Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 1 / 21
3.626 - 018877 en D – 74564 Crailsheim
I/H Converter
Type DSG-BXX112
Type DSG-BXX102
Instruction Manual
Version 1.0

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 2 / 21
3.626 - 018877 en D – 74564 Crailsheim
Should you have any questions concerning the I/H converter, please contact
the Service Department of the product group Electronic Drive Systems,
Voith Turbo GmbH & Co. KG, Crailsheim, indicating
article number and serial number of the I/H converter.
Voith Turbo GmbH & Co. KG
P.O. Box 15 55
D-74555 Crailsheim
Switchboard: ++49 – 7951 / 32 - 0
Fax: ++49 – 7951 / 32 – 500
Service department of the product group
Electronic Drive Systems
Direct dial: ++49 – 7951 / 32 - 470
Direct fax: ++49 – 7951 / 32 - 605
E-mail: [e-mail]
Address for goods supplied:
Voith Turbo GmbH & Co. KG
Dept. ce
Voithstr. 1
D-74564 Crailsheim
This instruction manual describes the technical condition of the
I/H converter on delivery from September 2003.
Any modifications following the delivery are not considered in this operating
manual.
ÓVoith Turbo GmbH & Co. KG 2003
This instruction manual is protected by copyright.
It may not be reproduced or translated in any form or by any
means (mechanical or electronic) or submitted to
third parties, without the publisher’s written approval.
Issued: 09 / 03
Order No.: 3.626- 018877 en
Version: 1.00
Printed in Germany

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 3 / 21
3.626 - 018877 en D – 74564 Crailsheim
Contents
1. Technical data
2. Safety Information
2.1 Definition of notes and symbols
2.2 Proper use
2.3 Important notes
2.4 Warranty
3. Functional Description
3.1 Mechanical design
3.2 Operating characteristics
4. Packing, Storage and Transport
5. Installation
5.1 Mounting
5.2 Hydraulic connection
5.3 Electric connection
6. Commissioning
6.1 Test run
6.2 Parameter setting
7. Operation
7.1 Operation with manual operation knob
7.2 Operation wit set signal
7.3 Trouble shooting and remedial action
8. Maintenance and Repair
9. Shutdown
10. Outline drawing with Wiring Diagram
11. Annex

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 4 / 21
3.626 - 018877 en D – 74564 Crailsheim
1. Technical Data
Ambient conditions:
Ambient temperature for storage -40 °C ... +90 °C
Ambient temperature -20 °C …+85 °C
Protection IP 65 to EN 60529
suitable for internal installation in industrial air
Electric data:
Supply voltage 24 VDC ±15%
Power consumption approx. 0.7 A
max. 3 A, for t <1 sec
Setpoint input w = 0/4...20 mA
input resistor 25 Ohm
with suppressor circuit
Hydraulic data:
Input pressure Pin min 1.5 bar more than PA max
Input pressure Pin max see table
Pressure fluid mineral oil or hydraulic oil (hardly
combustible fluids on request)
Viscosity pressure fluid ISO VG 32... ISO VG 48 to
DIN 51519
Temperature pressure fluid +10 °C...+70 °C
Oil purity recommended purity class:
To NAS1638 class 7
To ISO4406 class -/16/13
Leakage £5 l/min

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 5 / 21
3.626 - 018877 en D – 74564 Crailsheim
Type DSG- BXX 112
B03... B05... B07... B10... B30...
Output pressure
regulating range
PA[bar]
0..3 0..5 1..7 0..10 2..30
Input pressure
Pin max [bar] 40 40 40 40 70
Flow rate line P ®A
Q1 [l/min]
at DP = 1 bar
18 18 18 17 21
Flow rate line A ®T
Q2 [l/min]
at DP = 1 bar
20 20 20 18 24
Regul. range approx.
PAmax [bar]
at setpoint 20 mA
1..33..53,5..75..10 7..30
Regul. range approx.
PAmin [bar]
at setpoint 4 mA
0..1
0..2
0..1,5
0..3
1..2
1,5..4
0..2
0..6
0..3
0..18
Type DSG- BXX 102
B05... B07...
Output pressure
regulating range
PA[bar]
0..5 1..7
Input pressure
Pin max [bar] 40 40
Flow rate line P ®A
Q1 [l/min]
at DP = 1 bar
18 18
Flow rate line A ®T
Q2 [l/min]
at DP = 1 bar
20 20
Regul. range approx.
