American Standard Cadet 8115S Operating and safety instructions

HD-17
© 2008 AS America, Inc.
CADET
SINGLE CONTROL LAVATORY FAUCET
8115S Shown.
MODEL NUMBER:
8115S Lavatory Faucet
Speed Connect™ Pop-up drain. Metal Lever Handle.
Satin Nickel (PVD) finish.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
NSF 61/Section 9
CSA B 125
GENERAL DESCRIPTION:
Single control lavatroy faucet on 4" centers. Washerless
40mm ceramic disc valve cartridge. Durable cast brass
waterway with 1/2" male threaded brass inlet shanks. Metal
body with color matched underbody. Metal lever handle. 20"
(500mm) long flexible stainless steel drain cable is
pre-assembled to faucet body. Non-Metallic Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece. 1.5 gpm/5.7L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Single control lavatory fitting shall feature cast brass waterways with 1/2" male inlet shanks. Shall also feature washerless
40mm ceramic disc valve cartridge. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be
American Standard Model # 8115S.
PRODUCT FEATURES:
Cast Brass Waterways with "City Shanks": Strong and
durable. Integral tabs on casting provide a wobble-free
installation.
Ceramic Disc Valve Cartridge: Assures a lifetime of
drip-free performance.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Speed Connect™ Drain:
• 1/3 the parts, installs in 1/3 the time.
• No tools or plumbers putty required for installation.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight
spaces.
Longer Spout: Provides extended reach into lavatory.
Simple Installation: Fast and easy one person installation.
Faucet drops in from top. Quick spin nuts secure faucet in place.
Product
Number Description
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
121mm
(4-3/4)
85mm
(3-1/4)
76mm
(3)
41mm
(1-5/8)
25mm
(1)
40mm
(1-9/16)
153mm
(6-1/16)
102mm
(4)
107mm
(4-3/16)
Lavatory faucet. Non-Metallic Speed Connect™ Pop-up drain. Satin Nickel (PVD) Finish.
8115S
HOLE
SIZE
29mm
(1-1/8)
32mm OD
(1-1/4 OD)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
10080604020

HD-18
© 2008 AS America, Inc.
CADET
SINGLE CONTROL LAVATORY FAUCET
8115S Shown.
MODEL NUMBER:
8115S Lavatory Faucet
Speed Connect™ Pop-up drain. Metal Lever Handle.
Satin Nickel (PVD) finish.
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANSI A117.1
ASME A112.18.1
NSF 61/Section 9
CSA B 125
GENERAL DESCRIPTION:
Single control lavatroy faucet on 4" centers. Washerless
40mm ceramic disc valve cartridge. Durable cast brass
waterway with 1/2" male threaded brass inlet shanks. Metal
body with color matched underbody. Metal lever handle. 20"
(500mm) long flexible stainless steel drain cable is
pre-assembled to faucet body. Non-Metallic Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece. 1.5 gpm/5.7L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Single control lavatory fitting shall feature cast brass waterways with 1/2" male inlet shanks. Shall also feature washerless
40mm ceramic disc valve cartridge. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be
American Standard Model # 8115S.
PRODUCT FEATURES:
Cast Brass Waterways with "City Shanks": Strong and
durable. Integral tabs on casting provide a wobble-free
installation.
Ceramic Disc Valve Cartridge: Assures a lifetime of
drip-free performance.
Low Lead: Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Speed Connect™ Drain:
• 1/3 the parts, installs in 1/3 the time.
• No tools or plumbers putty required for installation.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight
spaces.
Longer Spout: Provides extended reach into lavatory.
Simple Installation: Fast and easy one person installation.
Faucet drops in from top. Quick spin nuts secure faucet in place.
Product
Number Description
Meets the American Disabilities Act Guidelines
and ANSI A117.1 Requirements for the
physically challenged.
121mm
(4-3/4)
85mm
(3-1/4)
76mm
(3)
41mm
(1-5/8)
25mm
(1)
40mm
(1-9/16)
153mm
(6-1/16)
102mm
(4)
107mm
(4-3/16)
Lavatory faucet. Non-Metallic Speed Connect™ Pop-up drain. Satin Nickel (PVD) Finish.
8115S
HOLE
SIZE
29mm
(1-1/8)
32mm OD
(1-1/4 OD)
FLOW RATE*
GALLONS PER MINUTE
INLET PRESSURE (PSI)
*Flow rates shown are for mixed hot and cold.
0.0
0.5
1.0
1.5
2.0
10080604020
