Vogelsang VX100Q User manual

29.11.2011
*WBV.PU.002.EN*
WBV.PU.002.EN V4.0
1/61
29.11.2011
*WBV.PU.002.EN*
WBV.PU.002.EN V4.0
Operating instructions
Rotary lobe pump
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
Pos: 1/ Grafiken/Pumpen/ WBV/Deckblatt/De ckblatt VX100, VX136, VX186 @ 24 \mod_1 207206001940_0.d oc@ 8759 3@ @ 1
Pos: 2/---S eitenumbruch--- @ 21\ mod_120169613622 9_0.doc@ 8 0575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
2/61
Pos: 3/ WBV/produktübergr eifend/Originalbetri ebsanleitung @ 51\mod_ 1292414850952_48 .doc @ 239496 @ @ 1
Original operating instructions
Pos: 4/ WBV/produktübergr eifend/Herausgeb er@ 51\ mod_12924149342 31_48.doc @ 239522 @ @1
Issuer
Hugo Vogelsang
Maschinenbau GmbH
49632 Essen/Oldb.
Germany
[phone]
[phone]
[e-mail]
vogelsang.info
In the absence of express, written authorisation from the issuer, the reproduction or partial reproduction of
this document in any form is prohibited.
We reserve the right to make technical modifications to the diagrams and information presented in this
document in the event that such modifications become necessary for the enhancement of the machine.
Pos: 5/R egistrierte Mar ken /Registrierte Mar kenu ndC opyright @ 49\ mod_12863746 97286_48.doc @ 21697 7@ @ 1
© 2010 Hugo Vogelsang Maschinenbau GmbH
Registered trademarks of Vogelsang
Vogelsang, Vogelsang Logo, RotaCut, HiFlo, ACC, CFC, BioCrack and XTill are registered trademarks
of Hugo Vogelsang Maschinenbau GmbH.
The registered trademarks are not always designated with a ®symbol in this document.
Pos: 6/---S eitenumbruc h---@ 21\ mod_120169613622 9_0.doc@ 8 0575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
3/61
Pos: 7/ Inhaltsverzeichnis @ 0\mo d_110856302645 2_48.doc @ 947 @ @ 1
Contents
1User information.....................................................................................................................................4
1.1 Using the operating instructions....................................................................................................... 4
1.2 Warning signs, danger symbols, information................................................................................... 5
1.3 Presentation convention................................................................................................................... 5
2Intended purpose ...................................................................................................................................6
3Safety Notes............................................................................................................................................6
3.1 General safety notes........................................................................................................................ 6
3.2 Training of persons........................................................................................................................... 9
3.3 Warning and safety notes on the pump ........................................................................................... 9
3.3.1 Warning and safety labels.......................................................................................................... 10
4Pump drives and direction of flow......................................................................................................12
4.1 Drive units ...................................................................................................................................... 12
4.2 PTO drive ....................................................................................................................................... 13
4.3 Marathon pumps ............................................................................................................................ 14
4.4 Pump systems................................................................................................................................ 14
4.5 InjectionSystem.............................................................................................................................. 15
5Assembly...............................................................................................................................................16
5.1 Transport........................................................................................................................................ 16
5.2 Assembly of pump and motor on base........................................................................................... 18
5.3 Installation the X-Ripper in pipe systems....................................................................................... 19
5.3.1 Pump installation........................................................................................................................ 19
5.3.2 Pipelines and connections ......................................................................................................... 20
5.3.2.1 Suction lines.......................................................................................................................... 20
5.3.2.2 Discharge pipes..................................................................................................................... 21
5.4 Notes on the control ....................................................................................................................... 21
5.4.1 Variable frequency drive operation............................................................................................ 21
5.5 Connection to the power supply..................................................................................................... 22
5.5.1 Electric drive............................................................................................................................... 22
5.5.2 Hydraulic drive ........................................................................................................................... 22
6Start-up..................................................................................................................................................23
6.1 Check list before start-up ............................................................................................................... 23
7Maintenance..........................................................................................................................................24
7.1 Buffer chamber............................................................................................................................... 24
7.1.1 Buffer fluid or quenching fluid .................................................................................................... 24
7.1.1.1 Amount of buffer fluid or quenching fluid............................................................................... 24
7.1.1.2 Buffer chamber oil types........................................................................................................ 25
7.1.2 Inspecting and changing the buffer/quenching fluid .................................................................. 26
7.1.3 Buffer chamber assemblies ....................................................................................................... 26
7.1.3.1 Pressurised buffer fluid tank.................................................................................................. 26
7.1.3.2 Unpressurised quenching fluid tank...................................................................................... 28
7.1.3.3 Pressure valve....................................................................................................................... 29
7.1.3.4 plug (for special designs, only, for example submersible pumps) ........................................ 29
7.1.3.5 Dry buffer chamber................................................................................................................ 30
7.1.3.6 Circulation system on the cartridge mechanical seal............................................................ 31
7.1.4 Draining and flushing the buffer chamber.................................................................................. 32