PAmax [bar]
at setpoint 20 mA
3..53,5..7
Regul. range approx.
PAmin [bar]
at setpoint 4 mA
0..1,5
0..3
1..2
1,5..4
The regulating range of PAmin depends on the set pressure PAmax.
The regulating range of PAmin indicated in the first line refers to the minimum
adjustable pressure PAmax.
Mechanical data:
Dimensions, fitting see chapter 10
Hydraulic connection see chapter 10
Mounting position see chapter 10
Sealing material FPM
Weight approx. 12 kg

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 6 / 21
3.626 - 018877 en D – 74564 Crailsheim
2. Safety Information
2.1 Definition of notes and symbols
Danger !
This symbol signals an imminent danger to the life and
health of individuals.
If this note is not observed, injury to health and even most
serious injuries may be the consequence.
Warning !
This symbol signals a harmful situation.
If this note is not observed, the product may be damaged.
Note !
This symbol refers to proper handling of the product. It does not refer to
or indicate a dangerous situation.
2.2 Proper use
The I/H converter serves to transform an electric set signal
into a related hydraulic output pressure reduced to feed-in pressure. This
allows, for example, adjusting control pistons at hydraulic cylinders which
are used to position the valves of steam turbines.
2.3 Important notes
The following notes refer to the entire instruction manual and have to be
observed in addition to the individual notes.
Accident prevention
·Improper use may cause operating agent under pressure to leak
at the sealing surfaces. There is a risk of fire around hot components.
·Isolate the hydraulic supply prior to working on the I/H converter.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 7 / 21
3.626 - 018877 en D – 74564 Crailsheim
·Failure of electric power or disturbance of the control electronics
integrated in the I/H converter may cause strong variations of the
output pressure when operating the I/H converter. Thus e.g. the
piston rod of a hydraulic cylinder may move uncontrolled, causing
danger to individuals or equipment.
·During operation, the outer surfaces of the I/H converter may heat up
due to the pressure fluid. Contact may cause skin burns. Make sure to
cool down the I/H converter prior to working on it.
·Electrical components are installed in the I/H converter. These
components can be destroyed by e.g. welding in its surrounding.
Therefore make sure to disconnect all electric connections prior to
electrical weldings in the surrounding of the I/H converter.
Environment protection
·During mounting, dismounting or improper use of the I/H converter
pressure fluid may leak out. Operating agent reaching the sewage
system or the open soil, causes severe environmental damages.
Leaking pressure fluid has to be collected and deposited in
accordance with the national legal regulations.
Instruction manual
·The instruction manual contains important information for proper
handling of the I/H converter. Prior to installation and commissioning
of the I/H converter, read the manual carefully and make sure it is
completely understood.
·Keep this manual in a location convenient to the operating staff.
·In addition to this operating manual: Have the relevant regulations for
prevention of accidents and environmental protection available and
observe these.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 8 / 21
3.626 - 018877 en D – 74564 Crailsheim
Staff qualification
·Only trained and instructed staff is allowed to perform any work on the
I/H converter. This personnel has to be trained and authorized to
mount I/H converters professionally.
Constructional modifications
·Mounting and constructional modifications are not permitted.
2.4 Warranty
The terms and conditions mentioned in the General Conditions
of Sale of Voith Turbo GmbH & Co. KG, Crailsheim, are applicable.
Warranty claims are excluded, if these are due to one or several of the
following causes:
·Improper transportation, storage, mounting, set-up, commissioning
and operation of the I/H converter.
·Not observing the safety instructions and guidelines included in this
instruction manual.
·Use of spare parts not approved by
Voith Turbo GmbH & Co. KG, Crailsheim.
Repair works on the I/H converter are to be performed or approved by
Voith Turbo GmbH & Co. KG, Crailsheim.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 9 / 21
3.626 - 018877 en D – 74564 Crailsheim
3. Function
3.1 Design
I/H converter DSG-BXX112
(In case of DSG-BXX102 the manual operation knob
item 4 is replaced by a cover, see chapter 10)
Bild: 3.1.1
1 – Control magnet VRM P - Input pressure Pin
2 – Tappet for power transmission PA- Output signal pressure
3 - Potentiometers X0 and X1
4 – Manual operation knob T1- Tank return line
5 – Electric connection T2- Tank return line for int. leakage
6 – Control housing FMag - Magnetic force
7 – Control piston FHyd - Hydraulic force
8 - Cover

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 10 / 21
3.626 - 018877 en D – 74564 Crailsheim
3.2 Operating characteristics
(see fig. 3.1.1)
A set signal w = 0/4...20 mA generates a magnetic force FMag in the
VRM, the limits of which can be adjusted by means of the X0 and X1
potentiometers and which is then transmitted onto the control piston via
tappet.
