Voda Plumbingware Eclipse Square 1 VECL61SBK User manual

9 421027 597402
Eclipse Square 1 Function Slide Shower
Matte Black
VECL61SBK
Congratulations on your purchase of this high quality product from Voda Plumbingware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for All Pressures
Minimum Pressure = 35kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Install the flow restrictor as shown in the diagram below.
Unequal Low Systems Install as supplied.
Equal Low systems Install as supplied.
CONTENTS
• Wall brackets
• Fixing kit
• Glide bar with adjuster/holder
• 1.5m shower hose
• Supply elbow
• Shower handpiece
• Flow restrictor (for Mains Pressure installations)
Mains Pressure installation only:
Insert the flow regulator with the O ring
facing away from the hose (as shown).
This will comply with the WELS rating.
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz

ATTACH PROOF OF PURCHASE HERE
INSTALLATION
For pressures exceeding 500kPa install a pressure reducing valve. Failure to do so may void the warranty.
WARRANTY
Please refer to our website for warranty information: www.vodaplumbingware.co.nz/warranty
In the unlikely event that this product fails during its warranty period, phone our Customer Service team
immediately on 0508 367 366 – as unauthorised removal of the product may void the warranty.
CARE AND MAINTENANCE
When cleaning your Voda product (including chrome, stainless steel, coloured or any other surface coating) you
must not use any type of astringent, abrasive or citric cleaners.
We recommend using only a so, damp cloth and on occasion a mild soap solution. Try to avoid excessive
scrubbing as this could cause damage and void your warranty.
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
Supply
Outlet
Drill holes 700mm apart
and screw in the fittings. Screw on the slide rail making
sure the orientation is correct.
Insert rose, attach hose with
conical end to the rose.
123
