Vizio L13 User manual

Important Safety Instructions
Explanation of WARNING symbols
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of not isolated dangerous voltage within the
inside of the product that may be sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and servicing instructions in the literature
accompanying the appliance.
Safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.

Important Safety Instructions
10) Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15) Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, shall not be placed on the apparatus.
16) The Shock Hazard Marking and Associated Graphical Symbol is
provided on the better panel of unit.
WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.

Thankyou forpurchasing multi-scan color LCD-TV.
Please read this guide thoroughly before installation.
FCC RADIO FREQUENCYINTERFERENCESTATEMENT
WARNING:(FORFCC CERTIFIEDMODELS)
ThisLCD TV hasbeen tested and found compliantwiththe limitsforaClass
Bdigitaldevice,pursuanttopart15 ofthe FCC Rules.Theselimitsare
designed toprovide properprotection againstharmfulinterferencetoa
residentialinstallation.ThisLCD TV generates,uses,and can radiateradio
frequency energy.Harmfulinterferencetoradiocommunication maybe led
asaresultifit‘s notproperlyinstalled and used.However,thereisno
guarantee thatinterferencewill notoccurinaparticularinstallation.If this
LCD TV doescauseseriousinterferencetoradioortelevisionreception,
resetting the LCD TV maydetermine it. Moreover,usersareencouragedto
correctinterferencebydoing one ormoreofthe following:
Reorientorrelocatethe receiving antenna.
Movethe LCD TV and the receiverfurtherawayfromeachother.
Connectthe LCD TV intoan outleton acircuitdifferentfromthattowhich
the receiverisconnected.
Consultyourlocaldealeroran qualified technician.
FCC Warning:
Toassureacontinued FCC compliance,ausermustuseagrounded power
supplycordand the provided shielded video interfacecablewithbonded
ferritecores.Also,anyunauthorized changesormodificationstothisLCD TV
wouldvoidthe user‘s authoritytooperatethisdevice.
Note:If necessary,shielded interfacecablesand ACpowercordmustbe
used tomeetthe emission levellimits.
EMICertification:
The Class Bdigitalapparatusmeetsall requirementsofthe Canadian
Interference-Causing EquipmentRegulation.
Cetappareil numerique de class Brespectetouteslesexigencesdu
Reglementsurlematerielbrouilleurdu Canada.
Operation Instructions

Content
Fisrt Setup........................................................................ 5
Front Panel Control .......................................................... 6
Installation ........................................................................ 7
Remote Control ................................................................ 8
How to uninstall the stand ..............................................9
Using the OSD functions ................................................. 10
-TV mode........................................................................ 10
-Video (Include-YCbCr, AV).............................................14
TV-Frequency table .........................................................16
Technical Information .......................................................18
Safety Precaution ............................................................19
Care and Maintenance....................................................20

FirstStep
Thankyou forpurchasing thisLCD TV ofhigh performance!
ThisLCD TV package comeswith:
PowerCable
UserGuide book
Remotecontrol29 key
Quick Installation
1.ConnectorTVANTANAorCATV
CableorConnectvideocable
Makesurethe LCD TV are
powered OFF.
ConnecttoTVantenna jack or
CATVboxby75-ohmcoaxial
cable.
2.ConnectPowerCord
Connectthe powercordtoa
properlygrounded ACoutlet,
then tothe LCD TV.
3.Power-ONLCD TV
Power-ONthe LCD TV.
4.SettinginputsourceforLCD-
TVfromsource ofremote,
orOSDmenu.
5.InTVmodeyou can autoscan
TVchannelfromOSDindicat
(page 10.)
◆AV Video cable

FrontPanelControl
VolumeDownoradjustdecaease
VolumeUporadjustincrease
Menu KeyOSDON/OFF
Scroll Down
Scroll UP
Enter
PowerLEDindicator
PowerON/OFF switch
Remotecontrolreceiver
1
2
3
4
5
6
7
8
9
1 2 3 4 5 6 7 8 9

Installation
Powerinput(ACinput)
Audiooutput(left/right)
CVBS /S-Video Audioinput(left/right)
YCbCr-Audioinput(left/right)
TVsignalinput
S-Video input
AV Video input
YCbCrsignalinput
B
C
D
E
F
G
H
A
E
F
G
H
ABC D

RemoteControl
Power ON/OFF
Function UP/DOWN
Select and Left/Right
adjust
Source and channel
display
MTSSelect
SwitchTVor CATV
Channel UP/DOWN
adjust
Volume UP/DOWN
adjust
Return to previous
channel
Switch channel
number key
TV Sleep time
setting
Source select
OSDMenu ON/
OFF
Mute ON/OFF
Enter

How to uninstall the stand
(for wall-mounting the LCD TV)
Fig.1 Fig.2
Fig.3 Fig.4
Fig.5 Fig.6
1. Pave a piece of fabric on the table, and lay the TV flat on the
table with the front face down (see Fig.1).
2. Press the two concave portions with both your thumbs (see Fig.2).
3.Pull the pivot cover to yourself to detach the cover from the back
panel of the TV (see Fig.3).
4. Remove the pivot cover (see Fig.4).
5. Unscrew the four setscrews (see Fig.5).
6. Remove the stand from the TV (see Fig.6).