7.2 Gearbox.......................................................................................................................................... 33
7.2.1 Gearbox oil................................................................................................................................. 33
7.2.1.1 Gearbox oil quantity .............................................................................................................. 33
7.2.1.2 Gearbox oil grade.................................................................................................................. 33
7.2.2 Checking and changing the gearbox oil..................................................................................... 33
7.3 Greasing of sealing prechamber.................................................................................................... 35
8Repair ....................................................................................................................................................36
8.1 Conversion and spare parts........................................................................................................... 36
8.2 Before opening the Q or QD cover................................................................................................. 37
8.3 Opening the Q cover ...................................................................................................................... 37
8.4 Closing the Q cover........................................................................................................................ 37
8.5 Opening the QD cover.................................................................................................................... 38
8.6 Closing the cover plate for QD/QD Marathon-pumps .................................................................... 39

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
4/61
8.7 Rotary lobe change ........................................................................................................................ 40
8.7.1 Rotary lobe change - series VX100Q, VX136Q, VX186Q......................................................... 41
8.7.1.1 Position of pressure disk and spring washer......................................................................... 42
8.7.2 Rotary lobe change - series VX136QD, VX186QD ................................................................... 43
8.7.3 Rotary lobe change - series VX136QDM2, VX186QDM2 ......................................................... 44
8.7.3.1 Tightening torques of the hex socket head screw or strain screw for mounting the pressure
disk ........................................................................................................................................ 45
8.8 Change of wear plates ................................................................................................................... 45
8.9 Change of cartridge mechanical seal............................................................................................. 46
8.9.1 Change of cartridge mechanical seal on the gearbox ............................................................... 46
8.9.2 Cartridge mechanical seal change on the QD cover................................................................. 48
8.10 Adjusting of pump housing segments............................................................................................ 49
8.11 Reducing the starting torque.......................................................................................................... 50
8.11.1 Increasing the gap by installing thinner wear plates.................................................................. 50
8.11.2 Increasing the gap by installing shims between rotary lobe and wear plate ............................. 51
9Maintenance plan .................................................................................................................................52
10 Service Plan ..........................................................................................................................................53
11 Trouble-shooting..................................................................................................................................54
11.1 Troubleshooting.............................................................................................................................. 54
11.2 Help................................................................................................................................................ 55
12 Specifications .......................................................................................................................................56
12.1 Material description for rotary lobes............................................................................................... 56
12.2 VX100 –Technical data................................................................................................................. 57
12.3 VX100 with flanged electric motor –Technical data...................................................................... 57
12.4 VX136 –Technical data................................................................................................................. 58
12.5 VX186 –Technical data................................................................................................................. 58
13 Putting out of operation and disposal................................................................................................59
14 Declaration of Installation ...................................................................................................................60
Pos: 8/ WBV/produktübergr eifend/Intro für Betriebsanl eitung @ 51\mod_129344 2565809_48.doc @ 240183 @ @ 1
Dear customer,
in every one of our products, you will see the entirety of our competence and our power of innovation at
work. Each product is developed and built so that you can work more successfully.
We call it quite simply: ENGINEERED TO WORK
If you want to know more about our company or put forward requests or suggestions, a wealth of information
can be found at www.vogelsang.info
Pos: 9/Ü berschriften/Übers chrift 1/Benutzerhin weise@ 4 9\mod_12863752 30148_48.doc @ 217001 @ 1 @ 1
1 User information
Pos: 10 /Überschriften /Überschrift 2 /Anwen dung der Betriebsanl eitung@ 49\mo d_12863753217 08_48.doc @ 217024 @ 2 @ 1
1.1 Using the operating instructions
Pos: 11 /WBV/produkt übergreifend/Anwe ndungd erB etriebsanleitung @ 49\mod _1286375369535_4 8.doc@ 2 17047 @ @ 1
These instructions contain all necessary information concerning the operating elements, handling, start-up
and maintenance and repair work, as well as all of the relevant technical data.
The operating instructions are a component of the machine.
Please therefore keep the instructions ready to hand to ensure easy access to the necessary information at
all times.
Read the operating instructions thoroughly. All of the points presented in these instructions must be
understood and observed by those persons responsible for the installation, operation, maintenance and
repair of the machine.
Vogelsang does not accept any liability for damage resulting from failure to comply with these maintenance
and operating instructions.
Pos: 12 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
5/61
Pos: 13 /Überschriften /Überschrift 2 /War nzeichen, Gefahrens ymbol, Hinweise @ 49\ mod_12863761 61084_48.doc @ 21707 0@ 2 @ 1
1.2 Warning signs, danger symbols, information
Pos: 14 /WBV/produkt übergreifend/S ymbole - neu mit Umweltsym bol@ 62\mo d_1319710644790_ 48.doc @ 325933 @ @ 1
Symbols
This warning advisory warns you of possible dangers to the health and life of yourself and other people
resulting from the handling and operation of this machine.
This warning advisory warns you of possible dangers through electric shock.
This warning advisory warns you of possible dangers for your machine.
This information provides you with additional advice and tips.