The hydraulic force FHyd being proportional to the output signal pressure
PAacts against this force.
In the case of the two forces being equal, the control piston is positioned
in the “hydraulic center” as shown in fig. 3.1.1 and the output signal
pressure PAcorresponds to the set signal w.
In the “hydraulic center“ position the control piston performs minimum
oscillating movements in the area of the guiding edges P®PAand PA®T,
in order to keep the output pressure PAon the value set by FMag.
When increasing the set signal and thus FMag from this condition, the
control piston position changes and thus connects the output pressure PA
to the feed pressure P and blocks PAtowards the tank return line T1.
Now pressure PAand thus the hydraulic force FMag will increase until the
same has returned the control piston to the “hydraulic center” and PA
corresponds to the new set signal.
In case of I/H converters with regulating range 0..X a pressure spring is
installed between cover, item 8, and the control piston.
This spring generates a force-offset FFed towards the effective direction of
FHyd in order to guarantee the I/H converter function for output pressures
of approx. 0 bar, too.
The internal leakage is fed back into tank return line T2.
Function of manual operation knob:
The control magnet of I/H converter DSG-BXX112 is provided with a
manual operation knob, by means of which an adjustable spring force
can be set instead of the magnetic force FMag . This spring force affects
the control piston via magnet armature and tappet. The hydraulic force
FHyd , being proportional to the output signal pressure PAalso acts
against this spring force here. Thus adjustment of output pressure is
possible without electric connection.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 11 / 21
3.626 - 018877 en D – 74564 Crailsheim
4. Packing, Storage and Transport
Packing
The I/H converter is delivered in a special packing.
The openings for the hydraulic connections are sealed with plugs to
prevent penetration of impurities and humidity.
Storage and preserving
The outer surfaces of the I/H converter are protected by means of a
preserving surface coat.
The internal parts are preserved by oil.
Within Europe the anticorrosion protection is sufficient for approx. 8
months in industrial air, presuming storage of the I/H converter in a dry
location.
In case the I/H converter is supposed to be stored for a longer period of
time, special precautions will have to be taken.
In each specific case, these precautions have to be agreed with
Voith Turbo GmbH & Co, KG, Crailsheim.
The storage ambient conditions have to be within the limits as indicated
in chapter 1.
Transport
Improper transport may cause personal injuries and damages to
property. Pack the I/H converter in a way that prevents housing damages
during transport.
In particular make sure that the socket-outlet for the electric connection
and the sealing surface at the hydraulic component are not damaged.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 12 / 21
3.626 - 018877 en D – 74564 Crailsheim
5. Installation
·Improper installation of the I/H converter may cause malfunctions and
premature failure of the operation of the I/H converter.
·Cleanliness is imperative during installation an connection. Prevent
that any impurities ( dust, metal chips etc.) can get into the I/H
converter or pipe system which may cause damage to the I/H
converter.
Cover and protect the I/H converter and in particular the electric lines
during construction time.
5.1 Mounting
Perform any work on the I/H converter only when it is in deenergized
condition and with switched off oil supply system.
Protect oil and power supply against unintentional switching-on during
mounting.
Install the I/H converter in accordance with the permissible installation
position as shown in chapter 10.
Recommended fastening bolts:
2 pieces hexagonal screws M10, strength category 8.8.
tightening torque MA=35 Nm, thread slightly oiled.
Select screw length according to mounting situation.
5.2 Hydraulic connection
The hydraulic connection on the I/H converter is made by means of
connection bores at its bottom. The connection flange is sealed with o-
rings. Please refer to chapter 10 for position and dimensions of the
connections.
Surface roughness of connecting flange:
Ra = 1.6 mm, Rmax = 6.3 mm
Only pressure-less return of the operating medium through return line T2
to the tank, ensures proper work of the I/H converter.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 13 / 21
3.626 - 018877 en D – 74564 Crailsheim
In practise the tank lines for the connections T1 and T2 are joined
together and laid downgrade towards the tank in one common pipe line.