Using theOSDFunctions
TVmode
PictureMenu:
Press menu keytodisplayOSDMenu,and press menu keyagainto
change menu page.
Thissubmenu can toadjustContrast, Brightness,Color,Tintand
sharpness.
Contrast:Toadjustthecontrastofthe video.(right:Max,left:Iow)
Brightness:ToadjusttheLuminanceoftheVideo.(right: Max,left:Iow)
Color:Toadjustcolorsaturation.(right: brilliant color,left: pale color)
Tint: Toadjustthe tintlevel.(right: greenishtone,left: reddishtone)
Sharpness:Toadjustthe picturesharpness ofdisplay.
Thissubmenu can toadjust,Balance,Bass,Treble,and toAudioOut
Off/On.
Sound Menu:

Using theOSDFunctions
Thissubmenu can setCaption (CC1,CC2,T1,T2)and SourceSelect
(AV,S-Video,YCbCr,TV)
Input:Toselectthe inputsource(AV, S-Video, YCbCr, TV).
MemoryRecall:Recall factorysetting condition,aboutvideo & Audio
setting.
Balance:Toadjustthe left and rightaudiobalance.
Bass:Toadjustthe bass.
Treble:Toadjustthe treble.
AudioOut: Toadjustthe AudioOutOff/On.
TV/CATVSELECT:ToselectTVsignalinputisTV,CATV,HRC,and IRC.
AutoScan:Toautoscan theTVchannel(TVorCATV).
Channel:Add ordeleteTVchannel.
ParentControl:TosetV-Chipcondition andpassword.
Option Menu:
Setup Menu:

Using theOSDFunctions
V-Chip setting: To enable V-Chip functions please enter 0000 if you
have not assignedthespecialpassword.
Useremotecontrolarrowkeys toselectV-chipblocking tosetparen-
talguidelineson oroff.
SelectMPAA/TVrating tosetrating grade.
Useremotecontrolarrowkeys tomovecursortodesirerating grade,
when the textisRed,press enterkeytosetblock orunblock
condition.
NewPIN-code you can change the password.
Useremotecontroltoenter4digitnumber,then press enter.

Use remote control numbering keys to confirm the number again, then
V-Chip blocked: To enable V-Chip blocked please enter 0000 if you
have not assigned the spical password.
Using theOSDFunctions
press enter.

Using theOSDFunctions
Videomode(Include-S-Video, YCbCr,AV)
PictureMenu:
Press menu keytodisplayOSDMenu.
Thissubmenu can toadjustContrast, Brightness,Color,Tintand
sharpness.
Contrast: Toadjustthe contrastlevel. (right: Max, left: Iow)
Brightness:Toadjustthe brightness level. (right: Max, left: Iow)
Color:Toadjustcolorsaturation.(right: brilliant color, left: pale color)
Tint: Toadjusttintlevel.(right: greenishtone,left: reddishtone)
Sharpness:Toadjustthe picturesharpness ofdisplay.(right: sharper,
left: soft)
Sound Menu:

Using theOSDFunctions
Thissubmenu can toadjust,Balance,Bass,Treble,and toAudioOut
Off/On.
Balance:Toadjustthe left and rightaudiobalance.
Bass:Toadjustthe bass.
Treble:Toadjustthe treble.
AudioOut: Toadjustthe AudioOutOff/On.
Thissubmenu can setCaption (CC1,CC2,T1,T2)and SourceSelect
(AV, S-Video, YCbCr, TV)
Input:Toselectthe inputsource(AV, S-Video, YCbCr, TV).
MemoryRecall:Recall factorysetting condition,aboutvideo & Audio
setting.
Option Menu:

TVFrequency Table
U.S.AChannel

TVFrequency Table

TechnicalInformation
TechnicalSpecification
13"TFT
640(H)x480(V)
0.4125 x0.4125 mm
16.7M(8bits/color)
170/155,CR 5
+20 ,-5
500 :1(typical),(Video-typical)
450 cd/m2(typical)
15 ms. Max.(Gray Scale Level)
264 mm x198mm
Operating:0 C~+40 C
Storage:-20 C~+60 C
UL,FCC-B
Voltage 100-240 V
2.5 W x2
LCD Panel
DisplayableResolution
PixelDimension
LCD Display Color
ViewingAngle
Tilt
ContrastRatio
Brightness
Response Time
Active Display Area
Temperature
Compliance
Power
Speaker
>
=
O
O
OO
OO
O

SafetyPrecautions
ThisLCD TV ismanufactured and tested on aground principlethata
user’s safetycomesfirst. However,improperuseorinstallation may
resultdangertothe LCD TV aswell astothe user.Carefullygo over
the following WARNINGSbeforeinstallation and keep thisguide
handy.
WARNINGS:
ThisLCD TV shouldbe operated onlyatthe correctpower
sourcesindicatedon the labelon the rearend ofthe LCD TV. If
you’reunsureofthe powersupplyinyourresidence,consultyour
localdealerorpowercompany.
Donottrytorepairthe LCD TV yourselfasitcontainsno user-
serviceableparts.The LCD TV shouldonlybe repaired bya
qualified technician.
Donotremovethe LCD TV cabinet. Thereishigh-voltage parts
inside thatmaycauseelectricshock tohuman bodies,even
whenthe powercordisdisconnected .
Stop using the LCD TV ifthe cabinetisdamaged.Haveit
checked byaservicetechnician.
PutyourLCD TV onlyinaclean,dryenvironment. Unplug the
LCD TV immediatelyifgetswetand consultyourservice
technician.
Always unplug the LCD TV beforecleaning it. Clean the cabinet
withaclean,drycloth.Applynon-ammoniabased cleaneronto
the cloth,notdirectlyontothe glass screen.
Keep the LCD TV awayfrommagneticobjects,motors,TVsets,
and transformer.
Donotplaceheavy objectson the cableorpowercord.
ForPLUGGABLEEQUIPMENT,the Socket-outletshall be
installed nearthe equipmentand shall be easilyaccessible.