We use this symbol to indicate measures to be observe to prevent damage to the environment.
Pos: 15 /Überschriften /Überschrift 2 /Darstellu ngskonvention @ 5 9\mod_13135 04290439_48.doc @ 31 0639 @ 2 @ 1
1.3 Presentation convention
Pos: 16 /WBV/produktüberg reifend/Darstellu ngskonvention @ 59\mod_ 1313500702862_48.d oc@ 31 0610 @ @ 1
Illustration
Meaning
•
Listing
Sublisting
1.
2.
Carry out these actions in the described sequence by
Fig. “Caption"
Reference to a figure for additional information
Chapter “Chapter heading"
Reference to a chapter for additional information
Table “Table caption"
Reference to a table for additional information
“Relevant Vogelsang document"
Request this document from us if you need it
 Technical support
Contact our Technical Support
Pos: 17 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
6/61
Pos: 18 /Überschriften /Überschrift 1/Besti mmungsgemäße V erwendung @ 52\ mod_12953639784 03_48.doc @ 24569 0@ 1 @ 1
2 Intended purpose
Pos: 19 /WBV/Pump en/Bestimmungsge mäße Verwendung/ 002 Bestimmungsg emäße Verwendung @ 5 9\mod_13136 60921508_48.d oc@ 3 11133 @ @ 1
The Vogelsang rotary lobe pump (hereinafter “pump”) is a self-priming positive displacement pump for
pumping aqueous to highly viscous fluids (hereinafter “medium”).
The medium can be chemically neutral, acidic or alkaline. It can be loaded with solid particles and/or gas.
The pump is designed for the medium to be pumped in accordance with customer specifications.
For a different medium or when the pump is not designed for a particular application, it has to be checked
whether the materials of the pump which come into contact with the medium are suitable. In some cases the
pump must be reconfigured.
Any other use is contrary to the intended purpose. Vogelsang is not liable for any damage resulting from
incorrect use.
The pump without connections or without drive is an incomplete machine. The pump installation instructions
are provided in the "Installation" chapter.
The declaration of installation is part of these operating instructions.
The pumps described in these operating instructions are not intended for use in potentially explosive
atmospheres.
Pos: 20 /Überschriften/Übersc hrift 1/Sicherheitshi nweise @ 0\ mod_11099247810 06_48.doc @ 1123 @ 1 @ 1
3 Safety Notes
Pos: 21 /Überschriften /Überschrift 2 /Allgem eine Sicherheitshin weise @ 37\mod_1 254832643077_48 .doc @ 130333 @ 2 @ 1
3.1 General safety notes
Pos: 22 /WBV/Pump en/Sicherheitshin weise/002 Allgemein e Sicherheitshin weise @ 59\mod_1313 661683207_48.doc @ 311163 @ @ 1
Before assembly, commissioning, start-up, maintenance and repair of the pump, read the operating
instructions completely and carefully observe the warning and safety notes.
Pos: 23 /WBV/Pump en/Warnhinweise/ Stromgefahr/Elektri scher Antrieb - elektr ischer Schlag @ 61\m od_1317021974767 _48.doc @ 316824 @ @ 1
Danger of electric shock from pumps with an electrical drive
Only qualified electricians may connect the device to the power supply.
Pos: 24 /WBV/Pump en/Warnhinweise/ Gefahr/Hydraulisch er Antrieb - Infektionsg efahr durch Hydra uliköl @ 61\mod_1317 022066220_48. doc@ 3 16854 @ @ 1
Danger of infection due to hydraulic oil under pressure escaping on pumps with
hydraulic drive
•The connection to the power supply must be done by qualified personnel.
•Leakages can occur due to seal faults.
•Wear protective goggles.
On injuries with hydraulic oil, seek out a doctor immediately!
Pos: 25 /WBV/X-Rip per/Warnhinweis e/Gefahr/Rotieren deT eile- NU R Antrieb @ 42\ mod_1274358039 910_48.doc @ 1864 13@ @ 1
Risk of injury from rotating parts
•Before performing any maintenance and repair work on the drive, switch off the drive and make sure
that the drive cannot be unintentionally switched on again.
Pos: 26 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
7/61
Pos: 27 /WBV/Pump en/Warnhinweise/ Gefahr/Berste n vonB auteilen und Herauss pritzen von Mediu m( max. Betriebsdruck) @ 58 \mod_131219988 3518_48.doc @ 3077 41 @ @ 1
Risk of injury from bursting components and medium spraying out under high pressure
•The maximum operating pressure must not be exceeded Chap. “Technical data" .
•Observe and implement the recommendations in the Chap. “Installation in pipelines".
•Protect the pump assembly against excess pressure. For example, the following safety devices can
be used:
a current limiter on the motor
a pressure relief valve
cut-off with a pressure switch
an overload coupling
Pos: 28 /WBV/Pump en/Warnhinweise/ Gefahr/Haut- un dAuge nreizungen durc hHilfs- Betriebsst offe und Medium (allg. Sich erheitshinweis) @ 59 \mod_131366272 1410_48.doc @ 3 11310 @ @ 1
Skin and eye irritation caused by auxiliary materials, operating materials and medium
•Protective clothing (protective goggles, protective gloves) must be worn during all work involving
possible contact with auxiliary materials, operating materials and medium. In certain situations these
materials or the medium can enter the buffer chamber or gearbox.
