volkano Core Series User manual

VK-5065-BK
Core Series
INSTRUCTION MANUAL
Please read these instructions carefully and
retain for future reference.
SPLASH RESISTANT
FITNESS WATCH
WITH HEART RATE MONITOR
TA-2017/2920
APPROVED

2
• Heart Rate Monitor
• Pedometer
• Message & Call Notification
• 3 Day Battery Life
THE HIGHLIGHTS
• Volkano Active Tech Core Series Smart Watch
• USB Charging Cable
• Instruction Manual
PACKAGE CONTENTS

3
• Heart Rate Monitor : Built-in
• Pedometer : Built-in
• Alarm Clock : Yes
• Notification : Yes via smartphone
• Call Reminder : Yes
• Screen Type : Colour LCD
• App : Volkano Active
• RAM : 16 Kb
• ROM : 256 Kb
• Screen Resolution : 160 x 80
• Screen Size : 0.96″
• Bluetooth Version : 4.0
• Bluetooth Operating Distance : 10 m
• Chipset : BK
• Battery Capacity : 90 mAh
• Battery Type : Lithium Polymer
• Standby Time : 7 days
• Playback Time : 3 days
• Charge Time : 2 hrs
SPECIFICATIONS

4
1. Screen
2. Virtual Key
3. Heart Rate Sensor
4. Charging Pogo Pins
DESCRIPTION OF PARTS
1
2
3
4

5
INSTRUCTIONS FOR USE
CHARGING
POWER OFF
Remove the watch from its strap and connect the
charge cable. Plug the USB charging cable into a
powered AC adapter or computer USB port.
Long press the “Virtual Key” to turn off your
watch when the “Off” option is selected from the
“More” menu.
INSTALLING THE VOLKANO ACTIVE APP
To download the Volkano Active App, please
direct your browser to the following website:
volkano.co.za/active-app or scan the QR
code from your phone.

6
CONNECTING THE WATCH WITH A MOBILE PHONE
1. Enable Bluetooth on your smartphone.
2. Pair your smartphone with the watch (see “Locating the Bluetooth Menu”
for more details).
3. Open “Volkano Active App” on your smart phone, set your profile from
the Settings menu in the “My Profile” tab.
4. Tap “Connect the smart watch” in the Settings Menu.
5. Select “VK-5065” from the list of devices.
6. A success prompt will appear on-screen. Tap “Next” to navigate to
the App’s dashboard.
LOCATING THE BLUETOOTH MENU
iPhone
a) On your iPhone device, go to “Settings”.
b) Select “Bluetooth”. If Bluetooth is not on, turn it on.
c) Then open the Volkano Active App. Go to “Settings”, click “Connect the
smartwatch”. You will see different options.
d) Choose “VK-5065” and click “Connect”.
Android™ Phones
a) On your Android phone, go to “Settings”.
b) Select “Bluetooth” (on older Android devices Bluetooth is found in
the Wireless & Networks menu). If Bluetooth is not on, turn it on.
c) Then open the Volkano Active App. Go to “Settings”, click “Connect the
smartwatch”. You will see different options.
d) Choose “VK-5065” and click “Connect”.

7
UNBIND THE VOLKANO ACTIVE FROM A MOBILE PHONE
1. Open “Volkano Active App” on your smartphone.
2. Tap “Disconnect Smart Watch” on Settings.
3. Forget your device on your smartphone’s Bluetooth settings. To do this, please
refer to your smartphone’s instruction manual.
CONNECTING WITH PAIRED DEVICES
Once the Volkano Active is turned on, it will automatically connect with the last
paired Bluetooth device that is on and within range. If the Volkano Active does not
connect automatically, open the Bluetooth menu on your device and select
“VK-5065” from the Bluetooth device list.
CONTROLS
• Press the “Virtual Key” to switch the main menu interface.
• Long press the “Virtual Key” to “Confirm”.
• Long hold the “Virtual Key” to switch on the watch from its powered-off state.

8
FUNCTIONS
Long press the “Virtual Key” to
change the way in which the watch’s
dashboard is displayed, and press
the “Virtual Key” again to confirm
your selection.
WATCH FACE
The watch will record your daily
activity automatically. After
synchronizing with the Volkano Active
App, you can check your steps,
calories and distance data on your
smartphone.
PEDOMETER

9
MULTI-SPORT
Long press the “Virtual Key” to enter the Multi-sports function once it is selected.
The Volkano Active has nine multi-sports modes: Walking, Running, Biking, Run
Indoor, Basketball, Swimming, Table Tennis, Badminton and Climbing. Choose your
desired mode by long pressing the “Virtual Key”. The Volkano Active will record the
data of the selected sport mode and send it to the Volkano Active App.

To exit the sport function, long press the “Virtual Key” then select to stop your
movement and save it. After synchronizing with the Volkano Active App,
you can check your sport record.
Please note that if the sport time is less than one minute, the data will not be saved.
10

11
HEART RATE
Long press the “Virtual Key” to monitor your
heart rate once it is selected and long press
to exit the heart rate monitor.
After syncing with the Volkano Active App,
you can check your heart rate data on
your smartphone.
SLEEP MONITOR
The Volkano Active will monitor your sleep
automatically. When sleep is ended, the
Volkano Active will show your sleep report
with the times of total sleep, light sleep and
deep sleep. After synchronizing with the
Volkano Active App, you can check a more
detailed sleep report.

