Vivotek AP-FXC-0150 User manual

100m
100m
AW-FED-0500
PoE switch
100m
Uplink
100m
100m100m
Line2
C1
C2
C3
R1 R2
AP-FXC-0250 AP-FXC-0250
POWER Green ON Power link is connected from the PoE source.
Green OFF Power is off.
PoE IN Green ON PoE IN port is connected.
Fast blinking Data is being transmitted or received.
OFF No connection.
OUT# Green ON Port is linked to a powered device.
OFF No device is connected.
1. Install the device in a ventilated and dry place, that is free of electromagnetic source, vibration, moisture, and dust.
2. Make sure the ventilation openings on the extender are not blocked.
3. Use CAT5 or 6 UTP/STP cables. Avoid using low-quality cables, which will seriously limit the cabling distance.
AP-FXC-0150 and AP-FXC-0250 PoE Extender
Quick Installation Guide
The AP-FXC-0250 is a PoE extender capable of feeding 15.4/30W power to powered devices for a distance of up to 300
meters. Multiple extenders can be cascaded to increase the cabling distance and the number of powered devices.
IMPORTANT:
INTRODUCTION
LED DEFINITIONS
CONNECTION
• 1x PoE extender • 1x Quick Installation Guide
PACKAGE CONTENTS
Following are the conditions for making the cabling:
1.Use18~19Ω,24AWGCAT5cables.
2. Typical VIVOTEK cameras stream size feature = 1080p@30fps - 6Mbps; 720p@30fps - 3Mbps.
Make sure the combined bandwidth consumption does not exceed the uplink bandwidth from the PoE switch.
3. The transaction on the PoE extender consumes 2W of power. Therefore, on Line2, the total power requirement is:
C1*+C2+C3+R1**+R2+(5W***x5).
If every camera consumes 5W, the total consumption is 44W.
* Cn = camera consumption,
** Rn = extender consumption, 2W.
*** A typical 100 meters connection induces a 5W power loss due to resistance.
AP-FXC-0250
Part no.: 625029100G
AP-FXC-0250_QIG,v1.0_20150120.indd 1 2015/1/27 下午 04:41:59

VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T:[phone]|F:[phone]|E:[email protected]
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
|T: 408-773-8686|F: 408-773-8298|E: [email protected]
VIVOTEK Netherlands B.V.
Busplein 36, 1315KV, Almere, The Netherlands
|T:[phone]|F:[phone]|E:[email protected]
100m
100m 100m 100m
Uplink
AW-FED-0500
PoE switch
Line2
C1R1 R2
AP-FXC-0150 AP-FXC-0150
POWER Green ON Power link is connected from the PoE source.
Green OFF Power is off.
PoE IN Green ON PoE IN port is connected.
Fast blinking Data is being transmitted or received.
OFF No connection.
OUT# Green ON Port is linked to a powered device.
OFF No device is connected.
1. Install the device in a ventilated and dry place, that is free of electromagnetic source, vibration, moisture, and dust.
2. Make sure the ventilation openings on the extender are not blocked.
3. Use CAT5 or 6 UTP/STP cables. Avoid using low-quality cables, which will seriously limit the cabling distance.
The AP-FXC-0150 is a PoE extender capable of feeding 15.4/30W power to powered devices for a distance of up to 300
meters. Multiple extenders can be cascaded to increase the cabling distance and the number of powered devices.
IMPORTANT:
INTRODUCTION
LED DEFINITIONS
CONNECTION
• 1x PoE extender • 1x Quick Installation Guide
PACKAGE CONTENTS
Allspecicationsaresubjecttochangewithoutnoice.
Copyright © 2014 VIVOTEK INC. All rights reserved.
Following are the conditions for making the cabling:
1.Use18~19Ω,24AWGCAT5cables.
2. Typical VIVOTEK cameras stream size feature = 1080p@30fps - 6Mbps; 720p@30fps - 3Mbps.
Make sure the combined bandwidth consumption does not exceed the uplink bandwidth from the PoE switch.
3. The transaction on the PoE extender consumes 2W of power. Therefore, on Line2, the total power requirement is:
C1*+R1**+R2+(5W***x3).
If the camera consumes 5W, the total consumption is 24W.
* Cn = camera consumption,
** Rn = extender consumption, 2W.
*** A typical 100 meters connection induces a 5W power loss due to resistance.
AP-FXC-0150
AP-FXC-0250_QIG,v1.0_20150120.indd 2 2015/1/27 下午 04:41:59