•Before opening covers, connectors etc., the pump assembly must be depressurised to prevent the
medium from spraying out.
•To protect against fluids spraying out, carefully and slowly open the buffer chamber and the gearbox.
Cover the valves or screws to be removed with a cloth or similar item where appropriate.
Pos: 29 /WBV/Pumpen/Warn hinweise/Gefahr/ Verbrennungs- oder Verbrü hungsgefahr @ 61\mod_131 7886379996_48.d oc@ 319 193 @ @ 1
Danger of burning or scalding
by auxiliary materials, operating materials and medium starting at 60°C
is present
•when there is direct contact with hot auxiliary materials, operating materials and hot medium.
•from spraying of hold auxiliary materials, operating materials and hot medium.
•when there is inadvertent contact with hot surfaces (pump housing, pipelines).
Therefore
•before maintenance and repair work, allow the pump to cool down, wear protective gloves and
protective goggles.
•avoid touching the pump and the pipelines during operation.
Pos: 30 /WBV/Pumpen/Warn hinweise/Gefahr/Tro ckenlauf @ 59\mod_ 1313411905450_48.d oc@ 31 0211 @ @ 1
Danger of burning due to exposed hot surfaces when the pump is running dry
Avoid pump dry running. Prevent the pump from running dry using, for example
•a temperature monitor
•a level gauge
•a flow rate gauge
Pos: 31 /WBV/Pumpen/Warn hinweise/Gefahr/Dre hkolbenpumpe nim Autom atikmodus @ 58\mod_13 12272827597_48. doc@ 30 7833@ @ 1
Automatic mode requires safety equipment
Rotary lobe pumps that are operated in automatic mode must be equipped with a temperature and pressure
monitoring unit (safety devices). These safety devices can be obtained from us as options.
Pos: 32 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
8/61
Pos: 33 /WBV/produktüberg reifend/Sicherheits einrichtungen @ 41\mod _1273236449259_48. doc@ 1 84125@ @ 1
Check safety devices
Qualified personnel must connect and check safety devices on a regular basis for proper function, especially
after doing maintenance and repair work, before restarting.
Pos: 34 /WBV/Pumpen/Warn hinweise/Gefahr/ Verletzungsgefahr durc hHera bfallen der Pumpe @ 59\mod_131 3412643635_48.doc @ 310 240 @ @ 1
Risk of injury when loading and transporting the pump or the pump unit
•Use the lifting eye bolts on the pumps only for lifting the pump without mounted parts (for example,
the motor).
•The unit may only be transported suspended or screwed to a Euro pallet. Fig. “Transport aids”.
•During loading operations and when setting down the pump or the pump unit, it may be begin to swing
or fall. Risk of crushing! Therefore:
The loading and transporting may only be carried out by specially trained persons.
Standing under raised loads is prohibited. Direct persons out of the danger area.
Pos: 35 /WBV/Pump en/Warnhinweise/ Gefahr/Verletzungsg efahr durch Stolpern a ufr utschigem Unterg rund @ 61\mod_1 317048539608_4 8.doc @ 316982 @ @ 1
Risk of injury from stumbling on slippery floor
•Keep work station clean and clean up any auxiliary materials, operating materials and medium residue
that may be present, especially before maintenance and repair work on the pump or the pump unit.
•Caution when temperatures are below freezing - keep workplace free of ice.
Pos: 36 /WBV/Pumpen/Warn hinweise/Maschin engefahr/Frostgef ahr@ 58 \mod_1312293 026339_48.doc @ 308069 @ @ 1
Risk of frost
•If there is a risk of frost, drain the pump by running the pump in either direction, until all liquid is
drained out of the pump. Therefore you may use the drain cocks in the connectors.
•For complete emptying, remove the Q or QD cover, Chap. “Opening the Q cover" or “Opening the
QD cover".
•Attention! Before start-up, refill with fluid.
Pos: 37 /WBV/Pump en/Warnhinweise/M aschinengefahr/H ochviskoses Medi um @5 8\mod_1 312362219883_48.d oc @ 308105 @ @ 1
High viscosity medium
When using the pump for a very viscous medium, the pump speed must be reduced according to the
material's viscosity, to prevent the suction flow from breaking off on the suction side (cavitation protection).
Pos: 38 /WBV/Pumpen/Warn hinweise/Maschin engefahr/Gleitringdic htung SiC-SiC @ 58\mod_1 312274737011_48.doc @ 3 07892 @ @ 1
Pumps with a mechanical seal consisting of the material combination SiC-SiC:
To avoid adhesion of the mechanical seal faces this pump needs to be rotated (at least one revolution) every
two months when not in service.
