Vizio E3D320VX User manual

E3D320VX / E3D420VX / E3D470VX
QUICK START GUIDE
THEATER 3D™LCD HDTV WITH VIZIO INTERNET APPS®

PACKAGE CONTENTS
1
Cleaning ClothRemote Control with
Batteries
User Manual and
Quick Start Guide
VIZIO 3D LCD HDTV with Stand
Power CordSafety Cable
(E3D420VX and E3D470VX only)
1 Pair
Basic Theater 3D Glasses
1 Pair
Premium Theater 3D Glasses

USING THE REMOTE
Power/Standby: Turn the TV on or off.
Input: Change the input device.
App Launcher: Launch the VOD (VIZIO On-Demand), Netflix, or
VUDU App.
A/V Controls: Control external device (CEC-enabled devices only).
Info: Display the Info Window.
CC: Open the Closed Captioning menu.
Menu: Display the on-screen menu.
Exit: Close the on-screen menu.
Arrow: Navigate the on-screen menu and episode guide.
OK: Select highlighted menu option.
Guide: Display the episode guide (digital channels only).
Back: Go to the previous on-screen menu options.
VIA Shortcuts: Control VIZIO Internet Apps.
Channel Up/Down: Change the channel. With each press of the button,
the channel will increase or decrease by one.
Volume Up/Down: Increase or decrease the loudness of the TV’s audio.
V Button: Start VIA Internet Apps.
Mute: Turn the sound off or on. When mute is activated, the
TV’s audio is turned off.
Last: Return to the channel last viewed.
Number Pad: Use the number pad to manually enter a channel.
Dash (-): Use with number pad to manually enter a digital
sub-channel. (For example, 18-4 or 18-5.)
3D: Activate 3D content.
QWERTY Keypad: Enter letters and numbers.
Power/Standby
A/V Controls
Info
Menu
Arrow
Channel Up/Down
Last
Number Pad
3D
Mute
Volume Up/Down
OK
Exit
Input
GuideBack
V Button
Dash (-)
CC
VIA Shortcuts
App Launcher
QWERTY Keypad
Arrow VIA Shortcuts
Battery Compartment

INSTALLING THE BASE
1
Place the TV screen-down on a clean, flat surface. To prevent
scratches or damage to the screen, place the TV on a soft
surface, such as carpet, rug, or blanket.
VIZIO RECOMMENDS
Though your TV has a stand included, it can also be mounted
on a wall. VIZIO recommends the XMT1200 Ultra Slim Tilt
Universal Wall Mount. This easy-to-install wall mount
supports 37” to 60” HDTVs up to 120 pounds and features:
• A built-in bubble level and is less than 2” thin
•Tilts up to 15° downward – perfect for mounting above
eye level
•Includes $10,000 insurance and 1-year warranty
Visit www.VIZIO.com to purchase online.

Align the stand with the holes on the back of the TV.
Using a philips-head screwdriver, attach the base to the TV by
inserting and tightening the 6 included screws.
23
Move the TV with attached stand into an upright position and
place on a flat, level, and stable surface.

Remove the battery cover by pressing gently and sliding away
from the remote.
Insert the batteries. The +and -symbols on the batteries
must correspond to the +and -symbols inside the battery
compartment.
Replace the battery cover by gently sliding it back into place.
FIRST-TIME SETUP
2
Connect the power cord to the back of the TV.
Plug the power cord into an electrical outlet.
1

If you have an external antenna or a cable connection that
extends from a wall outlet, connect it to the TV with an
RF/Coaxial cable.
If you have a high-speed internet connection and would like to
connect the TV with an ethernet cable, connect it to the back of
the TV as shown.
4
Turn the TV on by pressing the Power/Standby button on the
remote.
The Setup App is displayed.
Use the Arrow buttons on the remote to highlight
Home Mode Setup and press OK.
3

5
Use the OK and Arrow Up/Down buttons on the remote to read
and accept the Terms of Service and Privacy Policy for Yahoo! TV
Widgets.
When you are finished, highlight Next and press OK.
6
Select the name of your wireless network from the list of
available networks and press OK.
Enter your network key using the on-screen keyboard, then
highlight Connect and press OK.
If the TV is connected to your network with
an ethernet cable, you will not see this screen.

