Voda Plumbingware Eclipse VECL012 User manual

9 421027 595651
Eclipse Sink Mixer
Matte Black
VECL012
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
Congratulations on your purchase of this high quality product from Voda Plumbingware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for All Pressures
Minimum Pressure = 35kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Remove valve insert from nipple attached to cold flexi-hose. Change aerator to mains
pressure one supplied (included in the fittings pack).
Unequal Low systems Install as supplied.
Equal Low systems Remove the valve insert from the nipple attached to the cold in-feed hose. Install.
INSTALLATION
For pressures exceeding 500kPa, install a pressure limiting valve. Failure to do so may void the warranty.
• Before commencing installation turn o the water supply.
• Position tap in 35mm hole, making sure the seal between tap and supporting surface is in place.
• Anchor to bench with fittings pack (Note: Tube socket tools are available).
• Thoroughly flush all pipes to eliminate any remaining dirt and residue and install inline filters.
• Connect supply hoses to plumbing connections. Maximum bend for flexible hose is 35mm radius. Do not
stretch, crush or twist hoses. Do not swage hose ends.
• Turn on mains supply.
• Check for leaks.
Plumbers Note: Do not pressure test this mixer under static pressure.

WARRANTY
Please refer to our website for warranty information: www.vodaplumbingware.co.nz/warranty
In the unlikely event that this product fails during its warranty period, phone our Customer Service team
immediately on 0508 367 366 – as unauthorised removal of the product may void the warranty.
CARE AND MAINTENANCE
When cleaning this product (including chrome, stainless steel, coloured or any other surface coating) you must not
use any type of astringent, abrasive or citric cleaners.
We recommend using only a so, damp cloth and on occasion a mild soap solution. Try to avoid excessive
scrubbing as this could cause damage and void your warranty.
ATTACH PROOF OF PURCHASE HERE
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