Pos: 39 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
9/61
Pos: 40 /Überschriften /Überschrift 2 /Ausbild ung der Personen @ 55 \mod_1305539 164090_48.doc @ 26 0801@ 2 @ 1
3.2 Training of persons
Pos: 41 /WBV/Pump en/Sicherheitshi nweise/002 Ausbild ung der Personen - Pumpe n@ 5 9\mod_131358 7089592_48.doc @ 31 1090 @ @ 1
Only trained and instructed persons may work with and on the pumps. The operator must clearly define the
responsibilities of the persons for operating, servicing and maintaining equipment.
A person to be trained may only work with and on the pump under the supervision of an experienced person.
Activity/persons
Person specially
trained for the activity
1)
Instructed person 2)
Persons with
specialised training
(qualified workshop) 3)
Transport
X
--
X
Assembly, installation
--
--
X
Start-up
--
--
X
Operation
X
X
X
Maintenance
X
X
X
Repair
--
--
X
Legend:
X..allowed
--..not permitted
1) A person who can take over a specific tasks and is authorized to carry it out for a company that is
accordingly qualified.
2) Whoever has been instructed, and if necessary trained, about the tasks assigned to them and possible
risks associated with incorrect behaviour and has been instructed about the required protective
equipment and protective measures is considered a trained person.
3) Persons with specialised training are considered specialists. Based on your technical training and
knowledge of the relevant provisions, you can assess the tasks assigned to you and recognize
possible dangers.
Note:
A qualification equivalent to technical training may also have been attained by many years of activity in the
relevant field of work.
Pos: 42 /Überschriften /Überschrift 2 /War n-u ndSic herheitshin weise auf der Pumpe @ 59\ mod_1313662495 301_48.doc @ 31128 1@ 2 @ 1
3.3 Warning and safety notes on the pump
Pos: 43 /WBV/Pump en/Sicherheitshin weise/002 Warn- un dSic herheitshinweis eauf d er Pumpe @ 59\mod_ 1313662363724 _48.doc @ 311222 @ @ 1
Warning and safety labels on the machine provide important information for safe operation. Heeding the
label promotes the safety of persons who work with and on the pump.
The warning and safety labels must not be removed and must be replaced immediately if damaged or lost 
Chap. "Warning and safety labels"
Pos: 44 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
10/61
Pos: 45 /Überschriften /Überschrift 3 /War n-u ndSic herheitsauf kleber @ 59\mod_13 13670862426_48.d oc@ 3 11778 @ 3 @ 1
3.3.1 Warning and safety labels
Pos: 46 /Grafiken/Pu mpen/WBV/Warn- und Sicherheitsa ufkleber/VX War n-u nd Sicherheitsauf kleber @ 59\mod_1 313663488097_48 .doc @ 311399 @ @ 1
VX100Q
VX136Q, VX186Q
VX136QD, VX186QD
VX136QDM2, VX186QDM2
Fig.
1
: Positioning of the warning and safety labels
(The figures shown here are examples only and do not reflect the precise positioning of the labels)

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
11/61
Pos: 47 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1
Pos.
Sticker
Part no.
Meaning
1
VAU.133
Before starting up the pump, read the
operating instructions!
2
VAU.138
Buffer fluid tank or quenching fluid tank
3
VAU.115
(Only used for pumps with a mechanical
seal consisting of the material
combination SiC-SiC)
Text –see sticker
Attention! In the case of new pumps that are not
placed immediately into operation, the shaft needs
to be rotated approximately every two months (at
least one revolution) to prevent the sealing surfaces
on the rotating rings from adhering to one another.
4
VAU0050
Use a cross beam for lifting with the
pump VX136-420QDM2 and with pumps
VX186QD/VX86QDM2 starting at
chamber length 368.

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
12/61
Pos: 48 /Überschriften /Überschrift 1/Pump enantriebe und Förd errichtung @ 28\ mod_1213954037 191_48.doc @ 96203 @ 1 @ 1
4 Pump drives and direction of flow
Pos: 49 /WBV/Pumpen/För derrichtung/002 Förderr ichtung, Ausnahme n@ 58\m od_1312460165773 _48.doc @ 308285 @ @ 1
The pump is suited for both pumping directions.
Please observe the following machine and safety technology exceptions in which the direction of flow is
predefined:
•Marathon pumps VX136QDM2, VX186QDM2 chap. “Marathon pump".
•Installation in pipelines chap. "Pump assemblies".
•InjectionSystem Chap. "InjectionSystem".
Pos: 50 /Überschriften /Überschrift 2 /Motor antrieb @ 0\mod_1 109927198406_48.d oc @ 1228 @ 2 @ 1
4.1 Drive units
Pos: 51 /WBV/Pump en/Förderrichtung/ 002M otorantrieb @ 58 \mod_1312460 582382_48.doc @ 3083 14 @ @ 1
If you are using motor-driven pumps with one drive shaft, the direction of flow is selected by determining the
rotational direction of the drive motor, such as an electric motor or hydraulic motor.
