Vmictech VMIC-100 User manual

POWER
MIC2 STA MIC1
BUILD I N
DIGITA L E C H O & M I X E R
VMIC-100 WIRELESS MICROPHONE
User manual for OTT/DVB

-2-
Applications
Features
-- This is an unique&latest digital wireless Microphone built in Bluetooth and DSP function.
-- Idea for enjoying music,Karaoke entertainment,TV partner, Teaching,Conference,etc.
-- Support the various devices with blue tooth,eg: Smart phone, Tablet PC, personal computer,etc.
-- Built-in the professional Digital Signal Processors(DSP) to mix and echo the sound.
-- Wireless microphone has long battery life function to reach 28 hours for 2 pcs AA alkaline
batteries continuous working.
-- Wireless microphone has auto power off function under the condition of Non-continuous
working within 2 minutes.
1. Support 2pcs digital wireless microphones.
-- Working distance:8 meters
-- Frequency:20Hz-16Khz
-- Delay:13ms-14ms
-- Continuous working: 28 hours(2 pcs AA alkaline batteries)
-- Low battery reminder and auto power off
2. Receive Bluetooth stereo from smart phone,Tablet PC,Personal computer.
-- Working distance:8 meters
-- Bluetooth 3.0, Support A2DP
-- Automatically connect the bluetooth device from using last time.
-- Enjoy Karaoke by smartphone or Tablet PC(Many free Karaoke App from App market)
3. DSP Echo and Mixer
-- 44.1K 16bits high sound quality(CD quality)
-- Digital Vocal&Echo effect process
-- Each microphone can adjust Echo effect independently (Mic volume/Echo+/Echo-)
-- Support bluetooth and line-in at the same time.2-ways input control volume independently
4. Support Iphone Ipad earphone output and microphone input
5. Remote control optional
Specification

-3-
1. Connect with OTT Boxes
Package Include
Digital Wireless
Microphone * 2pcs Receiver*1pc 3.5mm Audio wire*1pc
RCA wire*1pc 5V 500mA Adapter*1pc
1. Connect power adapter with the receiver
2. Press "power" on the front panel of the receiver
Indicator
connect with receiver successfully
MIC1 and MIC2
the indicator keeps on for MIC1/MIC2
Bluetooth disconnect
Indicator of bluetooth
the indicator keeps on for bluetooth connect successfully
Remote Indicator
Package Include
The front panel of receiver
Indicator:
1. Flash once for connect successfully
2. Mute Mode: Keep flash
Power On/Off
Pair ID
The rear panel of receiver
OTT BOX AMPLIFIER / SPEAKER

2. Connect to STB box (Audio Output from TV speaker）
-4-
VIDEO L R
VIDEO L
R
VMK-100 Receiver
TV interfaces
Change to
YPbPr mode or
AV mode
STB BOX
TV
VIDEO L R
VIDEO L
R
VMK-100 Receiver
TV interfaces
Change to
YPbPr mode or
AV mode
STB BOX
TV
3. Connect to STB box (Audio Output from Amplifier or speaker）

-5-
LOCK
Fn
E
_
+
_
+
Nomally on: connected with receiver
flashing: search to conect with receiver
Replace the battery as soon as the low battery indicator appears
Mic Lock Mode On/Off(Children Mode)
(In Lock Mode,Mic buttons can't work), Cancel by pressing button 3 seconds
To choose Mic Effect
>Normal>Low Picth>MID>High
To choose Echo Effect
>Echo Off>Low Echo
>Middle Echo>High Echo
Mute On/Off
Music volume+Music volume-
Mic Volume+
Mic Volume-
Control button of microphone
Operating Steps
1.Turn off 2 microphones
2.Turn on the receiver, keep pressing the power button Until the indicator lamp of MIC1 flashes quickly,
then release the power button.
3.Turn on the MIC1 until it's power off Automatically
(the power indicator lamp flashing red and green alternately), pair ID for MIC1 successfully
4.Similarly,same operations on MIC2 to pair ID
.
In the following cases, microphone need to be paired ID:
1.Re-buy a new microphone
2.Someone uses the same microphone nearby, it will be found to interfere with other microphones.
Package Include
Pair ID for Microphone
