Vivotek FD7130 User manual

Quick Installation Guide
This guide describes the basic functions of FD7130
All detailed information is described in the user's manual.
FD7130
IP Surveillance
Vandal-proof .Tamper Detection .PoE
English ᖅϛ Рҏᇭ Español Português
ᙏϛ Français Deutsch Italiano Türkçe Polski Русский Česky Svenska

EN - 1
English
Power off the Network Camera as
soon as smoke or unusual odors are
detected.
Contact your distributor in the event of
occurrence.
Keep the Network Camera
away from water. If the Network
Camera becomes wet, power off
immediately.
Do not place the Network Camera
around heat sources, such as a
television or oven.
Refer to your user’s manual for
the operating temperature.
Keep the Network Camera away from
direct sunlight.
Do not place the Network Camera
in high humidity environments.
Contact your distributor in the event of
occurrence.
Warning Before Installation

EN - 2
Do not place the Network Camera
on unsteady surfaces.
Do not touch the Network Camera
during a lightning storm.
Do not disassemble the Network
Camera.
Do not drop the Network Camera.
Do not insert sharp or tiny objects
into the Network Camera.

EN - 3
English
Software CD
FD7130 with an RJ45 or M12 Cable
Quick Installation Guide /
Warranty Card
Screwdriver
Alignment Sticker
Ground Wire / Screws
Liquid Tight Connectors for
RJ45 or M12 Cable
Package Contents
1
RJ45 M12
RJ45
Silica Gel

EN - 4
Network Camera
Model No: FD7130
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Pat. 6,930,709
MAC:0002D107258A
RoHS
Record the MAC address
before installing the camera.
Screw Holes
Physical Description
2
Inner View
Outer View
Lens
MicroSD/SDHC Card Slot
Reset Button
Status LED
Temperature Alarm
The alarm will be triggered
once the temparature inside the
Network Camera reaches 60°C.
Waterproof Level: IP66

EN - 5
English
123
45
6
78
(D) (B) (C)
(A)
(E)
Cabling Assembly
3
Components of the Waterproof
Connector
Screw Nut (C)
Housing (D)
Gasket (E)
Seal (B)
Sealing Nut (A)
RJ45 Cable Dimension (unit: mm)
Prepare an Ethernet cable
and strip part of the sheath.
Insert the housing into the
screw nut.
Insert the seal into the housing.
Insert the stripped Ethernet
cable through the sealing
nut and the housing.
Clamp the cable with
an RJ45 plug.
Push the RJ45 plug into the
housing, then secure the
sealing nut tightly.
Attach the gasket to the front
of the housing.
Assembling Steps
Recommended cable gauge: 24AWG
(0.51 mm)
Connect the Ethernet cable to the RJ45 cable
and secure the connectors tightly.
RJ45 Cable Connector

EN - 6
123
4 5
6 7
Ø4.5mm~Ø6.5mm
(C) (D)
(B)
(A) (E)
M12 Cable Connector
Components of the Waterproof
Connector
M12 Cable Dimension (unit: mm)
Assembling Steps
Clamp Ring (C)
Gasket (D)
Plastic Nut (E)
Seal (B)
Sealing Nut (A)
Prepare an Ethernet cable
and strip part of the sheath.
Insert the seal into the clamp
ring.
Insert the gasket into the clamp
ring.
Insert the stripped Ethernet
cable through the sealing nut
and the clamp ring.
Follow the pin definition in the below table
to solder the stripped Ethernet cable to the
plastic nut.
Secure the sealing nut to the
clamp ring tightly.
Follow the pin definition in the below table
to connect the Ethernet cable to the M12
cable and secure them tightly.
Ethernet Cable /
M12 Cable
Wire Color
1 Orange/White
2 Orange
3 Green/White
4 Blue
5 Blue/White
6 Brown/White
7 Brown
8Green
Ethernet Cable M12 Cable

EN - 7
English
First, use the supplied screwdriver to detach the dome cover from the camera base. Insert your
MicroSD/SDHC Card if necessary.
Then, follow the steps below to install the camera to either the ceiling or the wall:
1. Attach the supplied alignment sticker to the ceiling/wall.
2. Using the 3 screw circles on the sticker, drill 3 pilot holes into the ceiling/wall. Then hammer the
plastic anchors into the holes.
3. This Network Camera can be mounted with the cable routed through the camera base or from
the side of the dome cover. If you want to feed the cable through the ceiling/wall, please also
cut or drill a hole (A) for the cable. If the cable goes through the side of the dome cover, please
remove the rubber stopper (B).
4. Through the 3 holes on the camera base, insert the screws to corresponding holes and secure
the camera base with a screwdriver.
12
3
4
A
B
A
Dome Cover
Hardware Installation
4
Tamper-proof Screw
Camera Base
Rubber Stopper
Ceiling Mount

EN - 8
1
2
B
A3
4
Wall Mount
Installing the Ground Wire
As shown in the following figure, please secure one side of the supplied ground wire to the screw
hole, then route the other side of the ground wire to the ground.
Please secure the screws tightly to
avoid moisture.

EN - 9
English
Network Deployment
5
Power over Ethernet (PoE)
POWER COLLISION
LINK
RECEI VE
PARTITION
12345
PoE Switch
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and a non-PoE
switch.
When using a PoE-enabled switch
This Network Camera is PoE-compliant, allowing transmission of power and data via a single
Ethernet cable. Follow the below illustration to connect the camera to a PoE-enabled switch via
Ethernet cable.
POWER COLLISION
LINK
RECEIV E
PARTITION
12345
PoE Power Injector
(optional)
Non-PoE Switch

EN - 10
Network Camera
Model No: FD7130
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Pat. 6,930,709
MAC:0002D107258A
RoHS
1. Install “Installation Wizard 2” from the Software Utility directory on the software CD.
2. The program will conduct an analysis of your network environment. After your network is ana-
lyzed, please click on the “Next” button to continue the program.
3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras
on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches the one
labeled on the bottom of your device to connect to the Network Camera via Internet Explorer.
0002D107258A
00-02-D1-07-25-8A 192.168.5.151 FD7130
Installation
Wizard 2
Assigning an IP Address
6

EN - 11
English
For further setup, please refer to the user's manual on the software CD.
Ready to Use
7
1. Access the Network Camera on the LAN.
2. Retrieve live video through a web browser or recording software.
To adjust the viewing angle
Adjust the lens to a desired viewing angle as the diagram shown below.
10° 10° 90°
Adjusting the Lens
8
DO NOT over rotate the lens. Doing
so will damage the camera lens
module.

EN - 12
Attach the dome cover to camera. Secure the dome screws with the supplied screwdriver. Finally,
make sure all parts of the camera are securely installed.
Completion
9
Fine-tune the Camera Focus
The focus of this network camera is set from 1.0m to infinity by factory default. If you want to focus
on objects closer than 1.0m or the lens has lost focus, please fine tune it in the following way.
Tighten the lens lock screw.
1. Loosen the lens lock screw.
2. Manually rotate the lens to fine-tune the focus
until the live image is clear.
3. Tighten the lens lock screw.
Please secure the screws tightly to
prevent the cabling against moisture.
Tear down the aluminum foil vacuum bag and take out the silica gel. Attach the supplied silica gel to
the inner side of the Network Camera. (Please replace the silica gel with a new one if you open the
back cover after installation.)

P/N: 625008801G Ver.1.1