Pos: 52 /Grafiken/Pumpe n/WBV/Förderrichtung /Motorantrieb @ 0\ mod_1112779983937 _48.doc @ 2226 @ @ 1
Fig.
2
: Motor driven pump
Pos: 53 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
13/61
Pos: 54 /Überschriften/Übersc hrift 2 /Schlepperantrie b@ 0\ mod_110992724611 7_48.doc @ 1233 @ 2@ 1
4.2 PTO drive
Pos: 55 /WBV/Pump en/Warnhinweise/ Gefahr/Lärm- und Sc hwingungsgefä hrdung durch falsches Anschli eßen und Ausrichte n der Gelenkwelle n@ 6 1\mod_131720 6718220_48.doc @ 317 462 @ @ 1
Risk of noise and vibration due to incorrect connection and orientation of the cardan
shafts
Development of noise and vibrations can cause impairment of communication and discomfort. Therefore:
•Read operating manual of the cardan shaft manufacturer and follow the instructions. Observe
permissible flex angle and minimum profile overlapping of the cardan shafts.
Pos: 56 /WBV/Pump en/Warnhinweise/ Gefahr/Gefahr durc hro tierenden Wellenz apfen @ 61\mod_1 317205637634_48.d oc @ 317403 @ @ 1
Danger from rotating shaft end
In order to prevent the hands or the work clothing from getting caught on the rotating shaft end (without
cardan shaft), the pump may only be operated with a suitable PTO shaft guard. Please contact us.
Pos: 57 /WBV/Pump en/Förderrichtung/ 002 Schlepperantri eb@ 58\mod_1 312288186027 _48.doc @ 307952 @ @ 1
If you are using tractor driven pumps with two drive shafts, connect either the upper or lower the cardan
shafts thus determining the direction of flow.
Pos: 58 /WBV/Pump en/Warnhinweise/M aschinengefahr/B etriebsmoment begrenzung bei Schlepp erantrieb @ 58\mo d_13122882941 08_48.doc @ 307982 @ @ 1
Limitation of operating torque for PTO drive
In order to prevent overloading the pump drive shaft, the operating torque must be limited:
Operating torque limited to
For cardan shafts with profile 1 3/8”, 6-parts 1600 Nm
For cardan shafts with profile 1 3/4”, 6-parts 3200 Nm
For cardan shafts with profile 1 3/4”, 20-parts 3200 Nm
Pos: 59 /WBV/Pump en/Warnhinweise/ Gefahr/Keine Überdr ucksicherung durch B etriebsmomentb egrenzung @ 59\ mod_131341562105 3_48.doc @ 31027 0@ @ 1
No overpressure protection via operating torque limitation
This operating torque limitation is not a safety device to prevent pump overpressure. (see 'Theoretical
operating torque’ in the chapter “Technical data".
Pos: 60 /WBV/Pump en/Warnhinweise/ Gefahr/Quetschge fahr durch schwergängig e Kupplungen der G elenkwellen @ 62\m od_13201607130 41_48.doc @ 326683 @ @ 1
Risk of crushing due to seized couplings of the cardan shafts
•In order to prevent the coupling from seizing, make sure assembly is clean and make sure that the
PTO shaft is in flawless condition.
•Wear protective gloves.
Pos: 61 /Grafiken/Pu mpen/WBV/Förderr ichtung/Schlep perantrieb @ 0\mod _1112780271747 _48.doc @ 2232 @ @ 1
Fig.
3
: PTO drive
Pos: 62 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
14/61
Pos: 63 /Überschriften /Überschrift 2 /Marat hon Pumpen @ 0\mod _11099272887 67_48.doc @ 1238 @ 2 @ 1
4.3 Marathon pumps
Pos: 64 /WBV/Pump en/Förderrichtung/ 002F örderrichtung bei M arathon-Pump en @ 58\mod_131246 0860040_48.doc @ 3 08344 @ @ 1
The marathon pump (VX136QDM2, VX186QDM2) is a 2-stage pump with defined suction side and
discharge side. Therefore, the direction of flow is not variable.
Pos: 65 /Grafiken/Pu mpen/WBV/Förderri chtung/Förderr ichtungM arathon @ 0 \mod_111278635 3205_48.doc @ 2256 @ @ 1
A
suction side 1st stage
B
pressure side 2nd stage
Fig.
4
: Direction of flow for Marathon-pumps
Pos: 66 /Überschriften /Überschrift 2 /Pumpa nlagen @ 0\mod_ 1109927346383_48. doc @ 1243 @ 2 @ 1
4.4 Pump systems
Pos: 67 /WBV/Pump en/Förderrichtung/ 002Dr uck- und Saugs eite in Pumpanlagen @ 58\mod_1312 462415553_48.doc @ 308403 @ @ 1
The pressure and suction sides are rigidly defined by the rotation of the pumps. When there are suction
difficulties, it is possible to draw in through the discharge side. A reversal of the pumping direction is not
possible if the pipelines are protected by automatic check valves/return valves.
