflects images
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector
lamp cool. Do not obstruct any of the ventilation openings.
4 5 7
61 32 8

—3—
Limited lens shift
(Only available in DW770UST and DW771USTi)
To shift up the projection image, twist the
adjusters counter clockwise
To shift down the projection image , twist the
adjusters clockwise
Hexkey(2.5mm)
Hx1.7%
H
Hx1.7%

—4—
Top view—On-screen Display (OSD) buttons and LEDs
ITEM
LABEL
DESCRIPTION
SEE
PAGE:
1.
MENU
Opens and exits OSD menus
17
2.
Navigates in the OSD
Quick Menu –For Keystone
3.
SOURCE
Enter the Source menu
4.
Navigates and changes settings in the OSD
17
5.
Enter or confirm highlighted OSD menu item
6.
AUTO
Optimizes image size, position, and resolution
7.
Navigates and changes settings in the OSD
17
8.
Navigates in the OSD
Quick Menu –For Keystone
9.
Turns the projector On or Off
10.
LAMP LED
Red
Lamp Fail
56
Flashing
Error code
11.
POWER LED
Green
Ready to power on (Standby)
Lamp Lit , System stable
Over Temperature
Flashing
System initial, Power on,
Cooling, Error code
12.
TEMP LED
Red
Over Temperature
1
6
2
3
4
5
12
7
8
9
10
11

—5—
Rear view
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Security bar
For security and authorized usage
54
2.
Kensington lock
Secure to permanent object with a Kensington Lock
system
3.
USB-B(Service)
Connect the USB cable from a computer
4.
AUDIO L/R
(For VIDEO/ S-VIDEO)
Connect an AUDIO cable from the audio device
5.
RS-232
Connect RS-232 serial port cable for remote control
6.
AUDIO IN
Connect an AUDIO cable from the audio device
7.
MIC
Connect the Microphone for use
8.
AUDIO OUT
Connect an AUDIO cable to an audio amplifier
9.
AC IN
Connect the POWER cable
12
10.
HDMI 1
Connect the HDMI cable from a HDMI device
11.
HDMI 2
Connect the HDMI cable from a HDMI device
12.
MONITOR OUT
Connect the RGB cable to a display
13.
COMPUTER
Connect the RGB cable from a computer or components device
14.
VIDEO
Connect the composite cable from a video device
15.
USB (1.5A)
Connect the USB cable for power supply.
16.
RJ –45
Connect a LAN cable from Ethernet
17.
INTERACTIVE
Connect the USB cable to PC (for Interactive function)
Note: Only available in DW771USTi/DH773USTi
1 2 345 6 78 9
1011
1213
14
15
16
17

—6—
Note:
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI/DVI, component (thru VGA), Composite for better picture quality.
Note:
User should install driver before used Interactive function.
For more detail see driver disc.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before
making connections.

—7—
Bottom view
255.3
149.3
43.3
247.0
135.5
1222
1
1
206.3
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Tilt adjustor
Rotate adjuster lever to adjust angle position
15
2.
Ceiling support holes
Contact your dealer for information on mounting the projector on a
ceiling
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum
screw depth of 12 mm (0.47 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling
mount load capacity must exceed the weight of the installed equipment, and as an additional
precaution be capable of withstanding three times the weight of the equipment over a period of
60 seconds.

—8—
Remote Control Parts
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency
fluorescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off
certain reflective surfaces such as projector screens.
3. The buttons and keys on the projector have the same functions as the corresponding buttons
on the remote control. This user’s manual describes the functions based on the remote control.
Note:
Complies with FDA performance standards for laser products except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007

—9—
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
IR transmitter
Transmits signals to projector
2.
Status LED
Lights when the remote control is used
3.
Laser
Press to operate the on-screen pointer
4.
Up
Up arrow when connected through USB to a PC
5.
Right
Right arrow when connected through USB to a PC
6.
Down
Down arrow when connected through USB to a PC
7.
Page Down
Page down when connected through USB to a PC
8.
Up cursor
Navigates in the OSD
17
9.
Right cursor
Navigates and changes settings in the OSD
10.
Down cursor
Navigates in the OSD
11.
Volume +/-
Adjusts volume
16
12.
Mute
Mutes the built-in speaker
13.
Zoom+
Zoom in
14.
Zoom-
Zoom out
15.
Freeze
Freeze/unfreezes the on-screen picture
16.
Blank
Makes the screen blank
17.
Source
Detects the input device
18.
Auto
Auto adjustment for phase, tracking, size, position
19.
Menu
Opens or exit the OSD
17
20.
Status
OpenstheOSDStatusmenu(themenuonly opens when
an input device is detected)
33
21.
Keystone
top/bottom
Corrects image-trapezoid (wider top/bottom) effect
16
22.
Left cursor
Navigates and changes settings in the OSD
17
23.
Enter
Changes settings in the OSD
24.
Page Up
Page up when connected through USB to a PC
25.
Left
Left arrow when connected through USB to a PC
26.
Enter
Enter key when connected through USB to a PC
27.
Power
Turns the projector on or off
12
28.
Laser
Use as on-screen pointer. DO NOT POINT IN EYES.
Caution:
Use of controls, adjustments or performance of procedures other than those specified herein may
result in hazardous laser light exposure.

—10—
Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point
the remote directly at the projector. Provided you are not holding the remote perpendicular to the
sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23
feet) and 15 degrees above or below the projector level. If the projector does not respond to the
remote control, move a little closer.
Projector and Remote Control Buttons
The projector can only be operated using the remote control. All operations can be carried out with
the remote control.

—11—
SETUP AND OPERATION
Inserting the Remote Control Batteries
1.
Remove the battery compartment
cover by sliding the cover in the
direction of the arrow.
2.
Insert the battery with the positive
side facing up.
3.
Replace the cover.
Caution:
1. Only use AAA batteries (Alkaline batteries are recommended).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.

—12—
Starting and Shutting down the Projector
1.
Connect the power cord to the
projector. Connect the other end to
a wall outlet.
2.
Turn on the connected devices.
3.
Ensure the POWER LED displays a
solid green. Then press the POWER
button of the remote to turn on the
projector.
The projector splash screen displays
and connected devices are
detected.
See Setting an Access Password
(Security Lock) on page 13 if
security lock is enabled.
4.
If more than one input device is
connected, press the SOURCE
button of the remote and use ▲▼ to
scroll among devices.
(Component is supported through
the RGB to COMPONENT
ADAPTER.)
HDMI1/HDMI2: HDMI, DVI
VGA: Analog RGB
Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr via HD15 connector
Composite Video: Traditional composite video
5.
When the “Power Off? /Press Power
again” message appears, press the
POWER button. The projector turns
off.
Caution:
Do not unplug the power cord until the POWER LED solid green–indicating the projector has
cooled down.