12
ALARM
Long press the “Virtual Key”, you can check
an alarm which you set on the Volkano
Active App. When alarm is on, its icon will be
animated and the watch will vibrate.
MESSAGE
Long press the “Virtual Key” to view the
notification contents. Including incoming call,
SMS, QQ, Wechat, Whatsapp, Facebook and
Twitter message notifications.

13
MOVEMENT
Long press the “Virtual Key” to enter the
“Movement” settings menu. Short press the
“Virtual Key” to switch this mode “On” or “Off”.
Long press the “Virtual Key” to exit. You can set
more conditions in the App, including the start
to the end of period, time interval (minutes),
threshold value (steps) and repeat setting (weeks).
The device will vibrate to remind the wearer to
move after the set conditions are met.
Long press the “Virtual Key” after the watch is
connected with the Volkano Active App, your
smart phone will ring. If you use iPhone, you
must keep your Volkano Active App displaying
on the screen.
FIND PHONE

14
Long press the “Virtual Key”, you can check
the Bluetooth Mac Address, Device name and
Firmware Version of your Volkano Active.
Long pressing the “Virtual Key” will turn off your
Volkano Active.
ABOUT
POWER OFF

15
VOLKANO ACTIVE APP DASHBOARD
The dashboard displays performance indicators of the day including weight, sleep and
heart rate.
SHARE
This button allows you to share your progress through social media.
ENTRY WEIGHT
This page allows you to enter your current weight, set an ideal weight and the date you
want to reach the ideal weight.
CALENDAR
This button displays the calendar.
ACTIVITY
This page displays a log of all the activities recorded while wearing the Volkano Active.
REMINDER
This page allows you to toggle and set reminders.

16
MY PROFILE
This page allows you to change your profile information.
GOALS
This page allows you to change and set goals for Steps, Distance, Calories and Sleep.
Once you have made changes, tap the save button.
NOTIFICATIONS
This page allows you to toggle which application notifications appear on the Volkano
Active.
ADVANCED SETTINGS
This page allows you to toggle settings related to weather, movement, heart rate,
drinking water, do not disturb and gesture control.
FIND THE SMART WATCH
Tapping this makes the Vokano Active vibrate to allow you to locate it.
GOOGLE FIT
Toggling this setting “On” will allow the Volkano Active App to send your performance
data to Google fit.
THEME
The theme of the App can be changed from this page.
SETTINGS

17
CONNECT THE SMART WATCH
This page allows you to choose which Volkano Active watch or band to connect with.
FIRMWARE UPDATE
From this page the firmware of the Volkano Active can be updated. Please remember
to keep the App running and a stable internet connection active when updating.
Please note that data charges apply to your respective cellular service provider.
RESET
Tapping this clears all the stored performance data from the App.
ABOUT
This page displays the App’s version information.
• The product should only be used with the parts provided by the manufacturer.
• The Volkano Active is intended for personal use only. Commercial use invalidates the
warranty and the supplier cannot be held responsible for injury or damage caused
when using the device for any other purpose than that which it was intended for.
• This Volkano Active is not intended for use by young children, or persons with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the device
by a person responsible for their safety. Extreme caution must be exercised.
• Children should be supervised to ensure that they do not play with the Volkano Active.
Packaging must never be left within reach of children, since it is potentially dangerous.
SAFETY PRECAUTIONS

18
• Before Cleaning: Ensure that your Volkano Active is not plugged into any device
before cleaning or maintaining it. Switch it off before cleaning.
• Cleaning: Wipe down the surface of your Volkano Active using a soft, slightly
damp cloth.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Volkano
Active as doing so may damage or scratch the surface finish.
• Do not expose your Volkano Active to high temperatures for extended periods of time.
• Do not store in temperatures over 60 °C.
CLEANING & CARE INSTRUCTIONS
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities. Contact your local government for information
regarding the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can leak into
the groundwater and get into the food chain, damaging your health and
well-being.
ENVIRONMENTALLY FRIENDLY DISPOSAL

19
DISCLAIMER
• All product and company names are trademarks™ or registered®trademarks
of their respective holders. Use of them does not imply any affiliation with or
endorsement by them.
• While our heart rate monitor technology is very advanced and has been tested
by a medical professional, there are limitations with the technology that may
cause some of the heart rate readings to be inaccurate under certain
circumstances. This may include the user’s physical characteristics, the fit of
the device and the type and intensity of user activity. The heart rate monitor is
NOT intended to be used for medical purposes, nor is it intended to diagnose,
treat, cure or prevent any disease or condition. You should not rely on the
information on the device as an alternative to medical advice from your doctor
or other professional healthcare provider. If you have any specific questions
about any medical matter, you should consult your doctor or other professional
healthcare provider. If you think you may be suffering from any medical condition,
you should seek immediate medical attention. You should never delay seeking
medical advice, disregard medical advice or discontinue medical treatment
because of information on this device.

20
This Volkano Active Tech Core Series Smart Watch includes a standard 12-month
limited warranty against manufacturing defects and faults. Should your product be
unboxed with any faulty parts, poor finishing or visible damage, or fail to perform
due to a manufacturing defect or poor workmanship, please return it with your proof
of purchase (till slip or invoice) to the store of purchase for an exchange, or repair,
depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty period.
NOTE: The Warranty does not apply to a Product that:
a) Has failed due to excessive wear and tear beyond what is considered to be
reasonable.
b) Has been misused or neglected.
c) Has been damaged accidentally or by acts of God including fire and flooding.
d) Has been used or operated contrary to operating or maintenance instructions
outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not been
returned in accordance to this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
WARRANTY