Pos: 68 /WBV/Pump en/Warnhinweise/ Gefahr/Bersten von Ba uteilen und Herauss pritzen von Medium (Schaugl as) @ 58\mod_ 1312462202388_4 8.doc @ 308373 @ @ 1
Risk of injury from bursting components and medium spraying out under high pressure
A connection with sight glass has to be installed on the suction side. If the sight glass is on the pressure
side (when pumping backwards), the pressure may not exceed 2 bars (29 psi).
Pos: 69 /Grafiken/Pumpe n/WBV/Förderrichtu ng/Schauglas Saugseite (nich tfür At ex-Pumpen) @ 0\mod_111 0275402707_48.doc @ 1548 @ @ 1
A sight glass on suction side, max. 2 bar (29 psi)
Fig.
5
: sight glass
Pos: 70 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
15/61
Pos: 71 /Überschriften/Übersc hrift 2 /InjectionSystem @ 59\ mod_13134162883 03_48.doc @ 310299 @ 2@ 1
4.5 InjectionSystem
Pos: 72 /WBV/Pumpen/För derrichtung/002 Förderri chtung beiI njectionSystem @ 59\ mod_131340041697 0_48.doc @ 310182 @ @ 1
With InjectionSystem I, the direction of flow is variable.
In the InjectionSystem II, the constructive filling optimisation is located only on the suction side. Therefore,
the direction of flow is set in advance. A brief reverse operation is possible.
Pos: 73 /Grafiken/Pumpe n/WBV/Förderrichtung /InjectionSyste m@ 59\m od_13136638612 85_48.doc @ 311429 @ @ 1
InjectionSystem I
InjectionSystem II
Fig.
6
: InjectionSystem
Pos: 74 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
16/61
Pos: 75 /Überschriften /Überschrift 1/Montag e @ 0\mod_ 1109924911984_48. doc @ 1128 @ 1 @ 1
5 Assembly
Pos: 76 /Überschriften/Übersc hrift 2 /Transport @ 11\mod_11 72823145915_48.doc @ 38 086@ 2 @ 1
5.1 Transport
Pos: 77 /Grafiken/Pu mpen/WBV/Mo ntage/Transporthilfe n VX Pumpen @ 59\m od_13136638828 31_48.doc @ 311459 @ @1
Q-pump
QD/QDM2 pump
with cross beam (example)
Pump on base, type belt drive tilted
Pump for base, type inline
Pump with flange-mounted electric motor
Fig.
7
: Transport aids
Pos: 78 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
17/61
Pos: 79 /WBV/Pump en/Warnhinweise/ Gefahr/Verletzungsg efahr durch Herabf allen der Pumpe @ 59\m od_131341264 3635_48.doc @ 310240 @ @ 1
Risk of injury when loading and transporting the pump or the pump unit
•Use the lifting eye bolts on the pumps only for lifting the pump without mounted parts (for example,
the motor).
•The unit may only be transported suspended or screwed to a Euro pallet. Fig. “Transport aids”.
•During loading operations and when setting down the pump or the pump unit, it may be begin to swing
or fall. Risk of crushing! Therefore:
The loading and transporting may only be carried out by specially trained persons.
Standing under raised loads is prohibited. Direct persons out of the danger area.
Pos: 80 /WBV/Pumpen/Mo ntage/002H ängender Trans port@ 59\ mod_131350 6555011_48.doc @ 310668 @ @ 1
If the pump is transported in suspension, use the fitted suspension points for hoisting gear, Fig.
“Transport aids" (indicated with arrows).
•Observe permissible weights of the lifting eye bolts:
Pos: 81 /WBV/Pumpen/Mo ntage/002R ingschraub en- Ge wicht- A ngriffswinkel (VX-Pum pen)@ 32\ mod_12284702589 69_48.doc @ 110057 @ @ 1
Max. permissible weight with one lifting eye bolt M8: 140 kg
Max. permissible weight with one lifting eye bolt M12: 340 kg
Max. permissible weight with two lifting eye bolts M12: 240 kg per lifting eye bolt
(At an angle of attack up to 45°)
Attention! With the pump VX136-420QDM2 and with the series VX186QD/VX86QDM2 starting
at chamber length 368, use a cross beam for lifting, Fig. “Transport aids"
Pos: 82 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
18/61
Pos: 83 /Überschriften /Überschrift 2 /Mont age von Pumpe und Mot ora ufK onsole @ 20\mo d_1196946363610_ 48.doc @ 73773 @ 2 @ 1
5.2 Assembly of pump and motor on base
Pos: 84 /WBV/Pump en/Montage/002 Mo ntage von Pumpe und Motor a uf Konsole @ 59\m od_13137448475 09_48.doc @ 311823 @ @ 1
Noise and vibration hazard
Wear
Noise, vibrations and oscillations can cause impairment of communication and discomfort.
To avoid wear, vibration and generation of noise:
•The base for the pump and motor must not be distorted during installation.
•The alignment of the coupling The alignment of the coupling must be checked and, if
necessary, corrected before start-up, Fig. “Alignment methods”.