7
Enter your First Name, Last Name, Phone Number, ZIP Code, and
E-mail Address using the on-screen keyboard.
Highlight Next and press OK.
8
Answer the on-screen questions about your TV connection using
the Arrow and OK buttons on the remote.
When you have finished the channel scan, highlight Exit to Live
TV and press OK.
The First-Time Setup is complete.

CONNECTING YOUR DEVICES
1
Ensure your device has one of the above ports.
Turn your device and the TV off.
Connect your devices using the connection chart on the next
page. This chart shows the most common connections. If you
would like to see additional connection options, see Connecting
Your Devices in the user manual.
HDMI
Component
Composite AV
VIZIO RECOMMENDS
To get the best high-resolution picture and sound on your new
VIZIO 3D TV, connect your devices with an HDMI cable.
VIZIO High Speed HDMI Cables are manufactured to produce
the best picture on VIZIO TVs and feature:
•1080p and for full HD video and future Ultra-HD video
•Great flexibility for thin wall mounts
•Stays securely connected at sharp angles
•Limited lifetime warranty
Visit www.VIZIO.com to purchase online.

High Speed HDMI Cable*
Composite AV Cable*
Component Video Cable*
Audio Cable*
Y
CB/PB
CR/PR
L
R
L
R
VIDEO
HDMI
Y
CB/PB
CR/PR
L
R
L
R
VIDEO
HDMI
Good Picture
(2D Only)
Best Picture
(3D-Ready)
Better Picture
(2D Only)
2
Blu-ray/DVD Player, Game Console,
or other Device
OR
CHOOSE ONE:
OR
Back of TV
*Not Included

Turn on the TV and select the input to which the 3D Blu-ray
player is connected (HDMI-1, HDMI-2, etc).
Turn your 3D Blu-ray player on and insert a Blu-ray 3D disc.
Select the Play Movie option in the Blu-ray 3D disc’s main menu.
HOW TO VIEW 3D
You will need:
•A 3D Blu-ray™ player*
•A Blu-ray 3D™disc*
•VIZIO Theater 3D Glasses
•A 3D-ready HDMI cable connecting the
3D Blu-ray player to your 3D HDTV*
1 2
3D Blu-ray Player
Blu-ray 3D Disc
3D-Ready HDMI Cable
*Not Included
VIZIO Theater 3D Glasses

The 3D HDTV asks if you would like to watch the movie in 3D.
Select Yes and press OK.
Put on your VIZIO Theater 3D glasses and enjoy Theater 3D!
For the best 3D experience:
 •TrytoviewtheTVstraight-on, as shown above. Do not view
the TV at an extreme angle, as some of the 3D effect will be
lost.
 •Sitatleast6 feet from the TV.
For more detailed information on viewing 3D, see the User Manual.
43
6’

USING VIZIO INTERNET APPS
1
Turn the TV on. Press the VButton on the remote.
To use VIZIO Internet Apps, your TV must
be connected to a high-speed internet
connection. If you did not set up your network
during First-Time Setup, see Setting Up Your
Network Connection in the User Manual.
VIZIO RECOMMENDS
For the best online experience, VIZIO recommends the next-generation
XWR100 Dual-Band HD Video and Wireless Internet Router. This
state-of-the-art router prioritizes the sending of media files over regular
data files, delivering a superior streaming experience with fewer delays.
Visit www.VIZIO.com to purchase online.
FREE Trial! Go to
www.netflix.com/VIZIO.
See Terms of Use for
details.
Listen to millions of songs
on demand. Go to
www.rhapsody.com/VIZIO
to get your free 30-day trial.*
Activate VUDU on your
VIZIO VIA TV to receive
a FREE 1080p HD
RENTAL.**
†See www.blockbuster.com/VIZIO for details.
*US only. Credit Card required. See site for complete terms.
**VUDU account activation required.
FREE Entertainment
Bundle worth $25+ when
you activate Blockbuster
on your VIZIO VIA TV.†
V Button

To start an App, use the Left/Right Arrow buttons to highlight an
App from the App Bar and press OK.
The highlighted App is in the lower left corner of the screen.
3
Once you have started an App, use the Arrow, OK, and VIA
Shortcut buttons on the remote to control the App.
Move/Delete App from VIA Dock
Change Screen Size
(when VIA Sidebar is open)
View Settings for Active App
Exit App/Exit VIA Dock
2
Highlighted App