Requirements to this pipe line:
Nominal size 20 mm or bigger for I/H converters with an output pressure
up to 10 bar.
Nominal size 30 mm or bigger for I/H converters with an output pressure
of more than 10 bar.
Observe the correct pressure range when selecting pipes, hoses,
screwings and flanges.
Immediately replace damaged pipes and hose lines.
When assembling the pipe lines, ensure that it is fastened to fixed
structures, free from vibration and not to moving equipment. Temperature
variations of the piping (thus alterations in length) must not apply
constraining forces to the I/H converter.
Clean pipe lines from dirt, cinder, sand, chips etc. prior to installation.
Pickle or flush welded pipes.
Clean and flush carefully all pipe and hose lines prior to attaching the
I/H converter.
=> For flushing, a flushing plate (Art. No. 43.8565.10) is available.
See chapter 11.
=> To connect the I/H converter to the piping system an adapter (Art. no.
43.9300.11) is available. See chapter 11.
·Residual oil may leak when removing the plug (max. 0.1 l). Collect the
oil in a suitable container and deposit it properly.
·Do not use fibrous or hardening sealing compounds, such as e.g.
hemp or mastic to seal the connections and screwings.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 14 / 21
3.626 - 018877 en D – 74564 Crailsheim
5.3 Electric connection
The electric system has to be connected by an electric expert in
accordance with electrical engineering standards and legal regulations of
the manufacturing country.
When connecting customer´s lines, avoid parallel run of the I/H converter
lines with the lines of current converter assemblies.
The customer`s signals and supply lines running to the I/H converter
must be screened.
Please refer to chapter 10 for the wiring diagram.
6. Commissioning
The I/H converter was adjusted and tested at Voith Turbo’s works by
means of the potentiometers X0 and X1. The test result is documented in
an attached test certificate.
The potentiometers are provided with a protective cap to avoid
unintentional maladjustment and impurities.
6.1 Test run
Make sure that pipe lines and hydraulic system are cleaned prior to
performing a test run. The operating fluid has to be in accordance with
the purity class as indicated in chapter 1. Do not flush or clean the
pressure fluid with the I/H converter being hydraulically connected.
Operation of the I/H converter with contaminated pressure fluid is not
permitted, the I/H converter may be damaged.
·Check the line mounting, connection and flow direction to and on the
I/H converter.
·Check the electric connection.
·Switch on the 24 VDC power supply.
·Switch on the oil supply and check input pressure.
The minimum input pressure has to be 1.5 bar more than the maximum
output pressure required at 20 mA.
·Set the signal w = 0/4.. 20mA and check output pressure.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 15 / 21
3.626 - 018877 en D – 74564 Crailsheim
During the test run, check all hydraulic connections for leakages. In
case of leakage, immediately switch off the hydraulic supply and
eliminate leakages.
6.2 Parameter setting
Due to unintentional maladjustment of the parameters or changed
operating conditions, new setting of one or both parameters may become
necessary.
We recommend to document adjustment of the parameters as well as the
set values.
The parameters are adjusted by means of potentiometers X0 and X1.
Please refer to chapter 10 for the position of the potentiometers.
Potentiometer effects:
X0 - With help of potentiometer X0 the minimum output pressure
PA min is adjusted at a setpoint of 0 mA or 4 mA.
Pressure increase by turning the potentiometer clockwise.
X1 - With help of potentiometer X1 the maximum output pressure
PA max is adjusted at a setpoint of 20 mA.
Pressure increase by turning the potentiometer clockwise
X1 should be adjusted before X0.
The X1- adjustment influences the adjustment of X0.
Manufacturer-provided adjustments:
At the works, the I/H converter has been adjusted as indicated in the
order.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 16 / 21
3.626 - 018877 en D – 74564 Crailsheim
7. Operation
7.1 Operation with manual knob
Operation with manually controlled rotary knob is possible without electric
energy.
On operation with manually actuated rotary knob, uncontrolled stroke
movements of the hydraulic components controlled by the I/H converter
output might occur due to the increase in the output signal pressure.
Manual operation is only possible when the circlip is removed from the
manual operation knob.
On completion of operation with manual operation knob, move the
manual operation knob in its final position by turning it counter clockwise
and pushing in the circlip to its final position.
·Remove the circlip.
·Slowly turn the manual operation knob clockwise and observe the
output pressure.
