Vivotek FD7131 User manual

EN - 1
English
Power off the Network Camera as soon as
it is found smoking or smelt unusual.
Contact your distributor when such cases
happen.
Keep the Network Camera away from the
water. If the Network Camera is wet, power
off immediately.
Do not place the Network Camera around
the heat sources, such as television or
oven.
Refer to your user's manual for the
operating temperature.
Keep the Network Camera away from direct
sunlight. Do not place the Network Camera in high humid environments.
Contact your distributor when such cases
happen.
Warning Before Install
Do not place the Network Camera on
unsteady surfaces.
Do not touch the Network Camera when
it's lightening.
Do not disassemble the Network Camera. Do not drop the Network Camera.
Do not insert any object into the Network
Camera, such as needles.

EN - 2
Software CD
FD7131
Warranty card
Screwdriver
Alignment sticker
Screws and I/O connector
Quick installation guide
Power adapter
Package Contents
1

EN - 3
English
Keep a note of the MAC address
before installing the camera.
Network Camera
Model No: FD7131
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Pat. 6,930,709
RoHS
C I
MAC: 0002D1122299
Drill holes
Dome cover
Physical Description
2
Lens
Tilt screw
Built-in MIC
PIR sensor
White-light LEDs
Power cord socket
Ethernet 10/100 RJ45 socket
Indented reset button
Audio Out Mic. In Ext. Int.
1 2 3 4
Focus controller
Zoom controller
General I/O terminal block
Audio out
MIC in
External/Internal MIC switch
Pan screw
Image adjustment
screw
Status LED

EN - 4
First, use the supplied screwdriver to detach the dome cover from the camera base. Then,
follow the steps below to install the camera; either to a ceiling or to a wall.
Ceiling mount
Through the two holes on each side of the camera base, insert
the supplied two screws to corresponding holes and secure
them with a screwdriver.
Wall mount
1. Attach the alignment sticker to the wall.
2. Through the two circles on the sticker, drill two pilot holes
into the wall.
3. Hammer the supplied plastic anchors into the holes.
4. Align the two holes on each side of the camera base with the
two plastic anchors on the wall, insert the supplied screws to
corresponding holes and secure them with a screwdriver.
Alignment sticker
Installation Tips
Before installing the camera, look for a spot that best suits your needs. The built-in PIR
sensor is designed to be triggered when a person enters its detection range. Therefore,
it is crucial to install the camera at a place with the PIR sensor facing the desired direc-
tion. (The sensitivity of PIR sensor depends on object size and temperature differences
between the object and the background environment.)
Audio Out Mic. In Ext. Int.
1 2 3 4
Side viewTop view
Hardware Installation
3

EN - 5
English
General Connection (without PoE)
1. If you have external devices such as sensors and alarms, make connections from gen-
eral I/O terminal block.
2. Connect the camera to a switch via a Ethernet cable.
3. Connect the supplied power cable from the camera to a power outlet.
POWER COLLISION
LINK
RECEI VE
PARTITION
12345
2
3
Ethernet switch
Network Deployment
4
1: Power
2: Digital output
3: Digital input
4: Ground
Audio Out Mic. In Ext. Int.
1 2 3 4
1

EN - 6
Power over Ethernet (PoE)
POWER COLLISION
LINK
RECEI VE
PARTITION
12345
PoE switch
POWER COLLISION
LINK
RECEI VE
PARTITION
12345
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the camera and a non-PoE
switch.
PoE power injector
(optional)
When using a PoE-enabled switch
The camera is PoE-compliant, allowing transmission of power and data via single Ether-
net cable. See the following illustration to connect the camera to a PoE-enabled switch
via Ethernet cable.
non-PoE switch

EN - 7
English
Network Camera
Model No: FD7131
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC: 0002D1122299
1. Install the "Installation Wizard 2" under the Software Utility directory from software CD.
2. The program will conduct analyses on your network environment. After your network is
analyzed, please click on the "Next" button to continue the program.
3. The program will search the VIVOTEK Video Receivers, Video Servers or Network Cam-
eras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches the
one labeled on the bottom of your device to connect the Internet Explorer to the Network
Camera.
0002D1122299
Installation
Wizard 2
Assigning IP Address
5

EN - 8
For further setup, please refer to user's manual on the software CD.
Ready to Use
6
1. Access to the Network Camera from the Internet.
2. Retrieve live video through web browsers or recording software.

EN - 9
English
Based on the live image retrieved from the camera, adjust the camera lens by doing the
following:
T
W
∞
N
DO NOT over tighten the controllers.
Doing so would damage the structure
of camera lens.
To adjust the viewing angle
1. Loosen the pan screw and then turn the lens module left and right. Upon completion,
tighten the pan screw.
2. Loosen the tilt screws on both side of the camera and then turn the lens module up and
down. Upon completion, tighten the tilt screws.
3. Loosen the image adjustment screw and then turn the lens to adjust the image
orientation. Upon completion, tighten the image adjustment screw.
To adjust the zoom factor and focus range
1. Loosen the zoom controller and then adjust zoom factor by moving the controller left and
right. Upon completion, tighten the zoom controller.
2. Loosen the focus controller and then adjust focus range by moving the controller left and
right. Upon completion, tighten the focus controller.
Audio Out Mic. In Ext. Int.
1 2 3 4
Audio Out Mic. In Ext. Int.
1 2 3 4 Audio Out Mic. In Ext. Int.
1 2 3 4
2
3
1
Loosen Tighten
Loosen
Tighten Loosen
Tighten
Loosen
Tighten
Rotate the screw
Turn the lens
Adjusting the Lens
7

EN - 10
Attach the dome cover to camera. Secure the two dome screws with a screwdriver.
Finally, make sure all parts of the camera are securely installed.
The supplied screwdriver is exclusively
designed to match the dome screws. In case
you will need to adjust the lens at a later time,
do not discard the screwdriver.
Completion
8
