Vivo DESK-AC05M User manual

Under Desk Storage Drawer with Mouse Platform
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/desk-ac05m
SKU: DESK-AC05M
[email protected]om www.vivo-us.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or
inappropriate use.
PACKAGE CONTENTS
TOOLS NEEDED
Scissors
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
ASSEMBLY STEPS
STEP 1
Place the Drill Template (C) on the
underside of the desktop, making sure
the flat side is flush with the edge, and
mark drilling locations with a pencil.
Drill 15mm (0.6”) deep holes using a
3mm (3/25”) drill bit.
WARNING!
Phillips
Screwdriver
A (x1)
Tray
B(x1)
Support Post
C(x1)
Drill Template
S-A (x3)
ST4.2x30mm
Screw
D (x1)
Cable Clip
6.6lbs
(3kg)
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
5/8” (16mm)
15mm (0.6”)
3mm
(3/25”)

3
STEP 2
Unscrew the Knob (B1) from the Support Post (B) and set aside.
Making sure the flat side is facing forward, mount the Support Post (B) to the desktop
using ST4.2x30mm Screws (S-A).
STEP 3 STEP 4
Snap the Cable Clip (D) into the back of
the Support Post (B). Attach the Tray (A)
to the post using the previously removed
Knob (B1).
Place mouse on the Tray (A). If the mouse
is wired, use the cable clip to organize
the wire. Swivel the mousepad on top to
open the tray for storage. The tray may be
swiveled underneath the desktop when not
in use.
+180 °
-180 °
+180 °
-180 °
D
A
B1
B
B
S-A
B
B1

LAST UPDATED: 08/16/2022
REV 1.1