Effective direction: Output pressure increase by clockwise rotation.
7.2 Operation with set signal
When the supply voltage is switched on, the output signal pressure can
be adjusted continuously by the set signal 0/4...20 mA within the limits
set by the potentiometers X0 und X1.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 17 / 21
3.626 - 018877 en D – 74564 Crailsheim
7.3 Trouble shooting and remedial action
Prior to all works, make sure that the I/H converter was commissioned
according to chapters 5 and 6.
Malfunction: Pressure variations
The output signal pressure PAmay vary now and then or
periodically with low or high frequency and amplitude.
Cause: 1. air inclusions in the hydraulic component
2. low or considerably varying input pressure.
3. dirt particles in the hydraulic component
4. pressure on return line
Remedy: 1. On first commissioning or after longer periods of
stand still air inclusions in the hydraulic component may
cause pressure variations. Positive opening operation
grants sufficient hydraulic damping due to the damping
piston within seconds.
2. Under load and in particular in case of higher output
signal pressure, a lower input pressure may lead to
pressure variations.
Increase and / or stabilize the input pressure by taking
appropriate measures (e.g. accumulator). See also chapter
1.
3. Contaminated pressure fluid results in increased friction at
the control piston, thus causing hysteresis and pressure
variations.
Open hydraulic component and clean the inner elements. In
case of damaged surfaces and guiding edges replace the
I/H converter.
4. The dimensions of the return line have to be sufficient.
In case of additional consumers of the output pressure
connected to this line, make sure they do not create any
pressure in the return line. See also chapter 5.2.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 18 / 21
3.626 - 018877 en D – 74564 Crailsheim
Malfunction: Output pressure PA ®0 bar or ®P (input pressure)
Due to a defective control valve VRM or blockage of the
control piston the output pressure may fall to 0 bar or
increase to the input pressure.
Remedy: The function of the hydraulic component can be checked using
the manually controlled knob with the supply voltage being
switched off. See chapter 7.1.
If the output pressure cannot be adjusted manually, the control
piston, e.g., may be blocked by particles (e.g. chips).
Open hydraulic component and clean inner parts.
If the surfaces and guiding lines are damaged, exchange
the I/H converter.
Should output pressure adjustment be possible with manual
operation knob, but not with the control magnet, the control
magnet VRM is defective.
Repairs on the control magnet VRM are not allowed.
Replace any defective I/H converter completely.
8. Maintenance and Repair
For a trouble-free and reliable operation of the I/H converter, it is
necessary to perform inspection, maintenance and repair work in
certain intervals.
Routine inspection
Check the pipes, screw connections and connections on the
I/H converter for leakage, impurities and damage.
Eliminate any leakage, impurity and damage noticed, if required, during
appropriate operating modes.
Monitor the control behavior of the I/H converter for any changes.
Analyse and eliminate the causes, if required, during appropriate
operating modes.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 19 / 21
3.626 - 018877 en D – 74564 Crailsheim
Inspection after approx. 740 operating hours / max. 1 month
Take an oil sample from the oil tank and analyse it for solid and
suspended matters, water content, shadings and air bubbles.
Analyse oil purity of the oil sample. Clean or exchange the oil, if
required, in an appropriate operating mode.
Inspection after approx. 8000 operating hours / max. 1 year
Take an oil sample from the oil tank and analyse it chemically.
If required, clean or change the oil during an appropriate operating mode.
Check and retighten, if necessary, the electric connections of the I/H
converter.
9. Shutdown
If the I/H converter is switched off for reasons of repair, inspection or
unit shutdown, switch off the oil supply system and relieve all pressure
reservoirs, if effective. Switch off the 24 VDC supply voltage and
remove the lines as well as piping and hose connections. Doing so, an
considerable oil quantity may leak out. Collect the oil in a suitable
container and deposit it properly. Close all holes. Now clean and pack
the I/H converter.
Disposal
In the event of disposal of the I/H converter, observe the local applicable
regulations regarding the environmental protection. The I/H converter
essentially contains steel, copper, synthetic materials, electronic
components and residual oil.

Instruction Manual
Voith Turbo I/H Converter DSG-BXX112
I/H Converter DSG-BXX102
09 / 03 cet - Ochs/ZAN1 Voith Turbo GmbH & Co, KG Page: 20 / 21
3.626 - 018877 en D – 74564 Crailsheim
10. Outline and Wiring Diagram
