volkano Cobalt Series User manual

Please read these instructions carefully and retain for future reference.
INSTRUCTION MANUAL
VK-20120-BK

HIGHLIGHTS
Keyboard:
• Chocolate block style keycaps
• Multimedia and Windows shortcut keys
• Wireless operation up to 8 meters / 26 feet
• Plug and Play - No drivers required
• Suitable for Windows, MacOS, Linux and Android
Mouse:
• Left or right-handed use
• Adjustable DPI 800 / 1200 / 1600
• Wireless operation up to 8 meters / 26 feet
• Plug and play - no drivers required
2

TECHNICAL SPECIFICATIONS
Mouse Specifications:
• Mouse Lighting: Red
• DPI Switch: 800 / 1200 / 1600
• Buttons: 3
• Sensor Type: Optical
• Sensor Brand: Mosart
• Wireless Type: 2.4 GHz
• Batteries: 1 x AA
• Wireless Range: 8 m / 26 feet
• Power Saving: Yes
• Nano USB Receiver: Yes
• Mouse Size: 99 x 61.5 x 35.5 mm
Keyboard Specifications:
• Connection Method: Wireless
• Wireless Range: 8 m / 26 feet
• Function Keys: 12
• Multimedia Keys: 12
• Key System: Membrane
• Key Type: Chocolate block
• Batteries: 1 x AAA
• Operating Voltage: 1.5 V DC
• LED Indicators: Power
• Power Saving Yes
• Keyboard Size: 450 x 158 x 24 mm
• Compatibility: Windows, MAC OS, Linux, Android 4.4 up
3

PACKAGE CONTENTS
• Volkano Cobalt Series Wireless Keyboard
• Volkano Cobalt Series Wireless Mouse
• Volkano USB Nano Receiver
• 1 x AAA Battery
• 1 x AA Battery
• Instruction Manual
DESCRIPTION OF PARTS
4
1
43
5
8
9
10
6
7
2
1. Function and Multimedia
Shortcuts
2. Power Light
3. Windows Shortcut Key
4. Function Key
5. Left Mouse Button
6. Right Mouse Button
7. Scroll Wheel with Button
8. Battery Compartment
9. Nano Receiver
10. Power Switch

SETUP
Open the battery compartment of the mouse to remove the Nano USB
receiver. Insert the AA battery into the mouse, and the AAA battery into the
keyboard’s battery compartment. Finally, insert the Nano USB receiver into the
USB port of your computer. Slide the Power Switch to the On position. After
a few seconds, your computer will install the device drivers and your combo
will be ready for use.
MOUSE BUTTON FUNCTIONS
DPI Switch
To toggle the mouse’s sensitivity settings between 800, 1200 or 1600 DPI,
simply press and hold the Left Mouse Button and the Right Mouse Button
at the same time for three (3) seconds. The mouse is set to 800 DPI by
default. Higher DPI makes the mouse more sensitive for higher
accuracy applications.
5

6
Multimedia Shortcut Keys
Hotkey Icon Function Description
<Fn>+<F1> Media
Player
Press the Function Button while
pressing the F1 Key to open your
default media player.
<Fn>+<F2> Volume
Down
Press the Function Button while
pressing the F2 Key to decrease the
volume.
<Fn>+<F3> Volume Up
Press the Function Button while
pressing the F3 Key to increase the
volume
<Fn>+<F4> Mute
Button
Press the Function Button while
pressing the F4 Key to mute all
sound.
<Fn>+<F5> Previous
Press the Function Button while
pressing the F5 Key to play the
previous item in your media player’s
playlist.
<Fn>+<F6> Next
Press the Function Button while
pressing the F6 Key to play the next
item in your media player’s playlist.
<Fn>+<F7> Pause /
Play
Press the Function Button while
pressing the F7 Key to play, or pause
media playing from your media
player.
<Fn>+<F8> Stop
Press the Function Button while
pressing the F8 Key to stop all media
playing from your media player

7
<Fn>+<F9> Homepage
Press the Function Button while
pressing the F9 Key to open your
internet browser. Your internet
browser will open your default
homepage.
<Fn>+<F10> Email
Pressing the Function Button while
pressing the F10 Key opens your
default Email program.
<Fn>+<F11> Computer
Pressing the Function Button while
pressing the F11 Key will open a
“This PC” window.
<Fn>+<F12> Bookmark
Press the Function Button while
pressing the F12 Key to open the
bookmarks tab in your internet
browser. Please note that this is only
supported in certain browsers.

8
SAFETY PRECAUTIONS
• The product should only be used with the parts provided by
the manufacturer.
• This product is intended for indoor use only.
• The Cobalt Series Wireless Set is intended for personal use only.
Commercial use invalidates the warranty and the supplier cannot be held
responsible for injury or damage caused when using the device for any
other purpose than that which it was intended for.
• This is not intended for use by children, or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the
device by a person responsible for their safety. Extreme caution must
be exercised.
• Children should be supervised to ensure that they do not play with the
Cobalt Series Wireless Set.
• Packaging must never be left within reach of children, since it is
potentially dangerous.
Low Power Alert
Please note that the keyboard’s red low power light will flicker repeatedly
to indicate that the batteries are depleted. Please replace the batteries to
continue using the keyboard should this arise.

9
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact your local government for information regarding
the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain,
damaging your health and well being.
CLEANING & CARE INSTRUCTIONS
Before Cleaning: Ensure that your Cobalt Series Wireless Set is not plugged
into any device before cleaning or maintaining it. Remove the batteries before
cleaning.
Cleaning: Wipe down the surface of your Cobalt Series Wireless Set using a
soft, slightly damp cloth.
Do not use any harsh or abrasive cleaning chemicals or materials on your
Cobalt Series Wireless Set as doing so may damage or scratch the surface
finish.
Do not expose your Cobalt Series Wireless Set to high temperatures for
extended periods of time.
Do not store in temperatures over 140°F (60°C).

10
DISCLAIMER
All product and company names are trademarks™ or registered®trademarks
of their respective holders. Use of them does not imply any affiliation with or
endorsement by trademark or registration holders.
WARRANTY
This Volkano Cobalt Series Wireless Combo includes a standard 12-month
limited warranty against manufacturing defects and faults. Should your
product be unboxed with any faulty parts, poor finishing or visible damage,
or fail to perform due to a manufacturing defect or poor workmanship,
please return it with your proof of purchase (till slip or invoice) to the store of
purchase for an exchange, or repair, depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your
warranty period.
NOTE:
The Warranty does not apply to a Product that:
a.) Has failed due to excessive wear and tear beyond what is considered to
be reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including fire
and flooding.
d.) Has been used or operated contrary to operating or maintenance
instructions outlined in this manual.
The store of purchase / seller cannot accept any returned products that have
not been returned in accordance to this warranty or which does not follow
their own returns policy. Please refer to the store of purchase / sellers returns
policy for details.
Should you require any further assistance or have any questions on your
warranty, please contact the store of purchase.
