VXT5200A
INSTALLATION GUIDE
PAGE 1 of 2
BEFORE BEGINNING YOUR INSTALLATION
Read through the instruction guide before getting started with the installation. Professional installation is recommended for
this product.
CONTENTS
6 Gallon Aluminum Air Tank (Silver)
Mounting Hardware
SAFETY INSTRUCTIONS
Install all fittings and accessories in the tank before pressurizing the tank.
Before assembly, use thread sealant on all fitting's threads, then use a wrench to tighten each part. IMPORTANT:
Do not over tighten.
Tank must be drain frequently.
We recommend always to install a drain and safety valves in the tank.
Always depressurize the tank before servicing or adding accessories.
Do not use this tank as a breathing device.
Be sure to pump nothing other than atmospheric air.
It is important to determine the maximum air pressure for any tool or attachment before using it.
Make sure your battery ground is detached before you begin the installation.
Employ equipment for eye protection during drilling operations.
Over pressuring the tank beyond the specified maximum working pressure (200 PSI) may result in death or
serious injury.
PLANNING YOUR INSTALLATION
Before beginning the installation, determine each component’s spot.
Confirm you have the proper length of airline and wire.

VXT5200A
INSTALLATION GUIDE
PAGE 2 of 2
MOUNTING
Find a convenient mounting location in your vehicle for the air tank. Ensure ports are reachable before drilling
any holes.
Mark the location of holes using the mounting bracket of the air tank as a template, and then drill to size.
Using mounting hardware provided, secure the air tank. IMPORTANT: Do not mount on a flexible material.
BRAIDED HOSE INSTALLATION
Connect the stainless steel braided hose of your compressor to the tank’s inlet port.
PORT LOCATIONS AND THREAD SIZE (NPT)
MAINTENANCE
Make sure that electrical and fitting connections are regularly inspected, cleaned and tightened when needed.
Make sure mounting screws are regularly tightened if needed.
Drain weekly, to avoid excessive buildup of condensation.
SOLUTIONS TO COMMON ISSUES
Issue: Loss of pressure of tank.
Solution 1: Tighten drain cock.
Solution 2: Examine air and check valves and replace if damaged or leaking.
Solution 3: Use soap and water solution on air connections and tank, and tighten connections or repair leaks where
needed.
Issue: Excessive moisture in horn or safety valve (if installed).
Solution 1: Depressurize and drain the tank.
Solution 2: Relocate the compressor to a drier location.