Add home theater surround sound without the excess clutter of wires! The VIZIO 5.1 Surround Sound Home Theater with Wireless
Subwoofer delivers big home theater sound in a sleek design that’s perfect for your TV:
•Universal 5.1 soundbar with rear satellite speakers and wireless subwoofer turns any TV into a home theater
•Wireless subwoofer uses Wireless HD Audio™2.4 GHz, so you can place it anywhere in the room
•Premium sound with Dolby Digital®, DTS, SRS CircleCinema HD™and SRS TruVolume™.
VIZIO RECOMMENDS

Complete your Theater 3D experience! The VIZIO 3D Blu-ray Player with Wireless Internet Apps delivers 3D, full 1080p HD video,
7.1 surround sound, and has built-in 802.11n dual-band wireless for easy access to movies, TV shows, music and more from the Internet.
•Exceptional 3D performance
•Streams movies, music, and more with VIZIO Wireless Internet Apps
•Built-in Wi-Fi 802.11n
AVAILABLE AT VIZIO.COM

HELP TOPICS
Products are often returned due to a technical problem rather than a defective product that may
result in unnecessary shipping charges billed to you. Our trained support personnel can often
resolve the problem over the phone. For more information on warranty service or repair, after the
warranty period, please contact our Support Department at the number below.
Customer support and quality service are integral parts of VIZIO’s commitment to service excellence.
For technical assistance contact our VIZIO Technical Support Department via email or phone.
Please have your VIZIO model number, serial number, and date of purchase available before your
call.
Phone:
Fax:
Email:
Web:
[phone]
[phone]
[email protected]
www.vizio.com
Hours of operation:
Monday - Friday: 6 am to 9 pm (PST)
Saturday - Sunday: 8 am to 4pm (PST)
The picture quality
seems low.
•Viewhigh-denition(HD)programswhenpossible.
•Ensureallcablesaresecurelyconnected.
•Ifyouareusinganantenna,thesignalstrengthofthechannelmaybelow.Ensureyourantennaisconnected
securely to the TV and move the antenna around the room or close to a window for the best signal.
There is no power.
•EnsurethepowercordissecurelyconnectedtotheACsocketontheTVandaworkingelectricaloutlet.
•PressthePower/Standby button on the remote or on the right side of the TV.
•Trypluggingthepowercordintoadifferentelectricaloutlet.
There is a picture,
but there is no sound.
•PresstheVolume Up button on the remote or on the right side of the TV.
•PresstheMUTE button on the remote to ensure Mute is off.
•PressMENU, then select TV Settings > Audio. Ensure TV Speakers is set to On.

The colors on the TV
don’t look right.
•AdusttheColorandTintsettingsinthePicturemenu.See Adjusting the Picture Settings in the user manual.
•Resetthepicturesettings.See Resetting the Picture Settings in the user manual.
•Checkallcablestoensuretheyaresecurelyattached.
I cannot return to
the Setup App.
•Theon-screenmenuhasguidedsetup.PressMENU, then select Help > System Reset >
Start Setup Wizard. Enter your PIN (default is 0000). Select Yes.
There are black/gray
bars on the top/bottom/
sides of the picture.
•SettheTVtoWideorZoomMode.PressMENU, then select Wide. Highlight Wide or Zoom and press OK.
•Adjustthevideosettingsofyourexternaldevice(Blu-ray™or DVD player).
•IfusingtheRGB(computer)input,ensureyouareusingasupporteddesktopresolution.
•Sometelevisionchannelsaddblackbarstothepicture.
I cannot view 3D content.
•Ensureyouhavea3DBlu-ray™player, VIZIO Theater 3D glasses, and a Blu-ray 3D™disc.
•Turnyour3DHDTVand3DBlu-rayplayeroff.Turnthe3DBlu-rayPlayeronrst,thenturnthe3DHDTVon.
Try to play your Blu-ray 3D™movie again.
•Ensureyour3DBlu-rayplayer’s3DsettingisEnabled/Auto. (Devices differ, see your player’s user guide.)
The TV displays “No Signal”
•Ensureyourconnecteddevicesareturnedon.
•PresstheINPUT button on the remote and select the input to which your device
is connected (HDMI, Composite, etc).

TRADEMARKS SHOWN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. VIZIO, THE V LOGO, WHERE VISION MEETS VALUE,
AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© 2011 VIZIO INC. ALL RIGHTS RESERVED.
110110ST-NC