Pos: 85 /WBV/Pump en/Montage/002 Wart ungshinweis Schra ubenn achziehen auf Kon sole @ 20\mod_1 198072479543_ 48.doc @ 78495 @ @ 1
Retighten all motor and pump mounting screws on the base after 20 operating hours.
Pos: 86 /Grafiken/Pu mpen/WBV/Mo ntage/Ausrichtmetho den - Kupplungen @ 20\ mod_1197033 538329_48.doc @ 7383 8 @ @ 1
Fig.
8
: Alignment methods
Pos: 87 /WBV/Pumpen/Mo ntage/002R iemenspan nung prüfen@ 5 8\mod_131227 8781396_48.doc @ 307922 @ @ 1
“Technical Information TINF.PU.020.xx, accompanying sheet for belt drives"
For pumps with belt drive check the belt tension acc. to the accompanying sheet:
•At start up
•before and after longer out-of-service periods
•After the first 10 operating hours
•every 2000 operating hours, once per year minimum
Chap. “Maintenance plan"
Pos: 88 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
19/61
Pos: 89 /Überschriften /Überschrift 2 /Einba uin Ro hrleitungen @ 2\m od_114051961 0703_48.doc @ 8858 @ 2 @ 1
5.3 Installation the X-Ripper in pipe systems
Pos: 90 /WBV/Pump en/Montage/002 Ei nbaud er Pumpe @ 59\m od_13134985405 27_48.doc @ 310581 @3 @ 1
5.3.1 Pump installation
•The pump may be installed in the standing, horizontal, vertical or suspended position. Fig.
“Installation versions".
With a horizontal installation, the inlet should be on the bottom and the outlet on the top.
In the case of a vertical installation, please request our “Technical Information
TINF.PU.019.xx", in which the filling and emptying of the gearbox and the buffer chamber are
described.
If the pump is to be suspended, please contact us .
•When installing the pump, ensure that there is easy access for maintenance work. If the hex head
screw plugs for draining the gearbox oil and buffer or quenching fluid are not easy to reach, drain
hoses may be used (part-no. PBT.013 and/or PBT.014).
•Ensure that the pump is free of constraints upon installation and also during operating.
Pos: 91 /Grafiken/Pumpe n/WBV/Montage/Ein bauvarianten @ 59\mod_13 13568469503_48. doc@ 31 0703@ @ 1
standing
horizontal
vertical (TopService)
suspended
Fig.
9
: Installation versions
Pos: 92 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1

Rotary lobe pump
Operating instructions
VX100Q/VX136Q/VX186Q, VX136QD/VX186QD, VX136QDM2/VX186QDM2
20/61
Pos: 93 /WBV/Pump en/Montage/002 Ro hrleitungen und Anschl üsse@ 58\m od_13122060767 12_48.doc @ 307799 @ 3 @ 1
5.3.2 Pipelines and connections
•Only use the pipeline diameters, wall thicknesses and materials recommended by us or by our
representatives. The sealing material must be compatible with the medium.
•Position the pressure and suction connections pointing upwards. This will ensure that the fluid remains
in the pump after it is switched off.
•Keep the pipeline as free as possible from foreign objects (stones, wood residues, etc.) in order to
prevent wear on rotary lobe and housing.
Pos: 94 /WBV/X-Ripper/W arnhinweise/Masc hinengefahr/Gefahre nhinweis Maschine - Bruchgefa hrAnsc hlüsse @ 41\mod_12735 63324004_48.doc @ 18440 9@ @ 1
Danger of breakage! Note on installation of connections
Flange connections can exert excessive forces on the unit. Risk of breakage. The connectors must therefore
be mounted free of stress, i.e. the connectors must be mounted exactly one in front of the other before they
are bolted together.
Pos: 95 /Überschriften/Übersc hrift 4/Saugleitunge n@ 59\ mod_13134969953 09_48.doc @ 310334 @ @ 1
5.3.2.1 Suction lines
Pos: 96 /WBV/Pump en/Warnhinweis e/Hinweis/Saugl eitungen @ 58\mod_1 312190583070_4 8.doc @ 307683 @ @ 1
To protect from high pressure losses and cavitation, heed the advice for laying the
suction lines
•The maximum suction height is 8 m. This is the maximum distance between the lowest and highest
points of the suction pipe. Observe NPSH.
•Suction lines whose diameter is too small may restrict the suction capability of the pump. Caution
cavitation hazard!
If the diameter of the suction pipe is too small, the maximum suction height will be reduced by
the loss of pressure due to pipe friction. Contact us for a calculation .
•Suction lines over 30 m must be laid with a slope of at least 2 x pipe diameter in the direction of flow,
ensuring that the pipeline can never run dry Fig. “Long suction lines".
Pos: 97 /Grafiken/Pu mpen/WBV/Mo ntage/neu- Lange Sauglei tungen @ 16\mo d_118666265711 5_48.doc @ 59423 @ @ 1
Fig.
10
: Long suction lines
Pos: 98 /---Seitenumbruch--- @ 21\m od_12016961362 29_0.doc @ 80575 @ @ 1
