VOLTCRAFT AD-65S User manual

VOLTCRAFT® - TOP PERFORMANCE IN EVERY WAY
“For more than 25 years, our product range has been dynamically adapting to the constant changes in the industry.
We commit to offering first-class quality to our customers while delivering an excellent cost-performance ratio. This
philosophy remains the cornerstone of Voltcraft’s success.”
AD-65S
NOTEBOOK MAINS
POWER UNIT
VERSION 08/10
Nº 51 25 15
This product serves as a replacement or additional power supply for notebooks and other devices. The additional USB
output also allows hassle-free power supply for USB devices (e.g. cell phones or MP3 players). The AD-65S is protected
against short-circuiting, excess temperature and overload.
HIGHLIGHTS
Ultra small, light and efficient //
Input 100 - 240 V/AC //
Stabilised output voltage
5, 12, 15, 16, 18, 19 and 20 V/DC //
Power output up to 65 W //
Additional USB output //
Voltage adjustment via
plug-in card //
1.65 m output cable //
Short-circuit, excess
temperature and
overload protection //

TECHNICAL DATA
Input voltage: 100 to 240 V/AC, 50/60 Hz, 2 A max.
Output power: 65 W max.
Output voltage: 12 V/DC: 3 A max. (with yellow plug-in card)
15 V/DC: 4 A max. (with purple plug-in card)
16 V/DC: 4 A max. (with blue plug-in card)
18 V/DC: 3.42 A max. (with red plug-in card)
19 V/DC: 3.42 A max. (with green plug-in card)
20 V/DC: 3.26 A max. (with grey plug-in card)
5 V/DC: 0.5 A max. / 2.5 W (USB power port)
Efficiency: ≥87 % (100 V/AC / at full load)
≥90 % (240 V/AC / at full load)
Operating temperature: 0 ºC to +40 ºC
Dimensions (W x H x D): 115 x 21 x 56 mm
Weight: 220 g
OUTPUT PLUG SPECIFICATIONS
Type Outer diameter (mm) Inner diameter (mm) Polarity
A6.5 4.5
B6.3 3
C5.5 2.5
D5.5 2.1
E4.75 1.7
I2 5.5 3.4
L7.9 5.6
S7.4 5
COMPATIBILITY LIST
Notebook brand Voltage (V) Plug-in card colour Connector
Acer 19 green C, D
Asus Eee PC 12 yellow E
Compaq 19 green C, E, S
Dell 18 red S
Dell 19 green C
Fujitsu-Siemens 19 green C
Gateway 19 green C, D
HP 19 green C, E, S
IBM 16 blue C
Lenovo 20 grey L
Sony 16 blue A
Sony 19 green A
Toshiba 15 purple B, C
Toshiba 19 green A
Samsung 16 blue I2
Samsung 19 green I2
PACKAGE CONTENT
Notebook mains power unit // 8 x output plug // 6 x voltage adjustment plug-in card // Power cord //
Operating instructions
This data sheet is published by Voltcraft®, Lindenweg 15, D-92242 Hirschau / Germany, Phone [phone]. The data sheet reflects the current
technical specifications at time of print. We reserve the right to change the technical or physical specifications.
© Copyright 2010 by Voltcraft®. V2_0810_02-SB
