Volt VAC-HUB5 User manual

VOLT®Low Voltage Landscape Lighting
VOLT®Pro Junction Hub
VAC-HUB5
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2021, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

Important: Please Read Before Installation
INSTALLATION INSTRUCTIONS
!
www.voltlighting.com
- 2 -
Product Dimensions
4” 1.85”
3.25”
VOLT®Pro Connection Hub
VAC-HUB5
Package Contents
This connection hub is intended for installation in accordance with local
codes and the National Electric Code (NEC). Failure to adhere to these codes
and instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
connection hub.
2. Warning: This connection hub is not intended to be installed within 10
feet [3 meters] of a pool, spa or fountain.
3. This connection hub is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25AMPS) at 12 volts.
4. Underground low energy cable must not be buried over 6” (15.2cm) in
order to connect to the main low voltage cable.
A. (1) Hub
B. (1) Stake
